Kontron CG1200 User manual

CG1200 Carrier Grade Server
Document Revision 1.1

Revision History
Revision
Date
Comments
0.1
12/13/2012
Initial Release
1.1
01/13/2014
Adding Intel® Xeon® processor E5-2400 v2 product
family
Copyright © 2014, Kontron

3 www.kontron.com
Table of Contents
I. INTRODUCTION.....................................................................................................4
II. ORDERING CG1200 SYSTEMS.............................................................................6
III. ORDERING CG1200 SERVICEABLE ITEMS.......................................................18
APPENDIX A. RACK MOUNTING OPTIONS FOR 1U AND 2U COMMUNICATIONS
RACK MOUNT SERVERS............................................................................................21

4 www.kontron.com
I. Introduction
Product Description:
The CG1200 Carrier Grade Server is the 4th generation of Kontron’s 1U Carrier Grade
Server products. The CG1200 supports Intel® Xeon® processor E5-2400 v2 product
family, coupling high performance with power efficiency to provide improved
performance-per-watt over previous-generation rack-mount servers.
The CG1200 is a NEBS-3 and ETSI compliant product which is suited for a host of
applications in the telecom Central Office and industrial environment. The server is
targeted to OSS (Operations System and Support), Billing, Provisioning, Softswitch,
Media Server, Wireless and Unified Messaging, Call Center and many other
applications. It can also support manufacturing, industrial, oil & gas, utility and even
military applications where a rugged, highly reliable server is required for harsh
environments such as dust, high altitude, fire hazard, earthquake propensity, and high
ambient temperatures.
To add to the many recognized benefits of Kontron’s Carrier Grade Server family, the
CG1200 introduces several new important features such as support of PCI-E Gen3,
Power Management Bus, DDR3 memory, SD flash storage, and increased memory
capacity.
More detailed product information on the CG1200 is available on Kontron’s website at:
http://us.kontron.com/products/systems+and+platforms/communication+rackmount+servers/carr
ier+grade+servers/cg1200+carrier+grade+server.html
Purpose of this Document:
This document serves as an ordering reference guide, providing details on what parts
are available from Kontron for the CG1200 Carrier Grade Server and its associated
accessories and spares. Included are the necessary order codes and other important
configuration information related to the ordering of the product.
Supported third-party components are not covered by this document, and may be found
in the Tested Hardware and Operating System List (THOL) for this product.

5 www.kontron.com
General Flow for Configuring a CG1200 System
Step
Implication
Reference info
A. Select Base System
AC or DC base System
B. Select Redundant
power supply
Redundant or non-redundant
Non-redundant as shipped
C. Select Number and
Type of CPUs
Impacts Performance
Technical Product Specification
C.2. Memory
DIMM slots depend on number
of CPUs
Technical Product
Specification,
Refer to Tested Memory
List for list of validated
DIMMs
Refer to Installation &
Maintenance Guide for
installation instructions
D. Heatsink
Required for each CPU
E. Select RAID
RAID Choices
RAID 0/1/10 included
Additional offerings
F. Select Hard Drives
Refer to Installation & THOL
for tested Hard Drives
G. Select Remote
Management
Dedicated server management
NIC port
H. Personality Modules
I. Select system mounting
Rack mount kits
Appendix A
Section III. Serviceable
Items
List of spare items used for
repair
Section III.

6 www.kontron.com
II. Ordering CG1200 Systems
This section includes important information regarding how to order CG1200 systems.
Please be familiar with each of these areas before placing an order.
A. Select CG1200 Base System
The CG1200 Base System SKUs are listed in the table below:
Product Code
Description
Min. Order
Qty.
CG1200A-00
CG1200 Carrier Grade Server
Base Model 0 with AC Power Supply
1
CG1200D-00
CG1200 Carrier Grade Server
Base Model 0 with DC Power Supply
1
The CG1200 system SKUs are ordered using the Product Code as the order number.
The CG1200 is offered as either an AC or DC version—as indicated by the 7th digit of
the product code (“A” for AC or “D” for DC).
The above SKUs are “Base Model 0”SKUs—meaning they do not include processors,
heat sinks, memory, hard drives, power cord, operating system, or plug-in adapters.
Those components should be ordered separately as Accessories from Kontron or from
third party vendors listed in the Tested Hardware and Operating System List (THOL).

7 www.kontron.com
See the CG1200 Base Model 0 Configuration table below for a list of components
included in each base model 0 SKU. Notice that there are a number of optional
accessory items which must be ordered separately.
Component Description
AC Model 0
Configuration
DC Model 0
Configuration
Chassis (sheet metal, top cover, PCI cages, air duct,
interconnection cables, misc. parts)
1 included
Baseboard S2400EP (Eagle Pass), power distribution
board, system boards, fans, interconnect cables
Included
AC power supply (650W)
1 included
-
DC power supply (650 W)
-
1 included
Power Distribution Board
1 included
Filler Panel in 2nd power supply bay
1 included
Bezel (unpainted)
1 included
RDIMM/UDIMM memory slots (memory not included)
8 included
Bays for hot-swap 2.5” Hard Disk Drives and drive carriers
4 included
Rear Panel GbE NIC (Cu) ports (via Server Board)
4 included
Power Cable
Purchase separately1
SAS RAID 5 Key
Purchase separately4
IOC/ROC Adapter
Purchase separately4
IOC/ROC RAID cable kit
Optional Accessories2
ROC Maintenance-free back-up kit (optional)
Purchase separately4
Remote Management Module 4
Purchase separately4
CG1200 Single slot PCI-e x16 Gen 3 passive riser
1 included
Rack Mount Kits
Optional Accessory3
SD Flash Module
Included
Kontron Deployment Assistant on SD Flash media
Included
Rail Enabling Kit (enables AXXBASRAIL13 and
AXXHERAIL2)
Optional Accessory3
Processor (refer to “Details on Ordering Processors”)
Purchase separately4
Heatsink
Accessory or purchase separately
RDIMM/UDIMM Memory
Purchase separately4
Hard Disk Drives (SAS or SATA SSD)
Purchase separately4
eUSB Flash Drive
Purchase separately4
1Refer to AC power cord accessory in this section
2Refer to “Production Spares/Accessories List” in section III
3Refer to “Rack Mounting Options” in the Appendix
4Should be purchased separately (parts not listed in this document)

8 www.kontron.com
B. Select the Redundant Power supply
The CG1200 System accommodates a 2nd power supply which enables redundancy. Order
the 2nd power supply to agree with either AC or DC base system. Order AC power cords to
agree with the number of power supplies in the final system. Example: One CG1200A-00
base system + the 2nd power supply require 2 AC Power Cords.
Because DC power input cabling is usually custom, no DC power cord is offered. The
CG1200D-00 does contain a DC input terminal block for terminating DC input power.
Product Code
Description
Products
Supported
Included in
Base Model
(Y/N)
Min.
Order
Qty
CG2200-ACPSU
AC Power Supply
CG1200 and
CG2200
Y (one in AC
SKU)
1
CG2200-DCPSU
DC Power Supply
Includes input power connector
CG1200 and
CG2200
Y (one in DC
SKU)
1
1-340000-0
AC Power Cord
Should be ordered by North America
customers. International customers should
procure their specific power cords directly.
All CRMS
servers
N
1
Power cords are not included with the Mod 0 system. For AC Power cords, order the
above North American power cable using the provided product code. This power cable
is RoHS-compliant.

9 www.kontron.com
C. Select Number and Type of CPUs
The CG1200 is designed to support the following processor SKUs from the Intel®Xeon®
processor E5-2400 and E5-2400 v2 series. The Base Model 0 CG1200 includes Zero
CPUs. Customer must separately purchase CPU 1 and 2.
Intel®Xeon®Processors Supported by the CG1200:
Processor
Number
Cores
Speed
TDP
Memory Speed
Support
Intel P/N (tray)
E5-2448L
8 cores
1.8 GHz
70W
DDR3-1600
CM8062007187409
E5-2428L
6 cores
1.8 GHz
60W
DDR3-1333
CM8062007187509
E5-2418L
4 cores
2.0 GHz
50W
DDR3-1333
CM8062000911406
E5-2448Lv2
10 cores
1.8 GHz
70W
DDR3-1600
CM8063401293802
E5-2428Lv2
8 cores
1.8 GHz
60W
DDR3-1600
CM8063401293902
E5-2418Lv2
6 cores
2.0 GHz
50W
DDR3-1333
CM8063401294008
Notes:
The above processors are on Intel’s long life roadmap and are recommended with
the CG1200 for highest performance and long availability and support.
These processors are orderable from Intel using the indicated part numbers.
Use of the above processors requires the purchase of a passive heatsink. See its
order code below.
D. Heat Sink
Please order the number of heatsinks to agree with the number of CPUs in the system.
Use the order code below.
Product Code
Description
Products
Supported
Included in
Base Model
(Y/N)
Min.
Order
Qty
CG1200-HEATSNK
Heatsink (passive)
Contents: 25.5mm Tall Passive Heatsink
(copper base with aluminum fins)
CG1200
N
8

10 www.kontron.com

11 www.kontron.com
E. Select RAID
As shipped the CG1200 Model 0 systems supports SAS Hard Drives, and RAID 0, 1,
10 only. Below are other choices for RAID which are made available by purchase of
additional items.
Bandwidth
RAID Level
Additional item to purchase
Cables
3Gbit/s
RAID 0,1,10
None, RKSAS4 (Green Key) is
installed on Base System
Included
RAID
0,1,5,10,50
RKSAS4R5 (Yellow Key)
Included
6Gbit/s
RAID 0,1,10
RMS25JB040 Entry-level RAID
SAS Module (IOC) * mechanical
restriction
Requires
CG1200-
RAIDCBLKIT
RAID
0,1,5,10,50,60
RMS25CB040 Full RAID SAS
Module (ROC) * mechanical
restriction
Requires
CG1200-
RAIDCBLKIT
AXXRMFBU2 Maintenance Free
Backup Unit with NAND Flash
and SuperCapacitor
(* mechanical restriction) Restricts PCI-e card length to half length only
Removal of the included RKSAS4 (which enables SATA functionality) is not
supported.
When 6Bbit/s RAID is desired, you will need to order the following cable kit:
Product Code
Description
Included
in Base
Model
(Y/N)
Included
in Base
Model
(Y/N)
Min.
Order
Qty
CG1200-
RAIDCBLKIT
CG1200 RAID Cable kit
Provides cables to support
both the ROC and IOC RAID
controllers (optional
accessories)
CG1200
N
1

12 www.kontron.com
F. Select Hard Drives
As shipped with the CG1200 Model 0 systems, there is hard drive support for up to 4
SAS hard drives or SATA SSD’s. SATA rotating hard drives are not recommended and
not qualified for use in this system. See the Tested Hardware and Operating System
List (THOL) for complete listing of HDD’s that have been validated to work in this
system. The THOL is a customer-driven document. If a certain HDD is required please
arrange for its testing with Kontron.

13 www.kontron.com
G. Select Remote Management Module Option
There is 1 choice recommended for remote management of the CG1200. This is an
optional accessory.
Product Code
Description
Products
Supported
Included in
Base Model
(Y/N)
Min.
Order
Qty
AXXRMM4
Intel® Remote Management
Module 4 kit
Contents: module, mounting brackets, long
and short cables
CG1200,
CG2200
N
1
AXXRMM4LITE
Intel® Remote Management
Module 4 Lite kit
Contents: module, mounting brackets, long
and short cables
CG1200,
CG2200
N
1

14 www.kontron.com
H. Personality Modules
The CG1200 physically supports one personality module. These personality
modules are available from Intel.
Personality Module
AXX10GBTWLIOM
Dual RJ-45 10GBASE-T IO Module
based on Intel® Ethernet controller
X540
AXX4P1GBPWLIOM
Quad port 1GbE IO Module bades on
Intel® Ethernet controller I350
Please note that use of a personality module will mechanically conflict with the
dedicated remote management NIC, a part of AXXRMM4.
Use of a personality module precludes the use of the AXXRMM4.
When a personality module is installed, the AXXRMM4LITE may be used.

15 www.kontron.com
I. Select System Mounting
There are many choices for mounting of the CG1200 within rack enclosures.
Depending on the application, the following rack mount kits are available. Please see
Appendix A for details.
Rack mounting kits for 2-post or 4-post, 19-inch or 23-inch racks are offered for this
product. These include TMLCMOUNT21, TMLPMOUNT41, TMLPMOUNT51,
TMLPMOUNT52, and TMLPSLIDE01. The Rail Enabling Kit (TMLREK01) is not
required for these rack mount kits.
Please refer to Appendix A to determine the correct options to suit your
needs. For ordering details, refer to “Production Spares/Accessories
List” in section III.
If AXXBASRAIL13 or AXXHERAIL2 (from Intel) will be used, then a Rail Enabling Kit
(TMLREK01) must be purchased from Kontron to enable support of these Intel rail kits.
Rack Mount Kits (refer to Appendix A for additional details)
Product Code
Description
Included in
Base Model
(Y/N)
Min.
Order
Qty
TMLCMOUNT21
Rack Mount Kit TMLCMOUNT21
Used for mounting servers on a 19-inch wide,
2-post rack
N
10
TMLPMOUNT41
Rack Mount Kit TMLPMOUNT41
Used for mounting servers on 19-inch wide, 2-
post or 4-post racks
N
10
TMLPMOUNT51
Rack Mount Kit TMLPMOUNT51
Used for mounting servers on 19-inch wide, 2-
post or 4-post racks
N
1

16 www.kontron.com
TMLPSLIDE01
Universal Front Mounting Brackets
Accessory kit designed for use in conjunction
with slide rails. Each kit contains two
Universal Front Mounting Brackets that
secure the server to the front of the rack.
N
10
AXXBASRAIL13
Basic Slide Rail Kit
NOTE: Does not support Cable Management Arm.
NOTE: Requires TMLREK01 to attach to CG2200
chassis
(orderable from Intel only –MM# 899080)
N
1
AXXHERAIL2
Full extending Slide Rail Kit
NOTE: Requires TMLREK01 to attach to CG2200
chassis
(orderable from Intel only –MM# 901082)
N
1
AXXRACKARM2
Cable Management Arm
NOTE: To be used with AXXHERAIL2 only
(orderable from Intel only –MM# 901084)
N
1
TMLREK01
Rail Enabling Kit
Enables AXXBASRAIL13
and AXXHERAIL2 on
CG2200
Each kit includes:
rackmount ears (2)
rackmount shoulder
screws (4)
screws (2)
N
10
(order in
multiples
of 10)

17 www.kontron.com
J. Additional Notes on the CG1200 Configuration &
Options
Please review the following important notes regarding certain accessories and
configuration options for the CG1200.
Flash Drives
oA single front accessible SD memory slot is provided. This SD memory is
bootable, and may be used for software update or logging purposes.
oRefer to the THOL for SD-Flash devices that have been validated for use on
this system.
oAn internal optional eUSB Drive is supported.

18 www.kontron.com
III. Ordering CG1200 Serviceable Items
The table below lists all of the Serviceable Spares items that may be ordered for the CG2100
system. Generally these are items that could potentially fail or need replacement over the life
of the product. These items are made available so that customers might stock their service
depots and repair centers. Please read the following notes regarding this parts list.
3rd Party Accessories: For a listing of compatible 3rd party accessories, please refer to
the Tested Hardware and Operating System List (THOL) document.
Riser:
Product Order Code
Description
Products
Supported
Included in
Base Model
(Y/N)
MOQ
CG1200-RISERPCIE
CG1200 Single slot PCI-e x16
Gen 3 passive riser
CG1200
Y
1
Hard Drive Carriers:
Product Code
Description
Products
Supported
Included in
Base Model
(Y/N)
Min.
Order
Qty
NSNSASHDDCARQ
SAS HDD Carrier
Contents: Carrier, black plastic filler,
screws (4)
CG1200,
CG2200,
CG2100,
NSN2U
Y
(four included)
12
(order in
multiples
of 12)
Bezels:
Product Code
Description
Products
Supported
Included in
Base Model
(Y/N)
Min.
Order
Qty
CG1200-BEZEL
CG1200 Bezel (Unpainted)
CG1200
Y
(one bezel)
12
(order in
multiples
of 12)

19 www.kontron.com
Other Service Items:
Product Code
Description
Products
Supported
Included in
Base Model
(Y/N)
Min.
Order
Qty
BBS2400EP4KT
Intel Server Board S2400EP
(Eagle Pass)
Available from Intel
CG1200
Y
1
NSNLEDSWITCHBDQ
LED / Switch Board
CG1200,
CG2200,
CG2100,
NSN2U
Y
1
CG1200-PWRDISBD
Power Distribution Board
CG1200
Y
1
CG1200-FPIOBD
Front Panel IO board
CG1200
Y
1
CG1200-FANSET
Fan Assembly (5 fans)
Contents: Five 40mm x 56mm fans.
CG1200
Y
1

20 www.kontron.com
CG1200-INTCBLKIT
CG1200 System Interconnect
Cable Kit
Contents: Includes all Every Unit item
cables.
CG1200
Y
1
CG1200-SASBKPLN
CG1200 SAS Backplane
CG1200
Y
1
CG2100-TAMMODULE
TAM Module for multiple
systems
CG1200,
CG2200,
CG2100
Y
1
CG1200-CHASSISKIT
CG1200 Chassis Parts kit
Various items that often
get lost
Replacement screws, ties,
and other loose items.
CG1200
N
1
