LENCO XEMIO-253 User manual

XEMIO-253
MP3-Player
User manual
www.lenco.com

XEMIO-243/253 USER MANUAL
2
Special Features
•Elegant appearance and easy to use.
•Multi-Code Player - Supporting MP3, WMA, formats.
•Driver Free U Disk - You may manage your files directly through “Portable
Device” in “My Computer” on Windows 2000 Operating System or above
without driver.
Brief View of Player
A. About player’s battery
Player has an internal, non–user-replaceable rechargeable lithium battery. For best
results, the first time you use the player, let it charging for about 1 - 2 hours or until
the charging LED lights go Off before you use it.
Charging the Battery
You can charge the Player’s battery in two ways:
1. Connect player to your computer. Or,
2. Use the USB power charger. (available separately)
B. Key function of buttons
Appearance

XEMIO-243/253 USER MANUAL
3
•button: To Play / Pause, On / Off.
•button: To previous song or fast-backward.
•button: To the next song or fast-forward.
•button: To increase volume level.
•Button: To decrease volume level.
•USB: For PC connection and charge function
C. Getting start player
1 Turn On / Off
1.1 Plug in earphone set into player’s jack
1.2 Press and hold button, for about 3 - 4 second, the player will turn
On and the music will play directly.
1.3 Press and hold button, for about 3 - 4 second, to turn Off the
player.
2 Play / Pause Music
2.1 Press button to pause the playing music, press it again to play.
2.2 If player is in pause state for 3 minutes, it will be turned to Off
automatically.
3 Adjust Volume
3.1 Pressing / button to increase or decrease volume level.
3.2 Press and hold / button to increase or decrease volume level
faster.
3.3 For hearing protection; a beep warning will be heard from earphone
every time you increase the volume level and reach to the default
setting level, which may exceed 85dB. Press button to accept the
warning and press / button again to increase the level until to
maximum level.
4 Play Next / Previous Music

XEMIO-243/253 USER MANUAL
4
4.1 In playing mode, press button to select next music.
4.2 Press button to select previous music.
5 Play Fast-Forward / Fast-Backward
5.1 In playing mode, press and hold button to enter fast-forward
mode.
5.2 Press and hold button to enter fast-backward mode.
D. USB mode
1 Connect player to computer
1.1 Connect player to computer with the USB cable, then a “USB Mass
Storage Device” is detected and related driver is installed by you
computer. (Windows 2000 / XP System or about)
1.2 A removable disk drive will be shown in “My computer” folder, now you
can start Read / Write operation. And the battery is charging in
background.
1.3 In connection mode, the player can be play music if you press or
pressing the play button. However, the player may stop or start playing
if removing the PC connection.
2 Remove player from computer:
Please safety to removes the player in computer, otherwise, the data stored in
the Player might loss.
2.1 If you’re using a Windows PC, you can disconnect the player in My
Computer or by clicking the “Safely Remove Hardware” icon in the
Windows system tray.
2.2 If you’re using a Mac, you can also disconnect player by dragging the
player icon on the desktop to the Trash.

XEMIO-243/253 USER MANUAL
5
2.3 And now, is safe to disconnect the player with your computer, unplug
the USB connector from player and then your computer.
2.4 If you’re accidentally disconnect player without disconnect it,
reconnect it to your computer.
2.5 At power ON mode, after remove the PC connection, the player will
auto-play the music directly.
E. Indicator light function
•Playing Mode: Red light flashing once per second.
•Pause Mode: Red light bright.
•PC Connecting Mode: Red light bright. (Charging in background)
•Recharging Mode: Red light bright.
•Recharge complete: Red light will turn OFF
F. Troubleshooting
Play cannot turn ON •Check whether battery have enough energy.
No sound is heard •Check whether Volume is set to “minimum”
and connect the headphone plugs firmly.
•Check whether the headphone plug is dirty.
•Corrupted WMA / MP3 may make a static
noise and the sound may cut off. Make sure
that the music files are not corrupted.
•Check whether music files format are support.
Download of music files fails. •Check whether player’s USB connector is
connected with computer properly.
•Check whether driver is installed correctly.
•Check whether the player’s memory is in full.

XEMIO-243/253 USER MANUAL
6
G. Specification
Dimension 45.5 mm (H) x 35 mm (W) x 18 mm (D)
Weight 15g
PC Connection USB 2.0 (High Speed)
Earphone Impedance 32 Ohm
Internal Memory Flash memory: Xemio-243 2GB
Xemio-253 4GB
Battery Built-in Rechargeable Lithium battery (3.7V 110mA)
Playing Time: about 6 – 7 Hours
Supports Music Format
MP3 32kbps - 320kbps
WMA 32kbps – 384kbps
Audio Earphone Output Power
L: 275mVrms + R: 275mV
(32 Ohm)
Frequency Response 20Hz – 20,000Hz
SNR 80dB
Operation Temperature
-0 ℃ - 40 ℃
Operation Systems Windows 98/SE/ME2000/XP/Vista, MAC 9.2 or above
Note: Product design and specification are subject to change without prior notice.

XEMIO-243/253 USER MANUAL
7
Safety instructions
IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY BEFORE USE.
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
CAUTION: TO PREVENT AN ELECTRICAL SHOCK, DO NOT
REMOVE ANY COVER SCREWS. THERE ARE NO USER
SERVICEABLE PARTS INSIDE. REQUEST A QUALIFIED SERVICE
PERSON TO PERFORM SERVICING.
This symbol indicates that there are important operating maintenance
instructions in the user manual accompanying this MP3.
This symbol indicates that dangerous voltage is present within this
MP3, constituting a risk of electric shock or personal injury.
Keep these instructions in mind:
Do not use this device near water.
Clean only with a slightly damp cloth.
Do not cover or block any ventilation opening. When placing the device on a
shelf, leave 5 cm (2”) free space around the whole device.
Install in accordance with the supplied user manual.

XEMIO-243/253 USER MANUAL
8
Don’t step on or pinch the power cord. Be very careful, particularly near the
plugs and the cable’s exit point. Do not place heavy items on the power cord,
which may damage it. Keep the entire device out of children’s reach! When
playing with the power cable, they can seriously injure themselves.
Unplug this device during lightning storms or when unused for a long period.
Keep the device away from heat sources such as radiators, heaters, stoves,
candles and other heat-generating products.
Avoid using the device near strong magnetic fields.
ESD can disturb normal usage of this device. If so, simply reset and restart the
device following the instruction manual. During file transmission, please
handle with care and operate in a static-free environment.
Safety instructions - continued
WARNING! NEVER INSERT AN OBJECT INTO THE PRODUCT THROUGH
THE VENTS OR OPENINGS. HIGH VOLTAGE FLOWS THRU THE
PRODUCT AND INSERTING AN OBJECT CAN CAUSE ELECTRIC SHOCK
AND/OR SHORT CIRCUIT INTERNAL PARTS. FOR THE SAME REASON,
DO NOT SPILL WATER OR LIQUID ON THE PRODUCT.
Do NOT use in wet or moist areas such as bathrooms, steamy kitchens or
near swimming pools.
Do not use this device when condensation may occur.
This MP3 is produced according to all current safety regulations. The following
safety tips should safeguard users against careless use and dangers involved with
such use.
Although this device is manufactured with the utmost care and checked
several times before leaving the factory, it is still possible that problems may
occur, as with all electrical appliances. If you notice smoke, an excessive

XEMIO-243/253 USER MANUAL
9
build-up of heat or any other unexpected phenomena, you should disconnect
the plug from the main power socket immediately.
This device must be well ventilated at all time!
This device must operate on a power source as specified on the specification
label. If you are not sure of the type of power supply used in your home,
consult your dealer or local power company.
The socket outlet must be installed near the equipment and must be easily
accessible.
Do not overload AC outlets or extension cords. Overloading can cause fire or
electric shock.
Keep away from rodents. Rodents enjoy biting on power cords.
Always hold the plug when pulling it out of the main supply socket. Do not pull
the power cord. This can cause a short circuit.
Avoid placing the device on any surfaces that may be subject to vibrations or
shocks.
When the device is not in use for long periods, unplug the AC power cable for
safety reasons.
To clean the device, use a soft dry cloth. Do NOT use solvents or petrol based
fluids. To remove severe stains, you may use a damp cloth with dilute
detergent.
The supplier is not responsible for damage or lost data caused by malfunction,
misuse, modification of the device or battery replacement.
If the device will not be used for an extended period, please charge the battery
at least once per month to maintain battery life.

XEMIO-243/253 USER MANUAL
10
Safety instructions - continued
Charge the battery if:
a) The battery level icon displays (An empty battery)
b) The device switches off automatically when restarted.
Do not interrupt the connection when the device is formatting or transferring
files. Otherwise, data may be corrupted or lost.
WARNING: Prolonged exposure to loud sounds from personal music
players may lead to temporary or permanent hearing loss.
BEFORE SENDING YOUR DEVICE TO LENCO DO NOT FORGET TO
BACKUP YOUR DATA. SUPPLIER IS NOT LIABLE FOR ANY DATA
LOSS.
Do not distribute copyright-protected material without the permission of
the content owners. Doing this may violate copyright laws. The
manufacturer is not liable for any legal issues caused by the user’s
illegal use of copyrighted material.

XEMIO-243/253 USER MANUAL
11
Service and support
For information: www.lenco.com
For support: http://lencosupport.zendesk.com
Lenco helpdesk:
Germany 0900-1520530 (Local charges)
The Netherlands 0900-23553626 (Local charges + 1ct p/min)
Belgium 02-6200115 (Local charges)
France 03-81484280 (Local charges)
The helpdesk is accessible from Monday till Friday from 9 AM till 6 PM.
When contacting Lenco, you will always be asked for the model and serial number
of your product. The serial number can be found on the back of the device. Please
write down the serial number below:
Model: XEMIO-253
Serial number:_________________________________
Lenco offers service and warranty in accordance to European law, which means
that in case of repairs (both during and after the warranty period) you should
contact your local dealer.
Important note: It is not possible to send products that need repairs to Lenco
directly.
Important note: If this unit is opened or accessed by a non-official service center
in any way, the warranty expires.
This device is not suitable for professional use. In case of professional use, all
warranty obligations of the manufacturer will be voided.

XEMIO-243/253 USER MANUAL
12
This symbol indicates that the relevant electrical product or battery
should not be disposed of as general household waste in Europe. To
ensure the correct waste treatment of the product and battery,
please dispose them in accordance to any applicable local laws of
requirement for disposal of electrical equipment or batteries. In so
doing, you will help to conserve natural resources and improve
standards of environmental protection in treatment and disposal of electrical waste
(Waste Electrical and Electronic Equipment Directive).
Products with the CE marking comply with the EMC Directive
(2004/108/EC) and the Low Voltage Directive (2006/95/EC) issued
by the Commission of the European Community.
The declaration of conformity may be consulted at
http://www.lenco.eu/supportfiles/CE/fqeiofha89fef.pdf
®All rights reserved
