Legrand Kenall luxtran lts series User manual

www.kenall.com |P: 800-4-Kenall |F: 262-891-9701 |10200 55th Street Kenosha, Wisconsin 53144, USA

This product complies with the Buy American Act: manufactured in the United State swith more than 50% of the component cost of US origin It may be covered by patents

INSTALLATION INSTRUCTIONS

LTS_F-5355_091118

Luminaires for Tunnel Applications

LUXTRAN™

IMPORTANT SAFEGUARDS

When using electrical equipment, basic safety precautions

should always be followed, including the following:

THIS PRODUCT MUST BE INSTALLED IN

ACCORDANCE WITH THE APPLICABLE

INSTALLATION CODE BY A PERSON FAMILIAR

WITH THE CONSTRUCTION AND OPERATION OF

THE PRODUCT AND THE HAZARDS INVOLVED.

CE PRODUIT DOIT ÊTRE INSTALLÉ SELON LE

CODE D’INSTALLATION PERTINENT, PAR UNE

PERSONNE QUI CONNAÎT BIEN LE PRODUIT ET

SON FONCTIONNEMENT AINSI QUE LES RISQUES

INHÉRENTS. DISCONNECT POWER TO ALL CIRCUITS

BEFORE WIRING FIXTURE. INSTALL IN ACCORDANCE WITH

ALL NATIONAL, STATE, AND LOCAL CODES. DO NOT CONNECT

TO AN UNGROUNDED SUPPLY. READ ALL FIXTURE MARKINGS

AND LABELS TO ENSURE CORRECT INSTALLATION OF FIXTURE.

SUPPLEMENTAL INSTRUCTIONS MAY BE LOCATED ON THE

FIXTURE, IN ADDITION TO THIS INSTRUCTION SHEET, REGARDING

ORIENTATION, OR MOUNTING RESTRICTIONS.

SAVE THESE INSTRUCTIONS

INSTALLATION INSTRUCTIONS

LTS SERIES

1. Secure xture to wall or ceiling using user supplied hardware. 3/8 × 1-3/8 slots in mounting brackets are

provided. See Figure 1.

15.6

19.4

30.2

19.4

The LuxTran LTS series luminaires contains sensitive electronics. Take care to avoid damage by improper handling or

static electricity discharge (ESD). Either type of damage could render the system inoperable or cause latent failure.

LuxTran LTS Series Luminaires are powered by RD700 distributed DC driver system; remotely-located for servicing

convenience.

NOTE: If the xture has directional optics, note the label indicating the direction of light and install appropriately.

2. Rotate latches and open door, which is retained by stainless steel cables.

3. Loosen wing nut and remove Wiring Cover.

4. Connect weather tight electrical service to 7/8 dia. opening provided.

Figure 1

www.kenall.com |P: 800-4-Kenall |F: 262-891-9701 |10200 55th Street Kenosha, Wisconsin 53144, USA

This product complies with the Buy American Act: manufactured in the United State swith more than 50% of the component cost of US origin It may be covered by patents

INSTALLATION INSTRUCTIONS

LTS_F-5355_091118

5. Fixture leads are marked: LED+ Circuit 1, LED – Circuit 1, LED+ Circuit 2 and LED – Circuit 2. Make connections

to Remote Driver output leads following Wiring Diagram, Figure 2.

SERVICE INSTRUCTIONS

6. Replace Wiring Cover and secure with wing nut.

7. Close door and secure rotating latches.

LTS series xtures have no eld serviceable parts.

LED module replacement may be done after the xture is removed from service

1. Open door and remove wiring cover, see above.

2. Remove reectors and disconnect LED module leads. See Figure 3.

Figure 2

Figure 3

RD-700

LTS-B2 (396L)

LTS-B2 (600L/780L)

DRIVER OUTPUT +

DRIVER OUTPUT -

LED + CIRCUIT 1

DRIVER OUTPUT +

LED - CIRCUIT 1

LED + CIRCUIT 2

LED - CIRCUIT 2

LED + CIRCUIT 1

LED - CIRCUIT 1

DRIVER OUTPUT +

DRIVER OUTPUT -

RD-700

DRIVER OUTPUT +

DRIVER OUTPUT -

LED + CIRCUIT 1

LED - CIRCUIT 1

LTS- A2

(300L/390L)

www.kenall.com |P: 800-4-Kenall |F: 262-891-9701 |10200 55th Street Kenosha, Wisconsin 53144, USA

This product complies with the Buy American Act: manufactured in the United State swith more than 50% of the component cost of US origin It may be covered by patents

INSTALLATION INSTRUCTIONS

LTS_F-5355_091118

3. Remove screws securing LED module. See Figure 4.

4. Secure new LED module by re-installing removed screws.

5. Attach leads and secure reectors.

6. Re-install wiring cover and door.

Figure 4
