Leviton Decora Smart DG6HD User manual

Getting Started Guide
Cat. No. DG6HD
DIMMER
WEB VERSION

WEB VERSION

3
See the complete line of Zigbee enabled
dimmers, switches and plug-ins
leviton.com/decorasmart
Welcome to the
Decora Smart™ family of
Zigbee®enabled devices
WEB VERSION

4
CALL
1-800-824-3005 (USA)
1-800-405-5320 (Canada)
ONLINE
leviton.com/decorasmart
CHAT
leviton.com
EMAIL
[e-mail]
Welcome
The Decora Smart™Dimmer
with Zigbee®technology is
designed for use with Zigbee
hubs. Using mesh networking
technology Zigbee provides
quick, reliable, secure
communication to a wide
variety of smart products.
Add your dimmer to a Zigbee
hub to control it with your
smartphone or a voice
interface.
We are here to help
WEB VERSION

5
5
RATINGS
LED / CFL 300W - 120VAC, 60Hz
Incandescent 600W - 120VAC, 60Hz
Operating Temp 0°C - 40°C (32°F - 104°F)
Operating Humidity 0-90% non-condensing
NETWORK
Zigbee Zigbee 3.0 Certified
Your dimmer works with:
Your Decora Smart dimmer with
Zigbee technology is compatible
with dimmable LED, dimmable
CFL, and incandescent bulbs.
Your dimmer should not be used
with electronic low voltage,
motor loads or aluminum wire. To
ensure proper communication do
not use metal wallplates. For LED
compatibility recommendations,
go to leviton.com/LED.
Note: When two or more dimmers
are installed next to each other
the incandescent load rating
becomes 500W for each dimmer.
No reduction is necessary if the
load is LED or CFL.
5
WEB VERSION

6
Features
Rocker
Manually
turn light on.
The bottom of the
paddle turns the
light off.
Dim / bright bar
Manually adjust
light levels.
Air gap switch
This feature will stop power to the lights to replace a bulb.
After servicing is complete, press the dim bright bar back into
place for normal operation. Engage the air-gap switch by gently
pulling the bottom of the dim/bright bar until the bottom lifts
completely out of the frame and a click is heard. The dimmer
brightness indicator lights and any connected lights will turn off.
Brightness
indicator lights
Displays light level
when adjusting
brightness.
Status light
Illuminates when
load is off.
WEB VERSION

7
Before you install
Things to consider:
• If light(s) are controlled from more than one location,
you will need a DD00R remote. See the DD00R
installation instructions for wiring instructions.
• Zigbee is a mesh network. It must be installed within
30 ft of hub or another Zigbee 3.0 compliant device.
NOTE: Communication through
exterior surfaces will likely
reduce transmission distances.
WEB VERSION

8
Check your wall box:
WARNING: TO AVOID FIRE, SHOCK OR DEATH, turn off power at
the circuit breaker.
1. Remove wallplate and disconnect switch.
2. Ensure disconnected wires are not touching.
3. Restore power. Carefully test wires with voltage tester to find
the hot wire.
4. Turn off power at the circuit breaker.
5. Mark the following wires:
Identify your wires
If your wall box looks different,
consult an electrician.
two or
more white
(neutral) wires
a hot (line) wire
(find with voltage tester)
a load wire
a copper ground
NEUTRAL
LINE
LOAD
GROUND
WEB VERSION

9
1. Work on only one connection at a time.
2. Connect wires as shown.
3. Secure wire connections with an electrical connector.
Wire your dimmer
If your wall box looks different,
consult an electrician.
BK
YL/RD RD
WH
HOT
GROUND
NEUTRAL
LOAD
WEB VERSION

10
Test and install
1. Restore power. Status
light should flash green
indicating your dimmer is
ready to join the network.
Turn off power at circuit breaker
before completing the dimmer
installation.
2. Gently push wires into wall box.
Screw dimmer to box.
3. Install screwless wallplate base
and snap on Decora wallplate.
Restore power.
Congratulations!
Your Decora Smart dimmer
is ready to control your light(s).
