Kyocera FS FS-C8500DN User manual

Installation Guide
Clearance
• Temperature: 10 to 32.5 °C (50 to 90.5 °F) The humidity should be 70 % or less when the
temperature is 32.5 °C (90.5 °F)
• Humidity: 15 to 80 %RH The temperature should be 30 °C (86 °F) or less when the humidity
is 80 %
• Power Supply: 120 V AC, 60 Hz, 12 A / 220 to 240 V AC, 50/60 Hz, 7.2 A
FS-C8500DN
Environment
CAUTION: Be sure to provide enough space around printer. Prolonged use
without sufficient clearance may cause overheating.
300 mm (11-13/16") 300 mm (11-13/16") 100 mm (3-15/16") 1,000 mm (39-3/8")
Unpacking
CD-ROMs Manuals and Other
Printed Materials
Printer Power Cord
Toner Containers (4)
Waste Toner Box
Installing the Toner Container and Waste Toner Box
Open the front cover.
Open the cap of the waste toner box.Press the release button and pull out
the waste toner tray.
Install the waste toner box.
3
1
1
567
Note: Ensure the toner container is in the
correct location for that color.
400 mm
(15-3/4")
Press the specified position to set the
waste toner tray. When the tray
reaches the correct position, it locks
into place with a "click" sound.
98 Press on the left edge of the new waste
toner box to lock it.
Unpack the printer and all its included components.
Important: The printer must be carried by four persons.
Check the parts and components.
12
Magenta (M)
Cyan (C)
Yellow (Y)
Black (K)
Cap
Close the front cover.
10
Turn the toner container release lever
to the horizontal position.
Follow the procedure above to install
the other color toner containers.
4
Paper Size
Sheets (4)
Removing the Lift Plate
Stoppers
2
Pull out the paper cassettes 1 and 2.
1
Remove the lift plate stopper and
attach it to the storage location.
2
Lift Plate Stopper
Hold the toner container with both
hands and shake it from side to side
several times so that the toner is
uniformly distributed inside.
2Hold the toner container with both
hands and gently push it in.
3

Pull the paper cassette out toward you
until it stops.
Paper Width Adjustment Knob
Loading Paper
Fan the paper, then tap it on a level
surface to avoid media jams or skewed
printing.
Grasp the paper width adjustment
knob and adjust the paper width guides
to the width of the paper.
Adjust the paper length guide to the
length of the paper.
When loading A4/Letter or smaller paper
into paper cassette 1, raise the paper
length guide. For B4/Legal or larger
paper, lower the paper length guide.
Paper Length Guide
Align the paper against the left side of
the paper cassette. Important: Ensure that the loaded paper
is not higher than the level indicator (see
illustration below).
Gently push the paper cassette back
in.
4
2
5
31
7
4
Connect the power cord to the printer
and the other end into a power outlet.
Turn the power switch off (O). Connect the printer to the PC or your
network device. Use shielded interface
cables. These cables are sold
separately.
Connecting Cables
5
132
© 2009 by KYOCERA MITA Corporation All rights reserved. 2-28, 1-Chome, Tamatsukuri, Chuo-ku, Osaka 540-8585, Japan Printed in China 302KA56030 First edition 2009.10
Refer to the Operation Guide to install the printer driver and to set network parameters.
Network Interface
USB Interface
Turn the power switch on (|).
Important: When the printer is first
switched on after installation, the printer
will begin cleaning the LSU; this will take
approximately 70 seconds.
4
Insert the appropriate paper size card
in the slot to indicate the size of the
paper.
6
Level Indicator
