Landscape Forms Connect 2.0 User manual

Includedcomponents:
ToolsRequired
•Safetyglasses
•protectivepadding
•9/16”socketwrench
•3/4”openend/12pt boxendwrenches
•3/16”hexkey
•3/32”hexkey
•4ftlevel
•ladder
•properpersonnelforliftingassembledframecomponents
Installation Guide
Connect 2.0 Shelter, Frame assembly
www.landscapeforms.com Ph: 800.521.2546
Date: November 6, 2018
Page 1 of 2
8ft 12ft
Rearhorizontal,8ft:1included
Rearhorizontal,forbackglass
Rearhorizontal,fornoglass
Bracketforwallpanel
Bracketforwallpanel
Rearhorizontal,forbackglass
Rearhorizontal,fornoglass
Rearhorizontal,12ft:1included
Light
location
FRONT
LEFT
FRONT
RIGHT
REAR
LEFT
REAR
RIGHT
Fronthorizontal,8ft:1included
Fronthorizontal,fornoglass
Fronthorizontal,forfrontglass
Bracketforwallpanel
Uplight
Bracketforwallpanel
Uplight
Fronthorizontal,fornoglass
Fronthorizontal,forfrontglass
Fronthorizontal,12ft:1included
RAFTER
8FT–3X
12FT–4X
RIGHTRAFTER
COVER
8FT–3X
12FT–4X
LEFTRAFTER
COVER
8FT–3X
12FT–4X
NOTCH
FOOTCOVERPLATE
–4X
3/8‐16x1‐1/2”
FLANGEDHD–8X
(horizontals)
3/8‐16x1”HEXHD
– 16X
(rafters)
3/8WASHER
‐16X
(rafters)
¼‐20x3/4”
SHCS– 16X
(raftercovers)
¼‐20x1/2”
SHCS– 24X
(verticalfillers)
#8‐32x5/16”
SBHCS– 24X
(rafterlights)
ASSEMBLEWITHCARE! Pangard IIPolyesterPowdercoat isastrong,long‐lastingfinish.Toprotectthisfinishduringassembly,place
unwrappedpowdercoated partsonpackagingfoamorothernon‐marringsurface.Donotplaceorslidepowdercoated partson
concreteorotherhardortexturedsurface– thiswilldamagethefinishcausingrusttooccur.Usetouch‐uppaintonanygougesinthe
finishcausedbyassemblytools.
1. Anchorkitinstallation
2. Frameassembly
3. Roofassembly
4. Wallglassassembly
5. Wiringconnections
Orderofoperations:

Installation Guide
Connect 2.0 Shelter, Frame assembly
www.landscapeforms.com Ph: 800.521.2546
Date: November 6, 2018
Page 2 of 2
LandscapeFormsisnotresponsibleforsitepreparationandfootings.
Minimum6”thick 4000psiconcreteslabisrecommended.Threadedanchorsallow
for2‐3/8”ofadjustabilityforslope.
WARNING!SHELTERMUSTBESECURELYANCHORED.
INSTALLATION:Note:fronthorizontalbeamhasuplights installed.Frontverticalshave
pocketsforLEDlightsnearthebaseandaretallerthantherearverticals.Shelterswithback
and/orfrontglasswillhavebracketsweldedtothehorizontalbeams.
1. Onprotectivepadding,setfrontverticalsinapproximateposition.Placefronthorizontal
inposition.Removeaccesscoversfromhorizontalbeam.
2. Usingflangeheadscrews,attachhorizontalbeamtoverticals.SeeFig.1.Donot
overtighten.
3. Liftfrontframeassemblyintopositionoveranchors.
4. Installwashersandnuts,seeFig.2.Donotovertighten.
5. Checklevelofverticalpostsonfrontandsidefaces.Adjustlevelingnutsasnecessary.
6. Repeatforrearverticalsandhorizontalassembly.
7. Installraftersusing3/8”washersandhexheadscrews,seeFig.3.Frontofrafteris
indicatedonpart,seeFig.3.Handtighten.
8. Onceallraftersareinstalledandunitisleveledandcheckedforsquare,fullytightenall
hardware.
9. Ifshelterdoesnothaveanywallpanels,theverticalfillerstripsshouldbeinstalled.The
frontfillerstripsaretallerthantherearstrips.Installeachonewith(3)¼‐20x½”socket
headcapscrews,seeFig.3.
10. Raftercoversandfootcoverplateswillbeinstalledafterwiringconnectionshavebeen
completed.
11. ProceedtoRoofInstallationGuide.
FRONTLEFT
VERTICAL
FRONTRIGHT
VERTICAL
(4)3/8‐16x1‐
1/2”FLANGED
HEADSCREWS
ACCESS
COVER
FRONT
HORIZONTAL
Fig.1– assemblehorizontalbeamtoverticals
FRAME
ASSEMBLY
INSTALLED
THREADEDROD
Fig.2–Installframeoveranchors
HEXNUT
WASHER
LEVELINGNUT
ANDWASHER
3/8‐16x1”HEX
HDSCREW
FRONT
INDICATOR
FRONT
RIGHT
VERTICAL
Fig.3– assemblehorizontalbeamtoverticals
3/8”WASHER
RAFTER
REAR
LEFT
VERTICAL
VERTICAL
FILLER
STRIP
