LAMPHUS®SolarBlast™SBLS14,24,44
LED Emergency Warning Deck Light Bar
SKU: PSZLEDSTB0701, 702, 704
IMPORTANT: READ CAREFULLY BEFORE ASSEMBLY AND USE.
Installer of this product must have a good understanding of automotive electronics, systems,
and procedures.
In the case that holes must be drilled in order to properly mount the product, the installer must
examine both sides of the mounting surface before drilling begins. It is the installer’s
responsibility to be sure that no vehicle components or vital parts could be damaged by the
drilling process. De-burr any holes in order to remove metal shards and remnants. Use
grommets in all wire passage holes.
If this manual states that this product may be mounted with suction cups, magnets, tape, or
Velcro®, clean the mounting surface and dry thoroughly prior to applying any adhesives for
maximum adhesion.
Do not attempt to activate or operate this product under hazardous driving situations.
•
•
•
•
Deployment area of the vehicle air bags must be cleared. Do not install this product or route
any electrical wires near the air bags deployment areas. Refer to your vehicle owner’s manual
for the air bag deployment area. Products or wires mounted in the air bag deployment area will
damage, reduce the effectiveness of the air bag, or even act as a projectile which may cause
serious injury or death. The user/installer of this product assumes full responsibility in
determining the proper mounting location while prioritizing the safety of all passengers in the
vehicle.
This product contains strobe light(s), halogen light(s), high-intensity LEDs, or a combination of
these components. Do not look directly into the lights. Momentary blindness and/or injury to
the eyes could result.
•
•
Wiring
RED – To 9 - 30 VDC Power Source
BLACK – To Chassis Ground
WHITE – Group Selection (Note: group selection can only be configured when the units are off.)
Units with WHITE connected to the RED will be grouped together as GROUP 1.
Units with WHITE NOT connected to the RED will be grouped together as GROUP 2.
Units of GROUP 1 and GROUP 2 will flash alternately if its’ YELLOW are connected to
each other.
YELLOW – Synchronization and Pattern Selection
Connect YELLOW of all units together to enable synchronization.
Apply YELLOW to BLACK for a brief second will advance unit to the next flash pattern.
Apply YELLOW to BLACK for 3-5 seconds will advance the unit to Steady Mode.
Apply YELLOW to BLACK for more than 5 seconds will advance the unit to Off Mode.
BLUE – High/Low Intensity Selection
Applying BLUE to RED will engage Low Intensity setting. Disconnecting BLUE from RED
will resume High Intensity setting.
-
-
-
-
-
-
-
-
WARNING! All customer supplied wires that connect to the positive terminal
of the battery must be sized to supply at least 125% of the maximum operat-
ing current and FUSED at the battery to carry that load. DO NOT USE
CIRCUIT BREAKERS WITH THIS PRODUCT!
Online LED Store S2B Inc. ©2015 All Rights Reserved
Flash Patterns:
SBLS14 / PSZLEDSTB0701
Specifications:
SBLS14 / PSZLEDSTB0701
Input Voltage: 9 - 30V DC
Max. Current: 700 mAMPS
Max. Output Power: 4W
SBLS24 / PSZLEDSTB0702
Input Voltage: 9 - 30V DC
Max. Current: 900 mAMPS
Max. Output Power: 8W
SBLS44 / PSZLEDSTB0704
Input Voltage: 9 - 30V DC
Max. Current: 1.6 AMPS
Max. Output Power: 16W
1. Off Mode
2. Double Burst
3. QUad Burst
4. Single Flash
5. Double Flash
6. Quad Flash
7. Super Flash
8. Single Flash w/ Quad Burst
9. Accelerator
10. Combination Mode
11. Steady Mode
12. Cycle Mode
SBLS24 / PSZLEDSTB0702
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Off Mode
Single Burst – Split
Single Burst – All
Single Burst –
Combination
Double Burst – Split
Double Burst – All
Double Burst –
Combination
Quad Burst – Split
Quad Burst – All
Quad Burst – Combination
Single Flash – Split
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
Single Flash – All
Single Flash –
Combination
Double Flash – Split
Double Flash – All
Double Flash –
Combination
Quad Flash – Split
Quad Flash – All
Quad Flash –
Combination
Super Flash – Split
Super Flash – All
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
Super Flash – Combination
Single Flash w/ Quad Burst
– Split
Single Flash w/ Quad Burst
– All
Accelerator – Split
Accelerator – All
Combination Mode
Combination Burst
California Steady 1
California Steady 2
Steady Mode
Cycle Mode
SBLS44 / PSZLEDSTB0704
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
Off Mode
Single Burst – Split
Single Burst – All
Single Burst –
Combination
Double Burst – Split
Double Burst – All
Double Burst –
Combination
Quad Burst – Split 1
Quad Burst – Split 2
Quad Burst – Split 3
Quad Burst – All
Quad Burst –
Combination
Single Flash – Split 1
Single Flash – Split 2
Single Flash – Split 3
Single Flash – All
Single Flash –
Combination
Double Flash – Split 1
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
35.
Double Flash – Split 2
Double Flash – Split 3
Double Flash – All
Double Flash –
Combination
Quad Flash – Split 1
Quad Flash – Split 2
Quad Flash – Split 3
Quad Flash – All
Quad Flash –
Combination
Super Flash – Split 1
Super Flash – Split 2
Super Flash – Split 3
Super Flash – All
Super Flash –
Combination
Single Flash w/ Quad
Burst – Split
Single Flash w/ Quad
Burst – All
Accelerator – Split
36.
37.
38.
39.
40.
41.
42.
43.
44.
45.
46.
47.
48.
Accelerator – All
Combination Mode
Combination Burst
California Steady 1
California Steady 2
Steady Mode
Cycle Mode
Single Flash Scan 75
Single Flash Scan Reverse
75
Single Flash Scan 120
Single Flash Scan Reverse
120
Single Flash Scan 375
Single Flash Scan Reverse
375

Mounting Options:
Mounting Options Diagram:
The SBLS series can be mounted permanently or via suction cups. The mounting brackets can be
secured on to the light bar with a flexible swivel angel of 117 degrees or in a fixed position with the
mounting surface side of the mounting bracket being perpendicular to the LED lenses of the light bar.
Replacing Light Modules:
The SBLS series are composed of replaceable 4W LED light modules. The light modules can be
replaced in the case of it becoming defective and in the case which the user wishes to have a
different color/module layout than the factory default. Please note that more than one module
may need to be removed in order to access the water tight quick disconnect plugs.
Mounting with Suction Cups Diagram:
Mounting with Suction Cups:
Install the suction cups onto the mounting brackets.
Secure the mounting brackets onto the strobe light unit by using the bolt, split washer, and
washer provided. Do NOT tighten the hardware all the way.
Adjust tilt angle of the light bar prior to tightening the hardware securing the mounting
brackets to the light bar.
1.
2.
3.
Permanent Mounting:
Permanent Mounting Diagram:
Secure the mounting brackets onto the strobe light unit by using the bolt, split washer, and washer
provided. Do NOT tighten the hardware all the way.
Place the mounting brackets against the desired mounting surface.
Mark the area where the mounting holes are to be drilled. Confirm that no vehicle parts could be
damaged by the drilling process.
Using a drill bit of appropriate size, drill three mounting holes. Thoroughly de-burr all hole(s).
Secure the mounting bracket to the desired mounting surface by using the mounting screws
provided.
Adjust tilt angle of the light bar prior to tightening the hardware securing the mounting brackets to
the light bar.
1.
2.
3.
4.
5.
6.
Mounting
CAUTION! Permanent mounting of this product will require drilling. It is
absolutely necessary to make sure that no other vehicle components could be
damaged by this process. Check both sides of the mounting surface before
starting. If damage is likely, select a different mounting location.
