DK37/M8 - H250/M8
1 Safety instructions 3
1.1 General notes ................................................................................................................... 3
1.2 EU conformity ................................................................................................................... 3
1.3 Approval according to the IECEx scheme ........................................................................ 3
1.4 Safety instructions............................................................................................................ 4
2 Device description 5
2.1 Device description ............................................................................................................ 5
2.2 Description code............................................................................................................... 6
2.3 Marking............................................................................................................................. 8
2.4 Flammable products ........................................................................................................ 9
2.5 Equipment category .........................................................................................................9
2.6 Types of protection ......................................................................................................... 10
2.7 Ambient temperature / temperature classes / product temperature .......................... 11
2.8 Surface temperature for equipment category II 2 D...................................................... 13
2.9 Electrical data................................................................................................................. 13
3 Installation 14
3.1 Mounting ......................................................................................................................... 14
3.2 Special conditions........................................................................................................... 14
4 Electrical connections 15
4.1 General notes ................................................................................................................. 15
4.2 Power supply .................................................................................................................. 16
4.3 Inputs/Outputs................................................................................................................ 16
4.4 Grounding and equipotential bonding............................................................................ 17
5 Operation 18
5.1 Start-up........................................................................................................................... 18
5.2 Operation ........................................................................................................................ 18
5.3 Electrostatic charge .......................................................................................................18
6 Service 19
6.1 Maintenance ................................................................................................................... 19
6.2 Dismantling .................................................................................................................... 19

SAFETY INSTRUCTIONS 1
3
DK37/M8 - H250/M8
www.krohne.com05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
1.1 General notes
This additional instruction applies to explosion-protected versions of variable area flowmeter
with electrical built-ins with protection type intrinsic safety "i", equipment category II 2 G and
II 2 D or EPL Gb and Db.
It completes the standard documentation for the non-explosion protected versions.
The information given in this instruction contains only the data relevant to explosion protection.
The technical details given in the manual for the non-explosion protected versions remain
unchanged unless excluded or superseded by this supplementary instruction.
1.2 EU conformity
The manufacturer declares with the EU declaration of conformity on his own responsibility
conformity with the protection goals of directive 2014/34/EU for use in hazardous areas with gas
and dust.
Conformity with harmonised standards was checked by a notified body in accordance with
EN 60079-0:2012 and EN 60079-11:2012.
The EU declaration of conformity for the equipment category II 2 G and II 2 D is based on the EU
type examination certificate:
The "X" after the certificate number refers to special conditions for safe use of the device, which
have been listed in these instructions.
If necessary, the EU type examination certificate can be downloaded from the manufacturer's
website.
1.3 Approval according to the IECEx scheme
Conformity for use in hazardous areas with gas and dust was tested in accordance with the
"IECEx Certification Scheme for Explosive Atmospheres" according to
IEC 60079-0:2011, IEC 60079-15:2010 and IEC 60079-31:2013.
The number of the IECEx certificate is:
The "X" after the certificate number refers to special conditions for safe use of the device, which
have been listed in these instructions.
If needed, the IEC certificate can be downloaded from the manufacturer's website.
KIWA 15 ATEX 0038 X
KIWA 15 ATEX 0038 XKIWA 15 ATEX 0038 X
KIWA 15 ATEX 0038 X
IECEx KIWA 15.0020 X
IECEx KIWA 15.0020 XIECEx KIWA 15.0020 X
IECEx KIWA 15.0020 X

1 SAFETY INSTRUCTIONS
4
DK37/M8 - H250/M8
www.krohne.com 05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
1.4 Safety instructions
If these instructions are not followed, there is a risk of explosion.
Assembly, installation, start-up and maintenance may only be performed by personnel trained in
explosion protection!
CAUTION!
The operator or his agent is responsible for observing any additional standards, directives or
laws if required due to operating conditions or place of installation.
This applies in particular to the use of easily detachable process connections when measuring
flammable media.

DEVICE DESCRIPTION 2
5
DK37/M8 - H250/M8
www.krohne.com05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
2.1 Device description
Variable area flowmeters measure and display the volume flow of flammable and non-
flammable gases and liquids.
Figure 2-1: Available indicators
1 Indicator M8E.: one signal output 4...20 mA with a bargraph indicator
2 Indicator M8M.: up to two separately adjustable electrical limit switches

2 DEVICE DESCRIPTION
6
DK37/M8 - H250/M8
www.krohne.com 05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
2.2 Description code
Type series H250
Type series H250Type series H250
Type series H250
The safety description code consists of the following elements*:
Figure 2-2: Safety description code
1 Type series of measuring unit H250
Type series of measuring unit H250Type series of measuring unit H250
Type series of measuring unit H250
2 Materials / versions
Materials / versionsMaterials / versions
Materials / versions
RR - stainless steel
C - PTFE or PTFE with ceramic liner
HC - Hastelloy
®
Ti - Titanium
F - Food
3 Type series of indicators
Type series of indicatorsType series of indicators
Type series of indicators
M8 - Indicator M8
4 Design of indicator M8
Design of indicator M8Design of indicator M8
Design of indicator M8
MG - mechanical indicator
EG - electronic indicator with signal output 4...20 mA
5 Design of indicator housing
Design of indicator housingDesign of indicator housing
Design of indicator housing
without - indicator housing in PPS
R - indicator housing in stainless steel
6 Limit switch (M8MG version)
Limit switch (M8MG version)Limit switch (M8MG version)
Limit switch (M8MG version)
K1 - one limit switch
K2 - two limit switches
7 Version
VersionVersion
Version
Ex - explosion-protected version

DEVICE DESCRIPTION 2
7
DK37/M8 - H250/M8
www.krohne.com05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
Type series DK37
Type series DK37Type series DK37
Type series DK37
The safety description code consists of the following elements*:
* positions which are not needed are omitted (no blank positions)
Figure 2-3: Safety description code
1 Type series of measuring unit DK
Type series of measuring unit DKType series of measuring unit DK
Type series of measuring unit DK
2 Type series of signal converter 37
Type series of signal converter 37Type series of signal converter 37
Type series of signal converter 37
3 Type series of indicators
Type series of indicatorsType series of indicators
Type series of indicators
M8M - mechanical indicator
M8E - electronic indicator
4 Design of indicator housing
Design of indicator housingDesign of indicator housing
Design of indicator housing
without - indicator housing in PPS
R - indicator housing in stainless steel
5 Optional differential pressure regulator
Optional differential pressure regulatorOptional differential pressure regulator
Optional differential pressure regulator
RE - inlet pressure regulator
RA - outlet pressure regulator
6 Limit switch (M8M version)
Limit switch (M8M version)Limit switch (M8M version)
Limit switch (M8M version)
K1 - one limit switch
K2 - two limit switches

2 DEVICE DESCRIPTION
8
DK37/M8 - H250/M8
www.krohne.com 05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
2.3 Marking
The marking of the entire device is clearly visible on the indication unit, in accordance with the
designation code.
Additional markings on the housing cover:
•SN - serial number
•SO - sales order / item
•PA - order
•Vxxx - product configurator code
•AC - article code
Additional plate
The association of the housing cover to the device is confirmed by an additional plate with the
serial number on the interior of the indicator part.
Figure 2-4: Example of a nameplate
1 Device type
2 Manufacturer
3 Identification number of the notified body ATEX & PED
4 Rating data: temperature & pressure rating
5 PED data
6 Ex data
7 Electrical connection data
8 QR code
9 Note to observe the documentation and for disposal

DEVICE DESCRIPTION 2
9
DK37/M8 - H250/M8
www.krohne.com05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
2.4 Flammable products
Atmospheric conditions:
Atmospheric conditions:Atmospheric conditions:
Atmospheric conditions:
The ATEX directive does not stipulate values for atmospheric conditions. However, for
determining the explosion characteristic parameters of temperature and pressure range, the
following is assumed as a basis:
T
atm
= -20...+60°C / -4...+140°F and P
atm
= 0.8...1.1 bar / 11.6...15.9 psi
Outside of these ranges, for most mixtures no key figures are available for the ignition
behaviour.
Operating conditions:
Operating conditions:Operating conditions:
Operating conditions:
Variable area flowmeters operate outside of atmospheric conditions, which means that
explosion protection, regardless of the zone assignment, is fundamentally not applicable due to
the lack of key safety data for the interior of the measuring unit.
2.5 Equipment category
Variable area flowmeters are designed in accordance with EN 60079-0 and EN 60079-11 in
category II 2 G or EPL Gb for use in zone 1.
Depending on the device version, variable area flowmeters are also designed in
category II 2 D or EPL Db for use in zone 21.
The inside of the measuring unit is also approved for zone 1.
WARNING!
Operation with flammable products is only permitted as long as no explosive fuel/air mixture
builds up on the inside of the flowmeter under operating conditions. The operator is responsible
to ensure that the flowmeter is operated safely in terms of the temperature and pressure of the
products used. In case of operation with flammable products the measuring units must be
included in the periodic pressure tests of the system. When using the device version H250/C...
(PTFE version, non-conductive) the minimum conductivity of the media must be 10
-8
S/m, in
order to avoid danger from electrostatic charge.
INFORMATION!
Definition of zone 1 according to EN 1127-1, Appendix B:
An area in which an explosive atmosphere, as a result of the mixture of flammable substances in
the form of gas, steam or mist with air, under normal operation may occasionally occur.
Definition of zone 21 according to EN 1127-1, Appendix B:
An area in which an explosive atmosphere may occasionally occur in the form of a cloud of
flammable dust in the air under normal operation.

2 DEVICE DESCRIPTION
10
DK37/M8 - H250/M8
www.krohne.com 05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
2.6 Types of protection
The variable area flowmeter is designed with protection type intrinsic safety "i" according to
EN 60079-11.
The identification for equipment category II 2 G or EPL Gb is:
II 2 G Ex ia IIC T6...T3 Gb
II 2 G Ex ia IIC T6...T3 GbII 2 G Ex ia IIC T6...T3 Gb
II 2 G Ex ia IIC T6...T3 Gb
The additional identification of the version for the equipment category II 2 D and EPL Db is:
II 2 D Ex ia IIIC T75
II 2 D Ex ia IIIC T75II 2 D Ex ia IIIC T75
II 2 D Ex ia IIIC T75°C ... T200
C ... T200C ... T200
C ... T200°C Db
C DbC Db
C Db
The marking contains the following information:
The marking contains the following information:The marking contains the following information:
The marking contains the following information:
II
IIII
II Explosion protection, group II
2
22
2Equipment category 2
G
GG
GGas explosion protection
Ex ia
Ex iaEx ia
Ex ia Explosion protection through intrinsic safety, protection level "ia"
IIC
IICIIC
IIC Gas group, suitable for gas groups IIC, IIB and IIA
T6...T3
T6...T3T6...T3
T6...T3 Temperature class range, suitable for temperature classes T6...T1
Gb
GbGb
Gb EPL, suitable for zone 1 and zone 2
INFORMATION!
For the equipment category II 2 G and EPL Gb, connection to an intrinsically safe circuit with
protection level "ib" is required.
When connecting the variable area flowmeter to an intrinsically safe circuit with protection level
"ia", a higher protection level is given.
The marking contains the following information:
The marking contains the following information:The marking contains the following information:
The marking contains the following information:
II
IIII
II Explosion protection, group II
2
22
2Equipment category 2
D
DD
DDust ignition protection
Ex ia
Ex iaEx ia
Ex ia Explosion protection through intrinsic safety, protection level "ia"
IIIC
IIICIIIC
IIIC Dust group, suitable for groups IIIC, IIIB and IIIA
T75
T75T75
T75°C ... T200
C ... T200C ... T200
C ... T200°C
CC
CMaximum surface temperature at +65°C / +149°F ambient temperature
Db
DbDb
Db EPL, suitable for zone 21 and zone 22
INFORMATION!
For the equipment category II 2 D and EPL Db, connection to an intrinsically safe circuit with
protection level "ib" is required.
When connecting the variable area flowmeter to an intrinsically safe circuit with protection level
"ia", a higher protection level is given.

DEVICE DESCRIPTION 2
11
DK37/M8 - H250/M8
www.krohne.com05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
2.7 Ambient temperature / temperature classes / product temperature
Due to the influence of the product temperature, variable area flowmeters with built-in electrical
equipment (electric variants) are not assigned to any fixed temperature class. The temperature
class of these devices is rather a function of the product temperature and ambient temperature
that is present and the specific device version.
The classification is outlined in the following tables.
The tables take into account the following parameters:
•built-in equipment
•Maximum values I
i
and P
i
for K1 and K2
•Ambient temperature T
amb
•Product temperature T
m
•Heat resistance of the connecting cable
When using more than one installed equipment, the data of the most unfavourable equipment
should be used.
For certain device versions, lower values apply due to differing boundary conditions (e.g. liner
materials). Here the user should consult the technical data sheet.
The maximum product temperature is outlined in the following tables.
DK37/M8../../.. permissible product and ambient temperatures
INFORMATION!
The maximum permissible product temperatures listed in the tables are valid under
the following conditions:
• The measuring device is installed and operated in accordance with the manufacturer's
installation instructions.
• It must be ensured that the flowmeter is not heated by the effects of additional heat radiation
(sunshine, neighbouring system components) and thus operated above the permissible
ambient temperature range.
• Insulation must be limited to the piping.
Unobstructed ventilation of the indicator part must be ensured.
Temperature
class
Ambient temperature
up to
Maximum permissible product temperature / maximum value
Type DK37/M8E/.. Type DK37/M8M/..K.
at 64 mW
Type DK37/M8M/..K.
at 169 mW
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
T6 +40 +104 +70 +158 +85 +185 +40 +104
+50 +122 --+85 +185 - -
+60 +140 --+75 +167 - -
T5 +40 +104 +100 +212 +100 +212 +90 +194
+50 +122 +95 +203 +100 +212 +65 +149
+60 +140 +75 +167 +100 +212 - -
+65 +149 --+100 1 +212 2 - -

2 DEVICE DESCRIPTION
12
DK37/M8 - H250/M8
www.krohne.com 05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
H250/../M8.G/.. permissible product and ambient temperatures
T4 +40 +104 +135 +275 +135 +275 +135 +275
+50 +122 +135 +275 +135 +275 +135 +275
+60 +140 +115 1 +239 2 +135 1 +275 2 +110 1 +230 2
+65 +149 +100 1 +212 2 +135 1 +275 2 +100 1 +212 2
T3 +40 +104 +160 +320 +200 1 +392 2 +160 +320
+50 +122 +140 +284 +190 1 +374 2 +135 +275
+60 +140 +115 1 +239 2 +150 1 +302 2 +110 1 +230 2
+65 +149 +100 1 +212 2 +135 1 +275 2 +100 1 +212 2
1Temperature resistance of the cable ≥+80°C
2Temperature resistance of the cable ≥+176°F
Temperature
class
Ambient temperature
up to
Maximum permissible product temperature / maximum value
Type H250/../M8EG/.. Type
H250/../M8MG/../.. at
64 mW
Type
H250/../M8MG/../... at
169 mW
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
T6 +40 +104 +85 +185 +85 +185 +40 +104
+50 +122 --+85 +185 - -
+60 +140 --+85 +158 - -
T5 +40 +104 +100 +212 +100 +212 +100 +212
+50 +122 +100 +212 +100 +212 +80 +176
+60 +140 +85 +185 +100 +212 - -
+65 +149 --+100 ---
T4 +40 +104 +135 +275 +135 +275 +135 +275
+50 +122 +135 +275 +135 +275 +135 +275
+60 +140 +135 1 +275 2 +135 +275 +135 +275
+65 +149 +125 1 +257 2 +135 1 +275 2 +135 1 +266 2
T3 +40 +104 +200 1 +392 2 +200 +392 +200 +392
+50 +122 +185 1 +365 2 +200 +392 +200 +392
+60 +140 +145 1 +293 2 +200 1 +392 2 +155 1 +311 2
+65 +149 +125 1 +257 2 +190 1 +374 2 +130 1 +266 2
1Temperature resistance of the cable ≥+80°C
2Temperature resistance of the cable ≥+176°F
Temperature
class
Ambient temperature
up to
Maximum permissible product temperature / maximum value
Type DK37/M8E/.. Type DK37/M8M/..K.
at 64 mW
Type DK37/M8M/..K.
at 169 mW
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]

DEVICE DESCRIPTION 2
13
DK37/M8 - H250/M8
www.krohne.com05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
The permitted ambient temperature range is indicated on the nameplate; depending on the
device version it is
T
amb
= -40...+65°C / -40...+149°F or T
amb
= -25...+65°C / -13...+149°F.
The minimum product temperature is -40°C/-40°F.
2.8 Surface temperature for equipment category II 2 D
For use in areas with flammable dust it should be noted that the indicated maximum surface
temperature of T75 at an ambient temperature of +65°C / +149°F and a product temperature of
+75°C / +167°F is valid without a dust coating.
For higher product temperatures the maximum surface temperature is defined by the product.
2.9 Electrical data
Built-in equipment for the variable area flowmeter may only be connected to separate
intrinsically safe circuits with the following maximum values:
Type Electrical built-ins Min. ambient temperature
H250/../M8EG
DK37/M8E/../.. Signal output 4...20 mA -40°C/-40°F
H250/../M8MG
DK37/M8M/../.. SC2-N0 -25°C/-13°F
H250/../M8MG
DK37/M8M/../.. I7S2002-N SJ2-SN -40°C/-40°F
Maximum values
Device version U
i
[V] I
i
[mA] P
i
[mW] C
i
[nF] L
i
[μH]
DK37/M8E/../.. or H250/../M8EG 30 120 1000 0~ 0
DK37/M8M/../.. or H250/../M8MG
SC2-N0... 16 25 64 165 150
52 169
DK37/M8M/../.. or H250/../M8MG
SJ2-SN 16 25 64 45 100
52 169
DK37/M8M/../.. or H250/../M8MG
I7S2002-N 16 25 64 165 120
52 169
WARNING!
Also, when operating the variable area flowmeter outside of the hazardous area, the connection
must be made to an intrinsically safe circuit.
When connecting to non-intrinsically safe circuits, there is a risk of damage to the safety-
defining components.

3 INSTALLATION
14
DK37/M8 - H250/M8
www.krohne.com 05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
3.1 Mounting
Mounting and setup must be carried out according to the applicable installation standards
(e.g. EN 60079-14) by qualified personnel trained in explosion protection. The information given
in the manuals and the supplementary instructions must be observed at all times.
Variable area flowmeters must be installed in such a way that
•there is no danger from mechanical impact effects.
•no external forces are affecting the indication unit.
•the device is accessible for any necessary visual inspections and can be viewed from all sides.
•the nameplate is clearly visible.
•it can be operated from a location with secure footing.
3.2 Special conditions
Electrostatics
For painted versions, risks due to electrostatic charge must be minimized.
Observe additional information regarding electrostatics. For further information refer to
Electrostatic charge on page 18.
Wetted parts made of titanium
When dealing with device versions of the type series H250 with wetted parts made of titanium (TI
option), use the protected installation to prevent sparking due to external impact and friction
between titanium and other materials.
Thermal and electrical data
Observe the maximum ambient and product temperatures and electrical data. For further
information refer to
Ambient temperature / temperature classes / product temperature on page
11 and refer to
Surface temperature for equipment category II 2 D on page 13 and refer to
Electrical data on page 13.
CAUTION!
The manufacturer is not liable for any damage resulting from improper use or use other than the
intended purpose. This applies in particular to hazards due to insufficient corrosion resistance
and suitability of the materials in contact with product.
DANGER!
Components made of titanium in oxygen applications
Components made of titanium in oxygen applicationsComponents made of titanium in oxygen applications
Components made of titanium in oxygen applications
Variable area flowmeters with titanium components are NOT
NOTNOT
NOT suitable for use in explosion-
protected areas in conjunction with oxygen applications (products with an oxygen content which
is significantly above the oxygen content in the earth's atmosphere)!

ELECTRICAL CONNECTIONS 4
15
DK37/M8 - H250/M8
www.krohne.com05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
4.1 General notes
The built-in equipment is connected electrically in the indication unit. The circuits are designed
in protection type "intrinsically safe" and galvanically isolated from ground (test voltage
≥500 V
eff
).
The connecting cables should be selected according to the applicable installation standards
(e.g. EN 60079-14) and the maximum operating temperature.
Ensure that no residual current can form between separate intrinsically safe signal circuits.
•The connecting cables must be fixed and laid so they are sufficiently protected against
damage.
•Not used cores must be securely connected to the earth potential of the hazardous area or
carefully insulated against each other and against earth (test voltage ≥500 V
eff
).
•Lay cables so as to ensure that there is sufficient distance between surfaces of the
measuring unit and the connecting cable.
•Supplied blind plugs / cable entries guarantee protection against foreign objects and water
(protection category) IP66/67 according to EN 60529.
•The outer diameter of the connecting cable must be within the sealing range of the cable
entry (plastic PG 3...7 mm / 0.12...0.28", metal PG 6...10 mm / 0.24...0.39").
•Unused cable entries are to be closed (>IP66/67).
Ensure that the gaskets and incised gasket ring are tight.

4 ELECTRICAL CONNECTIONS
16
DK37/M8 - H250/M8
www.krohne.com 05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
Connection diagrams
4.2 Power supply
The variable area flowmeter does not require a separate power supply. The necessary power for
the built-in electrical equipment is supplied via the signal circuits.
4.3 Inputs/Outputs
The terminal assignment of the built-in electrical equipment is described in the product
documentation. The signal circuits of the variable area flowmeters may only be connected to
certified intrinsically safe slave units or circuits. For more information refer to chapter
"Electrical data".
Figure 4-1: Indicator M8M - M8MG
1 Connection Kmin
2 Connection Kmax
Figure 4-2: Indicator M8E - M8EG
1 Connection signal output 4...20 mA

ELECTRICAL CONNECTIONS 4
17
DK37/M8 - H250/M8
www.krohne.com05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
4.4 Grounding and equipotential bonding
If the device is not sufficiently electrostatically grounded via the process pipes, an additional
ground connection must be established using the ground terminal 1. The position of the ground
terminal is illustrated below. The connection only ensures an electrostatic connection of the
device and does not comply with the requirements of an equipotential bonding connection.
For the H250/../M8.G/.. designs also ensure proper fit of the mounting screws 2.
Any existing cable shields and all cores that are not used must be carefully insulated against
each other and against ground (test voltage ≥500 V
eff
) according to applicable installation
regulations (EN 60079-14).
Figure 4-3: Position of the ground terminal and the mounting screw

5 OPERATION
18
DK37/M8 - H250/M8
www.krohne.com 05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
5.1 Start-up
Start-up is only permitted when the variable area flowmeter:
•is correctly installed in the system and connected.
•has been checked for the proper state with regard to its installation and connection
requirements.
•has been properly sealed in the electronic compartment or there is no explosive atmosphere
present.
The user of the system must have it checked before start-up in compliance with the national
regulations for checks before startup.
5.2 Operation
Variable area flowmeters must be operated in such a way that they remain within the maximum
and minimum permissible temperatures and pressures and the electrical limit values.
Variable area flowmeters may only be operated if the equipment parts necessary for safety are
effective in the long run, and are not rendered inoperable during operation.
Adjusting the limit switch and operating the display during operation is permitted. To do so,
remove the housing cover. Close the housing cover immediately after the adjustment of the limit
switches or the operation of the display.
For more information refer to chapter "Dismantling".
5.3 Electrostatic charge
In order to avoid ignition hazards due to electrostatic charge, painted versions of the
variable area flowmeter DK37 M8. R.... and H250.. M8.. R..Ex may not be used in areas
where the following appear:
•processes that generate strong charges,
•mechanical friction and cutting processes,
•spraying of electrons (e.g. in the vicinity of electrostatic painting systems) or
•pneumatically conveyed dust is exposed.
WARNING!
Ignition risks caused by pressure surges, impact or friction must particularly be avoided when
titanium measuring units are used.
INFORMATION!
Versions with plastic housing are equipped with an electrostatically conductive plastic.
CAUTION!
Electrostatic charging of the housing surface by friction must be avoided. The devices must not
be dry cleaned.

SERVICE 6
19
DK37/M8 - H250/M8
www.krohne.com05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en
6.1 Maintenance
Maintenance work of a safety-relevant nature within the meaning of explosion protection may
only be carried out by the manufacturer, his authorised representative or under the supervision
of authorised inspectors.
For systems in hazardous areas, regular tests are required in order to maintain the proper
condition.
The following checks are recommended:
•Check the housing, the cable entries and the feed lines for corrosion and/or damage.
•Checking the piping connections and the measuring unit as well as the needle valve, if
necessary, for leakage.
•Include the flowmeter in the regular pressure testing of the process line.
The cover is to be closed following maintenance work on the signal converter.
6.2 Dismantling
Replacing the display
Replacing the displayReplacing the display
Replacing the display
Due to the modular design of the variable area flowmeters, from a safety perspective the
complete display can be replaced with identical spare parts.
Exchanging the entire device
Exchanging the entire deviceExchanging the entire device
Exchanging the entire device
The dismantling and installation is within the responsibility of the operator.
Exchanging and dismantling should take place in a de-energised state, if at all possible. If this is
not possible, the basic conditions for intrinsic safety (e.g. no grounding or connection of different
intrinsically safe circuits to one another) must be observed during dismantling.
CAUTION!
There may be a loss of measuring accuracy!
CAUTION!
• Pressurised pipes have to be depressurised before removing the measuring unit.
• In the case of environmentally critical or hazardous products, appropriate safety precautions
must be taken with regard to residual liquids in the measuring unit.
• New gaskets have to be used when re-installing the device in the piping.

KROHNE –Process instrumentation and measurement solutions
• Flow
• Level
• Temperature
• Pressure
• Process Analysis
• Services
Head Office KROHNE Messtechnik GmbH
Ludwig-Krohne-Str. 5
47058 Duisburg (Germany)
Tel.: [phone]
Fax: [phone]
[email protected]
© KROHNE 05/2018 - 4005351602 - AD DK37/H250/M8 II2GD R02 en - Subject to change without notice.
The current list of all KROHNE contacts and addresses can be found at:
www.krohne.com
