PUMP-PLUS HO
HIGH OUTPUT
AIR COMPRESSOR / BATTERY CHARGER
NOTE :
This charger is designed for
vehicles with dual batteries
and negative ground.
INPUT :120 volt, 50/60 Hz
OUTPUT: 13.25 VOLTS, 11 AMPERES
MODEL #091-9C-HO

Independent Charge Controls
The Pump Plus HO contains two independent charge controls, one for each
battery. This allows each battery to be independently charged while maintain-
ing battery isolation. Each battery is individually sensed, eliminating the need
for sense wires. Each of the charge controls is completely automatic and stops
charging the battery when it is fully charged. There is no trickle charge and
therefore no danger of overcharging and water boil-off.
INTRODUCTION
The Pump Plus HO Automatic Battery Charger is a compact, completely
automatic, dual channel battery charger designed for vehicles with a two battery
system. The charger is ruggedized to withstand the shock and vibration encoun-
tered by vehicle mounted equipment.
Battery Charger Features:
• Independent charge controls for each battery
• Automatic current limiting
• Optional dual battery charge/condition indicator
• Power “ON” LED indicator
DESCRIPTION
Automatic Current Limiting
When batteries are severely discharged, some battery chargers can be over-
loaded due to the high charging current required. The Pump Plus HO contains an
automatic current limit. This circuit limits the output current to the rated 11 am-
peres when charging a deeply discharged battery or if the starter cranks the en-
gine while starting. The current limiter thus eliminates the need for an ignition
interlock circuit.

SPECIFICATION
Input: 120 volts A.C., 50/60 Hz., 3 amperes
Input Fuse: 5 amperes, fast acting
Pump Fuse: 15 amperes, slow blow
Output Volts: 13.25 volts, nominal
Output Current: 0 to 11 amperes, D.C., output determined by the state of charge of the
batteries
Remote Charge Indicator: Red Led indicates charging current
Green Led indicates batteries are fully charged
Weight: 12 lb.
