Lafayette Auto-Wand V2 Installation manual

Auto-Wand V2
Overview
Auto-Wand V2 oers a wirefree, rechargeable, easy to program and
use soluon to suit a large range of applicaons.
The favorite posion feature allows a pre-set posion to be recalled
for precise alignment at a desired mid window posion.
Auto-Wand Programming Instructions

Buon Descripon
Programming
Check motor direcon
To check travel direcon of shade, press UP
or DOWN on controller.
To reverse shade direcon, hold both UP
and DOWN.
Motor Response
Prior to programming. Your shade should be pre-programmed. If you need to adjust a limit please go to that
secon. If you have fully reset your motor then you will need to start at programming check motor direcon.

Seng Limits
Move shade to desired highest or lowest
posion by pressing the UP or DOWN
buons
Once you are at your upper limit, hold UP and
STOP.
Once you are at your lower limit, hold DOWN
and STOP.
DONE!
Adjusng Upper Limit
You can do this at ANY posion. Shade does not need to be at the current upper limit.
Hold UP and STOP on the
controller.
Move shade to desired
posion
Hold UP and STOP on the
controller.
Adjusng Lower Limit
You can do this at ANY posion. Shade does not need to be at the current lower limit.
Hold DOWN and STOP on
the controller.
Move shade to desired
posion
Hold DOWN and STOP on
the controller.

Delete All Sengs
Hold P1 on the motor head
for 3 connuous jogs
Favorite Posion
Move shade to the desired favorite posion Hold the STOP buon on
the wand and the shade
will jog once then release
Hold the STOP buon on
the switch again and the
shade will jog twice.
To send the shade to your favorite posion press and hold the STOP
buon unl the shade starts to travel.
18-AWAND-17 3/2017
For Motorization Technical Support call 877-548-0612
