Lancaster Mid-Century Table Base User manual

A
B
B
D
WWW.LANCASTERTABLEANDSEATING.COMMID-CENTURY TABLE BASE • ASSEMBLY INSTRUCTIONS WWW.LANCASTERTABLEANDSEATING.COM
36” x 36”, 30” x 48”, 30” x 60”, 30” x 72” Standard Height Tables
Mid-Century Table Base
ASSEMBLY INSTRUCTIONS
PARTS LIST:
2
D
A
F
B
STEP 2
Stand side legs up and align side legs (A) with
the other end of the cross bars (B). Using the
allen wrench (F), secure both cross bars to both
side legs with 4 bolts (D) per connection as
shown below. Do not fully tighten until step 4.
STEP 2
1. Inspect all pieces for damage before assembly. Do not assemble if any pieces are
broken or damaged. Ensure you have all required pieces before assembly.
2. Check tabletop screw length to verify compatibility with chosen tabletop.
3. Phillips head screwdriver (not included) needed to attach tabletop (power drill is
optional).
Bolts 24/PCS Tabletop Screws 4/PCS Allen Key 1/PC
NOTES:
DE F
Cross Bars 2/PCS Corner Supports 4/PCS
B C
Side Legs 2/PCS
A
Lay 1 side leg (A) on a smooth, clean surface.
Take 1 cross bar (B) and align with holes
on the top bar of side legs. Using the allen
wrench (F), secure with 4 bolts (D). Do not
fully tighten until step 4. Repeat for the
second cross bar, do not fully tighten.
A
B
STEP 1
STEP 2

WWW.LANCASTERTABLEANDSEATING.COMMID-CENTURY TABLE BASE • ASSEMBLY INSTRUCTIONS WWW.LANCASTERTABLEANDSEATING.COM
36” x 36”, 30” x 48”, 30” x 60”, 30” x 72” Standard Height Tables
Mid-Century Table Base
ASSEMBLY INSTRUCTIONS
D
E
Turn base upside down on a smooth, clean surface.
Using an allen wrench (F) and 2 bolts (D), attach
corner support (C) from cross bar to side leg. Repeat
for other 3 legs. Do not fully tighten until step 4.
Be sure to verify screw length with chosen tabletop
before installing! To attach to tabletop, turn tabletop
upside down on a smooth, clean surface. Turn table
base upside down on top of tabletop. Center base, and
secure with 4 tabletop screws (D).
C L E A N I N G & MAINTENANCE
• Periodically tighten bolts as needed.
• Wipe down table base with a damp cloth.
• Follow specific instructions for tabletop cleaning and maintenance.
STEP 3
STEP 5
Flip base right side up. Make sure base is level on flat ground, then tighten all bolts.
STEP 4
