LG ARNU093BHA2 User manual

Date:
JobName/Location:
PONo.:
Architect:
Engr:
GC:
Rep:
For: File
A
pp
roval
Mech:
Resubmit
Other
(Company) (ProjectManager)
Tag#:
ARNU093BHA2
MultiV™Ducted(HighStatic)
Btu/hIndoorUnit
Performance:
CoolingNominalTestConditions: HeatingNominalTestConditions:
Indoor: 80°FDB/67°FWB
Outdoor
:
95°FDB
Indoor: 70°FDB
Outdoor
:
47°FDB/43°FWB
HeatingCapacity(Btu/h)10,900
Electrical:
PowerSupply(V/Hz/Ø) 208‐230/60/1
Pi
p
in
g
:
Refrigerant:
Condensate:
StandardFeatures:
•LimitedWarrantywithLGCerfiedInstallaon
•TwoYearFunctionalPartsWarranty
ControlsFeatures:
•Autochangeover
(HeatRecoveryonly)
•Autooperaon
•Autorestart
•Childlock
•Dualthermistorcontrol
•Groupcontrol
•E.S.P.control
•Hotstart
•Selfdiagnoscs
•Sleepmode
•Timer(on/off)
•Weeklyschedule
•Sodry(dehumidificaon)
•Fanspeedcontrol
UnitData:
RefrigerantType R410A
RefrigerantControl EEV
Fan:
Type Sirocco
Quantity 1
Motor/Drive BrushlessDigitallyControlled/Direct
Notes:
PowerInput¹(W) 150
CondensateLine(in,OD) 1AirflowRateH/M/L(CFM) 353/300/265
Enterin
g
MixedAir:
HeatingMin(°FDB) 59
TotalCoolingCapacity(Btu/h) 9,600
FactoryInstalledPump² Yes
CoolingMax⁴(°FWB) 76
SoundPressure⁵dB(A)(H/M/L) 35/34/33
Filter WashablePre‐filter
ExternalStaticPressure⁶(inwg) 0.31
1.ThePowerInputisratedathighspeed.
2.Maximumliis27infromboomofunit.
3.Requiresa7‐Dayprogrammablecontroller.
4.SeeEngineeringManualforsensibleandlatentcapacies.
5.SoundPressurelevelsaretestedinananechoicchamberunderISOStandard1996.
6.Factorysetasstandard.
7.Allcommunicaoncabletobeminimum18AWG,2‐conductor,stranded,shieldedandmust
complywithapplicablelocalandnationalcode.
8.Powerwiringcablesizemustcomplywiththeapplicablelocalandnaonalcode.
9.Thisunitcomeswithadrynitrogencharge.
10.Thisdataisrated0abovesealevel,with25ofrefrigerantlineperindoorunitanda0
leveldifferencebetweenoutdoorandindoorunits.Allcapacitiesarenetwithacombination
ratiobetween95–105%.
11.MustfollowinstallaoninstruconsintheapplicableLGinstallaonmanual.
9,600
O
p
tionalAccessories:
RatedAmps(A) 0.92
LiquidLine(in,OD) 1/4Flare
VaporLine(in,OD) 1/2Flare
NetUnitWeight(lbs) 59
ShippingWeight(lbs) 68
Page1of2VRF‐SB‐DF‐002‐US012D18
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lg‐vrf.com
WirelessHandheldRemoteController‐PQWRHDF0
7‐DayProgrammableController(Black)‐PQRCVSL0
SimpleControllerwithMode(Black)‐PQRCVCL0Q
SimpleControllerwithoutMode(Black)PQRCHCA0Q
DryContactUnit‐PQDSB1
WallMountedTemperatureSensor‐PQRSTA0
7‐DayProgrammableController(White)‐PQRCVSL0QW
SimpleControllerwithMode(White)‐PQRCVCL0QW
SimpleControllerwithoutMode(White)‐PQRCHCA0QW
DryContactUnit‐PQDSBC
³

ARNU093BHA2
MultiV™Ducted(HighStatic)
Btu/hIndoorUnit
JobName/Location:
Tag#:
Date:
PONo.:
ARNU093BHA2
Center of Gravity
Note‐Alldimensionshavea
toleranceof±0.25in.
=Centerofgravity
9,600
Page2of2VRF‐SB‐DF‐002‐US012D18
