Lantronix S3100 Series User manual

S3100 Series
Stand-alone Fiber to Fiber Media Converter SFP to SFP for Data
Rates from 100Mbps to 2.5Gbps
Install Guide
Part Number 33581
Revision C August 2023

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 2 of 19
Intellectual Property
© 2023 Lantronix, Inc. All rights reserved. No part of the contents of this publication may be transmitted or
reproduced in any form or by any means without the written permission of Lantronix.
Lantronix is a registered trademark of Lantronix, Inc. in the United States and other countries. All other
trademarks and trade names are the property of their respective holders.
Patented: https://www.lantronix.com/legal/patents/; additional patents pending.
Warranty
For details on the Lantronix warranty policy, go to http://www.lantronix.com/support/warranty.
Contacts
Lantronix Corporate Headquarters
48 Discovery, Suite 250
Irvine, CA 92618, USA
Toll Free: 800-526-8766
Phone: [phone]
Fax: [phone]
Technical Support
Online:https://www.lantronix.com/technical-support/
Sales Offices
For a current list of our domestic and international sales offices, go to the Lantronix web site at
www.lantronix.com/about/contact.
Disclaimer
All information contained herein is provided “AS IS.” Lantronix undertakes no obligation to update the
information in this publication. Lantronix does not make, and specifically disclaims, all warranties of any
kind (express, implied or otherwise) regarding title, non-infringement, fitness, quality, accuracy,
completeness, usefulness, suitability or performance of the information provided herein. Lantronix shall
have no liability whatsoever to any user for any damages, losses and causes of action (whether in
contract or in tort or otherwise) in connection with the user’s access or usage of any of the information or
content contained herein. The information and specifications
contained in this document are subject to change without notice.
Revision History
Date
Rev
Description
09/19/14
A
Initial release for v 1.2.
7/24/23
B
Clarify “CLI access” references in the manual. Initial Lantronix re-brand.
8/31/23 C
FW v 2.0.3; clarify management support and features set. Minor technical and
editorial changes.

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 3 of 19
Contents
Product Description....................................................................................................................................... 4
Ordering Information ..................................................................................................................................... 4
Features ........................................................................................................................................................ 5
Management Features .................................................................................................................................. 5
Manual Overview .......................................................................................................................................... 5
Related Manuals and Online Help ................................................................................................................ 5
Application Example...................................................................................................................................... 6
Pre-Installation .............................................................................................................................................. 7
Safety........................................................................................................................................................ 7
Unpacking ................................................................................................................................................. 7
Package Contents .................................................................................................................................... 7
Installation and Setup.................................................................................................................................... 8
General ..................................................................................................................................................... 8
Install the S3100 ....................................................................................................................................... 8
Installing SFP Devices.............................................................................................................................. 9
Cabling.................................................................................................................................................... 10
Power Connection .................................................................................................................................. 11
Operation..................................................................................................................................................... 12
Power and Fiber Status LEDs ................................................................................................................ 12
Product Features .................................................................................................................................... 13
Technical Specifications.............................................................................................................................. 14
Troubleshooting .......................................................................................................................................... 15
Procedure ............................................................................................................................................... 15
Product and Packaging Labels ............................................................................................................... 15
Compliance Information .............................................................................................................................. 16
Declaration of Conformity ....................................................................................................................... 16
FCC Regulations .................................................................................................................................... 16
Canadian Regulations ............................................................................................................................ 16
European Regulations ............................................................................................................................ 17
Electrical Safety Warnings .......................................................................................................................... 18

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 4 of 19
Product Description
Lantronix ION x3100 is an SFP-to-SFP fiber repeater with two SFP ports for direct physical connection
back to back. The x3100 performs signal reamplify (1R) signal regeneration. The x3100 also supports:
•CWDM Wavelength transponder, general wavelength to specific wavelength.
•Connections between different types of fiber, such as SM-to-MM.
•Fiber repeater; MM-to-MM or SM-to-SM.
The x3100 can be used in telecom and enterprise applications where 100Mb - 2.5Gb links require fiber
extension or where 100Mb - 2.5Gb links require an interface between two fiber networks.
The x3100 performs a variety of protocol transparent services; it supports virtually any protocol from
100Mbps to 2.5Gbps. The x3100 can inter-connect with another x3100 and can support:
•100Mb (FE/FDDI)
•1.25Gb (GE)
•150Mb (ION x6120 and 6010)
•200Mb (ESCON/SBCON)
•155/622Mb (OC-3/12)
•2488Mb (OC-48)
•2.500Gb (2.5 InfiniBand/PCI-E)
•1.06/2.12 (2/1 GFC)
The x3100 is a “similar rate” to “similar rate” converter with no rate conversions. The x3100 is protocol
independent. Rate configuration is not required. LPT is always enabled.
Ordering Information
SKU
Description
C3100-4040
100Mbps to 2.5Gbps fiber repeater with two open SFP slots, any-rate to same-
rate. ION Chassis slide-in card media converter.
S3100-4040
100Mbps to 2.5Gbps Standalone fiber repeater with two open SFP slots, any-
rate to same-rate stand-alone media converter.
Optional Accessories
Sold separately.
SFP Modules
SFP and SFP+ modules supported; see the Lantronix SFP product page.
WMBL
Wall Mount Bracket 4” [102 mm]
WMBD
DIN Rail Bracket 5” [127 mm]
E-MCR-05
12-Slot Media Converter Rack
RMS19-SA4-02
4-Slot Media Converter Shelf
Power Supply included: to order the corresponding country specific power supply, add one of these
extensions to the end of the SKU. For example, S3100-4040-NA, where -NA = North America, -LA = Latin
America, -EU = Europe, -UK = United Kingdom, -SA = South Africa, -JP = Japan, -OZ = Australia, and
-BR = Brazil.
Lantronix SFP modules fully comply with Multi-Sourcing Agreement (MSA) as described at
https://www.lantronix.com/products-class/sfps/.

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 5 of 19
Features
•Supports various physical media types
•Fiber repeater, performs 1R signal regeneration
•DMI (Diagnostic Monitoring Interface)
•Link pass through
•Auto link restore
•No packet size limitation
Management Features
Manageable C3100 features are available when used in an ION chassis with an ION Management
Module (IONMM) including:
•Provides port link statistics (C3100 only).
•Supports Digital Diagnostics (DMI) on both ports.
•Link-pass-through (LPT) is always on and cannot be disabled.
Manual Overview
The purpose of this manual is to provide the information needed to install the S3100 to the point of
operation. Note that there is a separate install guide for the C3100. Transition Networks is now Lantronix.
Some products/firmware items are still in process of being re-branded and may still reflect the Transition
Networks name/logo.
Related Manuals and Online Help
A printed documentation card is shipped with each x3100 device. Context-sensitive Help screens, as well
as cursor-over-help (COH) facilities are built into the Web interface. For Lantronix Drivers, Firmware,
Manuals, Product Notifications, Warranty Policy & Procedures, etc. go to the Lantronix Technical
Resource Center. Note that this manual provides links to third party web sites for which Lantronix is not
responsible. Other ION system and related device manuals are listed below.
1. Product Documentation Postcard, 33504
2. ION C3100 Install Guide, 33580
3. ION S3100 Install Guide, 33581 (this manual)
4. ION x3100 Web User Guide, 33582
5. ION x3100 CLI Reference, 33583
6. Release Notes (firmware version specific)
Note: Information in this document is subject to change without notice. All information was deemed
accurate and complete at the time of publication. This manual documents the latest software/firmware
version. While all screen examples may not display the latest version number, all of the descriptions and
procedures reflect the latest software/firmware version, noted in the Record of Revisions on page 2.

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 6 of 19
Application Example
Lantronix ION x3100 is a SFP-to-SFP fiber repeater with two SFP ports for direct physical connection.
The x3100 performs signal reamplify (1R) signal regeneration.The x3100 can be used in telecom and
enterprise applications where 100Mb - 2.5 GB links require fiber extension or where 100Mb - 2.5Gb links
require an interface between two fiber networks.The x3100 performs a variety of protocol transparent
services; it supports virtually any protocol from 100Mbps to 2.5Gbps.
This fiber to fiber converter is a protocol independent device that supports data rates from 100Mbps up to
2.5 Gbps. It provides reliable and cost-effective conversion between single mode and multimode fiber,
while also providing wavelength conversion in CWDM applications. As an SFP based device, this any-
rate to similar-rate converter offers great application flexibility. Supported protocols, fiber connectors, and
transmission distances are determined by the SFP module used on the converter.
Figure 1: Network Scenarios

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 7 of 19
Pre-Installation
CAUTION: Observe electrostatic discharge precautions when handling the S3100. Failure to observe this
caution could result in damage or failure of the S3100.
Safety
Before installing the S3100, read these “Safety Cautions” and ensure that the requirements noted are
met. During installation and maintenance, avoid direct exposure to laser beams. Specifically, do not look
into laser ports. Ensure that each SFP port at which laser beams are (or will be) present is occupied by
an SFP that is locked in position. See the related SFP manual for details.
See "Electrical Safety Warnings" on page 18 for Electrical Safety Warnings translated into multiple
languages.
Unpacking
1. Carefully unpack all S3100 contents.
2. Verify receipt of all S3100 components; see “Package Contents” below.
3. Place the S3100 and related materials in the desired install location.
4. Save the S3100 shipping carton and packing materials for future use.
Package Contents
The S3100 is shipped with some standard and some optional components. Make sure you have received
the following standard items:
One S3100 device
One AC Power Cord/Adapter
One printed Product Documentation postcard

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 8 of 19
Installation and Setup
General
This section describes how to install the S3100 and the procedures to access and initially set it up via
either a local serial interface (USB) or a remote Ethernet connection (Telnet session or Web interface).
Install the S3100
The S3100 is a standalone module. The following section describes how to install the S3100.
Caution: Failure to observe electrostatic discharge precautions when installing the S3100 could
result in damage or failure of the module.
Figure 2: Installation
1. Locate the S3100 in its final install location.
2. Install SFP Devices in PORT 1 and PORT 2. See “Installing SFP Devices” below.
3. Perform cabling from the S3100.
4. Make the Power Connection. See the “Power Connection” section below.

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 9 of 19
Installing SFP Devices
The S3100 lets you install SFP devices of choice to make a fiber connection. The S3100 has two SFP
ports as shown below.
SFP Optical Transceivers
Lantronix SFP devices are small form factor, hot-pluggable transceivers which allow for a single piece of
network equipment to be connected to a multitude of interfaces, protocols, and transmission media via
the SFP port. All of Transition’s SFPs devices are compliant with the Multi-Sourcing Agreement (MSA)
ensuring interoperability with all other MSA compliant networking devices.
The SFP module used defines the fiber length and type that can be used. Identical SFP modules must be
used at each end of a link for each port on the device.
Figure 3: Port Locations and SFP Installation
To install an SFP device in the S3100:
1. Position the SFP device at either installation slot, with the label facing up.
2. Carefully slide the SFP device into the slot, aligning it with the internal installation guides.
3. Ensure that the SFP device is firmly seated against the internal mating connector.
4. Connect the fiber cable to the fiber port connector of the SFP device.
See the Lantronix SFP webpage web page for the latest information.

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 10 of 19
Cabling
The x3100 can be used in telecom and enterprise applications where 100Mb - 2.5Gb links require fiber
extension or where 100Mb - 2.5Gb links require an interface between two fiber networks.
The x3100 performs a variety of protocol transparent services; it supports virtually any protocol from
100Mbps to 2.5Gbps.
Figure 4: C3100-to-S3100 Connection
The figure above shows cabling a C3100 to an S3100. The procedure is provided below.
1. Locate a fiber cable with male, two-stranded TX to RX connectors installed at both ends. See “Cable
Specifications” on page 27 for details.
2. Connect the fiber cable to the SFP fiber port (Port 2 labeled SFP) on the S3100:
•Connect the male TX cable connector to the female TX connector.
•Connect the male RX cable connector to the female RX connector.
3. Connect the fiber cables to the SFP fiber port on the other device (C3100):
•Connect the male TX cable connector to the female RX connector.
•Connect the male RX cable connector to the female TX connector.
Figure 5: Fiber Connection

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 11 of 19
Power Connection
The S3100 ships with a power supply module that provides power via a barrel connector to the S3100
power receptacle.
Figure 6: Power Connection
Make the power connection as described below.
1. Plug the power supply’s barrel connector into the standalone module as shown above..
2. Plug the power supply’s cord into a live AC power outlet.
3. Verify that the green P(Power) LED lights.

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 12 of 19
Operation
Power and Fiber Status LEDs
The status LEDs (labeled PWR and LINK are shown below. Use the status LEDs to monitor S3100
operation in the network.
Figure 7: Power and Fiber Status LEDs
The Power and Fiber Status LEDs are described below.
LED Label
Meaning
Operation
PWR
Power Green ON for power applied to board.
PORT 1
LINK LED SDF Fiber Status 1 On = Fiber Signal Detected.
Off = Fiber Signal Not Detected.
PORT 2
LINK LED
SDF Fiber Status 2 On = Fiber Signal Detected.
Off = Fiber Signal Not Detected.

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 13 of 19
Product Features
The features described and illustrated in this section include:
•Link Pass through
Link Pass Through (LPT)
This function causes loss of link on one side of a media converter to be passed through to the other side,
so that upstream equipment can see fault conditions that would otherwise be hidden by the media
converters.
The LPT feature allows the Device to monitor the Fiber RX (receive) ports for loss of signal. For example,
when the Fiber #1 link on the near end device is lost (1), the local Device turns off the fiber transmit on
Fiber #2 (2), thus, “passing through” the link loss. The remote Device disables the Fiber #1 link to the far-
end device (3), which prevents the loss of valuable data unknowingly transmitted over an invalid link.
Note that although the link from local fiber #2-Tx to remote #2-Rx is disabled, the link from remote #2-Tx
to local #2-Rx is still alive (4). The LPT process is illustrated in the figure below.
Figure 9: Link Pass Through (LPT)
Local
Media
Converter
Remote
Media
Converter
①
②
④ ③
Near-End
Device
Far-End
Device
Original fault on the Port-1
Local converter turns off the
fiber transmit on port-2
remote converter
disables its Port-1
This direction of link still
valid
#1
#2-Tx #2-Rx
#1
#2-Rx #2-Tx

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 14 of 19
Technical Specifications
Standards IEEE802.3ae / ITU.G.709 / SFF8431
Multi-Source Agreement (MSA) Small Form Factor Pluggable (SFP)
Max. Frame Size 16384 bytes jumbo frame support
Data Rate 100 Mbps - 2.5 Gbps; Data Rates Protocol Independent
Dimensions Width: 3.25 inches (82 mm)
Depth: 6.5 inches (165 mm)
Height: 1.0 inches (25 mm)
Status LEDs PWR: ON (Green) = Power
Port 1 Link: ON = Fiber Signal Detected
Port 2 Link: ON = Fiber Signal Detected
Power Supply External AC/DC required: 12VDC Output; 120-240VAC input
Power Consumption 1.05W + SFP modules
Operating Temperature 0 to 50 degrees C
Storage Temperature -40 to +85 degrees C
Altitude 0-10,000 feet
Operating Humidity 5% to 95% (non-condensing)
Shipping Weight 2 lbs. (0.90 kilograms)
MTBF Greater than 250,000 hours (MIL-HDBK-217F)
Greater than 687,000 hours (Bellcore)
Regulatory Compliance for:
Emission FCC Class A; EN55022 Class A
Immunity EN55024
Safety Compliance CE Mark
NDAA Compliant
TAA Compliant
Warranty: Lifetime
The information in this manual is subject to change. For the latest information, see the online manual at
https://www.lantronix.com/.
WARNING: Visible and invisible laser radiation when open. DO NOT stare into the beam or view the
beam directly with optical instruments. Failure to observe this warning could result in an eye injury or
blindness.
WARNING: Use of controls, adjustments or the performance of procedures other than those specified
herein may result in hazardous radiation exposure.

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 15 of 19
Troubleshooting
Procedure
1. Is the PWR (power) LED lit?
NO
• Is the S3100 inserted properly into the chassis?
• Is the power cord properly installed in the S3100 and in the grounded AC outlet?
• Does the grounded AC outlet provide power?
• Contact Tech Support.
YES
• Proceed to step 2.
2. Is the LINK LED lit?
NO
• Check that the SFP device is supported and properly connected. See “Installing SFP Devices”
on page 9.
• Check the fiber cables for proper connection.
• Re-seat the SFPs. Note that with two copper SFP modules are used in the converter, no link is
established. At least one of the two SFPs must be a fiber SFP.
• Verify that the cable specs are met. See “Cable Specifications” on page 27.
• Contact Tech Support.
Product and Packaging Labels
The product and packaging labels provide valuable information that you can provide to help the Technical
Support Specialist in solving a problem.
Product Label Packaging Label

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 16 of 19
Compliance Information
Declaration of Conformity
Manufacture’s Name: Lantronics, Inc.
Manufacture’s Address: 48 Discovery, Suite 250, Irvine, California 92618 USA
Declares that the product(s):
C3100-4040
S3100-4040
Conforms to the following Product Regulations:
FCC Part 15 Class A; EN55022-2010
EN55024-2010; Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
IEC/EN 60950-1
With the technical construction on file at the above address, this product carries the CE Mark
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s)
and Standard(s).
Place: Irvine, California
Date: April 27, 2022
Signature:Eric Bass
Full Name: Eric Bass
Position: Vice President of Engineering
FCC Regulations
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which case the
user will be required to correct the interference at the user's own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set out on
the radio interference regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de la lass A prescrites dans le Règlement sur le brouillage radioélectrique
édicté par le ministère des Communications du Canada.

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 17 of 19
European Regulations
Warning
This is a Class A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
Achtung !
Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb dieses
Gerätes Rundfunkstörungen auftreten. In diesem Fäll ist der Benutzer für Gegenmaßnahmen
verantwortlich.
Attention !
Ceci est un produit de Classe A. Dans un environment domestique, ce produit risque de créer des
interférences radioélectriques, il appartiendra alors à l'utilsateur de prende les measures spécifiques
appropriées.
In accordance with European Union Directive 2002/96/EC of the European Parliament and of
the Council of 27 January 2003, Lantronix will accept post usage returns of this product for
proper disposal. The contact information for this activity can be found in the 'Contact Us'
portion of this document.
CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE PUBLIC
TELEPHONE NETWORK. Failure to observe this caution could result in damage to the public telephone
network.
Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EGMitgliedstaaten
verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der
Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über
Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 18 of 19
Electrical Safety Warnings
Electrical Safety
IMPORTANT: This equipment must be installed in accordance with safety precautions.
Elektrische Sicherheit
WICHTIG: Für die Installation dieses Gerätes ist die Einhaltung von Sicherheitsvorkehrungen
erforderlich.
Elektrisk sikkerhed
VIGTIGT: Dette udstyr skal 18nstallers I overensstemmelse med sikkerhedsadvarslerne.
Elektrische veiligheid
BELANGRIJK: Dit apparaat moet in overeenstemming met de veiligheidsvoorschriften worden
geïnstalleerd.
Sécurité électrique
IMPORTANT : Cet équipement doit être utilisé conformément aux instructions de sécurité.
Sähköturvallisuus
TÄRKEÄÄ : Tämä laite on asennettava turvaohjeiden mukaisesti.
Sicurezza elettrica
IMPORTANTE: questa apparecchiatura deve essere installata rispettando le norme di sicurezza.
Elektrisk sikkerhet
VIKTIG: Dette utstyret skal 18nstallers I samsvar med sikkerhetsregler.
Segurança eléctrica
IMPORTANTE: Este equipamento tem que ser instalado segundo as medidas de precaução de
segurança.
Seguridad eléctrica
IMPORTANTE: La instalación de este equipo deberá llevarse a cabo cumpliendo con las precauciones
de seguridad.
Elsäkerhet
OBS! Alla nödvändiga försiktighetsåtgärder måste vidtas när denna utrustning används

Lantronix S3100 Install Guide
33581 Rev. C https://www.lantronix.com/ Page 19 of 19
Lantronix Corporate Headquarters
48 Discovery, Suite 250
Irvine, CA 92618, USA
Toll Free: 800-526-8766
Phone: [phone]
Fax: [phone]
Technical Support
Online: https://www.lantronix.com/technical-support/
Sales Offices
For a current list of our domestic and international sales offices, go to the Lantronix web site at
www.lantronix.com/about/contact.
