Congratulations on purchasing your Kramer VP-440 Presentation Switcher/Scaler.
This product, which incorporates HDMI™ technology, is ideal for:
Classroom, lecture theaters and education application
Projection systems in conference rooms, boardrooms, hotels and churches

2
VP-440 - Getting Started
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Go to http://www.kramerav.com/downloads/VP-440 to check for up-to-date
user manuals, application programs, and to check if firmware upgrades are
available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer VP-440 away from moisture, excessive sunlight and
dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.

VP-440 - Getting Started
3
3
2.2 Safety Instructions
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics power supply that is
provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims
to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive, Kramer
Electronics has made arrangements with the European Advanced Recycling
Network (EARN) and will cover any costs of treatment, recycling and recovery of
waste Kramer Electronics branded equipment on arrival at the EARN facility. For
details of Kramer’s recycling arrangements in your particular country go to our
recycling pages at http://www.kramerelectronics.com/support/recycling/.

4
VP-440 - Overview
3 Overview
The VP-440 is a high−performance presentation scaler/switcher for HDMI and
computer graphics signals. The unit scales the video, embeds the audio, and outputs
the signal to both an HDMI and an HDBaseT output, as well as outputting to
unbalanced stereo audio.
The VP-440 features:
PixPerfect™scaling technology –Kramer’s precision pixel mapping and high
quality scaling technology, with full up and down scaling of all video input
signals
HDTV compatibility
HDCP compliance
6 video inputs - 4 HDMI on HDMI connectors, 2 computer graphics video on
15−pin HD connectors
Scaled output on HDMI and HDBT connectors simultaneously
System Range for the HDBT inputs and outputs - Up to 70m (230ft)
For optimum range and performance using HDBaseT™, use Kramer's
BC−HDKat6a cable. Note that the transmission range depends on the
signal resolution, source and display used. The distance using
non−Kramer CAT 6 cable may not reach these ranges.
Up to UXGA/1080p output resolutions
Microphone input with audio DSP options including mixing and talk-over
Companion AFV (Audio-Follow-Video) –stereo audio for every video input
6 unbalanced stereo inputs on 3.5mm connectors as well as embedded audio
for the HDMI inputs, each with individual level controls
Audio outputs –one unbalanced stereo on a 3.5mm connector as well as
embedded audio on the HDMI and HDBT outputs
Multiple aspect ratio selections - full, best fit, over scan, under scan, letter box
and pan scan

VP-440 - Overview
5
5
Powerful audio features via DSP technology including audio equalization,
mixing, delay and so on
Built-in ProcAmp - color, hue, sharpness, noise, contrast and brightness
Supports 4:4:4 (RGB and YUV) as well as 4:2:2 (YUV) color sampling in
Native mode
Maintains constant output sync –there is no disruption on the output while
switching between inputs and when no video is detected
Dedicated RS-232 port for bidirectional data tunneling via HDBT
Front panel lockout
Non-volatile memory –saves final settings
Control your VP-440:
Directly, via the front panel push buttons
By RS-232 serial commands transmitted by a touch screen system, PC, or
other serial controller
Via the OSD (on-screen display)
Via remote contact-closure switches
Via the Ethernet with built-in Web pages
The VP-440 is housed in a 1/2 19" 1U enclosure, letting 2 units to be rack mounted
side-by-side in a 1U rack space with the optional RK-1 universal rack adapter.
3.1 Using Twisted Pair Cable for HDBT
Kramer engineers have developed special twisted pair cables to best match our
digital twisted pair products; BC−HDKat6a (CAT 6 23 AWG cable) significantly
outperforms regular CAT 5 / CAT 6 cables.
We strongly recommend that you use shielded twisted pair cable.

6
VP-440 - Overview
3.2 Defining the VP-440 Presentation Switcher/Scaler
This section defines the VP-440.
Figure 1: VP-440 Presentation Switcher/Scaler Front Panel
#
Feature
Function
1
/ 48 V
Move up (48V) to select a condenser type microphone; down
to select a dynamic type microphone. (We recommend
keeping the switch down if a microphone is not connected to
the VP-440)
2
MIC 6.3mm Jack
Connect to the microphone source
3
Input Selector
Buttons
HDMI IN
Press to select the HDMI input (from 1 to 4)
4
PC IN
Press to select the computer graphics input (from 1 to 2)
5
MENU Button
Displays the OSD menu (see Section 5.2)
6
Navigation
Buttons

Press to decrease numerical values or select from several
definitions
When not within the OSD menu mode, press to reduce the
output volume

Press to move up the menu list values (see Section 5.2)

Press to increase numerical values or select from several
definitions
When not within the OSD menu mode, press to increase the
output volume

Press to move down the menu list (see Section 5.2)
ENTER
Press to accept changes and change the SETUP parameters
(see Section 5.2)
7
RESET TO XGA/720p
Button
Press to reset the video resolution to XGA or 720p
Press and hold for about 5 seconds to toggle between
switching to XGA or 720p
8
PANEL LOCK Button
Press and hold for about 5 seconds to lock/unlock the front
panel buttons

VP-440 - Overview
7
7
Figure 2: VP-440 Presentation Switcher/Scaler Rear Panel
#
Feature
Function
9
VIDEO INPUT
Connectors
HDMI
Connect to the HDMI source (from 1 to 4)
10
PC 15-pin HD
Connect to the computer graphics source (from 1 to 2)
11
AUDIO INPUT
Unbalanced
Stereo 3.5 Mini
Jack
Connector
HDMI
Connect to the analog audio HDMI source (from 1 to 4)
12
PC
Connect to the analog audio computer graphics source
(from 1 to 2)
13
AUDIO OUT 3.5 Mini Jack
Connector
Connect to a an unbalanced stereo audio acceptor
14
ETHERNET Connector
Connects to the PC or other controller through
computer networking
15
HDMI OUT
Connect to the HDMI acceptor
16
HDBT RJ-45
Connect to an HDBT Receiver (for example, the
Kramer TP-580Rxr)
17
INPUT SELECT Terminal
Block Connectors
For remotely switching the inputs via contact closure
switches
18
DATA (Tx, Rx, GND) Terminal
Block Connectors
Connect to the PC or control device to tunnel data
between this RS-232 port and the HDBT OUT port
19
CTRL (Tx, Rx, GND) Terminal
Block Connectors
Connect to the PC or the serial controller
20
5V DC/4A
+5V DC connector for powering the unit

8
VP-440 - Connecting the VP-440
4 Connecting the VP-440
Always switch off the power to each device before connecting it to
your VP-440. After connecting your VP-440, connect its power and
then switch on the power to each device.
You do not have to connect all the inputs and outputs, connect only
those that are required.
To connect the VP-440, as illustrated in the example in Figure 3, do the following:
1. Connect an HDMI source (for example, a BluRay disk player) to the HDMI 1
(H1) VIDEO INPUT connector (from 1 to 4).
Alternatively, you can connect the DVI connector on the DVD player to the HDMI
connector on the VP-440 via a DVI-HDMI adapter. When using this adapter, you can
connect the audio signal via the terminal block connector
2. Connect a computer graphics source to the PC 1 15-pin HD VIDEO INPUT
connector (from 1 to 2).
3. Connect the audio input signals to the AUDIO INPUT 3.5mm mini jack
connectors, as required (not shown in Figure 3).
4. Connect the HDMI OUT connector to an HDMI acceptor (for example, an
LCD display).
5. Connect the HDBT OUT connector to an HDBT receiver (for example, the
output of TP-580R connected to HDBT).
6. Connect the AUDIO OUT 3.5mm mini jack connector to an unbalanced stereo
audio acceptor (not shown in Figure 3).
7. On the front panel, connect a microphone to the MIC 6.5mm phone jack and
set it to condenser or dynamic type.
8. Connect the power cord (not shown in Figure 3).

VP-440 - Connecting the VP-440
9
9
9. Connect the:
RS-232 DATA 3-pin terminal block connector (Tx, Rx, G) to a PC for
sending RS-232 commands via HDBT
RS-232 CONTROL 3-pin terminal block connector (Tx, Rx, G) to a PC to
control the unit
10. Connect the INPUT SELECT 7-pin terminal block contact-closure remote-
control pins to select an input by momentarily pressing the switch.
11. Connect the ETHERNET port, see Section 5.4
Figure 3: Connecting the VP-440 Presentation Switcher / Scaler

10
VP-440 - Connecting the VP-440
4.1 Microphone Pinout
The microphone
6.3mm jack pinout for a
condenser microphone.
Figure 4: Condenser Microphone Pinout
The microphone
6.3mm jack pinout for a
Dynamic microphone.
Figure 5: Dynamic Microphone Pinout

VP-440 - Connecting the VP-440
11
11
4.2 Wiring the TP LINE OUT RJ-45 Connector
This section defines the TP pinout, using a straight pin-to-pin cable with RJ-45
connectors.
EIA /TIA 568B
Figure 6: TP PINOUT
PIN
Wire Color
1
Orange / White
2
Orange
3
Green / White
4
Blue
5
Blue / White
6
Green
7
Brown / White
8
Brown

12
VP-440 - Controlling the VP-440
5 Controlling the VP-440
The VP-440 can be controlled via:
The front panel buttons (see Section 5.1)
The OSD menu (see Section 5.2)
RS-232 port (see Section 5.3)
The ETHERNET (see Section 5.4)
Remote control contact closure (see Section 5.5)
5.1 Controlling via the Front Panel Buttons
The VP-440 includes the following front panel buttons:
Input selector buttons for selecting the required input: HDMI (1 to 4) and PC
(1 and 2)
MENU, ENTER, and up, down, left and right arrow buttons
RESET TO XGA/720p and PANEL LOCK buttons
5.1.1 The Auto Adjust Feature
The auto adjust feature may be implemented every time the input is switched to VGA
or when the input resolution changes, as set in the FINETUNE menu (see
Section 5.2.1).
5.2 Using the OSD Menu
The control buttons let you control the VP-440 via the OSD menu. Press the:
MENU button to enter the menu
The default timeout is set to 10 seconds
ENTER button to accept changes and to change the menu settings
Arrow buttons to move through the OSD menu, which is displayed on the
video output
On the OSD menu, select EXIT to exit the menu

VP-440 - Controlling the VP-440
13
13
5.2.1 The MAIN MENU
Mode
Function
OUTPUT
SOURCE
Select the input: HDMI 1, HDMI 2, HDMI 3, HDMI 4, PC1 or PC2
SIZE
Select the image size: FULL, OVER SCAN, UNDER 1, UNDER 2, LETTER
BOX, PAN SCAN or BEST FIT
RESOLUTION
Select the output resolution from the menu:
Output resolution:
Appears as:
Output resolution:
Appears as:
NATIVE HDMI
1680x1050 @60Hz
1680x1050 60
NATIVE HDBT
1600x1200 @60Hz
1600x1200 60
640x480 @60Hz
640x480 60
1920x1080 @60Hz
1920x1080 60
800x600 @60Hz
800x600 60
1920x1200 @60Hz
1920x1200 60
1024x768 @60Hz
1024x768 60
480p @60Hz
720x480P 60
1280x768 @60Hz
1280x768 60
720p @60Hz
1280x720P 60
1360x768 @60Hz
1360x768 60
1080i @60Hz
1920x1080I 60
1280x720 @60Hz
1280x720 60
1080p @60Hz
1920x1080P 60
1280x800 @60Hz
1280x800 60
576p @50Hz
720x576P 50
1280x1024 @60Hz
1280x1024 60
720p @50Hz
1280x720P 50
1440x900 @60Hz
1440x900 60
1080i @50Hz
1920x1080I 50
1400x1050 @60Hz
1400x1050 60
1080p @50Hz
1920x1080P 50
NATIVE - Select NATIVE to select the output resolution from the EDID of the
connected HDMI monitor
CONTRAST
Set the contrast (the range and default values vary according to the input
signal)
BRIGHTNESS
Set the brightness (the range and default values vary according to the input
signal)
RED
Set the red level
GREEN
Set the green level
BLUE
Set the blue level
HUE
Set the color hue (not applicable for VGA inputs)
SATURATION
Set the color saturation (not applicable for VGA inputs)
SHARPNESS
Set the sharpness of the picture (not applicable for VGA inputs)
NOISE
REDUCTION
Select the noise reduction: OFF, LOW, MID (middle) and HIGH (not
applicable for VGA inputs)
FINETUNE
Enabled for VGA: AUTO ADJUST (NO/YES), H-POSITION, V-POSITION,
PHASE, CLOCK, WXGA/XGA, RESET (NO/YES)
AUDIO
INPUT VOLUME
Set the volume separately for each input: HDMI 1, HDMI 2, HDMI 3, HDMI
4, PC1 and PC2
OUTPUT
VOLUME
Set the output volume
DELAY
Select the audio delay time: OFF, 40ms, 110ms and 150ms
MUTE
Select the sound mute options: ON or OFF
EMBEDDED
AUDIO
Select the audio source of the HDMI 1 to HDMI 4 inputs:
AUTOMATIC: the embedded audio on the HDMI input is selected for an
HDMI signal, or the analog audio input is selected if the input is not HDMI
(for example, for a DVI input signal)
EMBEDDED: the embedded audio in the HDMI signal is selected

14
VP-440 - Controlling the VP-440
Mode
Function
ANALOG: the analog audio input is selected
MIC SETTINGS
MIC MODE - set the mode to OFF, MIXER, TALKOVER or MIC ONLY.
When in TALKOVER mode (see Figure 7), set the:
DEPTH [%] –to determine the decrease of the audio level during
microphone 1 takeover (press + to further decrease the talkover audio
output level; press –to lessen the talkover output audio decrease level)
TRIGGER [dB] –to determine the microphone threshold level that triggers
the audio output-level decrease.
ATTACK TIME –to set the transition time of the audio level reduction after
the signal rises above the threshold level
HOLD TIME –to define the time period talkover remains active although
the signal falls below the threshold level (for a short period of time)
RELEASE TIME –to define the transition time for the audio level to return
from its reduced level to its normal level after the Hold Time period
MIC VOLUME
Set the microphone volume for MIC
DRC
Dynamic Range Compression –allows a dynamic volume range. Set to ON
to dynamically create a sound range according to the volume level. For
example, in a movie the volume will be high enough to hear the dialogues
and at the same time loud explosions and sudden noises in the soundtrack
will be toned down so others would not be disturbed.
ADVANCED
HDCP ON
INPUT
Select the HDCP option for the HDMI inputs (1 to 4): either ON (the
default) or OFF.
Setting HDCP support to disabled (OFF) on the HDMI input allows the
source to transmit a non-HDCP signal if required (for example, when
working with a Mac computer)
HDCP ON
OUTPUT
Set HDMI OUT and HDBT OUT:
Select FOLLOW INPUT or FOLLOW OUTPUT to define whether the
HDCP will follow the input or the output
When FOLLOW INPUT is selected, it changes its HDCP output setting (for
the HDMI output) according to the HDCP of the input. This option is
recommended when the HDMI/HDCP output is connected to a
splitter/switcher
When FOLLOW OUTPUT is selected, the scaler matches its HDCP output
to the HDCP setting of the HDMI/HDCP acceptor to which it is connected
AUTO SYNC
OFF
Turn to OFF (disable the AUTO SYNC OFF feature), FAST (for almost
immediate shut down if no input is present –about 10 seconds) or SLOW
(for shutdown after about 2 minutes).
This is useful, for example, when the output is connected to a projector,
and the projector will automatically shut down when it has no input
OSD
H POSITION
Set the horizontal position of the OSD
V POSITION
Set the vertical position of the OSD
TIMER
Set the timeout period in seconds
TRANSPARENCY
Set the OSD background between 100 (transparent)
and 0 (opaque)
DISPLAY
Select the information shown on the screen during
operation:
INFO: the information is shown for 10 seconds
ON: the information is shown permanently
OFF: the information is not shown

VP-440 - Controlling the VP-440
15
15
Mode
Function
AUTO
SWITCHING
MODE
Set the auto switching mode to OFF, AUTO SCAN or
LAST CONNECTED. SCAN PRIORITY (below) is
enabled when AUTO SCAN is selected
When one of the auto switching modes is selected
(AUTO SCAN or LAST CONNECTED), audio is
enabled only when a video signal is detected
SCAN PRIORITY
Set to HDMI to begin scanning with HDMI1 or to PC
to begin scanning with PC1
ETHERNET
IP MODE
Set the IP mode to DHCP or STATIC
STATIC IP ADDRESS (fill in if STATIC (above) is selected):
IP ADDRESS
Enter the IP address
SUBNET
Enter the subnet
GATEWAY
Enter the gateway
CONTROL PORT
Enter the control port
MAC ADDRESS
MAC address
LOCK MODE
ALL
Lock all the front panel buttons
MENU ONLY
Lock the MENU (and navigation) front panel buttons
only
ALL & SAVE
Lock all the front panel buttons.
The lock status is saved when the VP-440 is powered
down
MENU ONLY AND
SAVE
Lock the MENU (and navigation) front panel buttons
only.
The lock status is saved when the VP-440 is powered
down
TIMING SHIFT
Set to ON (recommended):
Implements a small shift on the horizontal sync to improve output picture
stability. Set to OFF if the display shows an instability at the selected
output resolution
FACTORY RESET
Select NO or YES
INFORMATION
Displays the INPUT and OUTPUT resolutions, INPUT and OUTPUT HDCP
status, the IP ADDRESS and the FIRMWARE revision number
