KSB SICCA GTC Series User manual

SICCA
Point no. Description Page no.
1 Declaration of conformity 1
2 General 2
3 Safety 2
3.1 Safety symbols in this operating
instructions 2
3.2 Qualicationofpersonnel&training 2
3.3 Danger or nonobservance of the safety 2
instructions
3.4 Safety consciousness 3
3.5 Safety instructions for the user/operator 3
3.6 Safety instructions for maintenance,
 inspection&installationwork 3
3.7 Unauthorisedmodication
and manufacturing of spare parts 3
3.8 Inadmissible modes of operation 3
4 Transport & interim storage 3
4.1 Transport 3
4.2 Interim storage 3
5 Description / related documents 3
5.1 MarkingforCErequirements 3
5.2 Design standards / related documents 3
5.2.1 CastGate,Globe,Checkvalves-Design 3
5.3 Sectionaldrawing&functionalprinciple 4
5.3.1 Sectionaldrawing-Gatevalve 4
5.3.2 Gatevalves(class900,1500,2500) 4
5.3.3 Gatevalves(class150,300,600) 4
5.3.4 Sectionaldrawing-GlobeValve 5
5.3.5 Globevalves(class900,1500,2500) 5
5.3.6 Globevalves(class150,300,600) 5
5.3.7 Sectionaldrawing-Checkvalve 6
5.3.8 Checkvalves
 (class900,1500,2500,3100,3600) 6
5.3.9 Checkvalves(class150,300,600) 6
5.3.10 ForgedGate,Globe&Checkvalves 7
5.3.11 ForgedGate,Globe,&Checkvalves 7
 (class800,1500,2500,4500)
Operating Instructions
0500.80/08-18G3
SICCA 150-600
types GTC, GLC, SCC
SICCA 800-4500
types GTF, GLF, PCF
SICCA 900-3600
types GTC, GLC, SCC
Point no. Description Page no.
5.3.12 Sectionaldrawing-Gatevalve 8
5.3.13 Gatevalves(class3100,3600) 9
5.3.14 Sectionaldrawing-ForgedGlobe&
 Checkvalves(class4500) 9
5.3.15 Forged,GlobeandCheckvalves(class4500) 9
6 Installation9
6.1 General 9
6.2 Installationposition 10
6.2.1 Gatevalves 10
6.2.2 Globevalves 10
6.2.3 Checkvalves 10
6.3 Pressuresealdesign 10
6.4 Weldinginstructions/installationofpipe 10
6.5 Actuatedvalves 10
6.6 Bodysafetyarrangement 10
7 Commissioning / Decommissioning 13
7.1 Commissioning 13
7.1.1 General 13
7.1.2 Operation 13
7.1.3 FunctionalCheck 13
7.1.4 Actuated valves 13
7.2 Decommissioning 13
8 Maintenance / Repair 13
8.1 Safety Instructions 13
8.1.1 Dismantling of valves 13
8.1.2 Removing Actuators 14
8.2 Maintenance 14
9 Troubleshooting 14
9.1 General 14
9.2 Faults&Remedies 14
10 Valve weights 15-18
Annexure I - Do’s & Don’ts 19-20
Annexure II - Environment Protection 21
- Product Disposal after useful life.

SICCA
1 Declaration of conformity
We,
KSB Limited,
151, Mettupalayam Road, NSN Palayam Road, Coimbatore 641 031. INDIA
 Regd.ofce:126,MakerChambersIII,NarimanPoint,Mumbai400021.INDIA
declarethatthevalveslistedbelowcomplywiththerequirementsofthePressureEquipmentDirective2014/68/EU.
Descriptionofthevalve-Type GTF,GLF,PCF:Class800upto4500-1/2”-2”
 GTC,SCC:Class150upto3600-2”-28”
 GLC:Class150upto2500-2”-10”
Suitablefor Fluidgroup1and2
ConformityAssessmentprocedure ModuleH
Nameandaddressofthe TUVNORDSystemsGMBH&Co.KG
authorizingandmonitoringnotied GroßeBahnstraße31,
body D-22525Hamburg,Germany
Notiedbodyidenticationno. 0045
Certicateno.* 07/202/9070/Z/1228/15/D/
Referencestandardsandcodes ASMEB16.34,API598,ASTM/ASME,API600,API602
 BS1873,BS1868,EN12516-1,EN12516-2
Valveswithanominalpipesizebelowandincluding1”complywithPressureEquipmentDirective2014/68/EUArt.4.3(SOUND
ENGINEERINGPRACTICE).TheyneednotbeareithertheCEnameplateortheidenticationnumberofthenotiedbody.
S.P.Sankaran        M.Subramaniam
Head - Quality Assurance Head - Product Management
(Thisdocumentwaspreparedelectronicallyandisvalidwithoutsignature).
Place:CoimbatoreDate:07February,2019
*Latestreferenceincaseofre-validation
1

SICCA
2 General
TheseoperatinginstructionsapplytoKSB–Gate,Globeand
Checkvalves(seesection4.1,4.2).
DevelopmentandproductionofKSBvalvesaresubjecttoa
QAsystemaccordingtoDN/ISO9001.
Correct installation and maintenance or repair will ensure
trouble free operation of the valves.
The manufacturer does not assume any liability for these valves
if the operating instructions are not being observed.
The valves are marked to ASME B16.34 if
required with an arrow indicating the flow
direction,Nominalsize,Class,materialofbody,
manufacturer.
The valves must not be operated beyond the limits dened
in the operating instructions/contractual documentation/type
seriesbooklet.Anyusebeyondtheaboveconditionswilllead
tooverloadwhichthevalvescannotwithstand.
Nonobservanceofthiswarningmayleadtopersonal
injuryorpropertydamage,e.g.:
- Injury caused by escaping fluids (cold/hot, toxic or under
pressure…)
- Incorrectoperationordestructionofthevalve.
The descriptions and instructions in this manual refer to the
standard versions but also apply to the related variants.
Theseoperatinginstructionsdonotconsider:
- incidentswhichmayoccurduringinstallation,operationand
maintenance.
- thelocalsafetyregulations.Itistheuser’sresponsibilityto
ensure that they are observed, also by the installation staff
involved.
Foractuatedvalves,thespeciedconnectionparametersand
theinstallation andmaintenanceinstructions–includingthe
operatingmanualfortheactuator–mustbeobserved.
Handling a valve requires skilled and
experiencedpersonnel.
The personnel in charge of operation, maintenance and
installation of this valve must be aware of the interaction
betweenthevalveandtheplant.
Operator’s errors concerning the valve may have serious
consequencesfortheentireplant,e.g.:
- fluidmayescape
- downtimeoftheplant/machine
- adverseeffect/reduction/increaseoftheefciency/function
of a plant/machine.
Forfurtherquestionsorincaseofdamagetothevalve,please
contactyourKSBSalesOfce.
For further questions and supplementary orders, especially
whenorderingspareparts,pleasealwaysstatethetypeseries,
versionandserialno.(SerialNo.ispunchedattopflangeof
thevalveonKSBletterside).
Thespecications(operatingdata)ofthevalvesarelistedin
thetechnicaldocumentation&typeseriesbookletoftherelated
valve(seealsosection5).
When returning valves to the manufacturer, please refer to
section 4.
3 Safety
Thismanualcontains basicinstructionsto becompliedwith
during operation and maintenance. It is therefore vital for the
tterandtheoperator/usertoreadthismanualbeforeinstalling/
commissioningthevalve.Also,thismanualmustalwaysbe
availableatthesitewherethevalveisinstalled.
It is not enough to observe the general instructions listed in
thesection“safety”,thespecicsafetyinstructionslistedinthe
other sections should also be observed.
3.1 Safety symbols in this operating Instructions
Safetyinstructionsputforthinthisinstructionmanualwhose
nonobservancewouldinvolve theriskof personalinjuryare
speciallymarkedwiththegeneralhazardsymbol:
in accordance with DIN 4844 (safety sign W9), or with the
electricvoltagewarningsign:
InaccordancewithDIN4844(safetysignW8),
Safetyinstructionswhosenonobservancewouldinvolvehazard
tothevalveandjeopardize itsoperationhavebeenmarked
withtheword
Instructions directly attached to the valve, (e.g. nominal
pressure)mustbecompliedwithandmaintainedinalegible
condition.
3.2 Qualicationofpersonnelandtraining
The personnel for operation, maintenance, Inspection and
Installationmustbeadequatelyqualiedfortheworkinvolved.
Thepersonnel’sresponsibilities,competenceandsupervision
must be clearly defined by the user. If the personnel in
questionisnot alreadyinpossession oftherequisiteknow-
how,appropriatetrainingandinstructionsmustbeprovided.
Ifdeemednecessary,the manufacturer/supplier will provide
suchtrainingandinstructionsattheuser’srequest.Inaddition,
the user is responsible for ensuring that the contents of these
operating instructions are fully understood by the personnel
inquestion.
3.3 Danger or nonobservance of the safety
instructions
Nonobservance of the safety instructions may lead to personal
injuryand alsotodangerforthe environmentandthevalve
itself.  Nonobservance of these safety instructions will also
forfeittheuser’swarranty.
Suchnoncompliancecould,forexample,resultin:
- failureofessentialfunctionsofthevalve/plant
- failureofprescribedmaintenanceandrepairpractices
- hazardtopeoplebyelectrical,mechanicalorchemicaleffects
- hazard to the environment due to leakage of hazardous
substances
ATTENTION
ATTENTION
ATTENTION
2

SICCA
3.4 Safety consciousness
The safety instructions contained in this manual, the applicable
nationalaccidentpreventionregulationsandanyoftheuser’s
ownapplicableinternalwork,operationorsafetyinstructions
mustbefullycompliedwith.
3.5 Safety instructions for the user/operator
Anyhotorcoldpartsofthevalve(e.g.bodyorhandwheel)that
could pose a hazard must be protected by the user against
accidental contact.
Leakage(e.g.atthestemseal)ofhazardoussubstances(e.g.
explosive,toxic,hot)mustbedrainedsoastoavoidalldangerto
peopleortheenvironment.Allrelevantlawsmustbeobserved.
Electricalhazardsmustbeeffectivelyprevented.(Fordetails,
please refer to the VDE standards and/or the local energy
supplyutilityregulations).
3.6 Safety instructions for maintenance,
 inspectionandinstallationwork
The user is responsible for ensuring that all maintenance,
inspectionandinstallationworkiscarriedoutbyauthorized,
adequatelyqualiedstaffwhoarethoroughlyfamiliarwiththis
instruction manual.
Allworkonavalvemayonlybeperformed when the valve
isun-pressurizedandhascooleddown.Thismeansthatthe
temperatureofthemediuminallthevalve’schambersmustbe
lowerthanthevaporizationpointofthemedium.
Allworkonactuatedvalvesmayonlybedoneaftertheactuator
has been disconnected from its energy supply. The procedure
describedintheoperatinginstructionstoshutdowntheactuator
must be observed.
Valvesincontactwithhazardousmediamustbedecontaminated.
Immediatelyfollowingcompletionofthework,allsafetyrelevant
andprotectivedevicesmustbereinstalledand/orre-enabled.
Prior to recommissioning, refer to the points listed under section
6,Commissioning.
3.7 Unauthorisedmodicationand 
manufacturing of spare parts
The equipment shall not be altered or modied in any way
prior to consultation with the manufacturer. Genuine spare
parts and accessories authorized by the manufacturer will
ensure operational safety. The manufacturer cannot be held
responsiblefordamageresultingfromtheuseofnon-genuine
parts or accessories.
3.8 Inadmissible modes of operation
Operational safety and reliability of the valve supplied is
only warranted for its designated use as dened in section
1“General”oftheoperatinginstructions.Thelimitsstatedin
thetechnicaldocumentationmustnotbeexceededunderany
circumstances.
Class PN <1” 1¼” 1½” 2” 2½” 3” 4” 5” 6” 8”
<25 32 40 50 65 80 100 125 150 >200
150 10
16
>300 25     
>40
5.2 Design standards / related documents
5.2.1 CastGate,GlobeandCheckValves-Design
Allcastvalveshavebeendesignedaccordingtothefollowing
standardsandspecications:
ASMEB16.34,API600,BS1873,BS1868
GateGTC150-600 : API600
GateGTC900-3600 : ASMEB16.34
GateGTF800-1500 : API602
GateGTF2500 : ASMEB16.34
GlobeGLC150-600 : BS1873
GlobeGLC900-2500 : ASMEB16.34
GlobeGLF800-1500 : API602
GlobeGLF2500-4500 : ASMEB16.34
CheckSCC150-600 : BS1868
CheckSCC900-3600 : ASMEB16.34
CheckPCF800-1500 : API602
CheckPCF2500-4500 : ASMEB16.34
Pr.Temperaturerating :ASMEB16.34/API602
ATTENTION
3
4 Transport & interim storage
4.1 Transport
Thevalvesintheas-suppliedconditionarereadyforoperation.
For transport and storage, the valves must always be
maintained in the closed position and the connection ends must
bepluggedusingsuitablemeans(e.g.covers,plasticsheets,
etc.)topreventdamagetotheseats.
To prevent damage, do not suspend the valve
byitshandwheelortheactuator.
Forvalveweights,pleaserefertoSection10.
Afterdeliveryorpriortoinstallation,thevalveshouldbechecked
for damage during transit.
4.2 Interim storage
Thevalvesmustbestoredinsuchawaythatcorrectoperation
isassuredevenafterprolongedstorage.Thiscomprises:
- Storing in the closed position (to protect the seats from
damage).
-Suitablemeasuresagainstcontamination,frostandcorrosion
(e.g.byusingplasticsheetsorendcovers).
5 Description / related documents
Thesectionaldrawingsshown on page no.3areexamples
forthegeneraldesignofourvalves.Fordrawingsandother
informationpertainingtoaspecicvalveseries,pleaserefer
totherelevanttypeseriesbooklet.
5.1 Marking-forCErequirements
ThevalvesaremarkedtoPED2014/68/EU
Inparticularthemarkingcontainsatleastfollowing
- Manufacturer
- Yearofproduction
- Valvestypemodelororderno.
- NPS(DN)/(Inch)
- Pressureclass

SICCA
5.3 Sectional drawing & functioning principle
5.3.1 Sectional drawing - Gate Valve
5.3.2 Gate valves (Class 900, 1500, 2500)
Thevalveconsistsmainlyofbody(100),bonnet(162),yoke
(139)aswellaswedgeandstem(200)andtheactuatingunit.
Stem seal area : The gland packing (461) which seals the
stem(200)istightenedbythestuds(902.2)andnuts(920.2)
ontheglandflange(452).Thebonnet(166)isequippedwith
anintegral,hardfacedbackseat,whichsealsthevalvewhile
stem is in upmost position.
Flow seal area:Theseatrings(515)aresealweldedintothe
body(100).Thewedgeunitconsistsoftwohardfaceddiscs
(350)whichcanpivotonthedischolder(367).Thediscsare
supported by replaceable thrust inserts held by a pin. The discs
are secured from turning by a retaining element at the bottom
ofthestem(200).Thedoublediscwedgeunitisscrewedon
thestem(200)andguidedbylateralrailsinthebody(100).
Bonnet seal area:Thevalveisequippedwithapressureseal
bonnet.Thebonnet(166)ispressedagainstthegasket(411)by
thepressureinthevalvebody(100).Thegasketissupported
bythespacerring(500)andthesegmentalthrustring(501)
whichisseatedinagrooveofthebody(100).Thegasketis
precompressedbetweendiscthrustplateandbonnet(166)by
meansofthestuds(902.1)andnuts(920.1).
GTC 900-2500 GTC 150-600
4
5.3.3 Gate valves (Class 150, 300, 600)
Thevalveconsistsmainlyofbody(100),bonnet(166)aswell
aswedge(361)andstem(200)andtheactuatingunit.
Stem seal area : The gland packing (461) which seals the
stem(200)istightenedbyglandbolts(900)andnuts(920.2)
ontheglandflange(452).Thebonnet(166)isequippedwith
abackseatbushing(450)whichsealsthevalvewhilestemis
in upmost position.
Flow seal area :Thehardfacedseatrings(515)arewelded
intothebody(100).Thesealfacesoftheflexiblewedge(361)
are hard faced. The wedge (361) is connected to the stem
(200)bya“T”joint.Thewedgeisguidedbylateralrailsinthe
body(100).
Bonnet seal area:Body(100)andbonnet(166)areconnected
toeachotherbystuds(902)andnuts(920.1).Tightnessis
assuredbymeansofthegasket(411).
Type Size Class Type leaflet no.
GTC150-600 2”-24” 150-600 7244.1/02-EN
GTC900-3600 2”-28” 900-3600 7241.1/02-EN
Related documents
162
 100 Body
 139 Bonnet
 162 Yoke
 162 Bonnet(L.P.)
 196 Lockingplate(Locknut)
 200 Spindle/Stem
324 Thrust Bearing
334 Bearing cover /
Adapter plate
334 Bearing cover /
Bearing retainer
361 Wedge
Part no. Name Part no. NamePart no. Name Part no. Name
367 Disc holder
 411 Gasket
 450 BackSeatBush
 452 Glandflange
 456 Glandbush
 457 Neckring
 461 Mouldedglandpacking
 461 Braidedglandpacking
 501 Thrustring
 504 Spacerring
 508 Wedgeretainingring
514 Bonnet bush
515 Seat ring
544 Stem nut / Threaded bush
 550 Disc
553 Thrust plug / Thrust insert
 560 Pin(Discholder)
 563 Pin(Thrustinsert)
583 Supporting plate /
Bonnet retainer
 636 Greasenipple
 901 Hex.screw
 902.1 Stud-1
 902.2 Stud-2
 904 Grubscrew
 914 Socketheadcapscrew
 920.1 Nut-1
 920.2 Nut-2
 921 Shaftnut/
  Handwheelnut
 926 Spindleheadnut
  (Stemstopnut)
 940 Key
 961 Handwheel
501
411
324
515

SICCA
5.3.4 Sectional Drawing - Globe valve
5.3.5 Globe valves (class 900, 1500, 2500)
Thevalveconsistsmainlyofbody(100)bonnet(166),yoke
(139)aswellasdisc(350)andstem(200)andtheactuating
unit.
Stem seal area : The gland packing (461) which seals the
stem(200)is tightenedbythe studs(902)andnuts (920.2)
ontheglandflange(452).Thebonnet(166)isequippedwith
anintegral,hardfacedbackseat,whichsealsthevalvewhile
stem is in upmost position.
Flow seal area:Theseatrings(515)aresealweldedintothe
body(100).Thesealfaceofthetapereddisc(350)and the
seat ring are hard faced.
Bonnet seal area:Thevalveisequippedwithapressureseal
bonnet.Thebonnet(166)ispressedagainstthegasket(411)by
thepressureinthevalvebody(100).Thegasketissupported
bythespacerring(500)andthesegmentalthrustring(501)
whichisseatedinagrooveofthebody(100).Thegasketis
precompressedbetweendiscthrustplateandbonnet(166)by
meansofthestuds(902.1)andnuts(920.1)
5
5.3.6 Globe valves (class 150, 300, 600)
Thevalveconsistsmainlyofbody(100),bonnet(166)aswell
asdisc(350)andstem(200)andtheactuatingunit.
Stem seal area : The gland packing (461) which seals the
stem(200)istightenedbyglandbolts(900)andnuts(920.2)
ontheglandflange(452).Thebonnet(166)isequippedwith
abackseatbushing(450),whichsealsthevalvewhilestem
is in upmost position.
Flow seal area:Thehardfacedseatring(515)isweldedinto
thebody(100).Theseatfaceoftheflatdiscishardfaced.
Bonnet seal area:Body(100)andbonnet(166)areconnected
toeachotherbystuds(902)andnuts(920.1).Tightnessis
assuredbymeansofthegasket(411).
GLC 150-600GLC 900-2500
Type Size Class Typeleafletno.
GLC150-600 2”-10” 150-600 7245.1/02-EN
GLC900-2500 2”-8” 900-2500 7242.1/02-EN
Related documents
162
Part no. Name
100 Body
139 Bonnet
162 Yoke
162 Bonnet(L.P.)
196 Locknut
200 Stem
324 Thrust Bearing
334 Bearing retainer /
Retainer plate
350 Disc
411 Gasket
411 SWGasket
414 Disc thrust plate
450 BackseatBush
Part no. Name
452 Glandflange
456 Glandbush
457 Neckring
461 Braided /
 Mouldedglandpacking
501 Thrust/Splitring
504 Spacerring
505 Stemcoller
514 Bonnet bush
515 Seat ring
544 Stem nut /
Threaded bush
550 Disc
553 Disc thrust pad
561 Pin
579 Stemlock
583 Retaining plate /
Bonnet retainer
636 Greasenipple
734 Disc retainer
900 Glandbilt
901 Hex.screw-1
902.0 Stud-1
904 Grubscrew
914 Socketheadcapscrew
920.1 Nut-1
920.2 Nut-2
921 Shaftnut/Handwheelnut
Part no. Name
940.1 Key-1
940.2 Key-2
961 Handwheel
Part no. Name
501
324
411
515

SICCA
5.3.7 SectionalDrawing-Checkvalve
6
SCC 150 - 600
5.3.9 Checkvalves(Class150,300,600)
Thevalveconsistsmainlyofbody(100),cover(160)aswell
asthedisc(350).
Flow seal area:Thehardfacedseatring(515)isweldedinto
thebody(100).Thedisc(350)ishardfaced.Itisconnected
toaDiscCarrier(570)bymeansofanut(920.2)andpin.The
swingingleverismountedtothebodybymeansofaninside
hingepin(563).
Bonnet seat area:Body(100)andcover(160)areconnected
toeachotherbystuds(902)andnuts(920.1).Tightnessis
assuredbymeansofagasket(411).
5.3.8 CheckValves
 (class900,1500,2500,3100,3600)
Thevalveconsistsmainlyofbody(100),bonnet(139)aswell
asthedisc(350).
Flow seal area:Theseatring(515)issealweldedintothe
body(100).Thesealingfacesofthedisc(350)andtheseat
ring(515)arehardfaced.Thediscisconnectedwithadisc
carrierbymeansofanut(920.2)andacotterpin(933).Thedisc
carrierismountedtothebodybymeansofahingepin(563).
Bonnet seal area : The valve is equipped with a pressure
sealbonnet.Thebonnet(139)ispressedagainstthegasket
(411)bythepressureinthevalvebody(100).Thegasketis
supportedbythespacerring(500)andthesegmentthrustring
(501)whichisseatedinagrooveonthebody(100).Thestuds
(902.1)andthehex.nut(920.1)whicharesupportedbythe
retainer(734)holdthebonnet(139)againstthegasket(411)
evenwhenthereisnopressureinthebody(100).
SCC 900-3600
Type Size Class Type leaflet no.
SCC150-600 2”-24” 150-600 7246.1/02-EN
SCC900-3600 2”-28” 900-3600 7243.1/02-EN
Related documents
100 Body
139 Bonnet
160 Cover
190 Parallelpin
194 Hingebracket
350 Disc
411 Gasket
411 SWgasket
501 Thrustring
504 Spacerring
515 Seat ring
550 Disc
554 Washer
570 Disccarrier
Part no. Name Part no. Name
563 Hingepin
577 Disc carrier
583 Bonnet retainer
901 Hex.screw
902.1 Stud-1
902.2 Stud-2
920.1 Hex.nut-1
920.2 Hex.nut-2
920.3 Hex.nut-3
933 Splitpin
515
501
411

SICCA
5.3.11ForgedGate,GlobeandCheckvalves
(class 800, 1500, 2500)
Allforgedvalveshavebeendesignedaccordingtothefollowing
standardsandspecications:ASMEB16.34.API602.
Forgedvalvesmainlyconsistofbody,bonnetandtheclosing
aswellastheactuatingunit(onlygateandglobevalves).
Stem seal area:Theglandpackingofgateandglobevalves
whichsealsthestemistightenedbythestudsandnutsonthe
gland flange. The bonnet is equipped with an integral back
seat,whichseatsthevalvewhenstemisinupmostposition.
GTF 800-2500 GLF 800-2500 PCF 800-2500
5.3.10 TypicalSectionalDrawing-ForgedGate,Globe&Checkvalves
7
Related documents
Type Size Class Type leaflet no.
GTF 1/4”-2” 800-2500 7235.1/04-EN
GLF 1/4”-2” 800-4500 7236.1/02-EN
PCF 1/4”-2” 800-4500 7237.1/02-EN
165
165
100 Body
160 Cover
165 Bonnet
200 Stem
350 Disc(GLF)
351 Disc(PCF)
360 Wedge
411 SWGasket
452 GlandFlange
456 GlandBush
457 Packingring
Part no. Name
461 GlandPacking
515 Seat Ring
544 Stem Nut
901 HexBolt
902 Stud
920 Hex.Nut
921 HandWheelNut
931 Washer
950 Spring
961 Handwheel
Part no. Name
Flow seal area : The hard faced seat rings of gate valves
areswaggedintothebody.Thesolidwedgeisconnectedto
thestembya“T”joint.Theintegralsealfacesofthebody
ofglobeandcheckvalvesarehardfaced.Theturningdiscof
globevalvesisconnectedtothestembycaulkingorT-slot
discaccordingtorespectivepressureclass.Thediscofcheck
valves is spring loaded.
Bonnet seal area:The bonnet/yokeofclass 800 valvesis
boltedtothebody.Inthecaseofclass1500&2500thebonnet
isthreadedandsealweldedtothebody.
‘T’SlotType
Stem-Disc
Connection
for1500-2500GLF
200
350
515

SICCA
5.3.12 Sectional Drawing - Gate valve
100 Body
139 Bonnet*
200 Stem
367 Disc holder
411 Gasket
452 Glandflange
456 Glandbush
457 Packingring
 (Neckring)
461 Glandpacking
501 Thrustring
500 Splitring
504 Spacerring
508 Wedgeretainingring
515 Seat ring
550 Disc**
553 Thrust plug
 (Thrustinsert)
560 Pin(Discholder)
Part no. Name Part no. Name
563 Pin(Thrustinsert)
583 Bonnet retainer
583.1 Retaining ring
900 Tierod
902.1 Stud-1
 (Glandflange)
904 Grubscrew
914.1 Socketheadcapscrew
 (Retainingring)
914.2 Socketheadcapscrew
 (Tierod)
920.1 Hex.nut-1
 (Glandflange)
920.2 Hex.nut-2
 (Retainingplate)
926 Stemstopnut
729 Topplate
870 GearBox
Related documents
Type Size Class Type leaflet no.
GTC900-3600 2”-28” 900-3600 7241.1/02-EN
5.3.13 Gate valves (class 3100, 3600)
Thevalveconsistsmainlyofbody(100),bonnet(139),tierods
(900),aswellaswedgeandstem(200)andtheactuatingunit.
Steam seal area : The gland packing (461) which seal the
stem(200)istightenedbythestuds(902)andnuts(920)on
theglandflange(452).Thebonnet(139)isequippedwithan
integral,hardfacedbackseat,whichsealsthevalvewhilestem
is in upmost position.
Flow seal area:Theseatrings(515)aresealweldedintothe
body(100).Thewedgeunitconsistsoftwohardfaceddiscs
(550)whichcanpivotonthedischolder(367).Thediscsare
supported by replaceable thrust inserts held by a pin. The discs
are secured from turning by a retaining element at the bottom
onthestem(200).Thedoublediscwedgeunitisscrewedon
thestem(200)andguidedbylateralrailsinthebody(100).
Bonnet seal area:Thevalveisequippedwithapressureseal
bonnet.Thebonnet(139)ispressedagainstthegasket(411)by
thepressureinthevalvebody(100).Thegasketissupported
bythespacerring(504)andthesegmentalthrustring(501)
whichisseatedinagrooveofthebody(100).Thegasketis
precompressedbetweendiscthrustplateandbonnet(139)by
meansofthestuds(902)andnuts(920).
GTC 3100-3600
8
367
515
550
100
508
904
139
504
457
583.1
461
900
914.2
729
200
902
920
452
914.1
500
583
501
411
563
553
870
456
GEAR BOX

SICCA
5.3.14 SectionalDrawing-Forged,Globe&Checkvalves
GLF 4500 PCF 4500
165
360
324
Related documents
Type Size Class Type leaflet no.
GLF 1/4”-2” 800-4500 7236.1/02-EN
PCF 1/4”-2” 800-4500 7237.1/02-EN
100 Body
165 Bonnet
200 Stem
324 Thrust bearing
360 Disc
452 Glandflange
456 Glandbush
461 Glandpacking
514 Threaded ring
515 Seat Ring
544 Stem nut
Part no. Name Part no. Name
561 Groovedpin
579 Stop
902 Stud(Glandflange)
920 Hex.nut(Glandflange)
940 Key
961 Handwheel
100 Body
160 Cover
351 Disc
515 Seat Ring
950 Spring
Part no. Name
5.3.15Forged,GlobeandCheckvalves
(class 4500)
Allforgedvalveshavebeendesignedaccordingtothefollowing
standardsandspecications:ASMEB16.34.
Forgedvalvesmainlyconsistofbody,bonnetandtheclosing
aswellastheactuatingunit(onlyglobevalve).
Stem seal area :Theglandpackingofglobevalvewhichseals
the stem is tightened by the studs and nuts on the gland flange.
Thebonnetisequippedwithanintegralbackseat,whichseats
thevalvewhenstemisinupmostposition.
Flow seal area:Theintegralsealfacesofthebodyofglobe
andcheckvalvesarehardfaced.Thediscofglobevalvesis
connectedtothestembyT-headjoint.Thediscofcheckvalves
is spring loaded.
Bonnet seal area:Thebonnetisthreadedandsealwelded
to the body.
ATTENTION
ATTENTION
6 Installation
6.1 General
To avoid leakage, deformation or rupture of
the body, the piping should be laid out in such
awaythatnothrustorbendingforcesacton
thevalvebodies(100)whentheyareinstalledandoperational.
Only remove the covers from the connection
endsjustbeforeinstallation.Thesealingfaces
of the flanges must be clean and undamaged.
The gaskets at the connecting flanges must be
precisely entered. Use only joints and gaskets of
approved materials. All holes provided in the flanges
must be used for the flange connection.
When painting the pipes, do not apply paint to bolts
andstem(200).Ifconstructionworkisstillinprogress,
the valves must be protected against dust, sand and
buildingmaterialetc.(coverwithsuitablemeans).
Donotusevalvehand-wheelsasfootholds!
Valvesandpipesusedforhigh(>500C)orlow(<00C)
temperaturesmusteitherbettedwithaprotective
insulation,ortheremustbewarningsignsinstalled
showingthatitisdangeroustotouchthesevalves.
If a valve is used as end-valve in a pipe, this
valve should be protected against unauthorized or
unintentionalopeningto preventpersonalinjuryor
damage to property.
9
Note:Thrustbearingonlyforsizes11/2”&2”

SICCA
ATTENTION
10
6.2 Installation position
Thevalvebodiesaremarkedwithanarrowindicatingtheflow
direction.Valvesshouldalwaysbeinstalledinsuchawaythat
theactualflowdirectionofthemediummatchesthearrowon
the body.
6.2.1 Gate valves
In general flow may pass a gate valve in either direction.
However in high pressure valves with pressure relieving
arrangement (refer clause 6.6, Execution ref. PR-01 to
PR-06)valvesareunidirectional.Wheninstallingagatevalvein
ahorizontalpipe,thestemshouldbevertical,i.e.thehandwheel
oractuatorisontop.Inclinedorhorizontalstemposition(e.g.
inaverticalpipe)isalsopossible,inthiscase,however,the
actuator must be supported by some suitable means.
6.2.2 Globe valves
Flowmaypassaglobevalveineitherdirectionifnotindicated
otherwise.Wheninstallingaglobevalveinahorizontalstem
position(e.g.inaverticalpipe)isalsopossible,inthiscase,
however, the actuator must be supported by some suitable
means.
Forged Steel Globe Valves in High Pressure /
Temperature Drain Service
InStart-upVent/Drainapplication,theGlobevalvesarelikely
toaccumulateforeignparticleslikescaleorrust.During‘‘rush’’
oftheflow,theseparticlesmayerodeSealingSurfacesonDisc
andBodySeat,whentheflowis‘‘BelowtheDisc’’.
KSB’s‘‘Y’’typeGlobeValvescanbeinstalledindividuallyorin
tandem for improved life time of valves in the high differential
drainservicewithgoodshutofffunction,with‘‘Flowoverthe
Disc’’orientation.
Insuchstart-up/ventanddrainapplications,werecommended
‘‘FlowovertheDisc’’forfollowingreasons:
- minimalSeaterosionduetooccasionallyflowingsediment/
foreign particles
- usingthedifferentialpressure,actingontopsideoftheDisc,
to assist effective sealing
- minimizingloads/stressintheStem
Thisorientationofthevalvei.e.‘‘FlowovertheDisc’’willserve
thesepurposeandthelifecycletimeofGlobeValvesmaybe
extended.
6.2.3 Checkvalves
Swingcheckvalvesshouldpreferablybeinstalledinhorizontal
pipes.Wheninstallingtheminverticalpipes,makesurethatthe
flowdirectionisupward,sothatintheunpressurizedcondition,
thediscwillbeclosedbyitsownweight.
Checkvalvesareprovidedwithtwoextralongstuds(902)or
atappedholeinthecover(refersketchSCC150-600)which
serves a means of lifting lugs.
6.3 Pressuresealdesign(gateandswingcheck
valves)
Ongatevalveswithpressuresealbonnet(166)
ofg.GTC900-2500&Pr.sealbonnet(139)of
g.GTC3100-3600wherethemediumtrappedintheclosed
valvecanheatup,theusermustcheckwhetheraconnection
from the middle of the body to the upstream side of the gate
ATTENTION
valve(flowinonlyonedirection)orabodysafetydevice(flow
ineitherdirection)shouldbeprovided.
If a swing check valve and a gate valve with pressure seal
bonnet (166) are connected in series over a short distance
thenthemediumtrappedwhenthevalveisclosedcancause
a pressure rise at the pressure seal bonnet and the closing
element.Theusermusttabodysafetydevice/valveonthe
pipe line to protect the Check valve body from being over
pressurizedduetoentrappedfluidbetweenclosedelements
ofGate&Checkvalve.Ifthereisanydoubtdonothesitateto
contactKSB.
6.4 Welding instructions / installation of pipe
Responsibility for welding the pipes lies with the piping
installation contractor.
Whenweldingvalvesontothepipingorwhen
welding pipes after the valves have been
installed,theweldermustmakesurethatno
foreignparticles,e.g. weldbeads,enter thevalvebody and
remainthere,becausethesewillcausedamagetothevalve
seats and or the valve stem.
Whenweldingthevalveintothepipeline,take
special precautions, i.e. welding in several
steps, to that the temperature in the middle of
thebodydoesnotexceedthemaximumpermissibleoperating
temperature.Duringtheweldingprocess,Gate/Globevalves
must be kept in open position. Follow the guidelines from
applicablecodesforweldingprocedure/postweldprocedures.
Do not attach the welding cables (opposite
pole) to the moveable parts of the valve,
otherwisethesepartsmaybescorched.
6.5 Actuated valves
Electricalcablesmayonlybeconnectedbyqualied
personnel.
The applicable electrical regulations (e.g. VDE),
alsoforequipmentinhazardouslocations,mustbe
observed.
Allelectricalequipmentsuchasactuator,switchboard,magnetic
valvedrive,limitswitchetc.mustbeinstalledinfloodproofdry
locations.
Voltageandfrequencymustmatchthevalvesstatedonthe
name plate.
6.6 Body safety arrangement (pressure relief)
Heat buildup of trapped liquid volumes is a
phenomenonwhichmainlyaffectsgatevalves.
Ifthereareliquidresidueinthevalvebodyafterthehydrostatic
pressure test, for instance, or condensate has collected in the
valve body due to a particular operating condition, there is a
riskofanimpermissiblepressurerisewhenthebodyisheated
upbyhotwaterorsteaminoneorbothoftheadjoiningpipes.
ATTENTION
ATTENTION
ATTENTION

SICCA
11
Gatevalveswithpressuresealthereforehavetobeequipped
withabodysafetyarrangementwheneverthereisariskof
trapped liquid volumes heating up. This prevents excessive
loads on the valve body and potential deformation under all
operating conditions and thus ensures safety.
This aspect has been addressed in ASME B16.34 which
says……
ASME B 16.34 Cl 2.3.3 – Fluid Thermal Expansion. “…..
A certain circumstance in which the center cavity is lled
or partially lled with liquid and subjected to an increase in
temperaturecanresultinanexcessivebuildupofpressurein
the center cavity that may lead to pressure boundary failure. An
exampleisapipingsysteminwhichliquidfromthecondensing,
cleaning, or testing fluids accumulates in the center cavity of a
closedvalve.Suchaccumulationmayresultfromleakagepast
theupstreamseatofthevalve.Ifduringsubsequentstart-up,
thevalveisnotrelievedoftheliquidbypartialopeningofthe
valve or by some other method, the retained liquid may be
heatedduringwarm-upofthesystem.Wheresuchacondition
is possible, it is the responsibility of the user to provide, or
requirestoprovide,meansindesign,installation,oroperation
procedure to ensure that the pressure in the valve will not
exceedthatallowedbythisstandardforattainedtemperature.
In the view of above KSB has standardized pressure relief
arrangementbywayofdrilledholeontheupstreamsidedisc
intheabsenceofcustomerspecication.However,thismakes
theValveUni-Directional.
The potential pressure rise depends on the
temperature and the degree to which the body is
lledandmayrapidlyreachunallowablevaluesfor
the body.
The problem of heat buildup of trapped liquid volumes is
particularly dangerous when the gate valve is tted with a
pressureseal,asthecoversealwillbecomeeventighteras
the pressure rise.
Ongatevalvewithflangedcovers,unallowablepressurerises
arerelievedthroughleaksdevelopingatthecovergaskets.
Pressure relief arrangement may be provided either in Upstream
ordownstreamsidebasedontheServicerequirements.
The other pressure relieving options offered by KSB are
illustrated on page no. 10 (Identied by Execution Ref. No.
PR-01toPR-08).
KSB advice the user to select a suitable pressure relieving
option and indicate the execution reference at the time of
ordering.
ImportantNote:KSBstandardValvesisprovidedwith
safetyarrangement-internalreliefthroughwedgedisc
ExecutionRef.No.PR-03.Itisspecicallystatedthe
valve is unidirectional.
The‘REDDOT’onthearrowplateindicatesthelocation
(Upstream/Downstream)ofpressurereliefarrangement.
Cautionplateindicatingtheaboveistaggedonthebody.

SICCA
12
Note:‘K’side&‘B’sideindicatedabovearewithrespecttoascast‘‘KSB’’markonthevalvebody.

SICCA
13
ReferPageNo.9“ImportantNote”
7 Commissioning / Decommissioning
7.1 Commissioning
7.1.1 General
Prior to commissioning the valve, the pressure, temperature and
material data stated on the valve should be compared to the
actualoperatingconditionsinthepipingsystemtocheckwhether
thevalvecanwithstandtheloadsoccurringinthesystem.
Possiblepressuresurges(waterhammer)mustnotbeexceed
thehighestadmissiblepressure.Adequateprecautionsshould
betaken.
Innewpipesystemsandespeciallyafterrepairwork,thesystem
shouldbeflushedwiththevalvesfullyopentoremovesolids,
e.g.weldbeads,whichmaydamagetheseats.
Largesizecheckvalves>12”inlowflow,low
pressureandfluctuatingflowconditionsmay
causechatteringofdiscwithseat.KSBrecommendsuseof
appropriate means of balancing of disc.
7.1.2 Operation
Thevalvesareclosedbyturningthehandwheelintheclockwise
direction (top view) and opened in the counterclockwise
direction.
Using additional levers when turning the handwheel is not
admissible,becauseexcessforcemaydamagethevalve
7.1.3 FunctionalCheck
Thefollowingfunctionsshouldbechecked:
Beforecommissioning,theshut-off-functionofthevalvesshould
becheckedbyrepeatedopeningandclosing.
Theglandpacking(461)shouldbecheckedwhenitissubjected
tothefulloperatingpressureandtemperatureforthersttime.
If necessary, retighten the nuts (920.2) at the gland flange
(452)evenly.
On valves in pressure seal design, the nuts (920.1) of stud
(902.1) which hold the bonnet (139) and the gaskets (411)
under tension must be tightened so as to prevent leakage,
duetothebonnet(139)sinkingintothebody(100)whenthe
pressure drops.
The cover flange connection (902.1/920.1) and the gasket
(411)shouldbecheckedfortightnessafterthersttemperature
riseatthevalves.Incaseofleakageatthegasket(411),the
connection should be tightened crosswise, evenly and in a
clockwisedirection.
Open the gate and globe valve by one or two turns of the
handwheel prior to retightening the nuts 920.1 to prevent
jammingoftheseat.
Retighteningofthenuts(920.1)ofthecoverboltingespecially
applies to valves used in heat transfer systems to DIN 4754.
7.1.4 Actuated valves
On valves with electric/pneumatic/hydraulic actuator, the
strokes/forcesmustbelimited.
Electricactuatorsshouldbewiredasfollows:
Alwaysusesuitablesparepartsandtools,eveninemergencies,
becauseotherwisecorrectoperationofthevalvescannotbe
assured.
ATTENTION Valve type Open Close
GTC-#150-600 Limit Torque1)
GTC-#900-3600 Limit Limit2)
GLC-#150-2500 Limit Torque
GTF/GLF-#1500/2500/4500 Limit Torque
1)Motortripsbytorqueswitchfollowedbylimitswitch
2)Motortripsbylimitswitchfollowedbytorqueswitch
Switchesarefactoryset.Donottamperwith
settings.Toreadjustsettingsreferinstruction
manual of actuator manufacturer and / or contact your nearest
KSBofce.
Forsettingofactuator,pleasereferinstructionmanualwhich
willbekeptinthewiringsidecompartment/coverofactuator.
Duringsettingensuretorquesettingforopenpositionmustbe
10%morethanclosedposition.
7.2 Decommissioning
During extended shutdowns periods, liquids liable to
change their condition due to polymerization, crystallization,
solidicationetc.mustbedrainedfromthepipingsystem.If
necessary,thepipingsystemshouldbeflushedwiththevalves
fully open.
8 Maintenance/Repair
8.1 Safety Instructions
Maintenanceandrepairworkmayonlybecarriedoutbyskilled
andqualiedpersonnel.
Forallmaintenanceand repair work, the safetyinstructions
listedbelowandalsothegeneralnotesinsection3mustbe
observed.
Alwaysusesuitablesparepartsandtools,eveninemergencies,
becauseotherwisecorrectoperationofthevalvescannotbe
assured.
8.1.1 Dismantling of valves
Before removing the complete valve from the pipe, or before
repairormaintenanceworkonthevalveitself,i.e.
- beforeremovingcover/yokeorpressuresealbonnetfrom
the body
- beforeremoving/unscrewingventordrainplugs
- beforeremovingtheglandcovertoreplacepackingrings
- beforeremovinganactuatorbolteddirectlytotheyokehead
The entire valve must be unpressurized and must
havecooleddownsufcientlysothatthetemperature
ofthemediuminallthevalve’schambersislower
than the vaporization point of the medium, to prevent
scalding.
Openingpressurizedvalveswillcausedangertolife
andlimb!
If toxic or highly inflammable substances or liquids whose
residues may cause corrosion by interaction with the air
humiditywerehandledbythevalve,thenthevalveshouldbe
drained and flushed or vented.
Ifnecessary,wearsafetyclothingandafaceguard/mask.
Dependingontheinstallationposition,anyliquidremainingin
the valve may have to be removed.
ATTENTION
ATTENTION

SICCA
ATTENTION
14
Prior to possible transport, the valves must be flushed and
drained carefully.
IfyouhaveanyquestionspleasecontactyourKSBSalesOfce.
8.1.2 Removing Actuators
Ifactuatorspoweredbyanexternalsourceofenergy(electric,
pneumatic,hydraulic)needtoberemovedfromthe
valves or dismantled, the energy supply must be
shutdownpriortostartinganyrepairworkandthe
instructions in the sections 3, 8.1.1 and the operating
instructions of the actuator must be observed.
Valveactuatorswithintegratedspring-loadingfeaturecannot
be removed.
Caution:Springsundertension!
IfyouhaveanyquestionspleasecontactyourKSBSalesOfce.
8.2 Maintenance
Our valves are largely maintenance free, materials of sliding
partswereselectedtokeepweartoaminimum.Toensure
reliable operation and to reduce repair costs, all valves -
especiallythosewhichareseldomoperatedorwhereaccess
isdifcult–shouldbecheckedperiodically.
Theuserisresponsiblefordeningappropriateintervalsfor
checksandmaintenance,dependingontheapplicationofthe
valve.
The service life of non-maintenance-free valves can be
extendedby:
- lubricatingmovablepartssuchasstem(200)andglandbolts
(notforoxygenvalves)andthroughgreasenippleprovided
in the case of gate valve using suitable lubricants to DIN
51825/equivalent
- timelychangingofthepackingrings
- timelyreplacingofthecovergasket(411)
The safety instructions in sections 3, 8.1 and the notes in section
9mustbeobserved.
9 Troubleshooting
9.1 General
Allrepairandserviceworkmustbecarriedoutbyqualied
personnel using suitable tools and genuine spare parts.
The safety instructions in sections 3 and 8 must be observed.
9.2 Faults & Remedies
Fault-Leakageattheseat
Remedy-Remachinetheseatonwedge/discandbodyusing
suitableregrindingequipmentafterdismantlingthevalve.Re-
grinding of body and cone seats should be continued until the
seatsshowasmoothandevenring.
Fault-LeakageatthecoverGasket
Remedy - Retighten the cover flange connection Remedy
-Replacethegasket (411) after removingthecoverbolting
(902/920.1). Clean the surfaces carefully before inserting a
newgasket.
On asbestos-free gaskets, no additional
sealingagentsmaybeused.Whenusinganti-
adhesivecoatings,usesealingagentsexplicitly
recommended by the manufacturer of the sealing material.
IfyouhaveanyfurtherquestionspleasecontactnearestKSB
Salesofce.
Fault-LeakageoftheStufngBox
Remedy-Retightenthestufngboxwiththenuts(920.1)at
theglandflange(452).Makesurethatthefrictionforcesatthe
stem do not increase too much.
Remedy - Replace the packing rings of the stuffing box;
Unscrewthenuts(920.2)andlifttheglandflange(452).Clean
the stufng box chamber thoroughly before inserting new
packingrings.Splitpackingringsshouldbeinsertedinsucha
waythattheslotsareoffsetby1200to1800.

SICCA
15
10 Valve weights
Size Class GATE (GTC) GLOBE (GLC) CHECK (SCC)
RF BW RF BW RF BW
2
150 15 15 25 20 20 15
300 30 25 35 25 25 20
600 35 30 45 40 30 25
2 1/2
150 25 20 35 30 20 15
300 40 30 45 40 30 20
600------
3
150 25 25 40 40 35 35
300 45 40 50 45 45 40
600 60 50 75 70 55 50
4
150 40 35 60 55 50 45
300 65 55 75 65 65 50
600 105 90 110 100 100 70
5
150 60 55 75 65 50 40
300 105 85 75 65 80 60
600------
6
150 70 65 120 90 80 65
300 135 110 135 120 120 100
600 210 170 215 165 160 130
8
150 125 115 145 130 125 105
300 235 185 305 260 265 225
600 400 330 540 500 310 235
10
150 200 180 260 240 220 190
300 335 280 375 315 280 235
600 600 520 790 720 490 440
12
150 280 245 - - 345 300
300 470 390 - - 390 350
600 820 660 - - 640 575
14
150 425 405 - - 440 415
300 685 575 - - 680 620
600------
16
150 550 555 - - 590 555
300 1110 1030 - - 890 815
600 1630 1425 ----
18
150 675 680 - - 765 730
300------
600------
20
150 815 820 - - 955 910
300------
600------
24
150 1220 1220 - - 1410 1340
300------
600------
SICCA 150 - 600 (Approx.inkg)

SICCA
16
Size Class GATE (GTC) GLOBE (GLC) CHECK (SCC)
FB RB BW BW
2
900 40 - 40 20
1500 45 -75 20
2500 65 -85 30
3
900 80 40 75 35
1500 80 45 95 35
2500 110 70 145 50
3100 165 145 - 70
4
3600 365 240 - 80
900 110 80 105 40
1500 125 80 170 60
2500 155 110 210 80
3100 250 170 - 95
3600 410 370 - 115
5
900 - 110 110 45
1500 - 135 185 65
2500 - 170 235 95
6
900 175 110 230 90
1500 250 140 380 130
2500 395 170 485 180
3100 405 265 - 270
3600 610 435 - 350
8
900 275 170 380 145
1500 380 225 - 210
2500 580 385 - 300
3100 755 430 - 475
3600 1055 650 - 605
10
900 460 285 -245
1500 665 415 -365
2500 990 660 - 540
3100 1090 815 - 790
3600 1500 1115 - 940
12
900 730 470 - 380
1500 1005 730 - 570
2500 1510 1090 - 850
3100 1820 1140 - 1330
3600 2410 1575 - 1610
14
1500 1370 1080 - 750
2500 2060 1620 - 1075
3100 2300 1850 - 1600
3600 2995 2455 - 2120
SICCA 900 - 3600 (Approx.inkg)

SICCA
Size Class GATE (GTC) GLOBE (GLC) CHECK (SCC)
FB RB BW BW
16
1500 1845 1445 - 1070
2500 2715 2085 - 1475
3100 3100 2370 - 2290
18
3600 3945 3090 - 2815
1500 2535 1925 - 1415
2500 3700 2850 - 2035
3100 4075 3190 - 3000
3600 5310 4055 - 3745
20
1500 3340 2665 - 1895
2500 4900 3875 - 2650
3100 5290 4155 -3815
3600 7100 5420 - 4950
22 3100 6870 5385 -4885
3600 9120 7230 - 6140
24
1500 - 3625 - 2940
2500 - 5505 - 4170
3100 8630 6980 - 6025
3600 11385 9275 - 7745
26 3100 10475 8755 -7475
3600 14100 11575 - 9940
28 3100 13000 10625 - 8885
3600 17195 14325 - 11380
SICCA 900 - 3600 (Approx.inkg)
17

SICCA
Size Class GATE (GTF) GLOBE (GLF) CHECK (PCF)
1/4
800 221
1500 331
2500 542
3/8
800 221
1500 331
2500 542
1/2
150 3.4 3 2.5
300 3.4 3 2.5
600 4.4 4 3.5
800 221
1500 331
2500 542
4500 NA 12 5
3/4
150 4.5 4 3.5
300 4.5 4 3.5
600 5.4 5 4.5
800 322
1500 452
2500 552
4500 NA 12 5
1
150 5.3 5.5 4.5
300 5.6 6 4.5
600 8.3 8.5 7.5
800 332
1500 663
2500 10 7 3
4500 NA 17 8
1 1/2
150 10.3 10.5 9
300 10.9 11 9.5
600 14.5 14.5 13
800 775
1500 11 12 8
2500 14 13 7
4500 NA 29 15
2
150 - 15 14.5
300 15.8 - -
600 21.4 - -
800 10 11 9
1500 14 15 10
2500 20 16 10
4500 NA 41 20
SICCA 150 - 4500 F (Approx.inkg)
18

SICCA
19
Annexure I
DO’s
1. Observe the safety instructions.
2. Employskilled,trainedandexperiencedpersonneltohandlethevalve.
3. Align the pipe correctly in position before mounting a valve on line.
4. Useacorrecttypeofflangegasket.
5. Ensurethecorrectdirectionofflowonthevalve.
6. Ensurethevalveisun-pressurisedbeforeanyworkiscarriedout.
7. Decontaminatethevalvesincontactwithhazardousfluids,beforeanyworkiscarriedout.
8. Lubricatethevalvesperiodically.
9. Protectthethreadswithametal/leatherjacketiftheworkingconditionsareabrasive.
10. Allowclearanceforraisingstemtypevalvetoopenfully.
11. Flush the valves in fully open condition to remove foreign material like welding flux, spatter, slag, dust etc. to avoid
damage of seats.
12. Checkshut-offfunctionbyrepeatedlyopeningandclosingbeforecommissioning.
13. Checkthefrequencyandvoltageofactuatorstomatchwiththelinevoltageandfrequency.
14. Ifgasketleakisobserved,tightengasketboltscrosswiseevenlyinaclockwisedirection.
15. Afterattainingthefulloperatingpressureandtemperature,checkandifnecessary,tightentheglandnut/Body-bonnet
nuts.
16. Whenagatevalveisfullyopened,screwitdown1/4turntopreventsticking.
17. During storage position the valve such that the stem is upright.
18. Forglobevalvefollowtheinstructionscarefullyfordirectionofinstallation.
DON’Ts
1. Don’texposethevalvestodust,sand,buildingmaterialetc.duringstorage.
2. Don’tuseunauthorisedspares.
3. Don’tremoveendprotectivecoversbeforeinstallation.
4. Don’tusevalvehand-wheelsasfootholds.
5. Don’texceedthelimitsstatedintechnicaldocumentation.
6. Don’tstorethevalveinopencondition.
7. Don’tattempttodismantlethepressurisedvalve.
8. Don’tuseavalvetopullanunsupportedandbadlyalignedpipesintoposition.
9. Don’tleaveagatevalveincrackopencondition.
10. Don’tuseagatevalveforthrottling.
11. Don’tforceagatevalveclosedwithawrench.
12. Don’tuseaflatdiscglobevalveforstart-up/ventapplication.
13. Oncethevalveisinstalledandcommissioneddonottamperthetorque&limitswitchesincaseofvalvewithelectrical
actuator.
