Kraus Ramus KBF-1221 User manual

Ramus™ Single Handle Basin Faucet
KBF-1221
INSTALLATION GUIDE
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2021 Kraus USA Plumbing LLC I REV. NOV 10, 2021

Congratulations on the purchase of your new
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance, or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [e-mail]
Have the model number available, and retain a copy of your receipt
with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
1

Prior to Installation:
•Make sure you have all necessary parts by checking the diagram and parts list. If
any part is missing or damaged, please contact Kraus Customer Service at 800-775-
0703 for a replacement
•
•
Pre-drilled countertop hole size requirement: 1-3/8”(min)
•
Max countertop thickness: 2 5/8”
Tools you will need:
13
Wrench Phillips Screwdriver Safety Goggles
Silicone Sealant
(optional)
Pipe Tape
2
to release any built-up pressure
STOP
Care & Maintenance
* To keep the product clean & shining, follow the steps below:
1. Rinse with clean water & dry with a soft cloth
2. Do not clean with soaps, acid, polish, abrasives or harsh cleaners
3. Do not use cloth with a coarse surface
4. Unscrew the aerator and clean when necessary
* This installation manual is subject to change without further notice.
ACID
Read all instructions and safety warnings and ensure you have all tools, parts,
and equipment necessary for a safe installation.
•

3
Diagram and Parts List
A. Faucet Body
C. Flange
D. Metal Washer
E. Lock Nut
C
A
D
E
F
F. Spanner Key
G
G. Hex Wrench
B
B. Aerator

4
a. Waste Stopper
c. Rubber Washer
d. Concave Washer
f. Mounting Nut
Diagram and Parts List-Lift Rod Drain
g. Tail Pipe
h. Top Hat Washer
b. Drain Flange
i. Drain Off Pole
k. Retaining Nut
l. Clip
m. Extender Rod
n. Thumb Screw
e. Metal Washer o. Lift Rod
a
b
c
d
e
f
g
h
i
jkl
m
n
o
j. Washer

Faucet Dimension
Installer Tip:
5
3/8” compression
Ø2 1/4"
[Ø57.0mm]
7 1/2"
[189.0mm]
5 1/2"
[140.4mm]
7"
[177.4mm]
3 3/8"
[84.6mm]
2 5/8"
[65.2mm]

Drain Dimension
Installer Tip:
6
Ø2 1/8”
[Ø54.0mm]
1 3/4”-2 3/4”
[43.3-68.3mm]
5 5/8”
[141.6mm]
Ø1 1/4”
[Ø32.0mm]
8 3/4”
[223.8mm]
1 1/4-18UNEF-2A

Step 1: Remove lock nut
Shut off the water supply.
Remove the lock nut (E) from the faucet (A).
7
Step 2: Installing the faucet
E
A
Before installation, ensure that the flange (C)
is placed on the bottom of the new faucet (A).
Place faucet (A) through the hole in sink.
Secure the faucet (A) to the sink using the
metal washer (D) and lock nut (E) provided.
Tighten lock nut (E) with spanner key (F)
provided. Ensure the metal washer (D) and
hoses are no interference.
D
E
F
A
C
D
E
F

Step 3: Connect waterlines tomain valve
Attach waterlines to angle stops
and tighten until snug. Turn on angles
stops and check for leaks (DO NOT TURN
FAUCETON)
Remove waste stopper (a) anddrain
flange (b)from tailpipe (g). Remove concave
washer (d), metal washer (e) and monting
nut (f)from drainflange (b).
Step 4A: Installing the drain
a
b
c
d
e
f
g
8
NOTE
are installed before connecting to
the main valve.

9
Insert drain flange (b) through drain hole
with rubber washer (c) attached. From
underneath, place concave (d) and metal
washer (e) on drain flange. Secure with
mounting nut (f). Thread tailpipe (g) onto
drain (b) and hand tighten.
Step 4B: Installing the drain
Insert waste stopper (a) into drain flange.
Remove extender rod (m) and clip (I) from
drain off pole (i). Reomve nut (k). Insert drain
off pole (i) into drain pole opening of
tailpipe (g). See insert 1. Secure nut (k) to
drain off pole opening of tailpipe (g).
Step 4C: Installing the drain
b
c
d
e
f
g
