LAMPHUS® SolarBlast TM SBWL14
Compact High Intensity LED Windshield Mount Strobe
Light
SKU: PSZLEDSTB0401 Rev.1
www.online-led-store.com
Phone: 1-855-LED-ONLINE (1-855-533-6654)
Fax: [phone]
E-mail: [email protected]

IMPORTANT: READ CAREFULLY BEFORE ASSEMBLY AND USE.
• Installer of this product must have a good understanding of automotive
electronics, systems, and procedures.
• In the case that holes must be drilled in order to properly mount the product, the
installer must examine both sides of the mounting surface before drilling begins.
It is the installer’s responsibility to be sure that no vehicle components or vital
parts could be damaged by the drilling process. De-burr any holes in order to
remove metal shards and remnants. Use grommets in all wire passage holes.
• If this manual states that this product may be mounted with suction cups,
magnets, tape, or Velcro®, clean the mounting surface and dry thoroughly prior
to applying any adhesives for maximum adhesion.
• Do not attempt to activate or operate this product under hazardous driving
situations.
• Deployment area of the vehicle air bags must be cleared. Do not install this
product or route any electrical wires near the air bags deployment areas. Refer to
your vehicle owner’s manual for the air bag deployment area. Products or wires
mounted in the air bag deployment area will damage, reduce the effectiveness of
the air bag, or even act as a projectile which may cause serious injury or death.
The user/installer of this product assumes full responsibility in determining the
proper mounting location while prioritizing the safety of all passengers in the
vehicle.
• This product contains strobe light(s), halogen light(s), high-intensity LEDs, or a
combination of these components. Do not look directly into the lights.
Momentary blindness and/or injury to the eyes could result.
Functions of Power Adapter:
Rocker On/Off Switch w/ LED Indicator Light
- To turn unit on and off. LED indicator light illuminates red when
the unit is powered on.
Momentary Rocker Switch
- Press for a second and release to advance the unit to the next
flash pattern.
- Press and hold for 3 seconds to advance the unit to Steady
Mode.
Flash Patterns:
1. Off Mode
2. Single Burst - Split
3. Single Burst - All
4. Single Burst - Combination
5. Double Burst - Split
6. Double Burst - All
7. Double Burst - Combination
8. Quad Burst - Split
9. Quad Burst - All
10. Quad Burst - Combination
11. Single Flash - Split
12. Single Flash - All
13. Single Flash - Combination
14. Double Flash - Split
15. Double Flash - All
16. Double Flash - Combination
17. Quad Flash – Split
18. Quad Flash - All
19. Quad Flash - Combination
20. Super Flash - Split
21. Super Flash - ALL
22. Super Flash – Combination
23. Single Flash w/ Quad Burst -
Split
24. Single Flash w/ Quad Burst - All
25. Accelerator - Split
26. Accelerator - All
27. Combination Mode
28. Combination Burst Mode
29. California Steady
30. California Steady Reverse
31. Steady Mode
32. Cycle Mode
Wiring (with power adapter detached)
WANRING! All customer supplied wires that connect to the
positive terminal of the battery must be sized to supply at least
125% of the maximum operating current and FUSED at the
battery to carry that load. DO NOT USE CIRCUIT BREAKDERS
WITH THIS PRODUCT!
RED – To 12/24V Power Source
BLACK – To Chassis Ground
YELLOW – Synchronization and Pattern Selection
- Connect YELLOW of all units together to enable synchronization.
- Apply YELLOW to BLACK for a brief second will advance unit to
the next flash pattern.
- Apply YELLOW to BLACK for more than 3 seconds will advance
unit to Steady Mode.
WHITE – Group Selection (Note: group selection can only be configured
when the units are off)
- Units with its WHITE connected to the RED will be grouped
together as GROUP 1.
- Units with its WHITE NOT connected to the RED will be grouped
together as GROUP 2.
- Units of GROUP 1 and GROUP 2 will flash alternately if it’s
YELLOW are connected to each other.
Specifications:
Input Voltage: 12/24 VDC +/- 20%
Input Current: 100 – 600/50 – 300 mAPMS
Output Power: 1 – 8 WATTS

Online LED Store S2B Inc. ©2016 All Rights Reserved
Wiring Diagram (with power adapter detached):
Mounting:
AIR BAG WARNING! Do not mount this unit or route any of its wiring in the air bag deployment zone of your automobile.
Items mounted or located within the air bag deployment zone may severely impair the performance of the air bag or damage
the air bag when in use. In addition, such items may act as projectiles during the deployment of air bag with the possibility of
causing serious injury or death. Refer to your automobile’s owner’s manual for the deployment zone of the air bags. The
user/installer assumes full responsibility of determining the most safe and suitable mounting location of this product.
1. Slide the suction cups into the grooves located on the upper portion of the unit’s housing.
2. Adjust the angle adjustment lever to desired position. (refer to diagram 1 & 2 below)
3. Secure the internal light block at the angle of choice by tightening the screws located on the left and right side of the unit using a Phillips-head
(crosshead) screw driver.
Diagram 1: Diagram 2:
