Kramer VS-88H2 User manual

P/N: 2900-301419 Rev 1 www.kramerAV.com
USER MANUAL
MODEL:
VS-88H2, VS-66H2, VS-84H2, VS-48H2
Matrix Switcher

Kramer Electronics Ltd.
VS-88H2 –Contents
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 3
Controlling your VS-88H2 4
Defining the Matrix Switcher 5
Mounting VS-88H2 8
Connecting VS-88H2 9
Connecting to VS-88H2 via RS-232 10
Connecting VS-88H2 via the ETHERNET Port 10
Operating VS-88H2 via Front Panel Buttons 13
Routing Signals 14
Storing and Recalling a Setup 22
Setting Switching Mode 23
Setting Switching Speed 23
Setting HDCP 24
Copying the EDID 25
Firmware Upgrade 26
Using Embedded Web Pages 27
Switching and Setting Ports 29
Changing Device Settings and Upgrading Firmware 40
Managing Web Page Security 42
Managing Timeout Settings 46
Setting Switching Modes 48
Setting Step-in Devices 51
Managing the EDID 53
Viewing About Page 57
Technical Specifications 58
Default Communication Parameters 59
Default EDID 60
Default Parameters 62
Input or Output Resolutions 63
Protocol 3000 Commands 64
Understanding Protocol 3000 64
Protocol 3000 Commands 65
Result and Error Codes 79

Kramer Electronics Ltd.
VS-88H2 –Introduction
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
•Review the contents of this user manual.
Go to www.kramerav.com/downloads/VS-88H2 to check for up-to-date user manuals, application
programs, and to check if firmware upgrades are available (where appropriate).
Achieving Best Performance
•Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
•Do not secure the cables in tight bundles or roll the slack into tight coils.
•Avoid interference from neighboring electrical appliances that may adversely influence
signal quality.
•Position your Kramer VS-88H2 away from moisture, excessive sunlight and dust.
Caution:
•This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
•For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
•There are no operator serviceable parts inside the unit.
Warning:
•Use only the power cord that is supplied with the unit.
•Disconnect the power and unplug the unit from the wall before installing.
•Do not open the unit. High voltages can cause electrical shock! Servicing by qualified
personnel only.
•To ensure continuous risk protection, replace fuses only according to the rating
specified on the product label which is located on the bottom of the unit.

Kramer Electronics Ltd.
VS-88H2 –Introduction
2
Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected
and recycled. To comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN) and will cover any
costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on
arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular
country go to our recycling pages at www.kramerav.com/support/recycling.
Overview
Congratulations on purchasing your Kramer Matrix Switcher. This User Manual describes
the following four devices: VS-88H2, VS-66H2, VS-84H2 and VS-48H2.
The devices described in this user manual are generally referred to as VS-88H2 or Matrix
Switcher. A device is named specifically only when a device-specific feature is described.
The Matrix Switcher is a high-quality switcher for 4K@60Hz (4:4:4) HDMI™ signals and
embedded audio. It reclocks and equalizes the signals and can route any one of the
selectable HDMI, HDCP-compliant sources to any or all outputs simultaneously.
The Matrix Switcher offers a flexible audio scheme where any HDMI digital audio input can
be routed to any HDMI digital audio output. In addition, an ARC matrix is supported to
produce AV matrices, as defined in the table below:
Device
Name
HDMI Video
Matrix
HDMI Embedded
Audio Matrix
(D-Audio Matrix)
ARC Audio
ARC In
(on HDMI OUT
Ports)
ARC Out
(on HDMI IN
ports)
Matrix
VS-88H2
8x8
8x8
8
8
8x8
VS-66H2
6x6
6x6
6
6
6x6
VS-84H2
8x4
8x4
4
8
8x4
VS-48H2
4x8
4x8
8
4
4x8
The Matrix Switcher provides exceptional quality, advanced and user-friendly operation, and
flexible control.
Exceptional Quality
•Max. data rate –18Gbps data rate (6Gbps per graphics channel).
•Max. resolution –Up to 4K@60Hz (4:4:4).
•Step-in over HDMI technology.
•HDMI, HDCP and DVI compliance.
•HDMI support –Deep color, 3D, ARC, up to 7.1 uncompressed audio channels.
•Kramer reKlocking™ and equalization technology –rebuilds the digital signal to travel
longer distances.

Kramer Electronics Ltd.
VS-88H2 –Introduction
3
Advanced and User-friendly Operation
•Automatic input selection –Based on priority selection or last connected input.
•Embedded pattern generator (480p) –With selectable patterns.
•Selectable HDCP per input.
•Memory locations –Up to 16 definable presets for quick access to common
configurations.
•Advanced EDID management per input.
•Active source and acceptor detection.
•Easy front-panel operation.
•Selectable switching speed.
•Lock button to prevent tampering.
•Kramer protocol 3000 support.
•Firmware upgrade via mini USB, Ethernet or the RS-232 port.
•Control Options –RS-232 serial commands transmitted by a PC, touch screen system or
other serial controller, Ethernet port via LAN.
•7-segment display, indicating the video and audio status and other functions.
•Audio breakaway and AFV (audio-follow-video) operation support.
•Efficient power-saving features.
•Includes non-volatile memory that retains the last settings, after switching the power off
and then on again.
Flexible Connectivity
•HDMI signal switching.
•Independent Audio Routing –Any embedded digital audio input can be routed to any
digital output, in addition to ARC sources.
•Optional ARC from HDMI outputs to all HDMI inputs.
•Housed in a 19” 1U rack mountable enclosure, with rack ears included, and is fed from a
100-240 VAC universal switching power supply.
Typical Applications
The Matrix Switcher is ideal for the following typical applications:
•Control rooms with multiple displays.
•Presentation and multimedia applications.
•Systems that require automatic HDMI routing.

Kramer Electronics Ltd.
VS-88H2 –Introduction
4
Controlling your VS-88H2
Control your Matrix Switcher directly via the front panel push buttons, or:
•By RS-232 serial commands transmitted by a touch screen system, PC, or other serial
controller.
•Via the Ethernet using built-in user-friendly web pages.

Kramer Electronics Ltd.
VS-88H2 –Defining the Matrix Switcher
5
Defining the Matrix Switcher
This section defines the VS-88H2, VS-66H2,VS-84H2 and VS-48H2 front panel.
Figure 1: VS-88H2 8x8 H2 Matrix Switcher Front Panel
Figure 2: VS-66H2 6x6 Matrix Switcher Front Panel
Figure 3: VS-84H2 8x4 Matrix Switcher Front Panel
Figure 4: VS-48H2 4x8 Matrix Switcher Front Panel
The behavior of the front panel buttons and the 7-segment display changes along with the
operation modes. For further details see Operating VS-88H2 via Front Panel Buttons on
page 13.

Kramer Electronics Ltd.
VS-88H2 –Defining the Matrix Switcher
6
#
Feature
Function
IN (PATTERN)
SELECTOR
Buttons
Press to select the input to switch to the output that was previously selected
(also used for storing machine setups in the STO-RCL modes and for
selecting a pattern in the Pattern mode).
In the ARC mode, all inputs can operate as audio outputs (see Operating in
ARC Mode on page 17).
OUT (MUTE)
SELECTOR
Buttons
Press to select an output to which the input is routed. Also used for storing
machine presets.
In the ARC mode, each output can operate as an audio input (see Operating
in ARC Mode on page 17).
MUTE/PATTERN
Button
Press to view the current pattern status and select the output/s to which a
pattern is routed.
Press to mute audio or video on a selected output when D-AUDIO and/or
VIDEO buttons are pressed (lit).
ALL Button
Press to perform an action on all outputs (for example, setting Mute mode,
Pattern mode and so on).
For switching, press ALL and then a specific IN button to route the selected
input to all outputs. For example, press ALL and then IN 2 to route input 2 to
all the outputs.
STO Buttons
Press STO to store the current switching setting to a preset button.
RCL Buttons
Press RCL to recall the switching setting from a preset button.
ARC Button
Press to set ARC mode on the inputs (see Operating in ARC Mode on
page 17).
D-AUDIO Button
Press to enable digital audio routing. When pressed together with VIDEO, the
digital audio is routed together with the video signal.
VIDEO Button
Press to select video inputs. When pressed together with D-AUDIO, video is
switched together with audio.
LOCK Button
Press and hold (for about 3 seconds) to toggle locking/releasing of the front
panel buttons.
Press to save the following setups: HDCP (On/Off), ARC, Fast Switch and
Switch mode.
EDID Button
Press to capture the EDID.
OUTPUT/INPUT
7-segment LED
Display
Displays the selected inputs switched to the outputs (marked above each
input).
1
2
3
4
5
6
7
8
9
10
11
12

Kramer Electronics Ltd.
VS-88H2 –Defining the Matrix Switcher
7
This section defines the VS-88H2, VS-66H2,VS-84H2 and VS-48H2 back panel.
Figure 5: VS-88H2 8x8 H2 Matrix Switcher Rear Panel
Figure 6: VS-66H2 6x6 Matrix Switcher Rear Panel
Figure 7: VS-84H2 8x4 Matrix Switcher Rear Panel
Figure 8: VS-48H2 4x8 Matrix Switcher Rear Panel
#
Feature
Function
INPUT HDMI Connectors
Connect to the HDMI sources.
OUTPUT HDMI Connectors
Connect to HDMI acceptors.
PROG Mini USB Port
Use for firmware upgrade or communication
(connecting to a PC or a serial controller).
SETUP DIP-Switches
N/A
5V/2A USB Port
Use to charge a device.
Reset Button
Press and hold while powering the device to reset IP
settings to factory default values.
ETHERNET RJ-45 Port
Connect to your LAN.
OPTIONAL Terminal Block Connectors
N/A
RS-232 3-pin Terminal Block Connectors
Connect to a PC or a serial controller.
Mains Power Connector
Connect to the mains power.
Mains Power Fuse
Fuse for protecting the device.
Mains Power Switch
Switch for turning the device on or off.
13
14
15
16
17
18
19
20
21
22
23
24

Kramer Electronics Ltd.
VS-88H2 –Mounting VS-88H2
8
Mounting VS-88H2
This section provides instructions for mounting VS-88H2. Before installing, verify that the
environment is within the recommended range:
•Operation temperature –0to 40C (32 to 104F).
•Storage temperature –-40to +70C (-40 to +158F).
•Humidity –10% to 90%, RHL non-condensing.
•VS-88H2 must be placed upright in the correct horizontal position.
Caution:
•Mount VS-88H2 before connecting any cables or power.
Warning:
•Ensure that the environment (e.g., maximum ambient temperature & air flow) is
compatible for the device.
•Avoid uneven mechanical loading.
•Appropriate consideration of equipment nameplate ratings should be used for avoiding
overloading of the circuits.
•Reliable earthing of rack-mounted equipment should be maintained.
Mount VS-88H2 in a rack:
•Attach both rack ears by removing the screws from each side of
the machine and replacing those screws through the rack ears.
For more information go to www.kramerav.com/downloads/VS-88H2.

Kramer Electronics Ltd.
VS-88H2 –Connecting VS-88H2
9
Connecting VS-88H2
Although this user manual describes the VS-88H2 only, it applies also to VS-66H2,
VS-84H2 and VS-48H2 except for the number of inputs and outputs per device.
Always switch off the power to each device before connecting it to your VS-88H2. After
connecting your VS-88H2, connect its power and then switch on the power to each device.
Although this connecting example shows only several inputs and outputs that are
connected, you can connect all the inputs and outputs simultaneously.
To connect the VS-88H2 as illustrated in the example in Figure 9, do the following:
1. Connect up to eight video sources to the INPUT HDMI Connector (from INPUT1 to
INPUT 8). For example, connect:
▪Laptops to INPUT 1, 3, 4 and 8 HDMI connectors.
▪Blu-ray players to the INPUT 2 and INPUT 6 HDMI connectors.
2. Connect the eight video OUTPUT HDMI Connectors (from OUTPUT 1 to OUTPUT 8)
to up to eight acceptors. For example, connect:
▪OUTPUT 1, 6 and 8 connectors to projectors.
▪OUTPUT 2, 4, 5 and 7 connectors to OLED displays.
3. Connect the power cord.
We recommend that you use only the power cord that is supplied with this machine.
4. If required, connect:
▪The 5V/2A USB Port to the USB port of another device to charge it.
▪The ETHERNET RJ-45 Port to a control device.
Figure 9: Connecting to the VS-88H2 Rear Panel
13
14
17
19

Kramer Electronics Ltd.
VS-88H2 –Connecting VS-88H2
10
Connecting to VS-88H2 via RS-232
You can connect to the VS-88H2 via an RS-232 3-pin Terminal Block Connector using, for
example, a PC.
To connect to the VS-88H2 via RS-232:
•Connect the RS-232 rear panel port on the VS-88H2 unit via a 9-wire straight cable (only
Tx to pin 2, Rx to pin 3, and G to pin 5 need to be connected) to the RS-232 9-pin D-sub
port on your PC.
•Pin 2 to the TX pin on the VS-88H2 RS-232 terminal block
•Pin 3 to the RX pin on the VS-88H2 RS-232 terminal block
•Pin 5 to the G pin on the VS-88H2 RS-232 terminal block
RS-232 Device VS-88H2
Connecting VS-88H2 via the ETHERNET Port
You can connect to the VS-88H2 via Ethernet using either of the following methods:
•Directly to the PC using a crossover cable (see Connecting the Ethernet Port Directly to
a PC on page 10).
•Via a network hub, switch, or router, using a straight-through cable (see Connecting the
Ethernet Port via a Network Hub or Switch on page 12).
If you want to connect via a router and your IT system is based on IPv6, speak to your IT
department for specific installation instructions.
Connecting the Ethernet Port Directly to a PC
You can connect the Ethernet port of the VS-88H2 directly to the Ethernet port on your PC
using a crossover cable with RJ-45 connectors.
This type of connection is recommended for identifying the VS-88H2 with the factory
configured default IP address.
After connecting the VS-88H2 to the Ethernet port, configure your PC as follows: compatible
1. Click Start > Control Panel > Network and Sharing Center.
2. Click Change Adapter Settings.
3. Highlight the network adapter you want to use to connect to the device and click Change
settings of this connection.
The Local Area Connection Properties window for the selected network adapter appears
as shown in Figure 10.
21

Kramer Electronics Ltd.
VS-88H2 –Connecting VS-88H2
11
Figure 10: Local Area Connection Properties Window
4. Highlight either Internet Protocol Version 6 (TCP/IPv6) or Internet Protocol Version 4
(TCP/IPv4) depending on the requirements of your IT system.
5. Click Properties.
The Internet Protocol Properties window relevant to your IT system appears as shown in
Figure 11 or Figure 12.
Figure 11: Internet Protocol Version 4 Properties Window

Kramer Electronics Ltd.
VS-88H2 –Connecting VS-88H2
12
Figure 12: Internet Protocol Version 6 Properties Window
6. Select Use the following IP Address for static IP addressing and fill in the details as
shown in Figure 13.
For TCP/IPv4 you can use any IP address in the range 192.168.1.1 to 192.168.1.255
(excluding 192.168.1.39) that is provided by your IT department.
Figure 13: Internet Protocol Properties Window
7. Click OK.
8. Click Close.
Connecting the Ethernet Port via a Network Hub or Switch
You can connect the Ethernet port of the VS-88H2 to the Ethernet port on a network hub or
using a straight-through cable with RJ-45 connectors.
Control Configuration via the Ethernet Port
To control several units via Ethernet, connect the Master unit (Device 1) via the Ethernet port
to the Ethernet port of your PC. Use your PC provide initial configuration of the settings (see
Connecting VS-88H2 via the ETHERNET Port on page 10).

Kramer Electronics Ltd.
VS-88H2 –Operating VS-88H2 via Front Panel Buttons
13
Operating VS-88H2 via Front
Panel Buttons
Press the Mains Power Switch to power the device. During the 10-second initialization
process, the:
•7-segment LED Display are on.
•All the front panel buttons illuminate.
•The FPGA/EPLD version (P), the firmware version (F) and the build version (b) appear
in succession.
Following initialization, the front panel buttons and 7-segment display enter normal operation:
•The 7-segment display shows the video IN-OUT status.
•The current operation mode button illuminates (VIDEO, by default).
•An illuminated IN (PATTERN) SELECTOR Button indicates an active signal
connected to the input.
•An illuminated OUT (MUTE) SELECTOR Button indicates that an acceptor is
connected to the output.
The VS-88H2 front panel buttons enable performing the following functions:
•Routing Signals on page 14.
•Storing and Recalling a Setup on page 22.
•Setting Switching Mode on page 23.
•Setting Switching Speed on page 23.
•Setting HDCP on page 24.
•Copying the EDID on page 25.
24
12
1
2

Kramer Electronics Ltd.
VS-88H2 –Operating VS-88H2 via Front Panel Buttons
14
Routing Signals
You can switch the video and the embedded audio signals together (AFV), or switch them
separately, via the following switching modes:
•Switching Video and Audio Signal Simultaneously on page 14.
•Switching Video Signal on page 15.
•Routing an Audio Input to HDMI Output on page 16.
•Operating in ARC Mode on page 17.
•Muting/Unmuting an Output Audio Signal on page 18.
•Muting/Unmuting an Output Video Signal on page 18.
•Routing a Pattern to an Output on page 19.
Switching Video and Audio Signal Simultaneously
You can select the digital audio signal to switch to the output together with the video signal.
To switch the audio and video signals together to an output:
1. Press D-AUDIO and VIDEO simultaneously.
The button illuminates and the 7-segment LED Display shows the current IN-OUT
video status.
2. Press an OUT (MUTE) SELECTOR Button (1 to 8).
The 7-segment display LED, under the selected output, flashes.
Press the ALL Button (instead of an output button) to route the selected input to all
the outputs. All the 7-segment display LEDs flash.
3. Press an IN (PATTERN) SELECTOR Button (1 to 8). The selected video and audio
input is switched to the selected output (or to all the outputs if ALL was pressed instead)
and the 7-segment display shows the current status.
4
12
2
1

Kramer Electronics Ltd.
VS-88H2 –Operating VS-88H2 via Front Panel Buttons
15
Switching Video Signal
The VIDEO button on the VS-88H2 front panel enables video routing.
To switch a video input to an output:
1. Press the VIDEO Button .
The button illuminates and the 7-segment LED Display shows the current IN-OUT
video status.
On the front panel buttons:
•An illuminated input button means that an active signal is detected on that input.
•An illuminated output button means that a display is connected to that output.
•A flashing output button means that a non-HDCP display is connected to that
output.
Note that in case an HDCP-encrypted input is routed through the matrix to a non-HDCP
screen, the video is not be presented and the non-HDCP screen turns black.
On the 7-segment display:
•A digit (from 1 to 8) shows the input number that is currently routed to the output.
•“P” under an output number indicates that a pattern is routed to that output.
•“0” under an output number indicates that the output is muted.
2. Press an OUT (MUTE) SELECTOR Button (1 to 8).
The 7-segment LED Display , under the selected output, flashes.
Press the ALL Button (instead of an output button) to route the selected input to all
the outputs. All the 7-segment display LEDs flash.
3. Press an IN (PATTERN) SELECTOR Button (1 to 8).
The selected input is switched to the selected output (or to all the outputs if ALL was
pressed instead) and the 7-segment display shows the current status.
4
9
12
2
12
1

Kramer Electronics Ltd.
VS-88H2 –Operating VS-88H2 via Front Panel Buttons
16
Routing an Audio Input to HDMI Output
The D-AUDIO Button button on the VS-88H2 front panel enables to route the HDMI
embedded audio input signals to the HDMI outputs .
Generally, digital audio routing is enabled by pressing D-AUDIO. When the button is
illuminated, the embedded audio on the HDMI input is the selected audio source.
To switch an HDMI audio input to an output:
1. Press D-AUDIO .
The button illuminates (HDMI audio input to HDMI output mode) and the 7-segment LED
Display shows the current IN-OUT digital audio status.
On the front panel buttons:
•An illuminated input button means that an active digital audio signal is detected on
that input that supports LPCM audio.
•A dark input button means that there is no active digital audio source on that input
(or that the source is DVI).
•A flashing input button means that a Dolby digital audio, Dolby-TrueHD audio, or
AC-3 audio signal from a DVD player is detected on that input.
•An illuminated output button means that a display that supports LPCM audio is
connected to that output.
•A dark button means either that the display that is connected does not support audio
or that a display is not connected at all.
•A flashing output button means that a display is connected that supports LPCM,
Dolby digital, AC-3 and NLPCM audio.
On the 7-segment display:
•“0” under an output number indicates that the audio output is muted.
•“.” under an output number indicates that the HDMI output port is in ARC mode.
•Any digit shows the HDMI audio input switching state.
2. While D-AUDIO is on, select an output button (for example, 6) and then an input button
(for example, 5). HDMI audio INPUT 5 is routed to HDMI audio OUTPUT 6 and on the
7-segment display, INPUT 5 appears under OUTPUT 6.
When switching you can also press:
•An output button (1 to 8) and then OUT (MUTE) to mute the selected output
(turns 0 on the 7-segment display).
•ALL (instead of an output button) and then an input button to route the selected input
to all the outputs.
All the 7-segment display LEDs flash and then display the selected input.
8
13
14
8
12
2
4

Kramer Electronics Ltd.
VS-88H2 –Operating VS-88H2 via Front Panel Buttons
17
Operating in ARC Mode
In ARC mode you can route the audio signal of the connected output to an input that is
connected to an audio system (for example, home theater receiver).
Ensure that the acceptor on the output side has ARC capabilities (follow the manufacturer’s
instructions).
ARC (Audio Return Channel) can be set via the front panel buttons and the embedded
webpages.
You can enable the input to accept the audio output signal, by ARC-enabling the outputs on
the device via the embedded web pages (see Switching Audio in Breakaway Mode on
page 38 for further reference). You can then route the audio output to the input either via the
embedded web pages (see Switching ARC to an Input on page 39) or via the front panel
buttons.
The following examples show how the output 6 ARC audio signal is routed to input 3, as
illustrated in Figure 14:
Figure 14: ARC Audio Routing Example
To route the audio signal from the output to the input via the front panel buttons:
1. Press the ARC button.
The ARC button illuminates, and the device enters ARC mode.
On the front panel, an ARC enabled input button:
•Flashes when that input is set to ARC mode.
•Illuminates when that button is not in ARC mode (and is set to Step-in mode).

Kramer Electronics Ltd.
VS-88H2 –Operating VS-88H2 via Front Panel Buttons
18
2. Press a flashing IN (PATTERN) Button (for example, input 3)
The corresponding 7-segment display LED flashes.
3. Press an illuminated OUT (MUTE) Button (for example, output 6).
The flashing 7-segment display LED shows the selected input number and after
selecting the HDMI audio OUT the port number appears (6).
On the 7-segment display:
•“.” under an output number (when in D-AUDIO mode) indicates that arc is enabled on
the corresponding output (outputs 1 and 6 to 8 in this example).
•“0” under an output number indicates that the audio output is muted.
The HDMI OUT 6 ARC audio signal is routed to ARC input 3.
Exit ARC mode by pressing D-AUDIO or VIDEO buttons.
Muting/Unmuting an Output Audio Signal
You can mute/unmute an audio signal and a video signal separately.
To mute/unmute an audio signal:
1. Press D-AUDIO .
The D-AUDIO button illuminates.
2. Press an OUT (MUTE) button (1 to 8).
Press ALL (instead of an output button) to mute/unmute all the outputs. All the
7-segment display LEDs flash.
3. Press MUTE/PATTERN .
The audio signal is muted/unmuted on the output. A muted output appears as “0” on the
7-segment display.
Muting/Unmuting an Output Video Signal
To mute/unmute a video signal:
1. Press VIDEO .
The button illuminates and the 7-segment LED Display shows the current IN-OUT
video status.
2. Press an OUT (MUTE) button (1 to 8).
The 7-segment display LED, under the selected output, flashes.
Press ALL (instead of an output button) to mute/unmute all the outputs. All the
7-segment display LEDs flash.
3. Press MUTE/PATTERN .
The audio signal is muted/unmuted on the output. A muted output appears as “0” on the
7-segment display.
4
4
1
2
2
3
9
12
2
3
