Kontron KISS 1U PCI762-A User manual

www.kontron.com
» User’s Guide «
KISS 1U
KISS 1U PCI762-A
User's Guide (Version 1.1)
1056-7706

1. Table of Contents KISS 1U_SBC_762 – User's Guide (Version 1.1)
www.kontron.com 1
1. Table of Contents
1. Table of Contents ...................................................................................................................................1
1.1. Table of Figures.................................................................................................................................... 2
2. Disclaimer ............................................................................................................................................4
2.1. Symbols used in this Manual.................................................................................................................... 7
3. Important Instructions...........................................................................................................................8
3.1. Warranty Note...................................................................................................................................... 8
3.2. Exclusion of Accident Liability Obligation ................................................................................................... 8
3.3. Liability Limitation / Exemption from the Warranty Obligation ........................................................................8
4. General Safety Instruction for IT Equipment ...............................................................................................9
4.1. Operation of Laser Source Devices .......................................................................................................... 10
4.2. Electrostatic Discharge (ESD) ................................................................................................................ 11
4.2.1. Grounding Methods ...................................................................................................................... 11
4.3. Instructions for the Lithium Battery........................................................................................................ 11
5. Electromagnetic Compatibility (Class A Device) ........................................................................................ 12
5.1. Electromagnetic Compatibility (EU) ........................................................................................................ 12
5.2. FCC Statement (USA) ........................................................................................................................... 12
5.3. EMC Compliance (Canada)..................................................................................................................... 12
6. Scope of Delivery ................................................................................................................................. 13
6.1. Type Label and Product Identification...................................................................................................... 13
7. Product Description.............................................................................................................................. 14
7.1. Front Side ......................................................................................................................................... 16
7.1.1. Controls and Indicators ................................................................................................................. 17
7.1.2. Ports on the Front Side .................................................................................................................. 18
7.1.3. Filter Mat and Filter Mat Holder ....................................................................................................... 18
7.1.4. External accessible Drive Bays ......................................................................................................... 18
7.1.5. System Fans installed in Fan Slide-in Modules ..................................................................................... 18
7.2. Rear Side .......................................................................................................................................... 19
7.2.1. System Configurations with SBC Card ................................................................................................ 19
7.2.2. Power Supply and ON/OFF Switch of the PSU....................................................................................... 20
7.2.3. Grounding Stud ........................................................................................................................... 21
7.3. Side View .......................................................................................................................................... 21
7.4. Installed SBC Card .............................................................................................................................. 22
7.4.1. Backplane, Riser Cards and Drive Bays............................................................................................... 23
7.5. Fan Slide-in Modules ........................................................................................................................... 24
7.6. Cover ............................................................................................................................................... 25
8. Installation and Removal ...................................................................................................................... 26
8.1. Attaching the Rubber Feet .................................................................................................................... 26
8.2. Accessing Internal Components ............................................................................................................. 27
8.2.1. Installing /Removing Expansion Cards .............................................................................................. 27
8.3. Installation in a 19" Industrial Cabinet.................................................................................................... 28
9. Starting Up ......................................................................................................................................... 29
9.1. AC Power Connection........................................................................................................................... 29
9.2. Operating System and Hardware Components Drivers.................................................................................. 30

1. Table of Contents KISS 1U_SBC_762 – User's Guide (Version 1.1)
2www.kontron.com
10. Maintenance and Prevention ............................................................................................................... 31
10.1. Replacing the System Fans...................................................................................................................31
10.2. Cleaning the Filter Mat........................................................................................................................32
10.3. Replacing the Lithium Battery ..............................................................................................................34
11. Slide Rails (Option) ........................................................................................................................... 35
12. Technical Data .................................................................................................................................. 36
12.1. Electrical Specifications ......................................................................................................................37
12.2. Mechanical Specifications ................................................................................................................... 37
12.3. Environmental Specifications ...............................................................................................................37
12.4. Directives and Standards.....................................................................................................................38
13. Standard Interfaces – Pin Assignments ................................................................................................. 39
13.1.1. Serial Interface (RS232) ...............................................................................................................39
13.1.2. VGA Port ...................................................................................................................................39
13.1.3. USB Port (2.0)............................................................................................................................40
13.1.4. USB3.0 Port............................................................................................................................... 40
1.1. Table of Figures
Fig. 1: Laser radiation warning label............................................................................................................. 10
Fig. 2: Rackmount version with closed access panel.......................................................................................... 14
Fig. 3: Desktop version with closed access panel.............................................................................................. 14
Fig. 4: Rackmount version with opened access panel ........................................................................................ 14
Fig. 5: Desktop version with opened access panel ............................................................................................ 14
Fig. 6: KISS 1U platform - front side ............................................................................................................. 15
Fig. 7: Front (rackmount version) with the front access panel closed.................................................................... 16
Fig. 8: Front side (desktop version) with opened front access panel ..................................................................... 16
Fig. 9: Detail - 19" bracket with mounting screws ............................................................................................ 17
Fig. 10: Power button on the front ............................................................................................................... 17
Fig. 11: USB interfaces on the front side (SBC card) ......................................................................................... 18
Fig. 12: USB interfaces on the front side (backplane) ....................................................................................... 18
Fig. 13: Configuration example with a DVD Slim drive (D1) and with no drive installed in the 3.5" drive bay (D2)............ 18
Fig. 14: Configuration example with a DVD Slim drive (D1) and a Raid1 slim drive for 2x 2.5" SATA HDD/SSD (D2) ......... 18
Fig. 15: Rear side of the KISS 1U with an SBC card (shown with a PCI-762 and an AC wide rage PSU) ............................ 19
Fig. 16: External ports of PCI-762 SBC card .................................................................................................... 19
Fig. 17: Detail: AC Wide Rang PSU ................................................................................................................ 20
Fig. 18: Grounding stud ............................................................................................................................ 21
Fig. 19: Side view ..................................................................................................................................... 21
Fig. 20: Example of KISS 1U Configuration with SBC PCI 762(Single Board Computer) .............................................. 22
Fig. 21: Grounding stud ............................................................................................................................ 23
Fig. 22: Grounding stud ............................................................................................................................ 23

1. Table of Contents KISS 1U_SBC_762 – User's Guide (Version 1.1)
www.kontron.com 3
Fig. 23: Exchangeable fan slide-in modules with captive knurled screws ................................................................24
Fig. 24: Inside of the cover with fixing brackets ...............................................................................................25
Fig. 25: Loosening the three knurled screws on the rear side of the KISS 1U system .................................................27
Fig. 26: Sliding the cover back will pull out the cover fixing brackets from the retaining brackets of the chassis..............27
Fig. 27: Removing the cover ........................................................................................................................27
Fig. 28: Front side detail: Position of the filter mats..........................................................................................32
Fig. 29: Front side detail without filter mats and filter holders ............................................................................32
Fig. 30: Filter mat .....................................................................................................................................32
Fig. 31: Filter mat holder ............................................................................................................................32
Fig. 32: Attaching the inner section of the slide rails.........................................................................................35
Fig. 33: KISS 1U platform with slide rails in pulled-out position...........................................................................35
Fig. 34: KISS 1U platform with slide rails in pushed-in position ...........................................................................35

2. Disclaimer KISS 1U_SBC_762 – User's Guide (Version 1.1)
4www.kontron.com
2. Disclaimer
Kontron would like to point out that the information contained in this user guide may be subject to alteration, particularly
as a result of the constant upgrading of Kontron products. This document does not entail any guarantee on the part of
Kontron with respect to technical processes described in the user guide or any product characteristics set out in the user
guide. Kontron assumes no responsibility or liability for the use of the described product(s), conveys no license or title
under any patent, copyright or mask work rights to these products and makes no representations or warranties that these
products are free from patent, copyright or mask work right infringement unless otherwise specified. Applications that are
described in this user guide are for illustration purposes only. Kontron makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification. Kontron expressly informs the user
that this user guide only contains a general description of processes and instructions which may not be applicable in every
individual case. In cases of doubt, please contact Kontron.
This user guide is protected by copyright. All rights are reserved by Kontron. No part of this document may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form
or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the express written permission
of Kontron. Kontron points out that the information contained in this user guide is constantly being updated in line with
the technical alterations and improvements made by Kontron to the products and thus this user guide only reflects the
technical status of the products by Kontron at the time of publishing.
Brand and product names are trademarks or registered trademarks of their respective owners.
©2014, 2017 by Kontron AG
Kontron AG
Lise-Meitner-Str. 3-5
86156 Augsburg
Germany
www.kontron.com

2. Disclaimer KISS 1U_SBC_762 – User's Guide (Version 1.1)
www.kontron.com 5
High Risk Applications Hazard Notice
THIS DEVICE AND ASSOCIATED SOFTWARE ARE NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE OR
RESALE FOR THE OPERATION OF NUCLEAR FACILITIES, THE NAVIGATION, CONTROL OR COMMUNICATION SYSTEMS
FOR AIRCRAFT OR OTHER TRANSPORTATION, AIR TRAFFIC CONTROL, LIFE SUPPORT OR LIFE SUSTAINING
APPLICATIONS, WEAPONS SYSTEMS, OR ANY OTHER APPLICATION IN A HAZARDOUS ENVIRONMENT, OR
REQUIRING FAIL-SAFE PERFORMANCE, OR IN WHICH THE FAILURE OF PRODUCTS COULD LEAD DIRECTLY TO
DEATH, PERSONAL INJURY, OR SEVERE PHYSICAL OR ENVIRONMENTAL DAMAGE (COLLECTIVELY, "HIGH RISK
APPLICATIONS").
You understand and agree that your use of Kontron devices as a component in High Risk Applications is entirely at your
risk. To minimize the risks associated with your products and applications, you should provide adequate design and
operating safeguards. You are solely responsible for compliance with all legal, regulatory, safety, and security related
requirements concerning your products. You are responsible to ensure that your systems (and any Kontron hardware or
software components incorporated in your systems) meet all applicable requirements. Unless otherwise stated in the
product documentation, the Kontron device is not provided with error-tolerance capabilities and cannot therefore be
deemed as being engineered, manufactured or setup to be compliant for implementation or for resale as device in High
Risk Applications. All application and safety related information in this document (including application descriptions,
suggested safety measures, suggested Kontron products, and other materials) is provided for reference only.

2. Disclaimer KISS 1U_SBC_762 – User's Guide (Version 1.1)
6www.kontron.com
Revision History
Revision Brief Description of Changes Date of Issue
1.0 Initial Version 2014-Sep-18
1.1 Front LAN port description corrected, legal information updated 2017-Apr-27
Terms and Conditions
Kontron warrants products in accordance with defined regional warranty periods. For more information about warranty
compliance and conformity, and the warranty period in your region, visit http://www.kontron.com/terms-and-conditions.
Kontron sells products worldwide and declares regional General Terms & Conditions of Sale, and Purchase Order Terms &
Conditions. Visit http://www.kontron.com/terms-and-conditions.
For contact information, refer to the corporate offices contact information on the last page of this user guide or visit our
website CONTACT US.
Customer Support
Find Kontron contacts by visiting: http://www.kontron.com/support.
Customer Service
As a trusted technology innovator and global solutions provider, Kontron extends its embedded market strengths into a
services portfolio allowing companies to break the barriers of traditional product lifecycles. Proven product expertise
coupled with collaborative and highly-experienced support enables Kontron to provide exceptional peace of mind to build
and maintain successful products.
For more details on Kontron’s service offerings such as: enhanced repair services, extended warranty, Kontron training
academy, and more visit http://www.kontron.com/support-and-services/services.
Customer Comments
If you have any difficulties using this user guide, discover an error, or just want to provide some feedback, contact
Kontron support. Detail any errors you find. We will correct the errors or problems as soon as possible and post the revised
user guide on our websit

2. Disclaimer KISS 1U_SBC_762 – User's Guide (Version 1.1)
www.kontron.com 7
2.1. Symbols used in this Manual
Symbol Meaning
This symbol indicates the danger of injury to the user or the risk of damage to the product if the
corresponding warning notices are not observed.
This symbol indicates that the product or parts thereof may be damaged if the corresponding warning
notices are not observed.
This symbol indicates general information about the product and the user manual.
This symbol precedes various product configuration details.
This symbol precedes helpful hints and tips for daily use.

3. Important Instructions KISS 1U_SBC_762 – User's Guide (Version 1.1)
8www.kontron.com
3. Important Instructions
This manual provides important information required for the proper operation of the KISS 1U platform!
This chapter contains instructions which must be observed when working with the KISS 1U platform.
3.1. Warranty Note
Due to their limited service life, parts which by their nature are subject to a particularly high degree of wear (wearing
parts) are excluded from the warranty beyond that provided by law. This applies to batteries, for example.
3.2. Exclusion of Accident Liability Obligation
Kontron Europe shall be exempted from the statutory accident liability obligation if the user fails to observe the included
document: “General Safety Instructions for IT Equipment” the hints in this manual or eventually the warning signs label on
the device.
3.3. Liability Limitation / Exemption from the Warranty Obligation
In the event of damage to the device caused by failure to observe the included document “General Safety Instructions for IT
Equipment”, the hints in this manual or eventually the warning signs label on the device, Kontron Europe shall not be
required to honor the warranty even during the warranty period and shall be exempted from the statutory accident liability
obligation.

4. General Safety Instruction for IT Equipment KISS 1U_SBC_762 – User's Guide (Version 1.1)
www.kontron.com 9
4. General Safety Instruction for IT Equipment
Please read this chapter carefully and take careful note of the instructions, which have been compiled for
your safety and to ensure to apply in accordance with intended regulations. If the following general safety
instructions are not observed, it could lead to injuries to the operator and/or damage of the product; in
cases of nonobservance of the instructions Kontron is exempt from accident liability, this also applies
during the warranty period.
The product has been built and tested according to the basic safety requirements for low voltage (LVD) applications and
has left the manufacturer in safety-related, flawless condition. To maintain this condition and to also ensure safe
operation, the operator must not only observe the correct operating conditions for the product but also the following
general safety instructions:
The product must be used as specified in the product documentation, in which the instructions for safety for the
product and for the operator are described. These contain guidelines for setting up, installation and assembly,
maintenance, transport or storage.
The on-site electrical installation must meet the requirements of the country's specific local regulations.
If a power cable comes with the product, only this cable should be used. Do not use an extension cable to connect the
product.
To guarantee that sufficient air circulation is available to cool the product, please ensure that the ventilation openings
are not covered or blocked. If a filter mat is provided, this should be cleaned regularly. Do not place the system close to
heat sources or damp places. Make sure the system is well ventilated.
Only devices or parts which fulfill the requirements of SELV circuits (Safety Extra Low Voltage) as stipulated by
IEC 60950-1 may be connected to the available interfaces.
Before opening the device, make sure that the device is disconnected from the mains.
Switching off the device by its power button does not disconnect it from the mains. Complete disconnection is only
possible if the power cable is removed from the wall plug or from the device. Ensure that there is free and easy access to
enable disconnection.
The device may only be opened for the insertion or removal of add-on cards (depending on the configuration of the
system). This may only be carried out by qualified operators.
If extensions are being carried out, the following must be observed:
•all effective legal regulations and all technical data are adhered to
•the power consumption of any add-on card does not exceed the specified limitations
•the current consumption of the system does not exceed the value stated on the product label.
Only original accessories that have been approved by Kontron can be used.
Please note: safe operation is no longer possible when any of the following applies:
•the device has visible damages or
•the device is no longer functioning
In this case the device must be switched off and it must be ensured that the device can no longer be operated.

4. General Safety Instruction for IT Equipment KISS 1U_SBC_762 – User's Guide (Version 1.1)
10 www.kontron.com
Additional safety instructions for DC power supply circuits
To guarantee safe operation of devices with DC power supply voltages larger than 60 volts DC or a power consumption
larger than 240 VA, please observe that:
•the device is set up, installed and operated in a room or enclosure marked with “RESTRICTED ACCESS”, if there are no
safety messages on product as safety signs and labels on the device itself.
•no cables or parts without insulation in electrical circuits with dangerous voltage or power should be touched
directly or indirectly
•a reliable protective earthing connection is provided
•a suitable, easily accessible disconnecting device is used in the application (e.g. overcurrent protective device), if
the device itself is not disconnectable
•a disconnect device, if provided in or as part of the equipment, shall disconnect both poles simultaneously
•interconnecting power circuits of different devices cause no electrical hazards
A sufficient dimensioning of the power cable wires must be selected – according to the maximum electrical
specifications on the product label – as stipulated by EN60950-1 or VDE0100 or EN60204 or UL508 regulations.
The devices do not generally fulfill the requirements for "centralized DC power systems“ (UL 60950-1, Annex NAB; D2)
and therefore may not be connected to such devices!
Caution:
Energy hazards
>
240 VA are present inside the chassis!
Activities such as system expansion with expansion cards, or maintanance have to be carried-out by
qualified personnel familiar with the associated dangers!
The installation instructions for the KISS 1U Platform is the responsibility of the distributor.
When used as intended the KISS 1U platform is to operate only closed and locked.
Only when the cover is properly installed, secured with the knurled screws on the rear and the cover
fastening screw on the front, and the access panel is locked with the key, it is ensured that the user doesn’t
have access to the internal parts of the KISS 1U platform, loaded with hazardous energy.
4.1. Operation of Laser Source Devices
Fig. 1: Laser radiation warning label
The optional CD ROM and DVD drives contain light-emitting diodes (classified in accordance with IEC 60825-1:2007: LASER
CLASS 1) and therefore must not be opened.
If the enclosure of such a drive is opened, invisible laser radiation is emitted. Do not allow yourself to be exposed to this
radiation.
The laser system meets the code of Federal Regulations 21 CFR, 1040 for the USA and the Canadian Radiation Emitting
Devices Act, REDR C 1370.

4. General Safety Instruction for IT Equipment KISS 1U_SBC_762 – User's Guide (Version 1.1)
www.kontron.com 11
4.2. Electrostatic Discharge (ESD)
A sudden discharge of electrostatic electricity can destroy static-sensitive devices or micro-circuitry. Proper packaging and
grounding techniques are necessary precautions to prevent damage. Always take the following precautions:
1. Transport boards in static-safe containers such as boxes or bags.
2. Keep electrostatic sensitive parts in their containers until they arrive at the ESD-safe workplace.
3. Always be properly grounded when touching a sensitive board, component, or assembly.
4. Store electrostatic-sensitive boards in protective packaging or on antistatic mats.
4.2.1. Grounding Methods
The following measures help to avoid electrostatic damages to the device:
1. Cover workstations with approved antistatic material. Always wear a wrist strap connected to workplace as well as
properly grounded tools and equipment.
2. Use anti-static mats, heel straps, or air ionizes to give added protection.
3. Always handle electrostatic sensitive components by their edge or by their casing.
4. Avoid contact with pins, leads, or circuitry.
5. Turn off power and input signals before inserting and removing connectors or connecting test equipment.
6. Keep work area free of non-conductive materials such as ordinary plastic assembly aids and styrofoam.
7. Use field service tools such as cutters, screwdrivers, and vacuum cleaners which are conductive.
8. Always place drives and boards PCB-assembly-side down on the foam.
4.3. Instructions for the Lithium Battery
The installed CPU board is equipped with a Lithium battery. When replacing the lithium battery, please follow the
corresponding instructions in the section 10.3 “Replacing the Lithium Battery”.
Caution
Danger of explosion when replacing with wrong type of battery. Replace only with the same or equivalent
type recommended by the manufacturer. The lithium battery type must be UL recognized.
Do not dispose of lithium batteries in general trash collection. Dispose of the battery according to the
local regulations dealing with the disposal of these special materials, (e.g. to the collecting points for
dispose of batteries).

5. Electromagnetic Compatibility (Class A Device) KISS 1U_SBC_762 – User's Guide (Version 1.1)
12 www.kontron.com
5. Electromagnetic Compatibility (Class A Device)
5.1. Electromagnetic Compatibility (EU)
This product is intended only for use in industrial areas. The most recent version of the EMC guidelines (EMC Directive
2004/108/EC) and/or the German EMC laws apply. If the user modifies and/or adds to the equipment (e.g. installation of
add-on cards) the prerequisites for the CE conformity declaration (safety requirements) may no longer apply.
Warning!
This is a class A product. In domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.
5.2. FCC Statement (USA)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
5.3. EMC Compliance (Canada)
The method of compliance is self-declaration to Canadian standard ICES-003:
(English): This Class A digital apparatus complies with the Canadian ICES-003.
(French): Cet appareil numérique de la class A est conforme à la norme NMB-003 du Canada.

6. Scope of Delivery KISS 1U_SBC_762 – User's Guide (Version 1.1)
www.kontron.com 13
6. Scope of Delivery
KISS 1U platform (system configuration ordered)
1x AC power cable
Rubber feet (self-adhesive)
General Safety Instruction for IT Equipment
Optional Parts
Slide Rails (PN: 1016-5807)
Rack Slide Rails Kit for KISS 1U and KISS 2U/4U V2 (PN: 1051-7200)
6.1. Type Label and Product Identification
The type label (product designation, serial number) and the inspection status label of your KISS 1U platform are located on
the right side of the device.
System Type Product Name Product Identifikation
KISS 1U KISS 1U xxxxxxxx-y KISS 1U = System Type
The “xxxxxxxxx” group is replaced by up to a max. 8-digit combination of
numbers, letter or space, and represents the installed CPU board
The “y” is replaced by a single letter (A through Z) representing the power
supply installed into the system.
Note:
A: corresponds to the systems with a wide range AC power supply

7. Product Description KISS 1U_SBC_762 – User's Guide (Version 1.1)
14 www.kontron.com
7. Product Description
The KISS 1U platform expands the Kontron KISS computer line. KISS 1U is a scalable 2U (19") platform, equipped with a
SBC (PCI-762) (Single Board Computer) board, supporting various system configurations (refer to “KISS 1U Systems -
Configuration Guides” on our website). The flexible customer-specific hardware system configuration and the robust
construction with excellent mechanical stability of the KISS 1U platform offer the superior qualities of a computer designed
for operation in harsh industrial environment.
The KISS 1U platform is designed to be installed in 19" racks. It may be also installed as a desktop unit.
Versions of the KISS 1U platform:
Fig. 2: Rackmount version with
closed access panel
Fig. 3: Desktop version with
closed access panel
Fig. 4: Rackmount version with
opened access panel
Fig. 5: Desktop version with
opened access panel
The system can be equipped with up to three drive bays (depending on the system configuration):
D1: one 5:25" Slim front accessible drive bay
D2: one 3.5" front accessible drive bay or an front accessible slim drive
D3: one 3.5" internal accessible drive bay
The KISS 1U platform can be expanded either with PCI, or with PCIe (full-size or half-size) expansion cards (depending on
the ordered system configuration).
For customized versions and system configurations, please observe the corresponding “KISS 1U System -
Configuration Guides” for KISS 1U on our web site www.kontron.com.
The device is equipped with an AC wide rang.
The controls of the KISS 1U platform are located behind the front access panel and consist, as standard, of a power button,
a power and HDD/SSD LED.
Four system fans are installed at the front side of the unit. These are attached to the system by two fan slide-in modules.
The fan slide-in modules simplify the installation and removal of these components.
The washable filter mats, which protect your system against dust and dirt, are located on the front side of the system.
These filter mats can be replaced during operation.
The type label is located on the right hand side of the device.

7. Product Description KISS 1U_SBC_762 – User's Guide (Version 1.1)
www.kontron.com 15
Fig. 6: KISS 1U platform - front side
The KISS 1U platforms are designed to be operated in horizontal position only.
When powering on the KISS 1U platform, make sure that the air intake and exhaust openings are not
obstructed by objects.

7. Product Description KISS 1U_SBC_762 – User's Guide (Version 1.1)
16 www.kontron.com
7.1. Front Side
The KISS 1U platform is available as a rackmount version.
The front access panel (Fig. 7, pos. 4) provides protection against unauthorized access to the front-accessible drives, the
filter mat holders and the power button of your KISS 1U platform. The front access panel can be screwed on and off by the
knurled screws. During standard operation, the front access panel should be closed and the knurled screws should be
tightened.
The power button, the power LED, the hard disk activity LED, 4x USB2.0 interfaces, 1x LAN interface (not used), a 3.5" and
a 5.25" slim drive bay are located behind the front access panel (Fig. 7, pos. 4).
If USB devices are connected to the USB ports on the front of the device, the front access panel can not
be closed and locked.
Fig. 7: Front (rackmount version) with the front access panel closed
119" bracket with handle
2Ventilation grille on the front access panel
3Light diffusors for HDD and power LEDs
4Front access panel with captive knurled screws
Fig. 8: Front side (desktop version) with opened front access panel
1Stop bracket with tapped hole for fixing the front
access panel
2D1: front-accessible 5.25" slim dive bay (shown
with a slim DVD drive installed)
3D2: front-accessible 3.5" drive bay (with blanking
cover)
42x USB 2.0 (from the SBC)
52x USB 2.0 (from the backplane)
61x LAN interface (not used)
7Power button
8Indicators (power LED and hard disk LED)
92x Filter mat holder with knurled screw (behind
each filter mat holder and filter mat, is located the
fan slide-in module)
10 Chassis front panel
2
1
4
3
1
4
2
1
1
5
8
3
6
9
4
7
9
10

7. Product Description KISS 1U_SBC_762 – User's Guide (Version 1.1)
www.kontron.com 17
You can easily convert your system to a desktop version. Unscrew the left and right hand 19" brackets from the device.
Fig. 9: Detail - 19" bracket with mounting screws
There are rubber feet (refer to the chapter 6 “Scope of Delivery” supplied, if you want to convert your KISS 1U to a desktop
unit. To attach the rubber feet (included), please follow the instructions in the section 8.1 “Attaching the Rubber Feet”.
7.1.1. Controls and Indicators
Fig. 10: Power button on the front
The power button (Fig. 10, pos. 1) is located at the front side of the platform, behind the front access panel
(Fig. 7, pos. 4) and allows to power ON/OFF the system. Please observe the settings option for “Restore on AC Power Loss”
in the BIOS Setup. Setting options: Power On/Power Off/Last State.
Power LED
(green)
This LED (Fig. 10, pos. 2) lights up green when the system is switched on using the power button. Please
observe the Warning below!
Prerequisite:
The system must be connected to an appropriate power source (AC).
HDD LED
(yellow)
This LED (Fig. 10, pos. 3) lights up yellow at HDD/SSD activity.
Do not press the eject button, while the drive LED is lit or flashing.
Warning!
Turning the power off using the power button (refer to Fig. 10 pos. 1) does not disconnect the
KISS 1U platform from the AC power source.
AC wide range PSU: Please observe that the ON/OFF switch (Fig. 15, pos. 8) of the AC wide range PSU
(Fig. 17) does not disconnect the KISS 1U from the AC power source. Even you turn off the system using
the power button Fig. 8, pos. 7), and the ON/OFF switch of the PSU, there is still a standby-voltage of
5 VSb on the SBC (refer also to the hint in the subsection 7.2.2).
1 19" bracket with handle
2KISS 1U platform chassis
3Holes for rack mounting
4Screws for attaching the 19" bracket
2
3
1
4
1
2
3
1 Power button
2Power LED
3Hard disk LED

7. Product Description KISS 1U_SBC_762 – User's Guide (Version 1.1)
18 www.kontron.com
7.1.2. Ports on the Front Side
7.1.2.1. USB Ports
The KISS 1U system has four USB (2.0) interfaces (see Fig. 8, pos. 4 and pos. 5) on the front side. Various USB-compatible
peripherals can be connected to these ports.
Fig. 11: USB interfaces on the front side (SBC card) Fig. 12: USB interfaces on the front side (backplane)
If USB devices are connected to the USB ports on the front of the device, the front access panel can not
be closed and locked.
7.1.2.2. LAN Interface
In the PCI-762 version of the KISS 1U system, the front LAN port is not used.
7.1.3. Filter Mat and Filter Mat Holder
The filter mat (Fig. 30) and the filter mat holders (Fig. 31, Fig. 8, pos. 9) are located behind the air grilles of the front
access panel (Fig. 7, pos. 2 and pos. 4) and over the vent openings of the chassis front panel (Fig. 29, pos. 5). The filter
mat holders are fastened to the chassis front panel (Fig. 8, pos. 10 and Fig. 28, pos. 1) by knurled screws Fig. 28, pos. 3).
The filter mats are inserted into the filter mat holders. These filter mats protect your system against dust and dirt (refer to
the subsection 10.2 “Cleaning the Filter Mat”).
7.1.4. External accessible Drive Bays
Two front-accessible drive bays, D1 (1x 5.25" Slim) and D2 (1x 3.5"), are located on the front side, which are equipped
according to the ordered system configuration.
Fig. 13: Configuration example with a DVD Slim drive (D1)
and with no drive installed in the 3.5" drive bay (D2)
Fig. 14: Configuration example with a DVD Slim drive (D1)
and a Raid1 slim drive for
2x 2.5" SATA HDD/SSD (D2)
7.1.5. System Fans installed in Fan Slide-in Modules
The four system fans are integrated in user-friendly, replaceable fan slide-in modules (refer to the subsection7.5 “Fan
Slide-in Modules”). The fan slide-in module (Fig. 8, pos. 9) can be replaced as described in the subsection 10.1 “Replacing
the System Fans”.

7. Product Description KISS 1U_SBC_762 – User's Guide (Version 1.1)
www.kontron.com 19
7.2. Rear Side
On the rear side, depending on the ordered KISS 1U platform configuration, are available the external interfaces of the
integrated SBC card, the additional interfaces, the power supply unit and the air exhaust openings.
The order or the number of the KISS 1U platform interfaces can be different depending on the device
configuration.
7.2.1. System Configurations with SBC Card
Fig. 15: Rear side of the KISS 1U with an SBC card (shown with a PCI-762 and an AC wide rage PSU)
1Rear side of the cover with captive knurled screws
2Free card slots for :
1x PCIe x16 + 1x PCIe x4 or
1x PCI (32 Bit) + 1x PCIe x4)
3COM1 (RS232)
4COM2 (RS232)
5External interfaces of the SBC (PCI-762) card
6Air exhaust openings
7AC inlet connector
8On/Off power switch of the PSU
9Bracket that secures the On/Off switch
of the PSU in “On” position
10 “Ground” label
11 Grounding stud
7.2.1.1. External Ports of the SBC Cards
A detailed ports description can be found in the manual for the PCI-762 SBC board. You can download the
corresponding manual from our web site www.kontron.com by selecting the product.
Fig. 16: External ports of PCI-762 SBC card
1PCI-762 slot bracket
2VGA port
32x USB (3.0) ports
42x LAN ports with integrated LEDs
3
1
2
4
3
1
2
5
7
1
1
10
6
4
8
9
11
