LightSense™Wireless Room Scene Remote
Installation Instructions
Specifications
Power Supply . . . . . . . .Three AAA Alkaline Batteries, provided
Operating Temperature . . . . . . . . .32°F to 104°F (0°C to 40°C)
Patents pending
Syracuse, NY 13221-4822
800.223.4185
www.passandseymour.com

UNIT DESCRIPTION
The LightSense™ PSWRR Wireless Room Scene Remote is a room level
scene controller. It provides instant recall of five user-recorded lighting scenes
(or presets) assigned to a room or designated area. It also provides off and on
functions, overall control of the room’s light level and control of individual
devices, all with convenient, handheld portability.
It can be identified by the icon on its front, which resembles the
outline of a door leading to a room. It is used to control a
variety of LightSense wireless devices including dimmers,
switches, plug-in appliance modules and plug-in lamp modules.
The PSWRR is a battery operated portable device, so you can use it to control
its designated room from anywhere in the house. Each PSWRR is assigned to
one room and cannot operate devices that are bound to different rooms (see
(ROOM BINDING).
The PSWRR has the same functionality as the wall-mounted
PSWRR wireless room controller, but also has a SEEK button.
The SEEK feature allows you to use the remote to find up to
30 room devices or groups of devices and remotely adjust light
levels or turn switch devices on or off.
You can control up to fifteen scenes in the room (see MORE SCENES section).
You can use additional room scene remotes or PSWRR room scene controllers
to control those scenes from multiple locations.
Note: To control the entire house, use a LightSense wireless house scene
controller (a wall mounted PSWC or a handheld PSWR remote).
LightSense Wireless
LightSense wireless devices use radio signals to communicate with each other
to control lighting and other types of electric loads in selected areas. They use
the 900M z band for high-speed control communication. Using the patented
“frequency-agile” Top Dog™ technology, LightSense wireless devices avoid
interference with other 900M z devices, such as cordless phones and baby
monitors.
Application Assistance
The LightSense Installation Guide provides more information about configuring
scenes. Instructions for installation and use are included with the relevant
LightSense wireless devices. Application support information and the
LightSense Installation Guide is available at the Pass & Seymour/Legrand
website, www.passandseymour.com.
Call 800.223.4185 for Technical Support
Room icon
Seek button

SET HOUSE ID
All LightSense™ wireless devices installed in the same home must acquire the
same unique ouse ID before use. This process is known as house binding.
Each LightSense wireless device is bound to all other LightSense wireless
devices in the house.
New Installation
1. With all devices installed and energized, make sure that every LightSense
wireless device LED is yellow. If
any LED is off, be sure the circuit
breaker is on and the device is
correctly installed. The PSWRR
remote shuts down when it is not in
use. Press any button to activate
the remote and illuminate its LED.
2. Press on any device paddle
until the LED flashes yellow (about
2 seconds). This indicates that it has acquired a unique ouse ID.
3. Make sure that all other LightSense wireless device LEDs are flashing
green, indicating that they have acquired the same ouse ID. For PSWR
or PSWRR remotes, be sure that the units are awake during the binding
process. Press any button to activate the remote and illuminate its LED.
4. Return to the device used in step 2, which is still flashing yellow. Press
until the LED changes to solid green (about 2 seconds). All device LEDs in
the ouse change to solid green, indicating house binding is complete.
Adding an PSWRR to an Existing Installation
If you’re adding or replacing a device in a LightSense wireless installation that is
already operating, the new device must be bound to the same ouse ID as the
other LightSense wireless devices in the house. After the new PSWRR is
powered up, the LED should be solid yellow. This indicates that it has not yet
acquired a ouse ID. To acquire the ouse ID for the existing system:
1. Press on any previously bound device until the LED flashes yellow
(about 2 seconds).
2. Be sure that the PSWRR is awake during the binding process. Press any
button to activate the remote and illuminate its LED. Verify that the new
PSWRR LED is flashing green, indicating that it has acquired the ouse ID.
3. Return to the same previously bound device used in step 1 and press
until the LED changes to solid green (about 2 seconds). All device LEDs
should now be solid green.
isit our website for FAQs: www.passandseymour.com
When you see
in the instructions,
firmly press and
hold both the top
and bottom of the
paddle until the
LED changes
(about 2 seconds).

ROOM BINDING
After the ouse ID is set in the PSWRR, you create a room by binding devices
to the PSWRR. You can also add the PSWRR to an existing room. When a new
PSWRR is added to a room, its scene buttons execute the same scenes as
other room scene controllers with the same scene set assignment (see MORE
SCENES). Paddle functions are the same at every room scene remote and
controller that is bound to the same room, regardless of scene set assignment.
IMPORTANT: If you are planning to use Groups in the room, you should bind
those devices together before beginning the room binding process. Group
binding instructions are provided with individual devices.
Binding a New Room
1. With all devices installed and energized, make sure that every LightSense™
wireless device LED in the room is green.
2. Press on the PSWRR until its LED flashes yellow (about 2 seconds). You
now have 5 minutes to complete this process.
3. To include or exclude a device press on the device until the LED changes
color. Yellow flashing LED = Included in room
Green flashing LED = NOT included in room
If you get to a device and it is NOT flashing, see TROUBLES OOTING.
4. Return to the PSWRR. Press for about 2 seconds until the status LED
stops flashing yellow and begins flashing green rapidly. It flashes for up to 25
seconds. It is now recording the devices controlled by the SEEK button.
During this time, the PSWRR ignores all button presses. When complete, the
LED turns off and all the status LEDs in the room should be green.
Adding an PSWRR to an Existing Room
To add a PSWRR in a room where room level scene control is already operating,
the new PSWRR must first acquire the ouse ID (see Adding a PSWRR to an
Existing Installation). Then it must be bound to the existing room as follows:
1. Press on any previously bound PSWCR room controller or PSWRR
room remote in the room until the LED flashes yellow (about 2 seconds).
2. Press any button on the new PSWRR to wake it up and illuminate its LED.
Verify that the new PSWRR LED is flashing green. All other devices included
in the room are flashing yellow. Press on the new PSWRR until its LED
changes color. Yellow flashing LED = Included in room
Green flashing LED = NOT included in room
3. Return to the same previously bound PSWCR or PSWRR used in step 1
and press until the LED changes to solid green (about 2 seconds). The
PSWRR stops flashing yellow and begins rapidly flashing green. It flashes for
up to 25 seconds. During this time, the PSWRR ignores all button presses.
When complete, the LED turns off.

STANDARD OPERATION
The PSWRR is shipped with most functions preprogrammed for ease of
installation and initial use. This section summarizes the default operation of the
PSWRR. To make changes from this standard operation, such as changing light
levels and including or excluding devices from specific scenes, see
CUSTOMIZING OPERATION.
Paddle Functions
Use the rocker paddle to begin and end binding functions. It also functions as
an On/Off switch and a master light level Raise/Lower control for the room. All
devices bound to the same room as the PSWRR are included in the paddle
operation (except fan controls).
Scene Button Functions
The smaller buttons, labeled A–E in the illustrations, are used to record and
recall scenes. You can write the function of each button on the label on the back
of the remote. All devices bound to the same room as the PSWRR are included
in each scene button (except fan controls).
The following illustration shows the default operation for scene set 1-5:
NOTES:
1Pressing and holding the paddle does not affect the operation of switched
devices. They will maintain their present state.
2If the lights were turned off using the default E scene button or any
customized scene button programmed for 0%/ALL OFF, pressing and
holding will not raise the light level. It will raise the light level if the lights
were turned off by tapping .
3Scene buttons on PSWRR controllers with scene set 6-10 or 11-15 are
preprogrammed to turn off all room devices.
Call 800.223.4185 for Technical Support
Paddle Scene Buttons3

SEEK FEATURE
The seek feature lets you find up to 30 LightSense™ Wireless devices or
groups in the room, adjust light levels and turn devices on or off without leaving
your chair.
When you press the seek button, the remote finds the first device on its internal
list of devices bound to the room. As each device or group is found, device
LEDs blink green for 3 seconds. To further identify the load controlled by a
dimmer or lamp module, it fades the load to 0%, up to 100%, and back down
to the previous level, over a period of 1 second. Press the seek button again
within 6 seconds to step to the next device or group.
Use and on the PSWRR to turn a switch or appliance module on or off or
change the light level on a dimming device. You can also use a scene button to
quickly set a dimmer or lamp module to 0%, 25%, 50%, 75% or 100%.
While in seek mode, the remote’s LED flashes green. It will time out 6 seconds
after the last button press. You cannot use other functions until the time out is
complete and the LED stops blinking.
Setup and Maintenance of Seek Operation
When the room remote is first bound to the room, it has to compile its internal
list of all the other devices present in the room.
When the room binding operation is closed (by pressing and holding for
about two seconds) and when the PSWRR batteries are replaced, the LED
changes color from yellow to green, and flashes rapidly, for up to 25 seconds.
During this time, the PSWRR is establishing which devices should be controlled
by the SEEK button. During this time, the device is busy, and will ignore all other
button presses. When the operation is complete, the LED will extinguish.
Each time a device controlling a load is added to, or removed from the room,
the following steps should be taken on each PSWRR to ensure that the SEEK
button will operate all appropriate devices:
1. Press and hold on the PSWRR until the LED begins flashing yellow.
2. Press and hold again, until the LED begins flashing green rapidly.
3. Wait for the LED to stop flashing (about 20-25 seconds). While the LED is
flashing, the remote is busy and other functions are not available. When the
LED stops flashing, the handheld is prepared for SEEK button operation and
other functions.
isit our website for FAQs: www.passandseymour.com
When you see in
the instructions,
touch the top of the
paddle as directed.
When you see in
the instructions, touch
the bottom of the
paddle as directed.

CUSTOMIZING OPERATION
Modify and Save the Light Levels of a Scene
1. Change lighting levels as desired by pressing or on individual devices.
2. Press and hold the desired scene button on the room scene remote until the
LED flashes once (about 2 seconds) to save the new settings.
Removing or Adding Devices to a Scene
1. Press on the PSWRR until the LED begins flashing (about 2 seconds).
2. Press the scene button that you wish to program. LEDs on all wireless
LightSense™ devices begin to flash. You now have 5 minutes to complete
this process.
3. To include or exclude a device in the scene press on the device until the
LED changes color. Yellow flashing LED = Included in the active scene
Green flashing LED = NOT
included in the active scene
If you get to a device and it is NOT flashing, see TROUBLES OOTING.
NOTE: You must include devices that are off in the room scene if you want
them to turn off when that scene is recalled.
4. Return to the PSWRR used in step 1. Press for 2 seconds or until all the
status LEDs in the room turn green. The PSWRR continues to flash (about
20-25 seconds). Wait for the LED to stop flashing before pressing a button.
Removing or Adding Devices to the Paddle “On” Function
1. Press on the PSWRR until the LED begins flashing (about 2 seconds).
2. Tap the paddle on the PSWRR. The LEDs on all the LightSense wireless
devices begin to flash. You now have 5 minutes to complete this process.
3. To include or exclude a device press on the device until the LED changes
color. Yellow flashing LED = Included in paddle operation
Green flashing LED = NOT included in paddle operation
If you get to a device and it is NOT flashing, see TROUBLES OOTING.
4. Return to the PSWRR used in step 1. Press for 2 seconds or until all the
status LEDs in the room turn green. The PSWRR continues to flash (about
20-25 seconds). Wait for the LED to stop flashing before pressing a button.
5. To test, tap on any room scene controller that is bound to the same room
to switch included devices to on (dimmers go to full bright).
Removing or Adding Devices to the Paddle “Off” Function
1. Press on the PSWRR until the LED begins flashing (about 2 seconds).
2. Tap the paddle on the PSWRR. The LEDs on all the LightSense wireless
devices begin to flash. You now have 5 minutes to complete this process.
3. See step 3 above.
4. See step 4 above.

Call 800.223.4185 for Technical Support
5. To test, tap on any room scene controller that is bound to the same room
to switch or fade included devices to off (dimmers go to 0%)
MORE SCENES
Up to 15 scenes are available per room. Each room level controller can access
a set of 5 scenes. The PSWRR is assigned to scenes 1-5 when shipped.
Changing to scene set 6-10 lets you record 5 more scenes; changing to scene
set 11-15 lets you record another 5 scenes. Binding three room level controllers
(PSWRR or PSWCR) to the room and assigning each to a different scene set,
lets you dedicate a controller to each scene set. You can bind more room scene
controllers to the room to control the same scenes from multiple locations.
All room scene controllers that have the same scene set assignment operate
the 5 scenes in the same way as all other room scene controllers programmed
for the same set. Scene buttons on controllers with scene sets 6-10 and 11-15
default to 0%/All room devices OFF. Use ROOM
BINDING and CUSTOMIZING OPERATION procedures
to set up the additional scene controllers.
To assign scenes 6-10, simultaneously press and B
until the LED blinks twice (about 2 seconds).
To assign scenes 11-15, simultaneously press and C
until the LED blinks twice (about 2 seconds).
To change the assignment back to scenes 1-5,
simultaneously press and button Auntil the LED
blinks twice (about 2 seconds).
A= 1-5 (default) B= 6-10 C= 11-15
LOCK ROOM CONFIGURATION
The Lock Configuration function operates from a wireless LightSense™ room
level controller, and prevents the LightSense wireless devices in the room from
being reprogrammed. Other operations such as dimming, switching and scene
recall are not affected.
When the configuration is locked, if is pressed and held on any LightSense
wireless device, the device’s LED flashes red and the command is ignored.
To lock the configuration:
Go to any room scene controller. Simultaneously press
and buttons Band Euntil the LED flashes (about
2 seconds) to toggle in and out of Lock Configuration.
• If the mode changes from unlocked to locked, the
LED flashes red for 2 seconds, indicating that
configuration is now locked.
• If the mode changes from locked to unlocked, the
LED flashes green for 2 seconds, indicating that
configuration is now unlocked.
Assigning the PSWRR
for scene set 6-10

BATTERY INFORMATION
The PSWRR operates using three 1.5V Alkaline AAA size batteries. The remote
goes to sleep whenever it is not performing a function. When asleep, its LED is
off. To check battery status, press any button to wake up the remote.
IMPORTANT: Observe the color of the LED immediately after you wake it up.
• GREEN indicates the batteries are good.
• RED indicates the batteries are getting weak and should be replaced.
The battery compartment is on the bottom of the remote. Gently press up on the
battery door latching tab, then lift the cover to expose the batteries. Replace all
three using the same brand. Observe the pole orientation (+ - ) illustration on the
bottom of the battery compartment. The SEEK list is automatically rebuilt. Wait
for the LED to stop flashing before attempting to use the PSWRR.
TROUBLESHOOTING
During house ID binding, the LED is not flashing on some devices.
• If LED is solid green before initiating house ID binding:
The device already has another house ID. Reset it to the factory default so
that it can be bound to the desired house ID. See “I made a configuration
mistake. I need to start over” on the next page.
• If LED is solid yellow after initiating house ID binding:
The device may be out of range of the initiating device. Add a PSWO
Wireless Repeater to boost signal range.
During binding or customizing, all LEDs stop flashing before I press .
The 5 minute binding process timer may have expired. Restart the timer by
repeating steps 1 and 2 of the procedure you were using. Notice that the
devices you previously excluded are flashing green; those included are
flashing yellow; simply finish the process from where you left off.
The device LED flashes red when I press .
The house or room configuration may be locked.
Go to any house level scene controller and simultaneously press and
buttons Band Euntil the scene controller LED flashes GREEN.
Go back to the previously locked device and press .
• If it flashes green or yellow, you have unlocked the house configuration.
• If the device still flashes red, the configuration may be locked
by a room level scene controller such as the PSWCR or PSWRR.
Go to the room scene controller and simultaneously press and buttons B
and Euntil the scene controller LED flashes GREEN.
Go back to the previously locked device and press .
• If it flashes green or yellow, you have unlocked the room configuration.
• If the device still flashes red, the configuration may be locked
by another room level scene controller in the house. Repeat the procedure
from different controllers until the device is no longer flashing red.

LIMITED FI E YEAR WARRANTY
Pass & Seymour will remedy any defect in workmanship or material in Pass & Seymour products which may
develop under proper and normal use within five years from date of purchase by a consumer: (1) by repair or
replacement, or, at Pass & Seymour’s option, (2) by return of an amount equal to consumer’s purchase price.
Such remedy is IN LIEU OF ANY AND ALL EXPRESSED OR IMPLIED WARRANTIES OF
MERC ANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Such remedy by Pass & Seymour does
not include or cover cost of labor for removal or reinstallation of the product. ALL OT ER FURT ER
ELEMENTS OF DAMAGE (INCIDENTAL OR CONSEQUENTIAL DAMAGES) FOR BREAC OF ANY AND
ALL EXPRESSED OR IMPLIED WARRANTIES INCLUDING WARRANTIES OF MERC ANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ARE EXCLUDED EREBY. (Some states do not allow
disclaimers or exclusion or limitation of incidental or consequential damages, so the above disclaimer and
limitation or exclusion may not apply to you.) ANY IMPLIED WARRANTIES INCLUDING W ERE REQUIRED
WARRANTIES OF MERC ANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE S ALL BE LIMITED
TO T E FIVE YEAR PERIOD SET FORT ABOVE. (Some states do not allow limitations on how long an
implied warranty lasts, so the above limitation may not apply to you.) To ensure safety, all repairs to Pass &
Seymour products must be made by Pass & Seymour, or under its specific direction. Procedure to obtain
performance of any warranty obligation is as follows: (1) Contact Pass & Seymour, Syracuse, New York
13221, for instructions concerning return or repair; (2) return the product to Pass & Seymour, postage paid,
with your name and address and a written description of the installation or use of the Pass & Seymour
product, and the observed defects or failure to operate, or other claimed basis for dissatisfaction. This
warranty gives you specific legal rights and you may also have other rights which vary from state to state.
FCC NOTICE
This equip ent has been tested and found to co ply with the li its for a Class B digital device, pursuant to part 15 of
the FCC Rules. These li its are designed to provide reasonable protection against har ful interference in a residential
installation. This equip ent generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, ay cause har ful interference to radio co unications. However, there is no
guarantee that interference will not occur in a particular installation. If this equip ent does cause har ful interference
to radio or television reception, which can be deter ined by turning the equip ent off and on, the user is encouraged
to try to correct the interference by one or ore of the following easures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equip ent and receiver.
• Connect the equip ent to an outlet on a circuit different fro that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or odifications to this device not explicitly approved by Pass & Sey our/Legrand could void
your authority to operate this equip ent.
The Seek button does not pick up all the devices in the Room.
When a room remote is ‘asleep’ it will not respond to changes in room
binding. Maybe a change to room binding took place, such as adding a new
device, and the remote doesn’t know about it. Press for two seconds TWO
TIMES, and the remote will re-tabulate its list of room members.
I made a configuration mistake. I need to start over.
To reset any LightSense™ wireless device to factory default settings, press
and hold until the LED changes to solid yellow (approximately 10
seconds). During the process, the LED flashes yellow. When complete, it
becomes solid yellow. The device can then be reconfigured, exactly like any
new device.
P.O. Box 4822 • Syracuse, NY • 13221-4822
Technical Support: 800.223.4185
www.passandseymour.com
