INSTALLATION MANUAL
Coda Single Lever Vessel Faucet
FVS-13800
www.kraususa.com I toll free: 1.800.775.0703 I © 2014-2015 Kraus USA Inc. I REV. August 11, 2015

1
Thank you for purchasing Kraus
We would like to take this opportunity to thank you for your business with Kraus
USA. It is our sincere hope that you are completely satised with your experience.
We welcome any questions or comments you may have, and will be glad to assist
you in the future.
For more information about Kraus products, please visit our website at:
www.kraususa.com
Please register your new Kraus product at the following web address in order to
activate the warranty and receive the full benet of customer support:
www.kraususa.com/registration
Sincerely,
Kraus Customer Service Department

2
Prior to Installation:
• Make sure you have all necessary parts by checking the diagram and parts list. If
any part is missing or damaged, please contact Kraus Customer Service at 800-775-
0703 for a replacement
• Turn o the hot and cold water supply at the angle stops and turn on the old
faucet to release any built up pressure. Remove existing faucet. Clean sink or
countertop to remove any debris, plumber’s putty, or silicone
• Place bucket under angle stops. Turn on to ush any debris prior to installing new
plumbing. Shut o angle stops
• Pre-drilled hole size requirement: 1-3/8” (min) – 1-1/2” (max)
• Max countertop thickness: 1-3/8”
Tools you will need:
6 5/8”
5 4/5”
3/8”
(10mm)
7/8”
19.7
º
(22mm)
8 5/16”
1 1/4-18UNF-2A
(21mm)
10 1/8”
(257mm)
1 3/8”
(35mm)
3 3/4”
(168mm)
(147.3mm)
(96mm)
∅ 1 3/4”
(
∅ 45mm)
∅ 1 15/16”
(
∅ 50mm)
9/16”-18UNEF
27mm ~ 41.3mm 1 1/16” ~ 1 5/8”
∅ 1 15/16”
(
∅ 50mm)
12 7/16”
(316mm)
1 5/8”
(42.5 mm Max)
7A
8B
8C
8D
8A
7A
8B
8C
8D
8A
Adjustable Wrench Phillips Screwdriver Safety Goggles Bucket

3
A
I
H1
H2
H3
G
B
C
D
E
F
FVS-13800 Diagram and Parts List
A. Faucet Body
B. Base O-Ring
C. Rubber Washer
D. Metal Washer
E. Mounting Nut
F. Mounting Screws
G. Hot & Cold Waterlines
H. Aerator Assembly
H1. Aerator Washer
H2. Aerator
H3. Aerator Cover
I. Hex Wrench

4
337
13 1/4”
∅48
∅1 7/8”
∅33~∅35
∅1 5/16”~∅1 3/8”
Max35
Max1 3/8”
136
5 3/8”
235
9 1/4”
267
10 1/2”
15º
Faucet Dimensions

5
Step1: Install mounting hardware and waterlines
Remove mounting nut (E) with
mounting screws (F) attached.
Remove metal washer (D), and
rubber washer (C) from threaded
mounting pipe. Place faucet body
(A) on a soft cloth, spout facing up.
Secure the hot & cold waterlines
(G) at the base of the faucet
(HAND-TIGHTEN ONLY)
A. Hot Side: Left
B. Cold Side: Right
Step 2: Install faucet
Install faucet body (A) through
1-3/8” hole in countertop, with
hot & cold waterlines (G) and
base O-ring (B) attached. Attach
rubber washer (C), metal washer
(D), and mounting nut (E) to
threaded mounting pipe
A
A
A
B
G
G
B
C
D
E
F
B
C
D
E
E
F
F
H1
H2
H3
A
A
A
B
G
G
B
C
D
E
F
B
C
D
E
E
F
F
H1
H2
H3

6
Step 3: Secure faucet
After adjusting direction of faucet
body (A), tighten mounting nut
(E) with adjustable wrench until
snug. Secure mounting nut (E) by
tightening mounting screws (F)
with a Phillips head screwdriver
Step 4: Connect waterlines to faucet and main valve
Thread hot & cold waterlines (G)
onto angle stops and tighten with
adjustable wrench until snug. Turn
on angle stops and check for leaks
A
A
A
B
G
G
B
C
D
E
F
B
C
D
E
E
F
F
H1
H2
H3
A
A
A
B
G
G
B
C
D
E
F
B
C
D
E
E
F
F
H1
H2
H3

7
A
A
A
B
G
G
B
C
D
E
F
B
C
D
E
E
F
F
H1
H2
H3
Step 5: Flush faucet
Remove aerator assembly (H).
Loosen aerator cover (H3) with
adjustable wrench. Remove
aerator (H2) and aerator washer
(H1). Turn water on for 1 minute
to remove any debris. Reassemble
aerator assembly (H)
Replacement Part List - FVS-13800
7
8
10
11
12
13
14
17
1
15
16
9
4
5
6
3
2
1. Metal Handle
2. Set Screw
3. Cover Button
4. Cartridge Cover
5. Locking Nut
6. Cartridge
7. Aerator Washer
8. Aerator
9. Aerator Cover
10. Base O-Ring
11. Rubber Washer
12. Metal Washer
13. Mounting Nut
14. Mounting Screw
15. Cold Waterline
16. Hot Waterline
17. Hex Wrench

8
Care & Maintenance
*To keep the product clean & shining, follow the steps below:
1. Rinse with clean water & dry with a soft cloth
2. Do not clean with soaps, acid, polish, abrasives, or harsh cleaners
3. Do not use cloth with a coarse surface
4. Unscrew the aerator and clean when necessary
*This installation manual is subject to change without further notice.
1
10
279
10 31/32”
Minimum distance 90mm
Less than 90mm
Cold Water
32 3/32”
Ø35~Ø38
1
23
10
9
11
12 13
Hexagon Nut
Hot
Water
Cold
Water
2 3
1
45
7
6
8
45
67
8
Ø1 3/8”~Ø1 1/2”
815
194
7 5/8”
Ø1 3/8~Ø1 1/2”
30˚
10 11
Close
Open Left
Hot Water
Push
25˚ 90˚
12
13
8
7
Ø35~Ø38
Max35
217
8 17/32”
Max1 3/8”
9
11
12 13
2
3
4
5
6
7
8
Trouble - Shooting
If you have followed the instructions carefully and your faucet still does not work
properly, take the following corrective steps:
PROBLEM CAUSE ACTION
Leakage under the
handle
Locking nut (5) has
come loose
Remove cover button
(3). Loosen set screw (2)
with hex wrench (17).
Remove metal handle
(1). Unscrew cartridge
cover (4) (by hand only).
Tighten locking nut (5)
with adjustable wrench
Aerator drips or has
inconsistent water flow
pattern
Aerator (8) may be dirty
or not seated properly
Unscrew aerator cover
(9) with adjustable
wrench. Remove
aerator (8) and clean
out debris
Water will not shut off
completely
Cartridge (6) may
need to be adjusted or
replaced
Remove cover button
(3). Loosen set screw (2)
with hex wrench (17).
Remove metal handle
(1). Unscrew cartridge
cover (4) (by hand
only). Unscrew locking
nut (5) with adjustable
wrench. Remove
ceramic disc cartridge
(6). Check for cracks

9
Codes/Standards Applicable:
NSF/ANSI 372
NSF/ANSI 61 ASME A112.18.1M
1.5GPM 5.7L/min maximum
GREEN
Water Eciency
LEAD FREE
IAPMOR&T
TM
KRAUS LIMITED LIFETIME WARRANTY
This product has been manufactured and tested to the highest quality standards by
Kraus USA Inc. (“Kraus”). We offer our customers thoughtfully crafted fixtures & accesso-
ries, engineered for enduring performance over years of use.
WHO IS COVERED BY THE WARRANTY
This warranty extends to the original purchaser only. This warranty is not transferable,
between homes or owners and is only applicable to residential use.
WHAT IS COVERED BY THE WARRANTY
Kraus warranties this product against defects due to material or craftsmanship error
during the warranty period: Kraus will provide replacement parts at no charge, or at
its option, replace any product or part of the product that is deemed defective, under
normal installation, use, service and maintenance. If Kraus is unable to provide a replace-
ment and repair is not practical or cannot be made in timely fashion, Kraus may elect to
refund the purchase price in exchange for the return of the product.
CONDITIONS AND EXCLUSIONS
Like other home fixtures, Kraus products will require light maintenance to ensure proper
function. We provide you with complete knowledge to perform this maintenance and
can also recommend resources if you are unable to fulfill this service.
A. Kraus will not be responsible for product failures due to lack of maintenance or proper
use. Please read your care and maintenance documentation to determine the limits of
proper use.
B. The original sales receipt, order number, and/or proof of purchase must be presented
at the time of the warranty claim, without exception, for this warranty to be applied to all
Kraus products.
C. Kraus recommends installing all Kraus products with a licensed, professional plumber.
Kraus will not be held responsible for any damage or product failure due to improper
installation, misuse, or failure to use a licensed professional. Please read your care and
maintenance documentation to determine the limits of proper use.
D. Commercial use will automatically void this warranty.
E. This warranty is not applicable to Kraus products purchased from an unauthorized
seller. For a complete list of authorized sellers please visit http://www.kraususa.com/
where-to-buy.html

10
HELP LINE
Our customer service hours are Monday – Friday, 9am – 8pm EST.
Be sure to visit our website at www.kraususa.com
NONAPPLICABILITY OF THIS WARRANTY
By the purchase and use of our products, you agree that Kraus is not liable for incidental,
consequential or special damages associated with the return, replacement, installation or
use of your product. This includes freight costs, cartridge replacement, labor, travel time,
lost profit, home damages and other contingent liabilities and costs (including, without
limitation, costs associated with experts, investigations, analyses, attorneys and other
professionals and services). The Kraus warranty is a comprehensive and explicit limit of
liability, and all items outside of it are not addressable by or the responsibility of Kraus.
Certain states have variances regarding implied warranties and in those situations we
remain fully compliant.
KRAUS USA Inc. makes no implication that products comply with any or all local building
or plumbing codes. It is the consumer’s responsibility to determine local code compliance.
This warranty extends to the original purchaser and first consumer.
If you are a homeowner please contact a Kraus Customer Service Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
Toll-free 800-775-0703
[email protected]
If you are a plumbing contractor or trade professional please contact a Kraus Pro
Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
[email protected]
If you are an Authorized Partner please contact a Partner Support Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
[e-mail]
In requesting warranty service, please be ready to provide:
1. Proof of purchase.
2. A description of the problem.

www.kraususa.com
