Kramer VP-771 User manual

KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
VP-771
Presentation Switcher/Scaler
P/N: 2900-300096 Rev 3

VP-771 – Contents i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 2
2.3 Recycling Kramer Products 3
3Overview 4
3.1 HDCP Compliance 6
3.2 About the Power Connect™ Feature 7
3.3 Using Twisted Pair Cable 7
3.4 Defining the VP-771 Presentation Switcher/Scaler 7
4Installing in a Rack 11
5Connecting the VP-771 12
5.1 Wiring the TP LINE IN / LINE OUT RJ-45 Connectors 15
6The OSD Menu 16
6.1 OSD Menu Operation Example 16
6.2 The Input Menu 19
6.3 The Audio Menu 26
6.4 The Process Menu 32
6.5 The Picture Menu 33
6.6 The Enhance Menu 34
6.7 The Scale Menu 35
6.8 The Miscellaneous Menu 37
7The Display Modes 40
7.1 The Single Window Display Mode 40
7.2 The Dual Window Display Mode 40
8Controlling the VP-771 45
8.1 Controlling via the Front Panel Buttons 45
8.2 Controlling via the OSD Menu 46
8.3 Controlling via the VP-771 Web Pages 46
8.4 Controlling the VP-771 via the REMOTE Terminal Block Connector 49
8.5 Controlling via the Infrared Remote Control Transmitter 51
9Flash Memory Upgrade 53
10 Technical Specifications 54
10.1 Default Communication Parameters 55
10.2 Input Resolutions 55
10.3 Output Resolutions 57
11 The VP-771 RS-232 Communication Protocol 58
11.1 The Protocol 3000 Common Operation Commands 58
11.2 Audio/Video Communication Protocol 61
11.3 Keystroke Codes 70

ii VP-771 - Contents
Figures
Figure 1: VP-771 Presentation Switcher/Scaler Front Panel 8
Figure 2: VP-771 Presentation Switcher/Scaler Rear Panel 9
Figure 3: Connecting the VP-771 Presentation Switcher/Scaler 14
Figure 4: TP PINOUT 15
Figure 5: Input Menu 19
Figure 6: Select the Display Mode 21
Figure 7: changing the size of the Window 22
Figure 8: Increasing the Width 22
Figure 9: Increasing the Height 23
Figure 10: Positioning the Window 23
Figure 11: Window Customization 24
Figure 12: H-Position Slide Bar 24
Figure 13: Moving the PiP Window 25
Figure 14: Audio Menu 26
Figure 15: Set the Output Volume Level 27
Figure 16: SDI Channeling Example 29
Figure 17: The SDI Channeling Menu 29
Figure 18: SDI Channeling Example 30
Figure 19: SDI bypassed Channels Menu 31
Figure 20: Process Menu 32
Figure 21: Picture Menu 33
Figure 22: Enhance Menu 34
Figure 23: Scale Menu 35
Figure 24: Misc Menu 37
Figure 25: PC 1 superimposed over PC 1 43
Figure 26: Entering the IP Number in the Address Bar 47
Figure 27: Local Area Connection Properties Window 48
Figure 28: Internet Protocol (TCP/IP) Properties Window 48
Figure 29: Connecting the Contact Closure Remote Control PINs 50
Figure 30: Connecting the PIP Contact Closure Remote Control PINs 50
Figure 31: Infrared Remote Control Transmitter 51

VP-771 – Introduction 1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined by
function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Video Products.
Congratulations on purchasing your Kramer VP-771 Presentation Switcher/Scaler.
This product, which incorporates HDMI™ technology, is ideal for:
•Projection systems in conference rooms, boardrooms, auditoriums, hotels
and churches, production studios, rental and staging
•Any application where high quality conversion and switching of multiple and
different video signals to graphical data signals is required for projection
purposes

2 VP-771 - Getting Started
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
•Review the contents of this user manual
Go to http://www.kramerelectronics.com to check for up-to-date
user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
•Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
•Do not secure the cables in tight bundles or roll the slack into tight coils
•Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
•Position your Kramer VP-771 away from moisture, excessive sunlight and dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
2.2 Safety Instructions
Caution: No operator serviceable parts inside the unit
Warning: You use only the power cord that is supplied with the
unit. Do not open the unit. High voltages can cause
electrical shock! Servicing by qualified personnel only.
Warning: Disconnect the power and unplug the unit from the wall
before installing
i
!
!

VP-771 – Getting Started 3
2.3 13BRecycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims
to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country go
to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

4 VP-771 - Overview
3 Overview
The Kramer VP-771 is a high quality presentation switcher and scaler. It accepts
one of nine inputs: a component video on RCA connectors, a DisplayPort (DP)
signal on a DisplayPort connector, an SDI signal on a BNC connector, two
computer graphics signals on 15-pin HD connectors, two composite video signals
on RCA connectors, and two HDMI signals on HDMI connectors. It scales the
video, embeds the audio, and simultaneously outputs the signal as follows: to the
HDMI output, to the computer graphics output, to the SDI output and to a DGKat TP
output, together with a digital audio output and an unbalanced stereo audio output.
COMPONENT VIDEO is also known as Y, Pb, Pr, or Y, Cb, Cr or YUV; compatible with both
SD and HD component
The VP-771 Presentation Switcher / Scaler features:
•K-Storm™ Scaling Technology - Kramer’s extremely high performance
scaling technology. High-quality 3:2 and 2:2 pull down de-interlacing and full
up and down scaling of computer graphics video input signals
•State-of-the-art video processing technology, with the highest quality de-
interlacing, noise reduction, and scaling performance for both standard-
definition and high-definition signals
•K-IIT XL™ Picture-in-Picture Image Insertion Technology - Ultra stable
picture−in−picture, picture−and−picture and split screen capability, or fully
customizable windows’ size and position control: any source can be inserted
into or positioned next to any other source and resized as desired
•Ultra Fast Fade-Thru-Black (FTB™) Switching - Video switching transitions
are clean and ultra-fast. The video fades to black and the new input fades
from black for smooth, glitch-free switching. The output signal provides
constant sync so the display never glitches
•Advanced deinterlacing functions - including 3D comb filtering, film mode,
diagonal correction and motion detection
•Scaled Outputs - HDMI, computer graphics, SDI output and a DGKat TP
output simultaneously
•Output Resolutions – HDTV and Computer Graphics up to 2K and
1080p/UXGA with selectable refresh rates

VP-771 – Overview 5
•Multiple Aspect Ratio Selections – Follow input, follow output, best fit,
letterbox, and user definable settings
•Multi-Standard SDI support - SDI (SMPTE 259M), HD-SDI (SMPTE 292M)
and 3G HD-SDI (SMPTE 424M)
•Max. Data Rate - 3Gbps (3G HD-SDI).
•Looping 3G HD-SDI Input
•SDI channeling, letting you select one active audio signal and three
bypassed signals from eight embedded stereo audio channels
•Multi-Standard Video support - NTSC (3.58/4.43), PAL (M/N/60) and SECAM
•Built-in Time Base Corrector - Stabilizes unstable video sources
•Built-in Proc-Amp with enhanced functions such as color correction, gamma
and dither
•Input and output audio level adjustment
•Digital (S/PDIF) and unbalanced stereo audio inputs and outputs, with
microphone talkover or microphone mix
•Built-in 2x10W power amplifier with speaker output connectors
•Automatic detection and selection of the HDMI and DP embedded audio.
The VP-771 automatically outputs the signal from the HDMI and DP
embedded audio inputs or performs an analog takeover to output the
respective analog audio input
•Selectable Power Save modes for energy efficient usage
•HDCP Compliant - The HDCP (High Definition Content Protection) license
agreement allows copy-protected data on the HDMI input to pass only to the
HDMI output
In addition, the VP-771 Presentation Switcher / Scaler:
•Includes luma keying via the PiP window
•Advanced EDID management per input
•Analyzes the EDID of a selectable Master connection to one of the outputs
•Supports picture zooming both on main and PiP window from 100% to
1600%, including separate V and H sharpness control

6 VP-771 - Overview
•Provides input and output color space control
•Supports HDMI deep color for inputs and output
•Features vertical Keystone operation
•Comes with an On-Screen Display (OSD) for easy setup and adjustment,
accessible via the IR remote control and via the front-panel buttons
•Has a non-volatile memory that retains the last settings used
•Supports firmware upgrade via RS-232 and Ethernet
Control your VP-771:
•Directly, via the front panel push buttons
•By RS-232 serial commands transmitted by a touch screen system, PC, or
other serial controller
•Remotely, from the infrared remote control transmitter
•Via contact closure remote control switching
•Via the Ethernet (optionally via the Web pages)
The VP-771 is housed in a 19” 1U rack mountable enclosure, with rack “ears”
included, and is fed from a 100-240 VAC universal switching power supply.
3.1 HDCP Compliance
If an HDMI signal is HDCP protected, it can only appear on HDMI
and DGKat outputs that are connected to supported HDCP
compliant displays.
The VP-771 will not output a picture on a display that is not HDCP
compliant as well as on the SDI/PC outputs; instead it will show a
black screen.
In the dual window display mode (see Section 7.2), even if only one
of the inputs is HDCP protected, and is output to a non compliant
display, it will affect the entire screen and turn it black.
i

VP-771 – Overview 7
3.2 15BAbout the Power Connect™ Feature
The VP-771 can power the receiver on the DGKat output when the devices are
within 90m (270ft) of each other. The Power Connect™ feature applies as long as
the cable can carry power and the distance does not exceed 90m on standard TP
cable. For longer distances, heavy gauge cable should be used (TP cable is still
suitable for the video/audio transmission, but not for feeding the power at these
distances).
3.3 16BUsing Twisted Pair Cable
Kramer engineers have developed special twisted pair cables to best match our
digital twisted pair products; the Kramer: BC-DGKat524 (CAT 5 24 AWG), the
Kramer: BC-DGKat623 (CAT 6 23 AWG cable), and the Kramer: BC-DGKat7a23
(CAT 7a 23 AWG cable). These specially built cables significantly outperform
regular CAT 5 / CAT 6 / CAT 7a cables.
3.4 17BDefining the VP-771 Presentation Switcher/Scaler
This section defines the VP-771.

Figure 1: VP-771 Presentation Switcher/Scaler Front Panel
# Feature Function
1 IR Receiver Accepts IR remote commands
2 IR LED Lights red when the unit accepts IR remote commands
3 INPUT Selector
Buttons
HDMI Press to select the HDMI input (from 1 to 2)
4 PC Press to select the computer graphics input (from 1 to 2)
5 COMP. Press to select the component video input
6 CV Press to select the composite video input (from 1 to 2)
7 DP Press to select the Display Port input
8 SDI Press to select the SDI input
9 PIP Button Toggles the dual window mode (Picture-in-Picture) function (see Section 7.2)
10 BLANK Button Press to toggle between a blank screen (blue or black screen) and the display
11 FREEZE Button Press to freeze/unfreeze the output video image
12 Navigation
Buttons
/- Button Press to move down the menu list (see Section 8.1.1) and to decrease numerical values. When not within the OSD menu mode,
press to reduce the output volume
13 /MENU Button Press to access the OSD menu, exit the OSD menu and, when in the OSD menu, move to the previous level in the OSD screen
(see Section 8.1.1)
14 /+ /VOLUME
Button
Press to move up the menu list values (see Section 8.1.1) and to increase numerical values. When not within the OSD menu
mode, press to increase the output volume
15 /ENTER Button Press to access sub-menu items and select from several settings (see Section 8.1.1)
16 RESET TO XGA/720P Button Press to reset the video resolution to XGA or 720p and change the deep color settings to Off on the output (see Section 6.7)
Press and hold for about 2 seconds to toggle between reset to XGA and reset to 720p
17 PANEL LOCK Button Press and hold for about 2 seconds to lock/unlock the front panel buttons
8 VP-771 – Overview

VP-771 – Overview 9
Figure 2: VP-771 Presentation Switcher/Scaler Rear Panel
# Feature Function
18 AUDIO IN
Unbalanced
Connectors
HDMI 3.5mm Mini Jack Connect to an unbalanced audio source for audio takeover of the HDMI 1 and HDMI 2 embedded audio
(see Section 6.3)
19 PC 3.5mm Mini Jack Connect to the unbalanced audio of the computer graphics source (from 1 to 2)
20 DP 3.5mm Mini Jack Connect to the unbalanced audio source for analog audio takeover of the DisplayPort embedded audio (see
Section 6.3)
21 CV (L, R) RCA Connect to the unbalanced stereo audio of the composite video source (from 1 to 2)
22 S/PDIF IN RCA Connect to the digital audio source of the component video (Y, Pb, Pr)
23 MIC IN 3.5mm Mini Jack Connect to a microphone
24 COND/DYN MIC DIP-switch Select between a condenser and a dynamic type microphone
25 S/PDIF OUT RCA Connector Connect to a digital audio acceptor
26 LINE OUT (L, R) Terminal Block Connector Connect to the L and R unbalanced stereo audio acceptor
27 REMOTE IR 3.5mm Mini Jack (opening)
Covered by a cap. The 3.5mm connector at
the end of the internal IR connection cable
fits through this opening
Connects to an external IR receiver unit for controlling the machine via an IR remote controller (instead of
using the front panel IR receiver)
Optional. Can be used instead of the front panel (built-in) IR receiver to remotely control the machine (only if
the internal IR connection cable has been installed), see Section 8.5.1
28 ETHERNET RESET Button Press while turning power off and then on, to reset the Ethernet settings to their factory default state
29 SPKR Terminal Block Connector Connect to a balanced stereo audio acceptor (speakers)
30 VIDEO INPUT
Connectors
HDMI Connect to the HDMI source (from 1 to 2)
31 PC 15-pin HD Connect to the computer graphics source (from 1 to 2)
32 Y RCA
Connect all three connectors to the component video source33 Pb RCA
34 Pr RCA
35 CV RCA Connect to the composite video source (from 1 to 2)

# Feature Function
36 DISPLAYPORT Connect to the DisplayPort source
37 SDI IN Connect to the SDI source
38 SDI LOOP Connect to a local display
39
VIDEO
OUTPUT
Connectors
PC 15-pin HD Connect to a computer graphics acceptor
40 SDI BNC Connect to an SDI acceptor
41 HDMI Connect to an HDMI acceptor
42 DGKAT RJ-45 Connect to a DGKat receiver (for example, Kramer PT-572+)
43 RS-232 9-pin D-sub Port Connect to the PC or other serial controller
44 ETHERNET Connector Connects to the PC or other Controller through computer networking
45 REMOTE Terminal Block Connectors For remotely switching the inputs and PIP input via contact closure switches
46 Power Connector with Fuse AC connector, enabling power supply to the unit
47 POWER Switch Switch for turning the unit ON or OFF
10 VP-771 – Overview

VP-771 - Installing in a Rack 11
11
4 Installing in a Rack
This section provides instructions for rack mounting the unit.

12 VP-771 - Connecting the VP-771
5 Connecting the VP-771
Always switch off the power to each device before connecting it to
your VP-771. After connecting your VP-771, connect its power and
then switch on the power to each device.
You do not have to connect all the inputs and outputs, connect only
those that are required.
To connect the VP-771, as illustrated in the example in Figure 3, do the following:
1. Connect an HDMI source (for example, a DVD player) to the HDMI 1 IN
VIDEO INPUT connector.
Alternatively, you can connect the DVI connector on the DVD player to the HDMI
connector on the VP-771 via a DVI-HDMI adapter. You can connect the audio signal via
the AUDIO IN HDMI 3.5mm mini jack, or use the embedded audio
2. Connect a computer graphics source to the PC 1 IN VIDEO INPUT 15-pin
HD connector.
3. Connect a component video source (for example, a component DVD player)
to the COMP PR, PBand Y, VIDEO INPUT RCA connectors.
4. Connect a composite video source (for example, a composite video player)
to the CV VIDEO INPUT RCA connector.
5. Connect a DisplayPort video source (for example, a computer graphics
source) to the DISPLAYPORT connector.
6. Connect the audio input signals to the AUDIO IN connectors (3.5mm mini
jack and RCA connectors), as required (not shown in Figure 3).
7. Connect an SDI source (for example, an SDI digital camera) to the SDI IN
BNC connector.
8. Connect the SDI LOOP BNC connector to an SDI monitor (for example, an
SDI display).
!
i

VP-771 - Connecting the VP-771 13
13
9. Connect the PC VIDEO OUTPUT 15-pin HD connector to a VGA acceptor
(for example, an analog display).
10. Connect the SDI VIDEO OUTPUT BNC connector to an SDI acceptor (for
example, an SDI display with speakers).
11. Connect the HDMI VIDEO OUTPUT connector to an HDMI acceptor (for
example, a plasma display).
12. Connect the DGKAT RJ-45 connector to a receiver (for example, the Kramer
PT-572+).
13. Connect the SPKR Terminal Block connector to speakers (not shown in
Figure 3).
14. If required, you can connect a PC and/or controller to the:
RS-232 terminal block (see Section 8.3.2)
Ethernet connector (see Section 8.3.3)
15. Connect the power cord (not shown in Figure 3).

14 VP-771 - Connecting the VP-771
Figure 3: Connecting the VP-771 Presentation Switcher/Scaler

VP-771 - Connecting the VP-771 15
15
5.1 Wiring the TP LINE IN / LINE OUT RJ-45 Connectors
This section defines the TP pinout, using a straight pin-to-pin cable with RJ-45
connectors.
Note, that the cable Ground shielding must be connected / soldered to
the connector shield.
EIA /TIA 568B
Figure 4: TP PINOUT
PIN Wire Color
1 Orange / White
2 Orange
3 Green / White
4 Blue
5 Blue / White
6 Green
7 Brown / White
8 Brown
i
