Korg SP-170S User manual

K
KO OR RG GD DI IG GT TA AL LP PI IA AN NO O
S
SP P- -1 17 70 0S S
S
SE ER RV VI IC CE EM MA AN NU UA AL L
TABLE OF CONTENTS
ASSEMBLY SKETCH (HOOKUP): 2
BLOCK DIAGRAM: 3
SCHEMATIC DIAGRAM: 4
TEST MODE: 11
PARTS LIST: 14
Issued: May. 11, 2011
Ver. 1.0
©2011 KORG INC.

Parts List
Part No. Part Name
X-08311BK UPPER CASE E20341-1
X-08311WH UPPER CASE E20341-2
X-08311RD UPPER CASE E20341-3
510646508019 X-08310BK SP NET L E30538-1
510646508021 X-08310WH SP NET L E30538-3
510646508020 X-08310BK SP NET R E30538-2
510646508022 X-08310WH SP NET R E30538-4
510500505555 X-08311BK PanelPlate F41637-1
510500505556 X-08311WH PanelPlate F41637-2
*1 X-08310 SP BOX E20322
*1 X-08310 FRONT BAR E30537
RH-4
510646502018 X-1200/10 VR KONB L KOC-E30313
510646508522 08311 CIRCLE SW NL LG E40724-2
*1 STAND SUPPORT PLATE C41657
*1 X08310 KB FELT F41576
510646508023 X08310BK MUSIC STAND E30539-1
510646508024 X08310WH MUSIC STAND E30539-2
510646508026 X08310RD MUSIC STAND E30539-3
*1
