OPTISONIC 6300 P Technical Datasheet
Portable ultrasonic clamp-on flowmeter for liquids
•User friendly operation using a tablet or smart phone
•Quick and easy installation with a wireless web application
•Exchangeable transducers mounted in a sensor rails for fast installation and high
performance
© KROHNE 02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en

CONTENTS
2 www.krohne.com 02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
OPTISONIC 6300 P
1 Product features 3
1.1 Portable clamp-on flowmeter.......................................................................................... 3
1.2 Variants and options......................................................................................................... 5
1.3 Measuring principle.......................................................................................................... 9
2 Technical data 10
2.1 Technical data................................................................................................................. 10
2.2 Dimensions and weight .................................................................................................. 16
2.2.1 Clamp-on sensor .................................................................................................................. 16
2.2.2 Converter............................................................................................................................... 17
2.2.3 I/O box ................................................................................................................................... 18
2.2.4 Hardcase on wheels.............................................................................................................. 19
3 Installation 20
3.1 Intended use ................................................................................................................... 20
3.2 Find location and determine data .................................................................................. 20
3.2.1 Horizontal (long) pipes.......................................................................................................... 21
3.2.2 Bends in 2 or 3 dimensions................................................................................................... 21
3.2.3 T-section ............................................................................................................................... 22
3.2.4 Open feed or discharge......................................................................................................... 22
3.2.5 Down going pipeline over 5 m / 16 ft length......................................................................... 22
3.2.6 Bends .................................................................................................................................... 23
3.2.7 Position of control valve........................................................................................................ 24
3.2.8 Position of pump ................................................................................................................... 24
3.3 Start up UFC 300 P signal converter.............................................................................. 25
3.4 Step 3: Mount the sensor rails....................................................................................... 28
3.5 Connect the sensor cable............................................................................................... 31
4 Electrical connections 32
4.1 Safety instructions.......................................................................................................... 32
4.2 Power supply .................................................................................................................. 32
4.3 Connection of the signal cables ..................................................................................... 34
4.4 Connection diagrams ..................................................................................................... 35
5 Application form 40
6 Notes 42

PRODUCT FEATURES 1
3
OPTISONIC 6300 P
www.krohne.com02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
1.1 Portable clamp-on flowmeter
The new OPTISONIC 6300 P flowmeter is the portable solution for liquid flow measurements
based on the proven stationary ultrasonic technology. It combines the straightforward and easy
to install sensor rails with a portable battery-powered flow converter for 1 or 2 path
measurements.
The portable converter has full measurement functionality with an integrated data logger and
can be connected to a handheld smart device by Bluetooth or USB cable. Flexibility and ease of
use make the OPTISONIC 6300 P the ideal solution for flow measurement in various applications
and virtually all sectors of industry.
Attach the sensor unit to the tube and download/install the mobile application on your device.
Configure your measuring application by following the installation wizard. The data is saved on
your handheld device and is ready to be evaluated.

1 PRODUCT FEATURES
4
OPTISONIC 6300 P
www.krohne.com 02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
Highlights
•Sensor rails with exchangeable transducers
•Fixating units with straps or magnets
•Integrated click and turn mechanism for easy access
•User interface by handheld smart device
•Android application with installation wizard
•Real time measurement or data-logging
•Up to 16 hours battery life
•1 or 2 path measurement
•Energy measurement
Industries
•Chemicals
•Petrochemicals
•Water and wastewater
•Oil & Gas
•Semi-conductor
•Food & Beverages
•Pharmaceuticals
•HVAC
•Metal & Steel
Applications
•Process optimization
•Checking of in-line flowmeters
•Commissioning of process systems
•Checking of pump performance
•Temporary replacement of defective flowmeters
•Periodic flow capacity test hydrants
•General flow related problem solving

PRODUCT FEATURES 1
5
OPTISONIC 6300 P
www.krohne.com02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
1.2 Variants and options
The OPTISONIC 6300 P is a battery powered ultrasonic clamp-on flowmeter that can be easily
installed on the outside of piping to measure the flow rate of liquids. The OPTISONIC 6300 P is
intended for temporary flow measurement. It consists of a combination of one or two clamp-on
sensor(s) and one hand-held electronic signal converter.
The OPTISONIC 6300 P is available in several variants for different pipe sizes and measurement
setups. The equipment is delivered in a soft case or optional hardcase with 2 or 3 organiser
layers to carry and store the converter, its transducers, the mounting materials and the main
accessories.
Standard included:
•UFC 300 P signal converter
•Transducer set (s)
•Mounting materials and rail(s)
•Coupling grease
•Tape measure
•Transducer signal-check block
•Quickstart
•Casing (soft- or hardcase)

1 PRODUCT FEATURES
6
OPTISONIC 6300 P
www.krohne.com 02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
Flow sensor options
•Transducer set for small pipe sizes
DN15...DN150 / ½...6"
•Transducer set for medium pipe sizes
DN50...DN1500 / 2...60"
•Transducer set for large pipe sizes
DN200...DN4000 / 8...160")
The small and medium transducers can be
mounted in one mounting rail for pipe
diameters up to DN250 / 10". Use a second
mounting rail for bigger pipe sizes. Up to two
transducer sets can be connected to the
converter to set up a dual-path or dual pipe
measurement.
I/O connection box
The I/O connection box has to be used to wire
the available in and outputs like current
outputs, pulse output or the current inputs for
temperature measurements..
The I/O box is available in 3 variants:
•Standard I/O box
•I/O box with two temperatures transmitters
•I/O box with two temperatures transmitters
and two clamp-on temperature sensors
Energy measurement
Standard the OPTISONIC 6300 P is provided
with a measurement option for thermal
energy. This requires the input of 2
temperature measurements in addition to the
flow measurement.
Optional thickness gauge
For setting up the flow measurement
correctly, the pipe wall thickness must be
known. To measure this, a pipe wall thickness
gauge can be ordered with the
OPTISONIC 6300 P.

PRODUCT FEATURES 1
7
OPTISONIC 6300 P
www.krohne.com02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
Standard fixation units
Each mounting rail consists of two exchangeable fixation
units with a unique "click-and-turn" mechanism. The fixation
units can easily be attached to the pipe by using straps. When
the rail is installed, the "click-and-turn" mechanism allows
access to the pipe/transducer contact surface at any time.
For smaller pipe sizes up to DN250, metal straps are used.
For large pipe sizes, specially designed nylon straps are
available in lengths of 3,5 or 13,5 meters to attach the
mounting rails up to pipe diameters of DN4000/160".
Magnetic fixation units
Optionally, to attach or detach the sensor rails onto the pipe
wall, fixation units with magnets are available. This is only
possible with pipe walls that have magnetic properties (e.g.
carbon steel).
Signal cables extension set
The 3-meter long signal cables are colour coded and have to
be plugged in the signal converter during installation.
Extension cables with a length of 7 meters are optionally
available for the larger pipe diameters or when the converter
needs to be placed on a distance, further as the 3-meter
cable length.

1 PRODUCT FEATURES
8
OPTISONIC 6300 P
www.krohne.com 02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
OPTISONIC 6300 P Application
The UFC 300 P converter has to be controlled
and operated with an Android application. The
App is free available in the app store and can
be installed on an Android 10+ smart device.
Tablet
Optionally, a factory configured grade tablet
with an installed App is available, which we
have selected and tested for use outdoors. An
ideal option for users who want to start
measuring without any concerns.
Car adapter charger
Optionally, a car charger cable is available to
use or charge the converter with a 12 VDC car
socket.
USB cable
A USB cable with a 15 pins connector is
available to connect the converter hard-wired
to a hand-held smart device.

PRODUCT FEATURES 1
9
OPTISONIC 6300 P
www.krohne.com02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
1.3 Measuring principle
•Like canoes crossing a river, acoustic signals are transmitted and received along a diagonal
measuring path.
•A sound wave going downstream with the flow travels faster than a sound wave going
upstream against the flow.
•The difference in transit time is directly proportional to the mean flow velocity of the medium.
Figure 1-1: Measuring principle (example reflected path set-up)
1 Transducer A
2 Transducer B
3 Flow velocity
4 Transit time from transducer A to B
5 Transit time from transducer B to A

2 TECHNICAL DATA
10
OPTISONIC 6300 P
www.krohne.com 02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
2.1 Technical data
• The following data is provided for general applications. If you require data that is more
relevant to your specific application, please contact us or your local sales office.
• Additional information (certificates, special tools, software,...) and complete product
documentation can be downloaded free of charge from the website (Downloadcenter).
Measuring system
Measuring principle Ultrasonic transit time
Application range Flow measurement of liquids
Measured value
Primary measured value Transit time
Secondary measured value Volume flow, mass flow, flow speed, flow direction, speed of sound, gain,
signal to noise ratio, diagnosis value, reliability of flow measurement,
quality of acoustic signal, thermal energy (requires 2 x temperature
input.
Design
The measurement system consists of one or two measuring sensors and
a portable signal converter.
Signal converter
Portable housing UFC 300 P
Measuring sensor
Standard Single or dual rail sensors with 500 kHz, 1 MHz or 2 MHz transducers
Optional OPTISONIC 6300 flow sensors using cable adaptors
Normal pipe diameter ranges (recommended)
Small transducers (2 MHz) DN15...150 / ½...6" (1 rail)
Medium transducers (1 MHz) DN50...250 / 2...10" (1 rail)
DN200...1500 / 8...60" (2 rail)
Large transducers (500 kHz) DN200...4000 / 8...160" (2 rail)
Options
Outputs 0(4)...20 mA, pulse, frequency and/or status output with optional I/O box.
Inputs 0(4)...20 mA (2 x) with optional I/O box.
Counters 4 internal counters with a maximum of 8 counter places, for counting
volume, energy and/or mass units.
USB 1 x host port (Mobile device USB-C via I/O connection of
OPTISONIC 6300 P to make a connection with Android device).
Self diagnostics Integrated verification, diagnostic functions: flowmeter, process,
measured value, empty pipe detection, bar graph.

TECHNICAL DATA 2
11
OPTISONIC 6300 P
www.krohne.com02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
User interface
Operator elements and
indicators 1 on/off key with LED indication
LED indication Bluetooth connection
LED indication charging battery
LED bar graph for status of battery charge
Display functions on Android device
Menu Wizard for setup and configuration of measurements.
Support for the configuration of 2 path / 2 pipe or 2 path / 1 pipe
measurement.
Averaging, adding or subtracting of measurement results of 2 path
measurements.
Storage of measurement configurations as site file.
Maximum number of site files is 100.
Measurement data can be displayed as value or as bar or trend graph.
Thermal energy
measurement By input of 2 temperature sensors providing a temperature difference, thermal energy can be calculated.
Data logger Logging of free selectable measured and calculated values. Data storage
up to 16 GB/500 logfiles on fielddevice. Per log file, a maximum of
1.500.000 values can be stored. Display of logged data through line
graphs.
Languages
Other languages on request.
Units Metric, British and US units selectable from list / free unit.
Measuring accuracy
Reference conditions Medium: water
Temperature: 20°C / 68°F
Pressure: 1 bar/14.5 psi
Straight inlet section: 10 DN
Straight outlet section: 5 DN
Maximum measuring error DN50/2 inch
< ± 1% of the actual measured flow rate; for 0.5…20 m/s / 1.64…65.6 ft/s
< ± 5 mm/s / 0.2 inch/s for 0.1…0.5 m/s / 0.33…1.64 ft/s
< DN50/2 inch
< ± 3% of the actual measured flow rate; for 0.5…20 m/s / 1.64…65.6 ft/s
< ± 15 mm/s / 0.6 inch/s for 0.1…0.5 m/s / 0.33…1.64 ft/s
Repeatability < ± 0.2%
English, French, German, Spanish, Italian, Chinese, Czech, Polish, Dutch

2 TECHNICAL DATA
12
OPTISONIC 6300 P
www.krohne.com 02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
Operating conditions
Temperature
Process temperature Standard version: -40...+120°C / -40...+248°F
Ambient temperature Sensor: -40...+70°C / -40...+158°F
Signal converter: -10…+45°C / +14…+113°F
(Humidity: 5...80%, non condensing)
Ambient pressure Up to an altitude of 3000 meters above sea level
Ambient conditions Signal converter and sensor rails can be used in wet conditions, for
indoor and outdoor use.
Pollution degree of the intended environment PD=3
Storage temperature -30…+80°C / -22…+176°F
(Humidity: 5...80%, non condensing)
Pipe specifications
Material Metal, plastic, ceramic, asbestos cement, internal / external coated
pipes (coatings and liners fully bonded to pipe wall).
Pipe wall thickness < 200 mm / 7.87"
Liner thickness < 20 mm / 0.79"
Media properties
Physical condition Liquids
Viscosity < 200 cSt (general guideline)
For detailed information please contact your local representative.
Permissible gas content
(volume)
 2%
Permissible solid content
(volume)
 5%
Recommended flow velocity 0.1...20 m/s / 0.3 ….60 ft/s
Installation conditions
Measurement configuration Single pipe, single path
Single pipe, dual path
Dual pipe, dual path
Inlet run  10 DN straight length
Outlet run  5 DN straight length
Dimensions and weights For detailed information refer to Dimensions and weight on page 16.
Materials
Sensor Anodized aluminium (rail)
Converter Polyamide PA12, covered with TPE soft touch layer on the sides
Hardcase Polypropylene, inner material EPP
Soft case Polyester, inner material EPP

TECHNICAL DATA 2
13
OPTISONIC 6300 P
www.krohne.com02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
Electrical connections
Power supply Adaptor: charger input: 100…240 VAC (Vnom), 50...60 Hz
Adaptor: charger output: 12 VDC, 2.33 A Pmax 28 W
Flow converter power supply input: 12 VDC, 0.5 A, 6 W
During charging, the current input increases to: 1.7 A (typical).
Overvoltage category Signal converter category 1
Battery pack Charging time: ± 8 hours
Measuring operation time: ± 16 hours
Battery type: Lithium-Ion polymer (10200 mAh)
Energy density: 72.4 Wh
Weight 0.33 kg /0.72 lb
Signal cable Double braided shielded coax cables; 3 m / 9.8 ft
Optional: extension cables; 7 m / 22.9 ft
USB ports 1 x for Android device
Bluetooth 2.4 GHz, 2.5 mW integral antenna build-in
Inputs / outputs 15 pin connector for I/O interfacing with optional I/O box
Optional: PT100 input
Function: PT 100 temperature input by 2 x KROHNE TT33C temperature
transmitters build into an I/O box
For specifications see TT33C data sheet.
Optional: temperature input
Function: temperature input by 2 x KROHNE TSR-W 30 clamp-on
temperature sensors only in combination with I/O box with temperature
transmitters.
For specifications see TSR-W 30 data sheet.
Inputs and outputs
Connections Inputs and outputs can only be connected using the optional I/O box.
Description of used
abbreviations Uext = external voltage/RL = load resistance/Uo = terminal voltage/Inom =
nominal current
Current output
Isolation The output is not galvanically isolated from the other circuits.
The - current out is connected to the metal connection panel and the
connector shielding of the sensor.
Output data All analog measurement parameters like volume and mass flow (at
constant density), flow speed, speed of sound, gain, signal to noise ratio,
reliability of flow measurement, quality of acoustic signal, thermal
energy (requires input of temperature (2 x)).
Settings Q = 0%: 0…20 mA; Q = 100%: 10…21.5 mA
Error identification: 0…22 mA
Operating data
Active Uint,nom = 15 VDC
I  22 mA
RL  1 k
Passive Uext 32 VDC
I  22 mA
U0  1.8 V at I = 22 mA
RL  (Uext - U0) / Imax

2 TECHNICAL DATA
14
OPTISONIC 6300 P
www.krohne.com 02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
Pulse or frequency output
Isolation The output is galvanically isolated from the other circuits.
Output data For pulse counting and/or analog output: Volume flow, mass flow,
thermal energy (requires input of temperature (2 x)
As analog output: Flow speed, speed of sound, gain, signal to noise ratio,
reliability of flow measurement, quality of acoustic signal
Function Can be set as a pulse output or frequency output
Settings For Q = 100%: 0.01...10000 pulses per second or pulses per unit volume
Pulse width: setting automatic, symmetric or fixed (0.05...2000 ms)
Operating data
Active Unom = 15 VDC
fmax  100 Hz:
I  20 mA
open:
I  0.05 mA
closed:
U0,nom = 15 V at I = 20 mA
100 Hz < fmax  10 kHz:
I  20 mA
open:
I  0.05 mA
closed:
U0,nom = 13.5 V at I = 1 mA
U0,nom = 12.5 V at I = 10 mA
U0,nom = 9 V at I = 20 mA
Passive Uext 32 VDC
fmax  100 Hz:
I  100 mA
open:
I  0.05 mA at Uext = 32 VDC
closed:
U0, max = 0.2 V at I 10 mA
U0, max = 2 V at I 100 mA
100 Hz < fmax  10 kHz:
I  20 mA
open:
I  0.05 mA at Uext = 32 VDC
closed:
U0, max = 1.5 V at I 1 mA
U0, max = 2.5 V at I 10 mA
U0, max = 5.0 V at I 20 mA

TECHNICAL DATA 2
15
OPTISONIC 6300 P
www.krohne.com02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
Status output
Isolation The output is galvanically isolated from the other circuits.
Function and settings Settable as automatic measuring range change, indicator for direction of
flow, overflow, error, operating point or empty pipe detection
Status and/or control: ON or OFF
Operating data
Active Uint = 15 VDC
I  20 mA
open:
I  0.05 mA
closed:
U0, nom = 15 V at I = 20 mA
Passive Uext  32 VDC
I  100 mA
open:
I  0.05 mA at Uext = 32 VDC
closed:
U0, max = 0.2 V at I 10 mA
U0, max = 2 V at I 100 mA
Current inputs
Isolation The inputs are not galvanically isolated from the other circuits.
Function Input of temperature, used for energy calculation in combination with
flow measurement
Range: -50...500°C / -58...932°F (default: 0...120°C / -32...248°F)
Operating data
Active Uint = 15 VDC
I  22 mA
Imax = 26 mA (electronically limited)
U0, min = 19 V with I  22 mA
No HART®
Passive Uext  32 VDC
I  22 mA
Imax = 26 mA (electronically limited)
U0, max = 5 V with I  22 mA
No HART®
Approvals and certificates
CE
This device fulfils the statutory requirements of the relevant directives. The manufacturer certifies
successful testing of the product by applying the conformity mark on the device.
For more information on the directives, standards and the approved
certifications, please refer to the declaration of conformity supplied with
the device or downloadable from the manufacturer’s website.
Other approvals and standards
Protection category according
to IEC 60529 Sensor: IP66/67
Converter: IP65
Hardcase on wheels: IP67
Power adaptor: IP40, NEMA 1
Shock resistance IEC 60068-2-27
30 g for 18 ms
Vibration resistance IEC 60068-2-64
1 g up to 2000 Hz

2 TECHNICAL DATA
16
OPTISONIC 6300 P
www.krohne.com 02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
2.2 Dimensions and weight
2.2.1 Clamp-on sensor
Version Dimensions [mm] Approx. weight
[kg]
L H W
V1 406 76 39.2 2.1 1
V2 406 81.5 42.7 2.2 1
1with transducers / cable, without mounting strap
Version Dimensions [inches] Approx. weight
[lb]
L H W
V1 16.0 3.0 1.54 4.6 1
V2 16.0 3.2 1.68 4.8 1
1with transducers / cable, without mounting strap

TECHNICAL DATA 2
17
OPTISONIC 6300 P
www.krohne.com02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
2.2.2 Converter
Dimensions UFC 300 P converter
Dimensions [mm] Approx. weight
[kg]
a b c d
247 289 168 66 1.5
Dimensions [inch] Approx. weight
[lb]
a b c d
9.7 11.4 6.6 2.6 3.3

2 TECHNICAL DATA
18
OPTISONIC 6300 P
www.krohne.com 02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
2.2.3 I/O box
Dimensions I/O box
Dimensions [mm] Approx. weight [kg]
a b c
112.5 84.6 44 0.34
Dimensions [inch] Approx. weight [lb]
a b c
4.4 3.3 1.7 0.75
a
b
b
c

TECHNICAL DATA 2
19
OPTISONIC 6300 P
www.krohne.com02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
2.2.4 Hardcase on wheels
Dimensions hardcase on wheels
Dimensions softcase
Dimensions [mm] Approx. weight [kg]
a b c
521 394 254 6.4
Dimensions [inch] Approx. weight [lb]
a b c
20.5 15.5 10 14.1
Dimensions [mm] Approx. weight [kg]
a b c
530 400 160 1.7
Dimensions [inch] Approx. weight [lb]
a b c
20.9 15.8 6.3 3.8

3 INSTALLATION
20
OPTISONIC 6300 P
www.krohne.com 02/2022 - 4000950304 - TD OPTISONIC 6300 P R04 en
3.1 Intended use
The OPTISONIC 6300 P portable clamp-on flow meter is specially designed for temporary liquid
flow measurement in full pipe systems. The measurement system consists of transducers
mounted in a sensor rail and a battery-powered portable converter and data logger. The system
is controlled by a KROHNE Clamp-on APP installed on a smart device.
The OPTISONIC 6300 P is meant to be used temporarily for liquid flow and energy measurement.
For example, the measured and calculated flow data is usable in process optimization, collecting
additional process data, comparing flow data with existing flowmeters, verifying other
flowmeters or flowmeter replacement during maintenance.
3.2 Find location and determine data
Finding transducer location:
The two most common ways to find the exact location are with the use of a fixed reference point
or determination of transducer position with the use of a paper/plastic material roll. Both
options are described in the manual.
Inlet, outlet and recommended mounting area
To perform an accurate flow measurement preferably mount the sensor rail at least 10 DN
downstream of a flow disturbance like elbows, valves, headers or pumps. Follow the given
installation recommendations.
Responsibility for the use of the measuring devices with regard to suitability, intended use and
corrosion resistance of the used materials against the measured fluid lies solely with the
operator.
The manufacturer is not liable for any damage resulting from improper use or use for other than
the intended purpose.
Figure 3-1: Inlet, outlet and recommended mounting area
1 Min. 10 DN
2 Min. 5 DN
3 Recommended installation location (120°)
Make sure that the rail is not mounted at the highest point (risk for air bubbles) or at the lowest
point (risk for particles) of the pipe.
