Kraus Oletto KPF-2600SFS User manual

Oletto™ Single Handle Kitchen Bar Faucet
KPF-2600
INSTALLATION GUIDE
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2019 Kraus USA Inc. I REV. DEC 21, 2020

Congratulations on the purchase of your new
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance, or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [e-mail]
Have the model number available, and retain a copy of your receipt
with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
1

Prior to Installation:
•Make sure you have all necessary parts by checking the diagram and parts list. If
any part is missing or damaged, please contact Kraus Customer Service at 800-775-
0703 for a replacement
•
•Pre-drilled countertop hole size requirement: 1-3/8”(min)
•Max countertop thickness: 2-3/8”
Tools you will need:
13
Wrench Phillips Screwdriver Safety Goggles
Silicone Sealant
(optional)
Pipe Tape
2
Turn o the hot and cold water lines at the angle stops and turn on the old faucet
to release any built-up pressure

3
A. Faucet Body
C. 6mm Hex Wrench
D. 2.5mm Hex Wrench
A
Diagram and Parts List
B. Easy Install Assembly
B
C
D

4
Faucet Dimension
Installer Tip:
3/8”-compression
12 1/4''
[312.2mm]
4 1/4''
[109.1mm]
Max: 2 3/8''
[61.0mm]
7''
[178.7mm]
5 1/2''
[140.8mm]
7 1/4''
[184.9mm]
2''
[52.0mm]

5
Step 1: Installing the easy install assembly
Shut o the water supply. Remove the old
faucet. Clean the mounting surface. Check
for the proper thickness of the sink.
Insert the base (a) into sink.
a
b
NOTE: “Front” on the base (a) must face the
front of the sink. The two mounting plates (b)
on the base (a) must be loose and movable
during the installation of the base (a).
Step 2: Installing the easy install assembly
Fig 1 Fig 2
Press the base (a) so that it can not move, then turn the screw with the provided
hex wrench (C, HEX: 6.0mm) clockwise, as shown Fig 1. When the mounting
plates (b) make contact with the sink (1), continue to turn the screw with the
provided hex wrench (C, HEX: 6.0mm) clockwise, as shown Fig 2, until the
base (a) is completely tightened and secured, as shown Fig.4.
Fig 3
Fig 4
C
a
b1
C
a
b
1
C
a
b
C
a
b
1
1

6
Step 3: Installing the faucet
Insert the supply lines (1) through the hole of the base (a). Carefully insert the
hoses into the base. Place the faucet assembly (A) onto the base (a) as shown in
the above gure. Secure the faucet assembly (A) by tightening the set screw
with the provided hex wrench (D, Hex: 2.5 mm).
1
a
D
A

7
Step 4: Connect waterlines to main valve
Attach waterlines to angle stops
and tighten until snug. Turn on angles
stops and check for leaks (DO NOT TURN
FAUCET ON)
Step 5: Flush faucet
After installing faucet, remove aerator.
Turn water on for 30 seconds to remove any
debris. Reassemble aerator. Do not lose the
gasket (1) in the aerator.
1

8
Replacement Parts
1. Aerator Assembly
Replacement Parts List Part #
2. Washer
3. Block
5. Index
6. Set Screw
7. Cartridge
9. Cap
10. Handle
11. Set screw
Finish / Color
KP27222
KP27033
KP27257
KP27258
KP27259
KP27260
KP27295
KP27031
KP27030
8. Bonnet Nut
4. O-ring KP27029
12. Cover Button
KP27001
KP27002
CH,SFS*
13. O-Ring Set of 2 KP27171
*Denotes faucet component color options:
SFS - Spot Free Stainless Steel;
CH - Polished Chrome;
GR - Grey;
CH, SFS*
14. Easy Install Assembly
15. Hex wrench
KP27262
16. Hex Wrench
KP27020
KP27263
17. Filter Washer KP27167
1
GR*
CH,SFS*
GR*
2
3
4
5
6
789
10
11
12
15
13
14
16
17
GR*

9
Troubleshooting
If you have followed the instructions carefully and your faucet still does not work
properly, take the following coorective steps:
Care & Maintenance
*To keep the product clean & shining, follow the steps below：
1. Rinse with clean water & dry with a soft cloth
2. Do not clean with soaps, acid, polish, abrasives, or harsh cleaners
3. Do not use cloth with a coarse surface
4. Unscrew the aerator and clean when necessary
*This installation manual is subject to change without further notice.
10
9
11
12 13
Hexagon Nut
Hot
Water
Cold
Water
Close
Open Left
Hot Water
Push
25˚ 90˚
PROBLEM CAUSE ACTION
Leakage under the
handle
Bonnet nut (8) has
come loose
Remove the cover button (12).
Loosen set screw (11) with hex
wrench (15). Remove the
handle (10). Unscrew cap (9) (by
hand only). Tighten bonnet nut
(8) with an adjustable wrench
The aerator has an
irregular or reduced
water ow
The aerator is dirty or
mis-tted
Remove the aerator and
check for debris.
Ensure that the rubber
washer is properly installed.
Water will not shut o
completely
Cartridge may need to
be adjusted or replaced
Remove the cover button (12).
Loosen set screw (11) with hex
wrench (15). Remove the
handle (10). Unscrew cap (9)
(by hand only). Tighten bonnet
nut (8) with an adjustable
wrench. Remove the cartridge
(7). Check for cracks
There is a low ow of
water.
The lter washer in the
hose connectors is dirty.
Turn o the water supply at
water valve and unscrew the
hose connectors from water
supply lines. Clean the lter
washer in the water lines with
hot water, removing any debris
or calcium build up
