LapSafe ClassBuddy User manual
The ClassBuddy™Wall
User Manual
Date: December 2017 Version: 1.1
LPL15_V1_06
2 of 2
2
The ClassBuddy™ Wall - User Manual
Copyright LapSafe® Self-Service Solutions
3
Copyright LapSafe® Self-Service Solutions
The ClassBuddy™ Wall - User Manual
Contents
Page No Section Title Section No
4Introduction 1
5Important actions 2
5Getting started 3
6Charge only - set up 4
7Warranty 5
7Care and maintainance 6
8Helpful links 7
9Health & Safety 8
10 Safety declaration 9
11 CE conformity 10
4
The ClassBuddy™ Wall - User Manual
Copyright LapSafe® Self-Service Solutions
1. Introduction
Congratulations and thank you for purchasing a ClassBuddy™ Wall from the
LapSafe® ClassBuddy™ range. Your product comes with a lifetime parts and
labour warranty which you will need to activate immediately (Section 5).
This manual guides you through the set-up and correct use of your product, for
instructions on how to install your ClassBuddy™ Wall please refer to your
installation guide supplied with your unit for further information.
Box contents:
1 x ClassBuddy™ Wall 16
1 x Mounting bracket (supplied fitted to ClassBuddy™ Wall)
6 x Securing screws (supplied fitted to mounting bracket)
1 x User guide
1 x Installation guide
1 x Cable management pack
5
Copyright LapSafe® Self-Service Solutions
The ClassBuddy™ Wall - User Manual
2. Important actions
Upon delivery of your new ClassBuddy™ Wall you must:
• Take a note and store in a safe place your product serial number which can
be found located on the top of the unit. The silver plate will hold your serial
number that begins with CB. You will need to quote this number for all
enquiries relating to your trolley.
• Take a note of your key number located on the key itself and store this in a
safe and secure place. You will need this if you wish to order additional keys.
• Visit lapsafe.com/activate to activate your Lifetime warranty. Your warranty
will not be valid unless you do this.
• Read the section on ‘Health & Safety’ (Section 8)
3. Getting started
There are ventilation holes through the base and on the top of the ClassBuddy
Wall, and care must be taken that none of these holes are obstructed.
The front le door of your ClassBuddy™ is unlocked using the key with the white
key cover, and the right door has a separate key with a black key cover.
The front le door is for everyday working access to the cabinet. The key can be
removed once the door is open, this will prevent the door from closing fully whilst
it is unlocked.
The right door should not be considered as day-to-day access to the cabinet but
used for initial setup by a responsible/authorised person.
6
The ClassBuddy™ Wall - User Manual
Copyright LapSafe® Self-Service Solutions
4. Charge only - set up
1. Open both front doors
2. You will find power strips for your AC adaptors in the right side compartment
3. Some AC adaptors can be described as ‘in-plug’ where they plug directly into
a socket and the charging lead goes directly to the device, and others can
be described as ‘in-line’ where they have a mains lead between the power
socket and the AC adaptor and then a charging lead going to the device.
4. For ‘in-plug’ AC adaptors simply pass the charging lead behind the divider
onto a shelf
5. If you are using ‘in-line’ AC adaptors you have the choice to pass the mains
lead behind the divider and place the adaptor on the shelf with your devices
or to leave the AC adaptor in the right side compartment and just pass the
charging lead behind the divider onto the shelf.
6. We provide both cable ties and cable clips to help with cable management
and we recommend that the charging lead is secured to the shelf in a
suitable position in order to prevent it ‘working’ its way o the shelf.
Repeat these steps until your wall unit is fully loaded.
NOTE: Maximum loading 100Watt (rated capacity) per socket. (400Watts (rated
capacity) per power strip).
in-plug AC adaptor in-line AC adaptor
7
Copyright LapSafe® Self-Service Solutions
The ClassBuddy™ Wall - User Manual
5. Warranty
All of our products come with a Lifetime Parts & Labour Warranty. To activate your
FREE Lifetime* Parts and Labour Warranty, please go on-line and register at
lapsafe.com/activate
6. Care and maintainance
Dos
• Lock your ClassBuddy™ Wall when not in use
• Keep your keys in a safe place and not in the same room as the wall unit
• Read the Health and Safety guidelines in the user guide and share this
information with all users
• Activate your warranty at lapsafe.com/activate
• Unplug charging leads before taking laptops out of the wall
Don’ts
• Do not leave keys in the doors
• Do not remove doors
• Do not try to modify the wall in anyway without contacting LapSafe® first to
check that it is safe to do so
8
The ClassBuddy™ Wall - User Manual
Copyright LapSafe® Self-Service Solutions
7. Helpful links
Replacement Keys
support.lapsafe.com/keys
Activate Warranty
support.lapsafe.com/warranty
Support Enquiries
support.lapsafe.com/enquiry
0800 130 3456
9
Copyright LapSafe® Self-Service Solutions
The ClassBuddy™ Wall - User Manual
8. Health & Safety
All products manufactured by LapSafe® have been thoroughly tested and certified
by an authorised and INDEPENDENT testing house before sale.
Full CE compliance, which includes the requirements of LVD and EMC directives,
is a STANDARD FEATURE of any solution manufactured by LapSafe®, as are many
more built in safety features. CE Marking can be found on the product serial
number plate, usually at the lower rear of the cabinet. CE Declaration of
Conformity Certificate is issued with each product in the User Guide Pack.
Please be advised of the following safety advice:
At no time are the service areas of the ClassBuddy Wall to be opened by anyone
other than an authorised person.
WARNING: Hand and power tools can be dangerous when used
incorrectly and the user should be trained to use work equipment
and have an understanding of the HSE leaflet, ‘using work equipment
safely’ (INDG229)
Please also refer to the manufacturers documentation for specific
information about the equipment you are using.
WARNING: Because surfaces vary widely and the fitting location and
method of fixing is out of LapSafe®’s control, it is imperative that you
consult with appropriate engineering, architectural, or
construction professional to ensure that your ClassBuddy™ Wall is
mounted properly and that the substrate is suitable to handle applied
loads.
WARNING: Before removing or accessing any service area unplug or
turn the power to the unit o.
IMPORTANT: Installation must be carried out by two responsible
persons and care should be taken when liing the ClassBuddy Wall
unit into position.
10
The ClassBuddy™ Wall - User Manual
Copyright LapSafe® Self-Service Solutions
Recent guidance from the Health and Safety Executive regarding “Laptop computer charging trolleys safety
alert” requires interpretation from each manufacturer as regards to their product compliance. The HSE
statement can be found at: www.hse.gov.uk/services/education/safety121009.htm
CE Testing, Conformity and Declaration of LapSafe®
At LapSafe® we are proud to conrm that ALL of our electrical products, going back over ten years, have been thoroughly tested and
certied (by an authorised and INDEPENDENT testing house) and accordingly have been clearly CE marked.
Full CE compliance, which includes the requirements of LVD and EMC directives, is a STANDARD FEATURE of LapSafe®, as are many
more“built in”safety features. CE Marking can be found on the product serial number plate, usually at the lower rear of the cabinet.
CE Declaration of Conformity Certicate is issued with each product in the User Guide Pack.
You may obtain further copies of the certicate specic to your product and serial number, or any further information and advice,
upon request to our Customer support– call direct 01787 226147 or FREEPHONE the switchboard on 0800 130
Rest assured that your LapSafe® Product has been designed and built with Safety as the highest priority since we rst introduced
the concept of the“mobile laptop trolley” into the UK market in the last century. This is, indeed, why we are called “Lap SAFE”.
Residual Voltage
The HSE has raised a concern (having identied at least one particular manufacturer’s trolleys with this “characteristic”) that many
manufacturers’trolleys (if indeed not the vast majority), may have a momentary residual voltage on the pins of the mains plug and
that this could, if you touched the pins within a second or two of unplugging, result in an electric shock.
LapSafe® have been designed from the outset with safety internal circuitry as standard so as NOT to retain or present any signicant
residual voltage in this way. In fact, it is virtually impossible to get any such signicant electric shock from our cabinets in normal
use.
However, regardless of how safe any particular trolley may be, we endorse the recommendations for employing common sense
practise as a generic rule for any mobile electrical appliance, such as switching o the mains socket before unplugging the power
leads and NOT moving the trolleys without disconnecting and unplugging the power leads at both ends. Two of the wheels are
tted with locks as standard and should be kept locked as a reminder when power is connected and as a general safety rule as per
the user instructions supplied with each cabinet.
For further information call LapSafe® on
0800 130 3456 or visit our website at lapsafe.
*Mentor™range from January 2010
LAPSF076_23052011V2
*
Safety Declaration
11
Copyright LapSafe® Self-Service Solutions
The ClassBuddy™ Wall - User Manual
EU Declaration of CE Conformity
to Council Directive 89/336/EEC
Amendment 2004/108/EC
&
to Council Directive 73/23/EEC
Amendment 2006/95/EC
Equipment Description: Laptop Battery Charging Unit
Device Name: LapSafe® ClassBuddy™ Range
Manufacture Address: LapSafe®
Unit 3 Wakes Hall Business Centre
Wakes Colne
Colchester
Essex
CO6 2DY
European Standards: IEC 60950-1:2005
EN 60950-1: 2006 + A1: 2010
Declaration: We hereby declare that the stated equipment complies with the required Emission,
Immunity and Electrical Safety standards stated above.
Issue Date: 4 December 2012
Authorised by LapSafe®:
John Hutton
Position: Director
EU Declaration of CE Conformity
LAPSF199_04122012V1
12
The ClassBuddy™ Wall - User Manual
Copyright LapSafe® Self-Service Solutions
