Ledj RGB DMX User manual

www.prolight.co.uk
RGB DMX Deck Skirt
2.1M x 1M Starcloth (order code: STAR25)
USER MANUAL

WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
CAUTION!
Keep this equipment away from rain,
moisture and liquids.
SAFETY INSTRUCTIONS
Every person involved with the installation, operation & maintenance of this
equipment should:
- Be competent
- Follow the instructions of this manual
CAUTION! TAKE CARE USING THIS EQUIPMENT!
HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!
Before your initial start-up, please make sure that there is no damage caused during
transportation. Should there be any, consult your dealer and do not use the
equipment.
To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
Please note that damages caused by user modications to this equipment are not
subject to warranty.
LEDJ RGB DMX Deck Skirt Safety

LEDJ RGB DMX Deck Skirt Safety
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused
by the non-observance of this manual or any unauthorised modication to the
equipment.
• Never let the power-cable come into contact with other cables. Handle the power-cable
and all mains voltage connections with particular caution!
• Never remove warning or informative labels from the equipment.
• Do not open the equipment and do not modify the equipment.
• Do not connect this equipment to a dimmer-pack.
• Do not switch the equipment on and off in short intervals, as this will reduce the
system’s life.
• Only use the equipment indoors.
• Do not expose to ammable sources, liquids or gases.
• Always disconnect the power from the mains when equipment is not in use or before
cleaning! Only handle the power-cable by the plug. Never pull out the plug by pulling the
power-cable.
• Make sure that the available voltage is between 220v/240v.
• Make sure that the power-cable is never crimped or damaged. Check the equipment and
the power-cable periodically.
• If the equipment is dropped or damaged, disconnect the mains power supply immediately.
Have a qualied engineer inspect the equipment before operating again.
• If the equipment has been exposed to drastic temperature uctuation (e.g. after
transportation), do not switch it on immediately. The arising condensation might damage
the equipment. Leave the equipment switched off until it has reached room temperature.
• If your product fails to function correctly, discontinue use immediately. Pack the unit
securely (preferably in the original packing material), and return it to your Prolight dealer
for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be carried out by a qualied
technician. THIS UNIT CONTAINS NO USER SERVICEABLE PARTS.
• WARRANTY; One year from date of purchase.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual,
the product may suffer damage and the warranty becomes void.
Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks,
lamp failure etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and property.

Operating modes:
1, Stand Alone with Sound Activation
2, DMX operation
For Sound Activation:
With the power turned off set dip switch 10 to ON and all others to OFF. Turn on the power and
the sensitivity control can now be set to the desired level.
For DMX operation:
With the power turned off set dip switch 10 to OFF, then using dip switches 1 - 9 set the desired
DMX address and then turn on the power. You can now control the RGB deck skirt using the table
below.
DMX table:
LEDJ RGB DMX Deck Skirt Technical specications
0-9
10-19
20-29
30-39
40-49
50-59
60-69
70-79
80-89
90-99
100-109
110-119
120-129
130-139
140-149
150-159
160-169
170-179
180-189
190-199
200-209
210-219
220-229
230-239
Channel DMX Number Function
Channel 1
Blackout
Pattern number 1
Pattern number 2
Pattern number 3
Pattern number 4
Pattern number 5
Pattern number 6
Pattern number 7
Pattern number 8
Pattern number 9
Pattern number 10
Pattern number 11
Pattern number 12
Pattern number 13
Pattern number 14
Pattern number 15
Pattern number 16
Pattern number 17
Pattern number 18
Pattern number 19
Pattern number 20
Pattern number 21
Pattern number 22
Pattern number 23

Side view:
LEDJ RGB DMX Deck Skirt Technical specications
240-249
250-255
0-255
Channel DMX Number Function
Pattern number 24
Auto run through all programmes
Animates the pattern selected on channel 1
(The higher the number the faster the speed)
Channel 1
(continued)
Channel 2
Back view:
Identcation:
1, Power switch
2, Power supply
3, Fuse
4, Volume control
5, Microphone
6, Starcloth power output
7, Starcloth signal output
8, Dip switches
9, DMX in
10, DMX out
89
10
1
23
5
6
7
4

DMX Control Mode
Operating in a DMX control mode environment gives the user the greatest exibility when it comes
to customising or creating a show. In this mode you will be able to control each individual trait of
the xture and each xture independently.
Setting the DMX address
The DMX mode enables the use of a universal DMX controller. Each xture requires a
“start address” from 1- 511. A xture requiring one or more channels for control begins to read the
data on the channel indicated by the start address. For example, a xture that occupies or uses 7
channels of DMX and was addressed to start on DMX channel 100, would read data from
channels: 100,101,102,103,104,105 and 106. Choose a start address so that the channels used
do not overlap. E.g. the next unit in the chain starts at 107.
Set the start address using the group of dip switches located usually on the back of the xture.
Each dipswitch has an associated value. Adding the value of each switch in the ON position will
provide the start address. Determining which switches to toggle ON given a specic start address
can be accomplished in the following manner. By subtracting the largest switch value possible
from the selected start address until zero is achieved.
on
on
EXAMPLE STARTING ADDRESS
Address 10
Pin NO: 4 = 8
Pin NO: 2 = 2
Total = 10
Address 24
Pin NO: 5 = 16
Pin NO: 4 = 8
Total = 24
DMX address using
simple maths
233 - (128 = 105,Turn on dip No: 8
105 - (64) = 41,Turn on dip No:7
41 - (32) = 9,Turn on dip No: 6
9 - (8) = 1,Turn on dip No: 4
1 - (1) = 0,Turn on dip No:1
You will most likely use the first available
number which maybe Number 1.This
number was selected for
example purposes
DIP SWITCH (DMX VALUE)
1
2
3
4
5
6
7
8
9
10
1
2
4
8
16
32
64
128
256
LEDJ RGB DMX Deck Skirt DMX control mode

DMX-512:
• DMX (Digital Multiplex) is a universal protocol used as a form of communication between
intelligent xtures and controllers. A DMX controller sends DMX data instructions form the
controller to the xture. DMX data is sent as serial data that travels from xture to xture via the
DATA “IN” and DATA “OUT” XLR terminals located on all DMX xtures (most controllers only have
a data “out” terminal).
DMX Linking:
• DMX is a language allowing all makes and models of different manufactures to be linked together
and operate from a single controller, as long as all xtures and the controller are DMX compliant.
To ensure proper DMX data transmission, when using several DMX xtures try to use the
shortest cable path possible. The order in which xtures are connected in a DMX line does not
inuence the DMX addressing. For example; a xture assigned to a DMX address of 1 may be
placed anywhere in a DMX line, at the beginning, at the end, or anywhere in the middle. When a
xture is assigned a DMX address of 1, the DMX controller knows to send DATA assigned to
address 1 to that unit, no matter where it is located in the DMX chain.
DATA Cable (DMX cable) requirements (for DMX operation):
• The RGB Deck Skirt can be controlled via DMX-512 protocol. The DMX address is set on the
back of the unit. Your unit and your DMX controller require a standard 3-pin XLR connector for
data input/output (gure 1).
Figure 1
Also remember that DMX cable must be daisy chained and cannot be split.
LEDJ RGB DMX Deck Skirt DMX set up
Further DMX cables can be purchased from all
good sound and lighting suppliers or Prolight
dealers.
Please quote:
CABL10 – 2M
CABL11 – 5M
CABL12 – 10M

Notice:
• Be sure to follow gures 2 & 3 when making your own cables. Do not connect the cable’s shield
conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer
casing. Grounding the shield could cause a short circuit and erratic behaviour.
Special Note: Line termination:
• When longer runs of cable are used, you may need to use a terminator on the last unit to
avoid erratic behaviour.
Using a cable terminator (part number CABL90) will decrease the possibilities of erratic
behaviour.
5-Pin XLR DMX Connectors:
• Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-Pin
XLR xtures may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin
XLR connectors in to a 3-pin line a cable adaptor must be used. The Chart below details the
correct cable conversion.
Termination reduces signal transmission problems
and interferance. it is always advisable to connect a
DMX terminal, (resistance 120 Ohm 1/4 W) between
pin 2 (DMX-) and pin 3 (DMX+) of the last fixture.
LEDJ RGB DMX Deck Skirt DMX Set Up

LEDJ RGB DMX Deck Skirt Dip Switch Reference Chart
DMX Dip Switch Quick Reference Chart
Dip Switch Position

Maintenance
The RGB DMX Deck Skirt requires almost no maintenance. However, you should keep the unit
clean, otherwise, the xture’s light-output will be signicantly reduced. Disconnect the mains power
supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. The cloth will require
monthly cleaning, as smoke-uid tends to build up residues, reducing the light-output very quickly.
Do not use alcohol or solvents. Keep connections clean. Disconnect the power, and then wipe the
connections with a damp cloth. Make sure connections are thoroughly dry before re-connecting
the
power supply.
The following points have to be considered during the inspection:
1. All screws used for installing the device have to be tightly connected and must not be corroded.
2. There should not be any deformations on housing, xing and installation points.
3. The electric power supply cables must not show any damages or material fatigue.
Replacing a Fuse
Power surges, short-circuit or inappropriate electrical power supply may cause a fuse to fail. If the
fuse fails, the product will not function whatsoever. If this happens, follow the directions below.
1. Unplug the unit from electric power supply.
2. Insert a at-headed screwdriver into a slot in the fuse cover. Turn the screwdriver to the left, at
the same time gently push (Turn and Push). The fuse will come out.
3. Remove the used fuse. If brown or unclear, it has failed.
4. Insert the replacement fuse into the holder where the old fuse was. Reinsert the fuse cover.
Be sure to use a fuse of the same type and specication. See the product specication
label for details.
Technical Specications:
Voltage: 240V AC 50Hz
Wattage: 5W
LED’s: R: 32, G: 32, B: 32 (Total: 96)
Dimensions: 2.1m x 1m
Weight: 3kgs
LEDJ RGB DMX Deck Skirt Maintenance
