Kraus Esta KBF-1211SFS-2PK User manual

Esta™ Single Handle Lavatory Faucet
KBF-1211
INSTALLATION GUIDE
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2019 Kraus USA Inc. IREV. JUN 06, 2019

Congratulations on the purchase of your new
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance, or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [e-mail]
Have the model number available, and retain a copy of your receipt
with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
1

Prior to Installation:
•Make sure you have all necessary parts by checking the diagram and parts list. If
any part is missing or damaged, please contact Kraus Customer Service at 800-775-
0703 for a replacement
•
•Pre-drilled countertop hole size requirement: 1-3/8”(min)
•Max countertop thickness: 2 3/8”
Tools you will need:
13
Wrench Phillips Screwdriver Safety Goggles
Silicone Sealant
(optional)
Pipe Tape
2
Turn off the hot and cold water lines at the angle stops and turn on the old faucet
to release any built-up pressure

3
Diagram and Parts List
A. Faucet Body
C. Aerator Key
D. Metal Washer
E. Lock Nut
C
A
D
E
F
F. Spanner Key
G
G. Hex Wrench
B
B. Aerator

4
a. Waste Stopper
c. Rubber Washer
d. Concave Washer
f. Mounting Nut
Diagram and Parts List-Lift Rod Drain
g. Tail Pipe
h. Top Hat Washer
b. Drain Flange
i. Drain Off Pole
k. Retaining Nut
l. Clip
m. Extender Rod
n. Thumb Screw
e. Metal Washer o. Lift Rod
a
b
c
d
e
f
g
h
i
jkl
m
n
o
j. Washer

Faucet Dimension
Installer Tip:
5
1 7/8"
[47.8mm]
3 7/8"
[98.0mm]
4 3/4"
[120.3mm]
6 1/4"
[159.2mm]
6 7/8"
[175.0mm]
2 1/8"
[54.6mm]
9/16-24UNEF-2B
M18.5X1.0-6g
2 3/8"
[59.6mm]

Drain Dimension
Installer Tip:
6
Ø2 1/8”
[Ø54.0mm]
1 3/4”-2 3/4”
[43.3-68.3mm]
5 5/8”
[141.6mm]
Ø1 1/4”
[Ø32.0mm]
8 3/4”
[223.8mm]
1 1/4-18UNEF-2A

Step 1: Installing the faucet
Shut off the water supply.
Place faucet (A) through the hole in sink.
Secure the faucet (A) to the sink using the
metal washer (D) and lock nut (E) provided.
Tighten lock nut (E) with spanner key (F)
provided. Ensure the metal washer (D) and
hoses are no interference.
7
Step 2: Connect waterlines to main valve
D
E
F
D
E
F
Attach waterlines to angle stops
and tighten until snug. Turn on angles
stops and check for leaks (DO NOT TURN
FAUCET ON)
A

Step 3A: Installing the drain
Remove waste stopper (a) and drain
flange (b) from tailpipe (g). Remove concave
washer (d), metal washer (e) and monting
nut (f) from drain flange (b).
Step 3B: Installing the drain
Insert drain flange (b) through drain hole
with rubber washer (c) attached. From
underneath, place concave (d) and metal
washer (e) on drain flange. Secure with
mounting nut (f). Thread tailpipe (g) onto
drain (b) and hand tighten.
a
b
c
d
e
f
g
b
c
d
e
f
g
8

9
Step 3C: Installing the drain
Insert waste stopper (a) into drain flange.
Remove extender rod (m) and clip (I) from
drain off pole (i). Reomve nut (k). Insert drain
off pole (i) into drain pole opening of
tailpipe (g). See insert 1. Secure nut (k) to
drain off pole opening of tailpipe (g).
Step 3D: Installing the drain
Insert lift rod (o) through spout and
connect with extender rod (m). Tighten
thumb screw (n).
