XC15 Air Conditioner ◆Up to 16.70 SEER
Home Comfort Systems
XC15
The quietest central air conditioner
you can buy*
Compatible with the exclusive Humiditrol®
whole-home dehumidification system—
indoor air quality you can feel

2
THE QUIETEST CENTRAL AIR CONDITIONER YOU CAN BUY*
The XC15 not only provides peace and quiet—it also offers peace of mind.
The exclusive Lennox System Operations Monitor continually monitors system
performance, helping technicians solve problems faster and more accurately.
And, like all Lennox products, the XC15 is built to deliver exceptional reliability
with a promise of quality you can count on year after year.
Dave Lennox Signature®Collection XC15 Air Conditioner
*Air conditioners/heat pumps have sound ratings established per ARI’s test standard: ARI 270. Size for
size, as a product family, these air conditioners have the lowest published sound ratings of any major
U.S. brand of air conditioning/heat pump equipment.
Patented SilentComfort™
technology provides
smooth, quiet cooling
Efficient design can result in
significant energy savings
Ozone-responsible
R410A meets the EPA’s
(Environmental Protection
Agency) most stringent
environmental guidelines
Lennox™System Operations
Monitor reviews system
performance for additional
peace of mind and faster,
easier servicing
Compatible with the exclusive
Humiditrol®whole-home
dehumidification system**
ENERGY STAR®qualified
seer
16.00 vs. 10.00 16.00 vs. 13.00
$1200
$1000
$800
$600
0
$1190
16.00 SEER XC15 air conditioner,
compared to older, less-efficient units
5-YEAR COOLING SAVINGS
$455
This chart compares the 5-year savings you can expect from
an XC15 air conditioner vs. units with lower efficiency ratings.
The regions used to calculate household fuel and utility
costs reflect a cross-section of cities in the U.S. using
2006 Department of Energy national average energy rates.
In addition to geography, cooling costs are based on 3-ton
capacity specification, with 1,600 cooling hours per year.
Your actual costs will vary depending on the weather, local
fuel rates, systems settings and your personal lifestyle.
Efficient Can save
hundreds of dollars each year
on utility bills
The XC15 air conditioner provides
cooling efficiencies of up to 16.70
SEER. The higher the efficiency
rating, the higher your energy
savings. In the case of the XC15,
those savings can translate to
hundreds of dollars over five years.
Innovation never felt so good.
™
EFFICIENCY RATING
Up to 16.70 SEER (Seasonal
Energy Efficiency Ratio).
WARRANTY***
10-year limited warranty
on the compressor and
all remaining covered
components.
SOUND INTENSITY
Note:
Manufacturers’
public ratings.
Typical 80 dB
air conditioner/
heat pump vs
XC15-024 or 030.
It would take 40 XC15s
to equal the sound from
one typical air conditioner.
Customizable Compatible with the new Humiditrol®
whole-home dehumidification system
The XC15 gives you the flexibility to choose a Humiditrol®whole-home
dehumidification system for improved comfort and indoor air quality.
The Humiditrol system uses patented technology to provide a level of humidity
control never before available.
**Must be accompanied by either a
variable speed air handler or furnace
and ComfortSense 7000 Series
Touchscreen Thermostat.
***Applies to residential applications only.
See actual warranty certificate for details.

3
13.00-16.70
21.013.0
THIS MODEL
Dave Lennox Signature®Collection XC15 Specifications
XC15 024 030 036 042 048 060
SEER Up to 16.70 Up to 15.20 Up to 15.50 Up to 15.20 Up to 15.20 Up to 14.00
Sound Rating-dB 63 63 66 66 70 70
Dimensions HxWxD (in.) 37 x 35-1/2 x 39-1/2 37 x 35-1/2 x 39-1/2 37 x 35-1/2 x 39-1/2 37 x 35-1/2 x 39-1/2 47 x 35-1/2 x 39-1/2 47 x 35-1/2 x 39-1/2
HxWxD (mm) 940 x 902 x 1003 940 x 902 x 1003 940 x 902 x 1003 940 x 902 x 1003 1194 x 902 x 1003 1194 x 902 x 1003
Note: Due to Lennox’ ongoing commitment to quality, all specifications, ratings and dimensions are subject to change without notice.
SilentComfort™Fan Grille –
Uses patent-pending vortex-suppression
technology to reduce sound of airflow exiting unit.
Factory-Installed Lennox™System
Operations Monitor – Continually reviews
system performance to allow fast troubleshooting.
Precision-Balanced, Direct-Drive Fan –
Delivers ultra-quiet operation with a
patent-pending fan design.
High-Efficiency Outdoor Coil –
Provides exceptional heat transfer and low air
resistance for high-efficiency operation.
Dependable Scroll Compressor
with SilentComfort Technology –
Provides smooth, efficient and reliable operation.
Durable Steel Cabinet –
Made to last with superior high-quality, pre-painted
steel and textured finish. Tested to withstand the
harshest environments.
OUTSTANDING FEATURES FOR EXCEPTIONAL COMFORT AND EFFICIENCY
XC15
Up to 16.70 SEER
The quietest central
air conditioner you
can buy.*
ENERGY STAR®
qualified
Quality you can trust.
Constructed of heavy-gauge, pre-painted
steel and tested in the most extreme
environments to ensure maximum durability.
Proper sizing and installation of
equipment is critical to achieve
optimal performance. Split
system air conditioners and
heat pumps must be matched
with appropriate coil components
to meet ENERGY STAR®criteria.
Ask your Lennox dealer for details,
or visit www.energystar.gov.
Lennox is proud of
the fact that these
products have
earned the Good
Housekeeping Seal.

© Lennox Industries Inc. 2008
Visit us at www.lennox.com, or contact us at 1-800-9-LENNOX. PC54609(14W56) XC15 06/08
1Air conditioner or heat pump
2Thermostat
3Furnace or air handler
4Filtration device
5Germicidal light
6Indoor coil
7Humidifier
8HEPA bypass filtration system
9Energy recovery ventilator
 Supply duct
 Return duct
 Dehumidifier system
 Residential generator
CUSTOMIZE YOUR COMFORT
Lennox®heating, cooling and indoor air quality products are designed to
provide efficient, economical comfort—not only as individual units, but also
together as an integrated system. This combined network of products delivers
on every comfort count, from consistent temperatures and balanced humidity to improved indoor air quality. Lennox
also offers a line of residential generators, which provide safe, reliable standby power in the event of outages.
DEALERS YOU CAN COUNT ON
Choosing the right dealer for your home’s heating, cooling and air quality needs is every bit as important as choosing the
right brand. We think you’ll agree our independent dealers are a big reason you can count on quality customer service
whenever you call. Your Lennox dealer’s dedication to quality shows in his knowledge, training and expertise in designing
the right system for your home, installing it properly and keeping it running perfectly for many years to come.
