Create a new KPrint port
KPrint Installation 1-1
KPrint Installation
KPrint installs a client port monitor that enables Windows TCP/IP printing to any
network card connected to a printing system. KPrint supports Raw mode, LPR, IPP,
Email, and Network FAX printing.
KPrint Setup
It is strongly recommended that you exit all Windows programs before running this
setup program.
1In Windows, click Start > Run. Type the file path: 1
<CD drive letter>:\Network\KPrint\KPInst.exe
Click OK.
2In the Welcome to KPrint Setup page, click Next to continue with the Setup
program, or click Cancel to quit setup. 2
3The KPrint Setup page displays a default Destination Folder. Click Next to accept
the folder and continue the setup, or Browse to select another location for the KPrint
utility files. 3
4The next KPrint Setup page displays a default Program Folder name where the
setup program will add program icons. (You can type a new folder name, or one from
the Existing Folders list.) Click Next. 4
5The last KPrint Setup pagedisplaysa KPrint is successfully installed message. You
can: 5
•SelectYes to add a new KPrint port using the KPrint Add Port Wizard. Click
Finish. (The selections for adding a new port appear in step 6 on page 1-2.)
•SelectNo to close the KPrint Setup Wizard without adding a new port. Click
Finish.
Create a new KPrint port
More commonly, KPrint ports will be created using the Add Printer Wizard.
1Click Start in the Windows taskbar, and click Printers and Faxes to open the
Printers and Faxes window. 1
2Click Add a printer in the Printer Tasks group box on the left. 2
Note: The Add Printer Wizard can also be launched by clicking Add printer in the
File menu of the Printers and Faxes window.
3The Add Printer Wizard page appears. In the Welcome page, click Next and follow
the instructions. 3
4Select Local printer attached to this computer. Click Next.4
5Select Create a new port, scroll down to KPrint Port. Click Next. 5

Add a Raw Port
1-2 KPrint Installation
6In the KPrint Add Port Wizard, select the desired KPrint port to install from the
following selections: 6
•Add a Raw Port on page 1-2
•Add a LPR Port on page 1-2
•Add an IPP Port on page 1-3
•Add an Email Port on page 1-3
•Add a Network FAX Port on page 1-4
Add a Raw Port
Raw mode transfers unprocessed print data directly to the printer.
1In the KPrint Add Port Wizard, select Print using Raw mode. Click Next.1
2If you know the IP address or Host name, type it in the text box. If you do not know
the IP address or Host name, click Search to open a list ofavailable printing systems
and their related IP addresses. Select a printing system. Click OK.2
Type a Port number and then click Next, or just click Next to accept theport number
displayed.
3Type a Destination printer port name and then click Next, or just click Next to
accept the port name displayed. Existing port names cannot be used. 3
4Confirm the settings, and then click Finish.4
The port addition is complete, and the KPrint Add Port wizard closes.
Add a LPR Port
LPRis aUNIX acronymforline printer.LPRcopies (orlinks) print filesto aspool area
from where a background program copies them to the printer.
1In the KPrint Add Port Wizard, select Print using LPR. Click Next.1
2If you know the IP address or Host name, type it in the text box. If you do not know
the IP address or Host name, click Search to open the Printing Systems Search
dialog box. A list of available printing systems and their related IP addresses
appears. Select a printing system. Click OK.2
Type a Port name for the print server and then click Next, or click the down arrow
to select a name from a list. Click Next.
3Type a Destination printer port name and then click Next, or just click Next to
accept the port name displayed. Existing port names cannot be used. 3
4Confirm the settings, and then click Finish.
5The port addition is complete, and the KPrint Add Port wizard closes. 4

Add an IPP Port
KPrint Installation 1-3
Add an IPP Port
IPP is an acronym for Internet Printing Protocol. It allows you to print a document on
a printer at another location by specifying an Internet URL.
1In the KPrint Add Port Wizard, select Print using IPP. Click Next.1
2Select Connects using a local area network. Click Next.2
3If your network uses a proxy, select Yes and type the Address and Port number.
(If you do not know this information, ask your network administrator.) 3
If a proxy server is not used, select No.
Click Next.
4Type the Printing system URL.4
ipp://(your printer's IP address)/printers/lp1
If your printer is one of the models listed in the wizard screen, use the following
example:
ipp://(your printer’s IP address)/ipp
5Click Next.The wizardthencommunicates withthe print serverusing the connection
you specified. 5
6Type a Destination printer port name and then click Next, or just click Next to
accept the port name displayed. Existing port names cannot be used. 6
7Confirm the settings, and then click Finish. 7
The port addition is complete, and the KPrint Add Port wizard closes. 8
Add an Email Port
KPrint can create an email port within Windows which directs jobs to a remote
printer’s email address. KPrint email printing is only available for Kyocera printing
systems.
The KPrint email port may be selected for existing or new printer drivers using the
same procedure as any other printer port, such as LPT1.
For successful email printing, the printing system must be configured to retrieve the
emailed print jobs from a POP3 mail server. POP3 configuration can be done using
a browser.
1In the KPrint Add Port wizard, select Print using Email. Click Next.1
2Read the information about Email Printing Configuration, and then click Next.
3Email servers often reject email that does not include a sender email address. The
name and email address are also used for return receipts and cover pages.
Type the Sender name and Sender address of the person who will be sending print
jobs.

Add a Network FAX Port
1-4 KPrint Installation
To send email print jobs, the email port must be able to establish a connection with
anSMTP mailserver. Type theSMTP server nameor IPaddress.ClickTest toverify
the connection to the SMTP server. Click Next.
4Type the Printing system Email address where print jobs will be received. Click
Search to search the network for printing systems with email printing capability.
To configure the printing system for email, in the Printing System Search dialog, click
Configure. Type the IP Network Address and Subnet Mask of a remote network
segment. Click Add to add it to the address list. All networks on the IP Network
Discovery List will be searched, in addition to the local network segment. When
finished, click OK to save settings and close the dialog boxes.
Type the Port name, or accept the email address as the port name.
If desired, select Display the print job cover page dialog to display the cover page
configuration dialog for each print job.
If desired, select Generate return receipts to direct the printing system to send an
email confirmation for each print job.
Click Next.
5If the mail server requires SMTP authentication, select Use SMTP authentication,
and type an authorized User ID and Password.
On some systems that limit the size of individual emails, it may be necessary to split
emails into more multiple email segments. To do this, select Split into multiple
emails when larger than this size, and type the desired number of kilobytes (KB).
6Confirm the settings, and then click Finish.
The following message appears: The port for [e-mail] is
successfully created. The port may be selected for printer drivers using the Windows
Add Printer wizard. Click OK.
The port addition is complete, and the KPrint Add Port wizard closes.
Add a Network FAX Port
1In the KPrint Add Port wizard, select Network FAX. Click Next.1
2If you know the IP address or Host name, type it in the text box.
If you do not know the IP address or Host name, click Search to open a list of
available printing systems and their related IP addresses. Select a printing system.
To type a broadcast address for the network to be searched, click Configure. When
finished, click OK to save settings and close the dialog boxes.
Click Next.
3Type a Port name and then click Next, or just click Next to accept the port name
displayed. Existing port names cannot be used.
4Confirm the settings, and then click Finish.
The port addition is complete, and the KPrint Add Port wizard closes.
