PRESSURE WASHERS
®
OPERATOR’S MANUAL
LANDA, INC. ■ 4275 N.W. Pacific Rim Blvd. ■ Camas, WA 98607 ■ USA
For technical assistance or the Landa Dealer nearest you, call 800-LANDA-4-U (800-526-3248) or [phone]
or consult our web page at www.landa.com
■ZF2-10021D
ZF

CONTENTS
2
ZF Manual •Form #96-6072 •Revised 9/02
Model Number ______________________________
Serial Number ______________________________
Date of Purchase ____________________________
The model and serial numbers will be found on a decal attached to
the pressure washer. You should record both serial number and
date of purchase and keep in a safe place for future reference.
Introduction ...................................................................................................................................3
Important Safety Information .....................................................................................................3, 5
Component Identification ..............................................................................................................4
Pre-Operation Check ....................................................................................................................5
Set-Up Procedures ....................................................................................................................... 5
Operating Instructions ...................................................................................................................5
How to Use the Multireg Nozzle ....................................................................................................6
Nozzle Installation .........................................................................................................................6
Cleaning and Changing Nozzle .....................................................................................................6
General Washing Techniques........................................................................................................ 7
Shut Down Procedures .................................................................................................................7
How to Use the Detergent Injector ................................................................................................8
Checking and Changing Oil ..........................................................................................................9
Checking the Water Filter ............................................................................................................. 9
Precautions Against Freezing .......................................................................................................9
Quick Lance, Exploded View and Parts List ................................................................................10
Multireg Nozzle, Exploded View and Parts List ...........................................................................10
Shut-Off Gun, Exploded View and Parts List ............................................................................... 11
Wiring Diagram ...........................................................................................................................12
Troubleshooting .......................................................................................................................... 13
Pump Oil Change Record ........................................................................................................... 14
Warranty .....................................................................................................................................15
Spanish.................................................................................................................................. 16-22

ZF SERIES PRESSUREWASHER OPERATOR’S MANUAL
3
LANDA ZF •REV. 9/02
INTRODUCTION
Thank you for purchasing a Landa Pressure Washer.
This manual covers the operation and maintenance of
the ZF2-10021D washer. All information in this manual
is based on the latest product information available at
the time of printing.
Landa, Inc. reserves the right to make changes at any
time without incurring any obligation.
The ZF Series was designed for maximum
use of 1 hour per day, 5 days per week.
Owner/User Responsibility:
The owner and/or user must have an understanding of
the manufacturer’s operating instructions and warnings
before using this Landa pressure washer.Warning infor-
mation should be emphasized and understood. If the op-
erator is not fluent in English, the manufacturer’s instruc-
tions and warnings shall be read to and discussed with
the operator in the operator’s native language by the pur-
chaser/owner, making sure that the operator compre-
hends its contents.
Owner and/or user must study and maintain for future
reference the manufacturers’instructions.
This manual should be considered a permanent
part of the machine and should remain with it if
machine is resold.
When ordering parts, please specify model and
serial number.
IMPORTANT SAFETY
INFORMATION
CAUTION: To reduce the risk of
injury, read operating instruc-
tions carefully before using.
1. Read the owner's manual thor-
oughly.Failure to follow instruc-
tions could cause malfunction
of the pressure washer and re-
sult in death, serious bodily in-
jury and/or property damage.
2. Know how to stop the machine and bleed pressures
quickly. Be thoroughly familiar with the controls.
3. Stay alert — watch what you are doing.
4. All installations must comply with local codes. Con-
tact your electrician, plumber, utility company or the
selling distributor for specific details.
To comply with the National Electrical code (NFPA
70) and provide additional protection from risk of elec-
tric shock, this pressure washer is equipped with a
UL-approved ground fault circuit interrupter (GFCI)
power cord.
WARNING: Flammable liquids
can create fumes which can ignite
causing property damage or se-
vere injury.
5. Risk of explosion — do not
spray flammable liquids or op-
erate in an explosive location.
WARNING: Keep water spray
away from electric wiring or fatal
electric shock may result. Read
warning tag on electrical cord.
6. To protect the operator from
electrical shock, the machine
must be electrically grounded.
It is the responsibility of the
owner to connect this machine
to a UL grounded receptacle of proper voltage and
amperage ratings. Do not spray water on or near
electrical components. Do not touch machine with
wet hands or while standing in water. Always dis-
connect power before servicing.
7. Grip cleaning wand securely with both hands before
starting the cleaner. Failure to do this could result in
injury from a whipping wand.
WARNING:Equipment can produce
a high pressure stream of fluid that
can pierce skin and its underlying
tissue,leading to serious injury and
possible amputation.
8. High pressure developed by
these machines can cause
bodily injury or damage. Use
caution when operating. Do not
point the spray gun at anyone
or at any part of the body.
9. Never make adjustments on machine while in op-
eration.
WARNING: High pressure spray
can cause paint chips or other
particles to become airborne and
fly at high speeds.
10. Eye safety devices must be worn
when using this equipment.
WARNING
KEEP WATER SPRAY
AWAY FROM
ELECTRICAL
WIRING.
WARNING
RISK OF EXPLOSION:
DO NOT USE WITH
FLAMMABLE
LIQUIDS.
WARNING
HIGH PRESSURE
STREAM CAN
PIERCE SKIN AND
TISSUES.
WARNING
USE PROTECTIVE
CLOTHING WHEN
OPERATING.
WARNING
READ OPERATOR’S
MANUALTHOROUGHLY
PRIORTO USE.
CAUTION

4 ZF SERIES PRESSUREWASHER OPERATOR’S MANUAL
LANDA ZF •REV. 9/02
COMPONENT IDENTIFICATION
ITEM PART NO. DESCRIPTION
1 1-36258470 Inlet Hose Connection
w/Water Filter (Inlet)
2 1-10014770 Nipple, Unloader Discharge
ZF Unit
3 1-36258351 Pressure Adjusting Knob
4 1-36258601 Pressure Indicator Gauge
1-94871800 Pressure Indicator Gauge Clip
1-36257751 Pressure Indicator Gauge Cover
1-36257851 Pressure Indicator Gauge Needle
9
ITEM PART NO. DESCRIPTION
5 1-93502700 ON/OFF Switch
6 1-ZOFILKIT Detergent Hose with Strainer
7 4-0111431 Fix Up
8 1-98209700 Oil Dipstick
9 1-97596800 Oil Level Indicator
10 4-012191 Trigger Spray Gun
11 4-011129 Quick Lance, 20"
12 4-2010 Multireg Nozzle
13 4-02011225 High Pressure Hose, 1/4" x 25'
7
6
12
1
4
25
8
3
11 10
13

ZF SERIES PRESSUREWASHER OPERATOR’S MANUAL
5
LANDA ZF •REV. 9/02
11. When the machine is working, do not cover or place
in a closed space where ventilation is insufficient.
12. Machines with shut-off spray guns should not be op-
erated with the spray gun in the off position for ex-
tended periods of time as this may cause damage
to the pump.
13. Protect from freezing.
14. Be certain all quick coupler fittings are secured be-
fore using pressure washer.
15. Do not allow acids, caustic or abrasive fluids to pass
through the pump.
16. Inlet water must be from a cold fresh water supply.
17. Do not allow CHILDREN to operate the pressure
washer at any time.
18. The best insurance against an accident is precau-
tion and knowledge of the machine.
19. Landa will not be liable for any changes made to our
standard machines or any components not pur-
chased from Landa.
PRE-OPERATION CHECK
❏ Pump oil (SAE 30W non-detergent oil, General)
❏ Cold water supply ( 6 gpm, 5/8", 20 psi)
❏ Hose, wand, nozzle (nozzle size per serial plate)
❏ Water filter (intact, non restrictive)
SET-UP PROCEDURES
1. Put teflon tape on the inlet fitting (about 3 wraps).
Screw on 3/4" garden hose swivel provided in bag.
Attach a 5/8" garden hose to inlet connector. Mini-
mum flow should be 3 gpm.
2. Attach high pressure hose by screwing hose con-
nector to pressure washer outlet, hand tight.
3. Assemble the wand by pushing the two halves to-
gether and then fix by turning the connector to
tighten.
4. Connect wand to trigger gun by turning the connec-
tor. Attach high pressure hose to trigger gun and
tighten.
5. Remove red oil plug on top of pressure washer and
replace with dipstick supplied. Remove plug from red
oil cap anytime the pressure washer is running.
6. Check oil level on sight glass on left side of pressure
washer. Oil level should be visible half way up the
sight glass (30 wt. non-detergent). If oil level is not
visible as described, add oil as needed.
OPERATING INSTRUCTIONS
1. With power switch in OFF position, plug power cord
into a grounded receptacle of proper voltage and
amperage reading. Then push GFCI reset button at
end of power cord if required.
2. Turn on water at faucet and pull trigger on spray gun
allowing water to flow until all air has discharged from
system. Check for water leaks; tighten as needed.
3. With trigger spray gun off, turn power switch to ON
position and check for leaks.
Step 1: Connect water suction hose to the INLET
connector. We recommend the use of a reinforced
suction hose with internal diameter not less than
13mm. (1/2 inch)
Step 4: Connect one end of the high pressure
hose to the spray gun (A) and the other to the
outlet connection (B). Assemble lance by
pushing the two halves together and then fix
by turning the connector.
Step 5: Replace the red oil
travel plug (1) with the black and
yellow dipstick (2) in the bag.
Step 6: Check
that the oil
level in the
sight glass is
at the halfway
level.
