Lancaster TRESTLE BASE User manual

2205 OLD PHILADELPHIA PIKE  LANCASTER, PA 17602
18009420412  WWW.LANCASTERTABLEANDSEATING.COM
1
4 5
2 3
44 pcs

2205 OLD PHILADELPHIA PIKE  LANCASTER, PA 17602
Gather Iron Side Top Braces (Part C) and Brace Supports (Part E) , 2 pieces each.
Secure both parts at pre-drilled holes using 2ea Button nut Screw Cap,
from the Brace Support (Part E), and 2ea Button nut from the opposite side.
Secure Button nut into Button nut Screw Cap. Repeat for second pair.
Iron Side Top Braces
Brace Support
c
E
1
25
5
5
3
x4 Button nut
x4 Button nut Screw Cap
For this step you will need:
3

18009420412  WWW.LANCASTERTABLEANDSEATING.COM
Take Connector Bar (Part D) to secure to Brace Supports (Part E).
Secure them by using Combined Screw, from Brace Support (Part E) side.
3
44
4
x2 Combined screws
For this step you will need:

Place Table Legs (Part A) into the Iron Side Top Braces (Part C), ensure the foot end of
each leg is level.
Place Iron Side Bottom Brace (Part B) down the Table Legs to meet Connector Bar
(Part D) at the pre-drilled holes.
Secure Iron Side Bottom Braces (Part B) to Connector Bar (Part D) using Button Nut
from the outside and Button nut screw cap from the opposite side. Repeat for
other side.
5
6
73
3
5
x4 Button nut
x4 Button nut Screw Cap
For this step you will need:
5

2
x16 Round Wire Cap Screws
(4 on each leg)
For this step you will need:
Secure Iron Side Bottom Brace (Part B) to Table Legs (Part A) by using Round Cap
Wire Screws at the pre-drilled holes.
8
2
2
2
x16 Round Wire Cap Screws
(4 on each leg)
For this step you will need:
2
Then use Round cap Wire Screws to secure Iron Side Top Brace (Part C) from the sides.
9
2

x4 Footpads
For this step you will need:
Place and secure Adjustable Footpad to bottom of the Table Base Legs (Part A).1
10 1
2
x4 Round Wire Cap Screws
For this step you will need:
Next, turn base right side up. Secure legs to Iron Side Top Brace (Part C) using Round Cap
Wire Screws .
11
2

Place Table Top on top of Iron Side Top Braces (Part C)
Secure by using Round Cap Wire Screws from underneath the top
12
13 2
x8 Round Cap Wire Screws
For this step you will need:
