latch C2 User manual

Installation Guide
C2

Document number 770-00018 V1
Revised on 10/27/2020
Table of contents
Things you should know
Included in the box
Hardware
Installation
Preparation
Regulatory compliance
23
08
48
11
06
04

C2 Installation Guide Ve rsion 1.04 5
Things you
should know
Although our products are optimized to work with all
types of doors, door alignment is extremely important
in a deadbolt install. Doors should be properly specied
and hung, and the strike should be prepped prior to
installation.
The lens and battery tray should always be paired
together. Avoid mixing the exterior and interior assemblies
with other locks on the job site.
If installing on an active construction site, it is
recommended to add painter’s tape around the exterior
of the trim where it meets the door and to leave the
protective lm on the device. Do not leave the painter’s
tape applied for longer than recommended by the
manufacturer.
The product certications depend on install in accordance
with this guide.
More resources, including the electronic version of this
guide, can be found online at support.latch.com.

C2 Installation Guide Ve rsion 1.06 7
Inside the box

C2 Installation Guide Ve rsion 1.08 9
Hardware
1-3/4” 1-3/8”
Depending on door thickness

C2 Installation Guide Ve rsion 1.010 11
Preparation
Here’s how to prepare your door and device for
the correct door thickness and device backset.

C2 Installation Guide Ve rsion 1.012 13
Select the correct cutsheet according to the door thickness.
Identify if your door has backset A, 2-3/4”, or backset B, 2-3/8”,
with the cutsheet.
1-3/8"1-3/4"
Measure
Preparation
A
B
A
B
A
B

C2 Installation Guide Ve rsion 1.014 15
Deadbolt
Preparation
Deadbolt body
Deadbolt hub Deadbolt
Important: Before you begin installation, make sure the deadbolt
is extended.
Before
After

C2 Installation Guide Ve rsion 1.016 17
The deadbolt extends or retracts by rotating the body of the
deadbolt 180º.
Extend or retract the body of the deadbolt depending on the
backset type.
A. Extend
B. Retract
Deadbolt
Preparation
A
B
A
B
A
B
A
B

C2 Installation Guide Ve rsion 1.018 19
1-3/4"
1-3/8"
Choose the respective mounting screws according to your door
thickness.
Screws
Preparation
If you have a 1-3/8” thick door, break the tailpiece to shorten it by
grabbing with pliers on both sides of the notch and snapping o
the end.
Pliers Pliers
Snap

C2 Installation Guide Ve rsion 1.020 21
Two screws are directly above the tailpiece. Remove the screw
for the handing you are not installing. The screw indicating door
handing will remain.
Before
Screws
Preparation
After choosing
left-handed
Left-handed door
Right-handed doorAfter choosing
right-handed

C2 Installation Guide Ve rsion 1.022 23
Installation
Once your door is prepped, proceed with
installation.

C2 Installation Guide Ve rsion 1.024 25
1.
If the door only has the 1” cross bore and no mortise for a
faceplate, remove the faceplate and armor plate from the
deadbolt. Press the drive-in option onto the end of the deadbolt.
Important: Make sure that the deadbolt hub is on the bottom.

C2 Installation Guide Ve rsion 1.026 27
2.
Turn the deadbolt hub so that the deadbolt is extended.
Insert in the door, and keep the deadbolt extended throughout
the installation.
Screw the deadbolt in if using the provided rounded-corner
faceplate.

C2 Installation Guide Ve rsion 1.028 29
Prepare the outer trim. The tailpiece will be vertical for both left
and right-handed doors.
3.
Refer back to nal preparation step to ensure the correct handing
conguration.
Before
After choosing
left-handed
After choosing
right-handed

C2 Installation Guide Ve rsion 1.030 31
Insert the outer trim into the deadbolt. It is recommended to
support the tailpiece with the index nger of your o hand.
4.
The cable routes over the deadbolt.
The post goes over the deadbolt.

C2 Installation Guide Ve rsion 1.032 33
Separate the back cover.
5.

C2 Installation Guide Ve rsion 1.034 35
Rotate the thumb-turn hub so that it is in the vertical position.
6.
Thumb turn hub
Alignment post holeCable hole
Then place the battery tray assembly while ensuring that the
cable and post go in their respective holes.

C2 Installation Guide Ve rsion 1.036 37
Select the set of screws for your door thickness.
7.
1-3/4"
1-3/8"
Screw the two shorter screws from the set in the battery tray
assembly.

C2 Installation Guide Ve rsion 1.038 39
Remove the red alignment post by unscrewing it from the front
trim. Recycle the post if ABS is collected in your area. Do not
pull the post out.
8. 9.
Take the remaining longer screw for your door thickness, and
install it in the hole where you removed the red post.
