lap 775PG Manual

Instruction leaflet
Dotless LED 5 Mtr Tape Kit
775PG, 989PG
For your safety, always switch off the supply before changing adjusting or cleaning.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice. The packaging on this product can also be recycled.
Recycling advice
Safety information
26/05/2021
UK Manufacturer:
Kingfisher International Products Limited,
3 Sheldon Square, London, W2 6PX,
United Kingdom.
EU Manufacturer:
Kingfisher International Products B.V.
Rapenburgerstraat 175E,
1011 VM Amsterdam, The Netherlands.
• Plug in and test.
• Peel the adhesive backing off of the strips
and stick in place.
• Your strip is now ready for use.
Commissioning
Fig. 4
5000
10
24V-
24V+
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V+ 24V+
24V- 24V- 24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and satisfactory
operation of this product. Please retain these instructions for future reference.
Warning
Specification
Dimensions: 10mm wide, 1.6mm high, 5m long
Voltage: 240-240V~50/60Hz
Wattage: 22W
Lumens: 775PG 1700 lm, 989PG 1800 lm
IP rating: 20
Kit Contents
• This is a self contained kit and cannot be extended.
• The LEDs are mounted on an adhesive tape which
can be stuck to most surfaces.
• The LED strip can be shortened to a minimum of 100mm.
• Avoid locating any cables in positions that would
cause a hazard.
• Position cables and LEDs away from areas where
they may be at risk from being cut, trapped or
damaged.
• This product has no special protection against
the ingress of moisture.
Layout
Basic Installation
• Position the plug and in-line LED driver next to the
indoor mains outlet socket that the system will
connect to. Do not plug-in at this stage.
• After deciding the layout of the LED strip, ensure that
the cable is not snagged when in the desired position.
• It is possible for the LED strip to be shortened.
This can be done to a minimum of 100mm.
Look for the line on the strip with four copper pads
with scissors symbol, as shown below in Fig. 1.
• Cut using a sharp pair of scissors. Do not cut
anywhere else on the strip as this may cause
the LED strip to stop working.
• To connect the connection/corner cable, ensure
the polarity is correct; '+' to the black cable Fig. 2.
Push strip firmly into connector ensuring copper pads
contact metal tabs. Push metal tabs down to lock.
This kit contains:
• 1 x in-line LED driver with 1.5m Output cable,
UK 3 Pin Plug with 0.5m mains cable.
• 1 x 5000mm strip with SMD 2128 LEDs.
• 3 x connection/corner cable
This product is Double Insulated and does
not require connection to an Earth circuit.
The LED strips are Safety Extra Low Voltage
and must not be earthed.
Please read these instructions carefully before
commencing any work.
This unit must be fitted by a competent and
qualified electrician.
Install in accordance with IEE Wiring regulations
and current Building Regulations.
This system operates at Safety Extra Low Voltage
(12V), via a LED driver. Never connect the light
fittings directly to the mains without using
the supplied LED driver.
Do not exceed the LED driver load. LED drivers may
require a minimum load to operate.
Always disconnect the LED driver from the mains
when installing or maintaining this system.
This system contains non-replaceable parts and cannot be
serviced. If damage occurs the part should be scrapped.
This product cannot be dimmed.
This product is rated at IP20 and must be situated
indoors.
Waste electrical products should not be disposed of
with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for
recycling advice.
24V-
24V+
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V+24V+
24V-24V-24V-
5000
10
24V-
24V+
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V+ 24V+
24V- 24V- 24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
24V+
24V-
Fig. 1 Fig. 2
Fig. 3
x 3
