LENCO XEMIO-119 User manual

Instruction Manual
Xemio-119/129/139

Notice : Thank you for choosing our product! Please read the user's manual
carefully to ensure proper operation.
Content
Precautions
System requirement
1. Installation instruction
1.1 Installing the driver
1.2 Installing the battery
2. Connecting/ downloading
2.1 Connecting to PC
2.2 Removing USB device
3. Basic operation
3.1 Buttons and functions
3.2 Power on/off
3.3 Main menu setup
4. MP3 Player Operation
4.1 Playing music
4.2 Playing voice files
4.3 Function Setting
1

4.3.1 Setting EQ mode
4.3.2 Setting Play mode
4.3.3 Setting Contrast
4.3.4 Setting Backlight
4.3.5 Setting Power set
4.3.6 Setting Recording
4.3.7 Setting Language
4.3.8 Exit
4.4 Preview function
4.5 About
4.6 Folder function
4.7 Exit
5. Recording function
6. A-B loop playing
7.Lock function
Lyric sync
USB mode
FAQ
Technical specifications
2

Precautions
1) Never use the player during driving or operating other vehicles to avoid
traffic accident, which is also restricted by the law in some districts. Even on
foot, it is still dangerous to listen to extremely high volume levels, especially
when crossing the street. Whenever your surroundings require alertness,
please stop using the player for safety purposes.
2) Please connect the earphones before you switch on the player. This not
only avoids damaging the earphones, but also helps to keep the player in
good condition.
3) Keep the player clean and away from heat sources or direct sunlight, dirt,
high humidity and rain.
4) If the surface is dirty, please clean it carefully with a damp soft cloth or soft
abluent. Never clean the case with alcohol or diluents.
5) Never use the player in rather dry environment to avoid static.
6) Never disconnect the player from PC abruptly during downloading,
uploading and formatting to avoid application failure.
7) When the player is used as removable disk, please follow the proper file
download and upload procedures. Our company resumes no responsibility for
any file lost due to improper operation.
3
8) You can res et by removing the AAA batteries.

System requirement
System requirement of MP3 player:
Microsoft Windows 98 se /2000/Me/XP
Pentium 200MHZ or above.
USB port
120MB hard disk space
Mouse installed
CD-ROM drive
4

1. Installation instruction
1.1Installing driver for Windows 9 8se (not required for Windows ME or above)
a. Connect the MP3 Player to the USB port of a PC, "Find new hardware"
appears on the screen, then click "Search latest driver for this device" and
insert the driver CD into CD-ROM, and then click "Next".
b. Select "Look in" to direct the installation directory to the "Drivers" files in
the driver CD, then click Yes.
c. PC will install the driver for Windows 98 se automatically.
1.2 Installing battery
Install one AAA alkaline battery properly upon indicator on the play.
Press button to power the player on and enter the MP3 standby mode.
2. Connecting and downloading
2.1 Connecting a PC as USB
Before operation, please verify the player is powered on with one end of the
USB cable came with the system inserted into PC and another end into the
MP3 player.
Data transferring
Reminder: Due to computer capability issue, please turn on your MP3 Player before
connecting to the USB port !
5

2.2Removing the USB device
a.Double click the Safely Remove Hardware icon in taskbar:
b.From Safely Remove Hardware screen, highlight "USB Mass Storage
Device" item, and then click "Stop" button. "Stop to Hardware Device"
window appears on the screen as shown in the picture below.
player can be disconnected from PC safely.
Notice: Never unplug the USB cable when transmitting data with PC to avoid
damaging the Player; after data transmitting, please do not disconnect the player
6
from PC until "Device now be safely removed" appears; while using USB function,
all other buttons will be nonfunctional. Any application lost or I/O error and power
on issues caused by improper operations, please refer to FAQ.

7

8

3. Basic operation
3.1 Buttons and functions
1) Earphone jack 2) Next 3) VOL- 4) Microphone
5) VOL+ 6) Play/Pause/Stop 7) LCD display
8) A-B/REC 9) Last 10) Menu 11) Hold
9

3.2 Power on/off
From power off mode, press the button to power the player on and
enter the MP3 standby mode; press the button 3 seconds under any
mode, the player will save the data and enter power off mode.
MP3 standby mode
* Importance If the power is directly cut off in standby mode or play back
process, all the data set cannot be saved! *
3.3 Main menu setup
From standby or playing mode, you can keep pressing the MENU button to
enter the main menu function-setting mode.
Push the or button to select: Play music, Play voice, Setting, Preview,
About, Folder and Exit; you can press the MENU button to enter the desired
setting.
4. How to use the MP3 player
4.1Playing music
a) From MP3 standby mode, you can press the button to play MP3
10

music and press the button again to pause. To resume playing, please
press the button the third time.
Play Pause
b) From play or pause mode, press and hold the button 2 seconds,
the player will return to the MP3 standby mode, press and hold the
button again, it will repeat step "a)".
c) From MP3 standby or play mode, you can push the or button to
select last or next music.
d) From STOP status, you can push and hold the or button to find
your desired music quickly.
e) From play mode, you can press the or button to fast backward
or forward in this music.
f) From play mode, press the V + or V-button to adjust volume.
g) From MP3 standby, play and pause mode, press and hold the
button 3 seconds, the player will save the data and enter the power off
mode.
4.2 Playing voice
a) From MP3 mode or voice standby mode, keep pressing the MENU button
11

to enter the main menu. To enter the playing voice mode, push the or
button to select Voice and press the MENU button. You can press the
button to play, and press this button again to pause. To resume playing,
please press this button a third time.
Play pause
b) From voice standby or play mode, you can press the or button to
select last or next voice file.
c) From STOP status, you can push and hold the or button to find
your desired music quickly.
d) From Play mode, you can push and hold or button to fast
backward or forward in this music.
e) From voice standby mode, press the button 3 seconds, the player
will enter the MP3 power off mode.
Note : The EQ selection will be unavailable when playing the voice files.
4.3 Function Setting
From MP3 mode or voice standby mode, keep pressing the MENU button to
enter the main menu, and push the or button to select setting and press
the MENU button to enter. The function setting includes: EQ mode,play mode,
12

contrast,backlight, power set, recording set, language and exit. press the
MENU button to save the selected setting mode.
4.3.1 Setting EQ mode
Push the or button to select the EQ mode: Normal, pop, rock, classical ,
jazz and bass. Press MENU button to save the selected EQ set.
4.3.2 Setting Play mode
Push the or button to select the playing mode, including: Normal,
repeat one, repeat all and shuffle. You can press the MENU button to save
the selected play mode.
Normal repeat one
repeat all shuffle
13

4.3.3 Setting Contrast
Push the or button to adjust the contrast of LCD. Press MENU
button to save the selected setting.
4.3.4 Adjusting Backlight
Push the or button to select the backlight setting, including: Off, 5s,
10s, on. Press MENU button to save the selected setting.
4.3.5 Setting Power set
Push or button to select the Power set, including: 2m, 10m, 30m,
off. Press the MENU button to save the selected shutdown time.
4.3.6 Setting Recording
Push or button to select the recording setting, including: 8000Hz,
11000Hz, 16000Hz, 22000Hz. Press the MENU button to save the select
14

the recording setting.
4.3.7 Setting language
Push the or button to select language: German, English, French,
Spanish, Italian,Dutch ,Portuguese or Hungarian. Press the MENU button
to save the selected language.
4.3.8 Exit
Return to previous mode.
4.4 Preview function
From MP3 mode or voice standby mode, you can press the MENU button to
enter the main menu, and push the or button to select the preview
function setting, and then press the MENU button to begin previewing. During
preview, it will play the initial 10 seconds of each music file and then skip to
next. You can press the button to exit.
15

4.5 About
From MP3 mode or voice standby mode, you can press the MENU button to
enter the main menu, and push the or button to select About function,
and then press the MENU button to view the total memory and available
memory.
4.6 Folder function
From MP3 mode or voice standby mode, you can press the MENU button to
enter the main menu, and push the or button to select folder function,
and then press the MENU button to enter. You can push and hold the MENU
button to browse the file, and push the or to select the desired one.
In folder mode, press MENU to enter PLAY OR DELETE mode,press the
or button to select.press MENU to confirm .if you select the play,it will
play the current song.if you select the delete,it will go to the delete menu.
Press the or button to select YES OR NO. Press MENU to confirm and
press to exit.
16

Note: You can not view the record folder and file under play music mode, which will
only be available in play voice mode. )
4.7 Exit
Return to MP3 mode. Note: From setting mode, you can press the button
to exit the setting mode quickly.
5.Recording function
From MP3 mode or voice standby mode, keep pressing the A-B /REC button,
the player begin recording, and press the A-B/REC button again to stop. You
can press the button to play voice, and press this button again to pause.
To resume playing, please press this button a third time.
recording Stop recording
6. A-B Play Mode
From MP3 or voice mode:
1) Press the A-B /REC button to select starting point A.
2) Press the A-B /REC button to select end point B, it will repeat between A-B.
3) Press the A-B /REC button again to cancel setting and resume playing MP3
or voice.
17

7. Lock function
From MP3 and voice standby/ play/ pause/ record mode, you can push the
HOLD switch opposite the arrow to lock all the other buttons with a Lock icon
on the LCD accordingly. If you want to use other buttons, please push the
HOLD switch to the opposite direction of arrow.
Lyric sync
This player supports lyric sync function.
Notice: The lyric name shall be the same as music with suffix of *. LRC and saved in
the same directory, and only the lyrics with time indication can be displayed properly.
USB mode
Plug the Player into the USB port of a PC, relative icons appears on the LCD
screen.
LCD screen may display relative icon when transmitting files between the
Player and PC.
On how to update the software or format the removable disk, please refer to
the website.
18

FAQ
Problem Causes Solution
No display after
pressing the
power button.
Without installing
battery or battery low.
Verify the battery is installed,
change battery.
Without sound
when playing
music.
1. Volume is too low or
without music in your
player.
2. Battery low.
1. Adjust volume or download
file.
2. Change battery.
3. MP3 or WMA file is
corrupt.
3. Download the documents
again.
Can not
download music
file after
connection.
1. HOLD is on, the disk
is write protected.
2. The USB is not
connected to PC
properly.
3. Storage directory is
wrong.
1. Push the HOLD switch to
the opposite direction.
2. Connect to the USB
interface again and verify PC
identified the removable disk.
3. Maximum 256 folders or
files can be saved under root
directory (if the file name is
over 8 characters, the
number of folder or file will
decrease accordingly); if
exceeded, please create
another subdirectory under
root directory before copy.
19
