Ledj LEDJ472 User manual

Order code: LEDJ472
TPix Panel
User Manual

www.prolight.co.uk TPix Panel User Manual
2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Beforeyourinitialstart-up,pleasemakesurethatthereisnodamagecausedduringtransportation.
• Shouldtherebeanydamage,consultyourdealeranddonotusetheequipment.
• Tomaintaintheequipmentingoodworkingconditionandtoensuresafeoperation,itisnecessary
fortheusertofollowthesafetyinstructionsandwarningnoteswritteninthismanual.
• Pleasenotethatdamagescausedbyusermodicationstothisequipmentarenotsubjecttowarranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
Ifthisequipmentisoperatedinanyotherway,thanthosedescribedinthismanual,theproductmaysufferdamageand
thewarrantybecomesvoid.Incorrectoperationmayleadtodangere.g:short-circuit,burnsandelectricshocksetc.
Donotendangeryourownsafetyandthesafetyofothers!
Incorrectinstallationorusecancauseseriousdamagetopeopleand/orproperty.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Neverletthepowercablecomeintocontactwithother
cables.Handlethepowercableandallmainsvoltage
connectionswithparticularcaution!
• Neverremovewarningorinformativelabelsfromtheunit.
• Donotopentheequipmentanddonotmodifytheunit.
• Donotconnectthisequipmenttoadimmerpack.
• Donotswitchtheequipmentonandoffinshortintervals,
asthiswillreducethesystem’slife.
• Onlyusetheequipmentindoors.
• Donotexposetoammablesources,liquidsorgases.
• Alwaysdisconnectthepowerfromthemainswhen
equipmentisnotinuseorbeforecleaning!Onlyhandle
thepower-cablebytheplug.Neverpullouttheplugby
pullingthepower-cable.
• Makesurethattheavailablemainssupplyvoltageis
between100~240VAC,50/60Hz.
• Makesurethatthepowercableisnevercrimpedor
damaged.Checktheequipmentandthepowercable
periodically.
• Iftheequipmentisdroppedordamaged,disconnectthe
mainspowersupplyimmediatelyandhaveaqualied
engineerinspecttheequipmentbeforeoperatingagain.

• Iftheequipmenthasbeenexposedtodrastic
temperatureuctuation(e.g.aftertransportation),
donotconnectpowerorswitchitonimmediately.
Thearisingcondensationmightdamagetheequipment.
Leavetheequipmentswitchedoffuntilithasreached
roomtemperature.
• Ifyourproductfailstofunctioncorrectly,stopuse
immediately.Packtheunitsecurely(preferablyinthe
originalpackingmaterial),andreturnittoyourProLight
dealerforservice.
• Onlyusefusesofsametypeandrating.
• Repairs,servicingandpowerconnectionmustonlybe
carriedoutbyaqualiedtechnician.THISUNITCONTAINS
NOUSERSERVICEABLEPARTS.
• Thislightingxtureisforprofessionaluseonly-itis
notdesignedfororsuitableforhouseholduse.The
productmustbeinstalledbyaqualiedtechnicianin
accordancewithlocalterritoryregulations.Thesafetyof
theinstallationistheresponsibilityoftheinstaller.The
xturepresentsrisksofsevereinjuryordeathduetore
hazards,electricshockandfalls.
• Warning!RiskGroup2LEDproductaccordingto
EN62471.Donotviewthelightoutputwithoptical
instrumentsoranydevicethatmayconcentratethebeam.
• WARRANTY:Oneyearfromdateofpurchase.

www.prolight.co.uk TPix Panel User Manual
3
Product overview & technical specications
TheTPixseriesarearangeof25mmpitch,pixelmappablexturescontrollablebyDMX,Art-NetorKling-Net.
Theon-boardnetworkswitchallowsfortheArt-NetorKling-Nettobefullydaisychainedforswiftrigging.Ahostof
builtinmacroscanbetriggeredfromthemenusystemorviaDMXforsimpleoperation,orforfullpixelcontrol,the
Art-NetorKling-Netprotocolsmaybeused.Allfeaturerobustaluminiumchassis,completewithslidinghardware
forriggingandpaneltopanelalignment.Allxtureshaveawide120°viewingangleandfeatureamilky,frost
effectfrontscreen.Aclearfrontscreenisalsoincludedtofurtherexpandtheversatilityofthisseries.
TPix Panel
300mm 117mm
60mm
300mm
• 144tri-colourSMD5050LEDs(RGB)
• Viewingangle:120°
• Illuminance:3290Nits-clearfrontscreen
• Illuminance:2900Nits-frostedfrontscreen
• Refreshrate:400Hz
• Pixels:12x12
• Pixelpitch:25mm
• DMXchannels:8
• Art-Netchannels:432
• Bracketallowsformultiplerigging
oroorstandingapplications
• 4pushbuttonmenuwithLCDdisplay
• PowerCONinput/output
• 5-PinXLRinput/output
• 3-PinXLRinput/output
• Etherconinput/output(Art-Net/Kling-Net)
• Convectioncooled
Specications TPix Panel
Powerconsumption 55W
Powersupply 100~240V,50/60Hz
Fuse T3.15A250V
Dimensions 300x300x117mm
Weight 2.5kg
Ordercode LEDJ472

www.prolight.co.uk TPix Panel User Manual
4
Technical specications
01-Earthpoint
02-LCDdisplay
03-Functionbuttons
04-SignalLED
05-3-PinDMXinput
06-3-PinDMXoutput
07-5-PinDMXinput
08-5-PinDMXoutput
09-RJ45ArtNet/
KlingNetinput
10-RJ45ArtNet/
KlingNetoutput
11-PowerCONinput
12-PowerCONoutput
13-FuseT3.15A250V
14-Hangingbracket
15-Paneltopanel
alignmentbrackets
16-Safetyeye
Inthebox:1 x xture,
1 x clear front screen,
1 x frosted front screen,
1 x PowerCON cable
& 1 x user manual
TPix Panel
SIGNAL
MENU ENTER UP DOWN
POWER INPUT:
100-240V~50/60Hz
FUSE: T3.15A 250V
POWER OUTPUT:
100-240V~50/60Hz
POWER CONSUMPTION: 55W
RJ45 INPUT
Artnet/Klingnet
RJ45 OUTPUT
Artnet/Klingnet
5-PIN
DMX INPUT
5-PIN
DMX OUTPUT
3-PIN
DMX INPUT
3-PIN
DMX OUTPUT
05 07 09 1015 08 06
01
15
13 12
16
15
14
03
04
11
0215

www.prolight.co.uk TPix Panel User Manual
5
Operating instructions
Software version
Software Version
KS6001 Dream 1.2
Software Version
MENU
Auto mode program setting
Auto mode speed setting
Auto Mode
Speed: 1
Auto Mode
Speed: 9
Auto Mode
Program: Mix
Auto Mode
Program: 1
Auto Mode
8CH DMX address setting
432CH DMX address setting
DMX Address
001
DMX Address
080
DMX Address
504
DMX Address
001
DMX Address
DMX channel setting
DMX CH Mode
DMX CH Mode
8CH
DMX CH Mode
432CH
Slave mode setting
Slave Mode
Slave Mode
YES [NO]
Slave Mode
[YES] NO
Network Settings Network settings
IP Address
002.[000.000.002
Net SubNet Unive
[00] 00 00
Subnet Mask
255.[000.000.000
IP Address
Net SubNet Unive
Subnet Mask

www.prolight.co.uk TPix Panel User Manual
6
Operating instructions
DMX mode:
OperatinginaDMXcontrolmodeenvironmentgivestheuserthegreatestexibilitywhenitcomes
tocustomisingorcreatingashow.Inthismodeyouwillbeabletocontroleachindividualtraitofthe
xtureandeachxtureindependently.
ToaccesstheDMXchannelmode,pressthe“MENU”buttonandusethe“UP”and“DOWN”buttonson
therearoftheunittoshow“DMX CH Mode” ontheLCDdisplay.Nowpressthe“ENTER”buttonanduse
the“UP”and“DOWN”buttonstosettherequiredDMXchannel“DMX CH Mode 8CH” or
“DMX CH Mode 432CH”.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
ToaccesstheDMXaddressmode,pressthe“MENU”buttonandusethe“UP”and“DOWN”buttonson
therearoftheunittoshow“DMX Address” ontheLCDdisplay.Nowpressthe“ENTER”buttonanduse
the“UP”and“DOWN”buttonstosettherequiredDMXaddress.Pressthe“ENTER”buttontoconrm
thesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
IMPORTANT! PLEASE NOTE:TheLCDdisplayforthisxturehasatimerthatturnsthedisplayback-
lightoffafter20secondsofinactivity.Toilluminatethedisplayagainpressoneofthe4buttons.
Channel Value Function
1 000-255 Masterdimmer(0-100%)
2000-255 Strobe(slow-fast)
3000-255 Reddimmer(0-100%)
4 000-255 Greendimmer(0-100%)
5 000-255 Bluedimmer(0-100%)
6
(CH1
&CH2
mustbe
setto
000)
000-015 Nofunction
016-031 Program1
032-047 Program2
048-063 Program3
064-079 Program4
080-095 Program5
096-111 Program6
112-127 Program7
128-143 Program8
144-159 Program9
160-175 Program10
176-191 Program11
192-207 Program12
208-223 Program13
8 channel mode:
Channel Value Function
6cont. 224-239 Program14
240-255 Program15
7
(CH1
&CH2
mustbe
setto
000)
000-015 Nofunction
016-031 Program16
032-047 Program17
048-063 Program18
064-079 Program19
080-095 Program20
096-111 Program21
112-127 Program22
128-143 Program23
144-159 Program24
160-175 Program25
176-191 Program26
192-207 Program27
208-223 Program28
224-239 Program29
240-255 ProgramMix
8 000-255 Speed(slow-fast)

www.prolight.co.uk TPix Panel User Manual
7
Operating instructions
Channel Value Function
1 000-255 LED1Reddimmer(0-100%)
2000-255 LED1Greendimmer(0-100%)
3000-255 LED1Bluedimmer(0-100%)
4 000-255 LED2Reddimmer(0-100%)
5 000-255 LED2Greendimmer(0-100%)
6 000-255 LED2Bluedimmer(0-100%)
7 000-255 LED3Reddimmer(0-100%)
8 000-255 LED3Greendimmer(0-100%)
9 000-255 LED3Bluedimmer(0-100%)
••••• •••••• •••••••••••••••••••••••
430 000-255 LED144Reddimmer(0-100%)
431 000-255 LED144Greendimmer(0-100%)
432 000-255 LED144Bluedimmer(0-100%)
432 channel mode:
Auto mode:
ToaccesstheAutomode,pressthe“MENU”buttonandusethe“UP”and“DOWN”buttonsontherear
oftheunittoshow“Auto Mode” ontheLCDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”
and“DOWN”buttonstoselecteither“Speed” or “Program”.
Whenselecting“Speed” pressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstoselect
between“Speed: 1” ~“Speed: 9”.
Whenselecting“Program” pressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstoselect
between“Program: 1” ~“Program: 29” or “Program: Mix”.
Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Software version:
Toaccessthexturessoftwareversion,pressthe“MENU”buttonandusethe“UP”and“DOWN”buttons
ontherearoftheunittoshow“Software Version” ontheLCDdisplay.Nowpressthe“ENTER”button
and“Software Version KS6001 Dream 1.2” willbedisplayed.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
IP Address setting:
ToaccesstheIPaddresssetting,pressthe“MENU”buttonandusethe“UP”and“DOWN”buttonson
therearoftheunittoshow“Network Settings” ontheLCDdisplay.Nowpressthe“ENTER”buttonand
usethe“UP”and“DOWN”buttonstoselect“IP Address”.Pressthe“ENTER”buttonandusethe“UP”
and“DOWN”buttonstoselectthepartoftheIPaddressyouwouldliketochangeindicatedbya“[”.
Pressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstoadjusttheselectedpartoftheIP
addressyouhavechosen.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.

www.prolight.co.uk TPix Panel User Manual
8
Subnet Mask setting :
ToaccesstheSubnetMasksetting,pressthe“MENU”buttonandusethe“UP”and“DOWN”buttons
ontherearoftheunittoshow“Network Settings” ontheLCDdisplay.Nowpressthe“ENTER”button
andusethe“UP”and“DOWN”buttonstoselect“Subnet Mask”.Pressthe“ENTER”buttonandusethe
“UP”and“DOWN”buttonstoselectthepartoftheSubnetmaskyouwouldliketochangeindicatedby
a“[”.Pressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstoadjusttheselectedpartofthe
Subnetmaskyouhavechosen.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Net SubNet Universe setting:
ToaccesstheNetSubNetUniversesetting,pressthe“MENU”buttonandusethe“UP”and“DOWN”
buttonsontherearoftheunittoshow“Network Settings” ontheLCDdisplay.Nowpressthe“ENTER”
buttonandusethe“UP”and“DOWN”buttonstoselect“Net SubNet Universe”.Pressthe“ENTER”
buttonandusethe“UP”and“DOWN”buttonstoselectthepartoftheNetSubNetUniverseyouwould
liketochangeindicatedbya“[ ]”.Pressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonsto
adjusttheselectedpartoftheNetSubNetUniverseyouhavechosen.
Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Master/slave mode:
Tosetthemasterunit,pressthe“MENU”buttonandusethe“UP”and“DOWN”buttonsontherearof
theunittoselectoneoftheAutoPrograms.
Tosettheotherunitsinslavemode,pressthe“MENU”buttonandusethe“UP”and“DOWN”buttons
ontherearoftheunittoshow“Slave Mode” ontheLCDdisplay.Nowpressthe“ENTER”buttonanduse
the“UP”and“DOWN”buttonstosetslavemodeon/off“Slave Mode [YES]” or “Slave Mode [NO]”.
Pressthe“ENTER”buttontoconrmthesetting.
Operating instructions

www.prolight.co.uk TPix Panel User Manual
9
Connecting to a Network
KlingNet Settings:
01)InstallaKlingNetbasedsoftwareonyourPC(WindowsorMac).
02)ConnecttheTPixPaneltoapowersupplyviathePowerCONinput.
03)MakesurethePChasaxedIPAddress.Nofurthernetworksettingsneedtobeadjusted.
04)ConnecttheTPixPaneltoyourcomputerviaaCAT-5/CAT-6cable(seepage10).Oncethextures
havebeenconnectedthewillbeautomaticallyrecognisedbytheKlingNetbasedsoftware.
05)Mapthedevicesusingthe“draganddrop”method,placingthexturesinthe“on-screen”interface
ontherightposition.Thiswilltakeafewminutesandoncedonethesystemisfullysetup.
Pleasenote:Whencreatinglargesetups,itisrecommendedtousea16-bit,highspeedethernetswitch
totransmittheKlingNetdatasignal.
ArtNet Settings:
01)InstallanArtNetbasedsoftwareonyourPC(WindowsorMac).
02)ConnecttheTPixPaneltoapowersupplyviathePowerCONinput.
03)ConnecttheTPixPaneltoyoursoftware/controllerviaaCAT-5/CAT-6cable(seepage10).
04)SettheIPaddressofthesoftware/controllerto2.x.x.xor10.x.x.x,dependingontheArtNetsettings.
05)SettheSubnetmaskto255.0.0.0onboththeTPixPanelandthesoftware/controller.Makesure
thatallxturesinthenetworkhaveauniqueIPaddress.
Pleasenote:Ifyouwanttoconnectmorethanonextureoperatingin432channelmodeisadvised.
Followtheexamplebelow:
Example: TPix Panel 432 channel mode
01)MakesurethateachconnectedTPixPanelhasauniqueIPaddress.
02)MakesuretheSubnetmaskoneachxtureissetto255.0.0.0.
03)SettheuniverseoftherstTPixPanelto1.
04)SettherstTPixPanelsDMXAddressto001.
Pleasenote:DuetotheTPixPanelhaving432DMXchannelsyoucannotconnectasecondpanelinthe
sameuniverseasthelimitforoneuniverseis512DMXchannels.
05)SetthesecondTPixPaneltouniverse2withaDMXaddressof001.Youcanrepeatthisstepupto
15times,eachpanelbeingthenextascendingnumberuniverse(15universesavailableintotal).
06)Ifyourequiremorethan15TPixPanelstobeconnectedsettheNetofthe16thTPixPanelto2.
Youarenowabletoconnectanother15Panels.ThenumberofNetsavailabledependsonthe
softwareused.
07)Usingyoursoftware/controller,mapalltheconnecteddevicesusingthesettingsabove.
08)TheTPixPanelsarenowreadyforuse.
Pleasenote:Whencreatinglargesetups,itisrecommendedtousea16-bit,highspeedethernetswitch
totransmittheArtNetdatasignal.

www.prolight.co.uk TPix Panel User Manual
10
Making a data cable:
AstandardETHERNETcablecanbeusedtoreplacethedatacablerequiredtotransmitthedata.
Pleasefollowtheinstructionsbelowinordertocreateextracables:
Takeastandardnetcable(CAT-5/CAT-5E/CAT-6)andconnectittoanRJ45connectorasshownbelow.
EthernetPatchCableColourStandardEIA/TIAT568A
RJ45 Pin#
Green/WhiteTracer 1
Green 2
Orange/WhiteTracer 3
Blue 4
Blue/WhiteTracer 5
Orange 6
Brown/WhiteTracer 7
Brown 8
Pin# RJ45
1 Green/WhiteTracer
2Green
3Orange/WhiteTracer
4 Blue
5 Blue/WhiteTracer
6 Orange
7 Brown/WhiteTracer
8 Brown
TX+
TX–
RX+
RX–
PR3
PR3
PR2
PR1
PR1
PR2
PR4
PR4
87654321
12345678
12345678

www.prolight.co.uk TPix Panel User Manual
11
Setting the DMX address:
TheDMXmodeenablestheuseofauniversalDMXcontroller.Eachxturerequiresa“startaddress”
from1-511.Axturerequiringoneormorechannelsforcontrolbeginstoreadthedataonthechannel
indicatedbythestartaddress.Forexample,axturethatoccupiesoruses7channelsofDMXandwas
addressedtostartonDMXchannel100,wouldreaddatafromchannels:100,101,102,103,104,105
and106.Chooseastartaddresssothatthechannelsuseddonotoverlap.E.g.thenextunitinthe
chainstartsat107.
DMX 512:
DMX(DigitalMultiplex)isauniversalprotocolusedasaformofcommunicationbetweenintelligent
xturesandcontrollers.ADMXcontrollersendsDMXdatainstructionsformthecontrollertothexture.
DMXdataissentasserialdatathattravelsfromxturetoxtureviatheDATA“IN”andDATA“OUT”
XLRterminalslocatedonallDMXxtures(mostcontrollersonlyhaveadata“out”terminal).
DMX linking:
DMXisalanguageallowingallmakesandmodelsofdifferentmanufacturestobelinkedtogether
andoperatefromasinglecontroller,aslongasallxturesandthecontrollerareDMXcompliant.
ToensureproperDMXdatatransmission,whenusingseveralDMXxturestrytousetheshortest
cablepathpossible.TheorderinwhichxturesareconnectedinaDMXlinedoesnotinuencethe
DMXaddressing.Forexample;axtureassignedtoaDMXaddressof1maybeplacedanywherein
aDMXline,atthebeginning,attheend,oranywhereinthemiddle.Whenaxtureisassigneda
DMXaddressof1,theDMXcontrollerknowstosendDATAassignedtoaddress1tothatunit,
nomatterwhereitislocatedintheDMXchain.
DATA cable (DMX cable) requirements (for DMX operation):
ThisxturecanbecontrolledviaDMX-512protocol.TheDMXaddressissetonthebackoftheunit.
YourunitandyourDMXcontrollerrequireastandard3-pinXLRconnectorfordatainput/output,
seeimagebelow.
Note: DMX cable must be daisy chained and cannot be split.
DMX setup
FurtherDMXcablescanbe
purchasedfromallgoodsound
andlightingsuppliersor
ProLightConceptsdealers.
Pleasequote:
CABL10 – 2m
CABL11 – 5m
CABL12 – 10m

www.prolight.co.uk TPix Panel User Manual
12
Notice:
Besuretofollowthediagramsbelowwhenmakingyourowncables.Donotconnectthecables
shieldconductortothegroundlugorallowtheshieldconductortocomeincontactwiththeXLRs
outercasing.Groundingtheshieldcouldcauseashortcircuitanderraticbehaviour.
Special note:
Line termination:
Whenlongerrunsofcableareused,
youmayneedtouseaterminatoron
thelastunittoavoiderraticbehaviour.
Using a cable terminator will decrease
the possibilities of erratic behaviour.
(3-pin - Order ref: CABL90, 5-pin - Order ref: CABL89)
5-pin XLR DMX connectors:
Somemanufacturesuse5-pinXLRconnectorsfordatatransmissioninplaceof3-pin.5-pinXLRxtures
maybeimplementedina3-pinXLRDMXline.Wheninsertingstandard5-pinXLRconnectorsintoa
3-pinlineacableadaptormustbeused.Thediagrambelowdetailsthecorrectcableconversion.
Terminationreducessignaltransmission
problemsandinterference.Itisalways
advisabletoconnectaDMXterminal,
(resistance120Ohm1/4W)betweenpin2
(DMX-)andpin3(DMX+)ofthelastxture.
5-pin XLR (female)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-pin XLR (female)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
3-pin XLR (male)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-pin XLR (male)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
DMX setup

www.prolight.co.uk TPix Panel User Manual
13
WEEE notice
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
Thismarkingshownontheproductoritsliterature,indicatesthatitshouldnotbedisposed
withotherhouseholdwastesattheendofitsworkinglife.Topreventpossibleharmtothe
environmentorhumanhealthfromuncontrolledwastedisposal,pleaseseparatethisfromother
typesofwastesandrecycleitresponsiblytopromotethesustainablereuseofmaterialresources.
Householdusersshouldcontacteithertheretailerwheretheypurchasedthisproduct,ortheir
localgovernmentofce,fordetailsofwhereandhowtheycantakethisitemforenvironmentally
saferecycling.
Businessusersshouldcontacttheirsupplierandcheckthetermsandconditionsofthe
purchasecontract.Thisproductshouldnotbemixedwithothercommercialwastesfordisposal.

www.prolight.co.uk TPix Panel User Manual
14

www.prolight.co.uk TPix Panel User Manual
15

www.prolight.co.uk TPix Panel User Manual
16
