Kraus Purita KPF-2620-FF-100BB User manual

Purita™ Single Handle
Water Filtration Faucet
FF-100
INSTALLATION MANUAL
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2023 Kraus USA Plumbing L LC I Rev. March 20, 2023

2
Congratulations on the purchase of your new
R
Kraus plumbing fixture!
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [email protected]
Have the model number available and retain a copy of your
receipt with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
STOP

3
Prior to Installation:
·Make sure you have all necessary parts by checking the diagram and
parts list. If any part is missing or damaged, please contact Kraus
Customer Service at 800-775-0703 for a replacement.
·Read all instructions and safety warnings and ensure you have all tools,
parts, and equipment necessary for a safe installation.
·Turn off the hot and cold water supply at the angle stops and turn on
the old faucet to release any built up pressure. Remove existing faucet.
·Pre-drilled hole size requirement: 1 1/4" (min)
·Max countertop thickness: 3 1/16”
Care & Maintenance
* To keep the product clean & shining, follow the steps below:
1. Rinse with clean water & dry with a soft cloth
2. Do not clean with soaps, acid, polish, abrasives or harsh cleaners
3. Do not use cloth with a coarse surface
4. Unscrew the aerator and clean when necessary
* This installation manual is subject to change without further notice.
ACID
R
STOP
For technical assistance or replacement parts, please contact Kraus Customer
Service and one of our representatives will be happy to help:
Toll-Free: 800-775-0703 or [email protected]
Tools Required
Adjustable Wrench Phillips Screwdriver Silicone Sealant Safety Goggles Supply Lines

B
A
D
E
F
G
A. Faucet Assembly
B. Flange
C. Rubber Washer
D. Metal Washer
E. Mounting Nut
F. Connector
G. Hex Wrench
C
Diagram and Parts List
4

Faucet Dimensions
2 3/4“
[69.5mm]
12”
[304.5mm]
MAX 3 1/16”
[77.0mm]
7 1/8”
[181.5mm]
6”
[153.0mm]
8 3/8“
[212.0mm]
7/16-24UNS-2A
Ø1 3/4"
[Ø45.0mm]
Installer Tip:
Shut off main water supply before installing new faucet.
5

Step 1: Preparing for installation
Remove the rubber washer (C), metal washer
(D), and mounting nut (E) from the end of the
stud.
Step 2: Installing the faucet assembly
Place the faucet assembly (A) through the
selected hole in the sink or countertop. On
the underside of the sink or countertop, slide
the rubber washer (C) and metal washer (D)
onto the stud. Thread the mounting nut (E)
onto the stud, and tighten securely using
your wrench.
D
E
C
D
E
C
A
6

Step 3: Connecting the quick connect adaptor and water line
Thread the quick connect adaptor (F) onto
the end of the faucet assembly (A) stud, and
tighten securely using a wrench. Connect the
3/8 in. water line from the filtration system
by pushing the line into the connector (F).
Pull down on the 3/8 in. line slightly to
ensure the quick connect fitting has
engaged.
F
3/8 in. Water line from
filtration system
A
7

Replacement Parts
1. O-ring
Replacement Parts List Part #
3. Locking Ring
4. O-ring
6. Handle
8. Flange
9. Rubber Washer
10. Metal Washer
Finish / Color
KP27173
KP27174
KP27175
KP27176
KP27168
KP27170
KP27171
5. Cartridge
CH, SFS, MB, BG,
BB, SFACB, SFSB*
KP27172
11. Mounting Nut KP27177
12. Connector KP27178
13. Hex Wrench KP27020
1
3
4
5
6
8
9
10
11
12
13
CH, SFS, MB, BG,
BB, SFACB, SFSB*
2. Spout Nut KP27169
2
CH, SFS, MB, BG,
BB, SFACB, SFSB*
7. Index KP27194
7
GR, BL*
*Denotes faucet component color options:
CH - Chrome
SFS - Spot Free Stainless Steel
MB - Matte Black
BG - Brushed Gold
BB - Brushed Brass
SFACB - Spot Free Antique Champagne Bronze
SFSB - Spot Free Black Stainless
SFSMB - Spot Free Stainless Steel/Matte Black
BBMB - Brushed Brass/Matte Black
GR - Grey
BL - Black
8

Troubleshooting
If you have followed the instructions carefully and your faucet still does not work properly, take the
following corrective steps:
Leakage under the handle
PROBLEM CAUSE ACTION
Cartridge (5) has come
loose
Remove index (7) and loosen set screw with
hex wrench (13). Remove the handle.
Tighten cartridge (5) with a adjustable
wrench.
Water will not shut off
completely.
Cartridge may need to be
adjusted or replaced.
Remove index (7) and loosen set screw
with hex wrench (13). Remove the
handle . Loosen the cartridge (5) with a
adjustable wrench. Remove the cartridge
(5). Check for cracks.
9

Codes/Standards Applicable:
Faucet - Lifetime Limited Warranty
R
Kraus USA Plumbing, LLC (“Kraus”) extends this warranty to the original purchaser for personal household use of the
Faucet when purchased from an authorized Kraus dealer and in the location of original installation. This warranty is
non-transferable.
Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal
usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
Kraus warrants the Faucet's sprayhead assembly (including the engine, aerators, structure, restrictors, back flow
preventers, sprayer hoses, braided supply line hoses which encompasses nylon, silicon and stainless steel) of the product
to be free from defects in material and workmanship under normal usage for a period of one (1) year from the date of
purchase.
Kraus warrants the Faucet's cartridge to be free from defects in material and workmanship under normal usage for a
period of five (5) years from the date of purchase.
Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired
or replaced with a product of equal value at the option of Kraus.
Commercial Warranty
Kraus USA Plumbing, LLC (“Kraus”) warrants its Products for a period of one (1) year to commercial purchasers of
Products used in industrial, commercial and business applications.
Care and Cleaning Instructions
Certain cleaning products may cause damage to a Product's finish and use of the following on the Product will void this
warranty:
·Abrasive cleaners such as powders, bleach, ammonia, alcohol or chorine
·Abrasive pads, steel wool or wire brushes
What is Not Covered
This warranty does not cover Products that were discontinued when purchased or display Products, whether such
Products were purchased at discount outlets, unauthorized dealers, and/or sold on clearance. This warranty does not
cover any free gifts included with purchase.
This warranty does not cover damage resulting from neglect, misuse (including use for an unintended application),
abuse, carelessness, accident, hard water or mineral deposits, exposure to corrosive materials, improper maintenance,
alteration of the Product, or failure to follow care, cleaning or installation instructions enclosed with your Product. Kraus
recommends that all Kraus Products be installed by a fully licensed and insured trade professional with experience in the
installation of bathroom and/or kitchen manufactured goods.
10
UPC
CR
NSF/ANSI 372
ASME A112.18.1
1GPM 3.8L/min maximum
IAP
TM
LEAD FREE
NSF/ANSI 61
MOR&T
UPC
CR
NSF/ANSI/CAN 61: Q ≤ 1

How to Make a Warranty Claim
R
If you are a consumer purchaser, please contact a Kraus Customer Service Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
Toll-free 800-775-0703
[email protected]
If you are a plumbing contractor or trade professional, please contact a Kraus Pro Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
[email protected]
If you are an authorized partner, please contact a Partner Support Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
[email protected]
In requesting warranty service, please be ready to provide your proof of purchase and a description of the problem.
Shipping charges will be covered for the first (1) year of the warranted replacement part or product (HI, AK, and Puerto
Rico shipping charges may apply). International shipping fees are not included.
Limitation on Duration of Implied Warranties
Please note that some states/provinces (including Quebec) do not allow limitations on how long an implied
warranty lasts, so the below limitations may not apply to you. TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, ANY IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
OF FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED TO THE STATUTORY PERIOD OR THE DURATION OF THIS
WARRANTY, WHICHEVER IS SHORTER.
Limitation of Special, Incidental or Consequential Damages
Please note that some states/provinces (including Quebec) do not allow the exclusion or limitation of special,
incidental or consequential damages, so the below limitations and exclusions may not apply to you. TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA
PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
(INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING
OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
This warranty gives you specific legal rights, and you may also have other rights which vary from state/province to
state/province.
Download the Kraus Care & Maintenance Guide at:
http://www.kraususa.com/maintenance
11

Register Your Kraus Product
Activate Your Warranty
Access Premium Customer Support
Get Product Information
REGISTER TODAY
http://www.kraususa.com/registration
