LG ARNU123SER2 User manual

Date:
JobName/Location:
PONo.:
Architect:
Engr:
GC:
Rep:
For: File
A
pp
roval
Mech:
Resubmit
Other
(Company) (ProjectManager)
Tag#:
ARNU123SER2
MultiVArtCool™Mirror
Performance:
CoolingNominalTestConditions: HeatingNominalTestConditions:
Indoor: 80°FDB/67°FWB
Outdoor
:
95°FDB
Indoor: 70°FDB
Outdoor
:
47°FDB/43°FWB
HeatingCapacity(Btu/h)13,600
Electrical:
PowerSupply(V/Hz/Ø) 208‐230/60/1
RatedAmps(A)0.3
Pi
p
in
g
:
Refrigerant:
LiquidLine(in,OD) 1/4Flare
VaporLine(in,OD) 1/2Flare
Condensate:
ControlsFeatures:
UnitData:
RefrigerantType R410A
RefrigerantControl EEV
NetUnitWeight(lbs) 25
ShippingWeight(lbs) 29
PrimaryFilter WashablePre‐filter
SecondaryFilter Plasma
Fan:
Type CrossFlow
Quantity 1
Motor/Drive BrushlessDigitallyControlled/Direct
AirflowRateH/M/L(CFM) 353/283/212
PowerIn
p
ut¹
(
W
)
40
CondensateLine(in,OD) 5/8
Enterin
g
MixedAir:
HeatingMin(°FDB) 59
StandardFeatures:
•LimitedWarrantywithLGCerfiedInstallaon
•TwoYearFunconalPartsWarranty
•StandardMirrorFrontPanel
Notes:
TotalCoolingCapacity(Btu/h) 12,300
12,300 Btu/hIndoorUnit
FactoryInstalledPump No
CoolingMax²(°FWB) 76
SoundPressure³dB(A)(H/M/L) 41/36/27
•Autochangeover
(HeatRecoveryonly)
•Autooperaon
•Autoclean(coildry)
•Autorestart
•Childlock
•Dualthermistorcontrol
•Forcedoperaon
•Groupcontrol
•Hotstart
•Selfdiagnoscs
•Sleepmode
•Timer(on/off)
•Weeklyschedule
•Sodry(dehumidificaon)
•Autodirecon/swing(up/down)
•Autodirecon/swing(le/right)
•Fanspeedcontrol
•Chaosswing(randomlouverswing)
•Chaoswind(randomfanspeed)
•Jetcool(fastcooling)
1.ThePowerInputisratedathighspeed.
2.SeeEngineeringManualforsensibleandlatentcapacies.
3.SoundPressurelevelsaretestedinananechoicchamberunderISOStandard1996.
4.Allcommunicaoncabletobeminimum18AWG,2‐conductor,stranded,shieldedandmust
complywithapplicablelocalandnationalcode.
5.Powerwiringcablesizemustcomplywiththeapplicablelocalandnaonalcode.
6.Thisunitcomeswithadrynitrogencharge.
7.Thisdataisrated0abovesealevel,with25ofrefrigerantlineperindoorunitanda0
leveldifferencebetweenoutdoorandindoorunits.Allcapacitiesarenetwithacombination
ratiobetween95–105%.
8.MustfollowinstallaoninstruconsintheapplicableLGinstallaonmanual.
Page1of2VRF‐SB‐DA‐003‐US012B07
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lg‐vrf.com
Blue‐PSAPECB10
Silver‐PSAPECV10
O
p
tionalAccessories:
ChangeableFrontPanel(fieldinstalled):
WirelessHandheldRemoteController‐PQWRHDF0
7‐DayProgrammableController(Black)‐PQRCVSL0
SimpleControllerwithMode(Black)‐PQRCVCL0Q
SimpleControllerwithoutMode(Black)PQRCHCA0Q
DryContactUnit‐PQDSB1
7‐DayProgrammableController(White)‐PQRCVSL0QW
SimpleControllerwithMode(White)‐PQRCVCL0QW
SimpleControllerwithoutMode(White)‐PQRCHCA0QW
DryContactUnit‐PQDSBC

JobName/Location:
Tag#:
Date:
PONo.:
Note‐Alldimensionshavea
toleranceof±0.25in.
ARNU123SER2
MultiVArtCool™Mirror
12,300 Btu/hIndoorUnit
Page2of2VRF‐SB‐DA‐003‐US012B07
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lg‐vrf.com
