KTI Networks KC-10TF Series User manual

Specifications
 Comply with IEEE 802.3 10BASE-T and 10BASE -FL std.
 rovide a push button to set the crossover function for
the T port
 rovide LEDs for easy network monitoring:
- ower status
- Link and receive status for T port
- Link and receive status for fiber port
 Fiber optic connectors:
- multimode ST
- multimode SC
- single mode ST
 Environment: Temperature 0 - 40oC
Humidity 10-90% non condensing
 Dimensions: 101mm x 96mm x 25mm
 ower: +12V / 800mA minimum
 DC plug type:
Connectors & Cables
10BASE-T RJ-45 Connectors (TP Port)
One RJ-45 connector is provided on the converter for
10BASE-T connection. For easy connection to any device
using standard straight-through UT cable, a push button
is available to set the crossover function for the RJ-45.
RJ-45 Pin MDI-X Jack MDI Jack
1 Rx+ Tx+
2 RX- Tx-
3 Tx+ Rx+
6 Tx- Rx-
10BASE-T UTP Cable
Cable: Category 3, 4, or 5 UT
Maximum cable distance: 100 meters (328 feet)
General Description
The KC-10TF Ethernet media converter series are designed
to convert a 10BASE-T signal to a 10BASE-FL signal. It is
used to extend the connection distance between two Ether-
net Twisted-pair devices via fiber cable transparently with
no performance degradation. The converter series provide
different types of fiber connectors such as ST and SC for
MM (multimode) or SM (single mode) fiber cables.
The outline of the converter is:
Installation Guide
10BASE-T/10BASE-FL
Ethernet Media Converter
KC-10TFSERIES
DOC. 000830-KC10TF-K Rev.1.0
P/N: 750-0145-001
iber Optic Connector ( iber Port)
The series provides different types of fiber connectors for
different applications. The connectors include multimode ST,
multimode SC, and single mode ST are shown as follows:
The wavelength used is 850nm. The series also support
MM (multimode) fiber cables and SM (single mode) fiber
cables. The recommended MM cable is 62.5/125µm and SM
cable is 9/125µm.
Models
The following table lists the fiber connectors, fiber cables
and the maximum length supported by each converter
model:
Model Connector Cable Used Cable Length*
KC-10TF/T ST MM 2Km
KC-10TF/C SC MM 2Km
KC-10TF/S ST SM 14Km
* Cable length : the maximum length in point-to-point full duplex
operation

The information contained in this document is subject to change
without prior notice.
Copyright+ KTI. All Rights Reserved.
TRADEMARKS
Ethernet is a registered trademark of Xerox Corp.
WARNING:
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protec-
tion against harmful interference when the equipment is
operated in a commercial environment. This equipment gener-
ates, uses, and can radiate radio frequency energy and if not
installed and used in accordance with the instruction manual
may cause harmful interference in which case the user will be
required to correct the interference at his own expense.
NOTICE:
(1) The changes or modifications not expressively approved by
the party responsible for compliance could void the user's
authority to operate the equipment.
(2) Shielded interface cables and AC power cord, if any, must
be used in order to comply with the emission limits.
CISPR A COMPLIANCE:
This device complies with EMC directive of the European
Community and meets or exceeds the following technical
standard.
EN 55022 - Limits and Methods of Measurement of Radio
Interference Characteristics of Information Technology Equip-
ment. This device complies with CISPR Class A.
WARNING: This is a Class A product. In a domestic environment
this product may cause radio interference in which case the
user may be required to take adequate measures.
CE NOTICE
Marking by the symbol indicates compliance of this
equipment to the EMC directive of the European Community. Such
marking is indicative that this equipment meets or exceeds the
following technical standards:
EN 55022: Limits and Methods of Measurement of Radio
Interference characteristics of Information Technology Equip-
ment.
EN 50082/1:Generic Immunity Standard -Part 1: Domestic
Commercial and Light Industry.
EN 60555-2: Disturbances in supply systems caused by
household appliances and similar electrical equipment - Part 2:
Harmonics.
Installation
1. Install the media converter with the DC power adapter
provided. ( +12VDC, 800mA)
2. Connect the power adapter cable to the media con-
verter before connecting the adapter to the AC outlet.
Making Network Connections
The converters serve as a conversion path between two
Ethernet devices. To both devices, the conversion is
transparent. The connection could be one of the following
configurations:
Important rule: When a connection is established, make
sure the devices located at both ends of the path are
configured and operated using the same duplex mode and
the maximum distance must comply with IEEE 802.3
specifications.
Interpreting LED Indicators
The LED labeled "UT " is used to indicate the status of
the T port and the LED labeled "FX" is for Fiber port.
LED Status State Interpretation
POWER Power status On Converter is on.
Off Converter is off.
UTP TPportlink/Rx On TheUTPlinkisok.
Off No link or the link is faulty.
Blink Receiving on TP port
FL Fiber port link/Rx On The fiber link is ok.
Off No link or the link is faulty.
Blink Receiving on Fiber port
