Leister Electron User manual

1
LEISTER Electron
Hot-Air Blower
Please read operating instructions carefully
before use and keep for further reference.
•Heating-up for forming, bending and sealing of thermoplastic semi-
finished materials.
•Drying of water-damp surfaces and joints.
•Shrinking of heat-shrink sleeves, films, tapes, solder sleeves and moulded
parts.
•Activating/dissolving of solvent free adhesives and fusion adhesives.
•Removing old shellac, oil, resin paints and underseals on vehicles.
•Defrosting of frozen water pipes.
•Welding thermoplastic materials as well as modified bitumen.
•Igniting of wood shavings, paper, coal or straw in furnaces.
GB
OPERATING INSTRUCTIONS
APPLICATION
LEISTER Process Technologies, Riedstrasse, CH-6060 Sarnen/Switzerland
Tel. [phone] Fax [phone] www.leister.com [e-mail]
®
LEISTER SALES & SERVICE CENTER CHINA , 20H Building No.1 515 Yishan Road ,Shanghai, PRC
Tel. [phone] Fax. [phone]
http://www.plasticwelding.cn E-mail: [email protected]

Voltage V~
Power consumption W
Temperature °C
Air flow l/min.
Air pressure mbar
Emission level LpA (dB)
Weight kg
Size mm
42, 120, 200, 230, 230, 230, 400 for 50/60 Hz
1000, 2700, 2600, 2300, 3400, 4500, 5500
20 – 650, steplessly adjustable
max. 500, manual air slide
30
65
1.5 with 3m power supply cord
320 ×64
2
Line/mains voltage
cannot be
switched over
Electrical safety: Double insulated
TECHNICAL DATA
Danger to life when opening the tool, as live compo-
nents and connections ar exposed. Unplug the tool
before opening it.
Incorrect use of hot air blowers can cause fire and
explosion hazard, especially near combustible materials
and explosive gases.
The tool must be operated with supervision. Warmth
can reach combustible materials, which are out of sight.
For personal protection on building sites we strongly
recommend the tool be connected to a GFCI (Ground
Fault Circuit Interrupter) or a RCCB (Residual Current
Circuit Breaker) .
The voltage rating stated on the tool must correspond to
the line/mains voltage.
Do not touch the element housing and nozzle when
they are hot as they can cause burns. Let the tool cool
down. Do not point hot air flow in the direction of
people or animals.
Protect tool from damp and wet.
FI
120
230
WARNING
CAUTION
APPROVAL MARK

Description of tool
1. Power supply cord
2. On/off switch
3. Potentiometer for
temperature adjustment
4. Handle
5. Air slide
6. Air filter
7. Rubber stand
8. Heater tube
9. Scale
Operating condition
• As required, push-fit appropriate nozzle or reflector.
•Connect tool to the line/mains.
• Reduce air flow as required by use of the air slide (5).
•Adjust hot-air temperature by use of the potentiometer (3). Standard values see
temperature scale (9).
•Switch on (3) and allow to warm up for about 5 min.
Operation
•LEISTER Process Technologies as well as the Service Centres offer free training
courses for all applications (see page 1).
• Cool down the tool after use.
Change of nozzles/reflectors
•Before changing nozzles/reflectors, allow the tool to cool down, or use only
combination pliers.
•Do not touch hot nozzle/reflector and make sure to put it only on a heat resistant
surface, because of the fire hazard.
•The nozzles/reflectors are easily pushed onto the conical heater tube (8) and are
then secured by fastening the screw on the clamp.
• Only LEISTER nozzles/reflectors should be used.
6
85
7 9 2
34
1
3
OPERATION LEISTER Electron

4
BA Electron/11.2001/GB
MAINTENANCE
ACCESSORIES
•The hot-air blower’s air filter (6) should be cleaned with a brush if nescessary.
•Check power supply cord (1) and plug for any possible electrical or mechanical
damages.
SERVICE AND REPAIRS
•The carbon brushes of the welding tool's motor should be checked after
about 1600 hours running time by your Service Centre.
•Repairs have to be carried out by authorised LEISTER Service Centres only.
They guarantee a specialized and reliable repair service within 24 hours using
original LEISTER spare parts.
•Guarantee and liability are in accordance with the guarantee certificate as
well as with the currently valid general business and sales conditions.
•LEISTER Process Technologies rejects any guarantee claims for tools which are
not in their original condition. The tools must never be altered or changed.
Technical data and specifications are subject to change without prior notice.
Your authorised Service Centre is:
GUARANTEE AND LIABILITY
®
LEISTER Process Technologies, Riedstrasse, CH-6060 Sarnen/Switzerland
Tel. [phone] Fax [phone] www.leister.com [e-mail]
•Use LEISTER accessories only.
