LG LH247HV User manual

Date:
JobName/Location:
PONo.:
Architect:
Engr:
GC:
Rep:
For: File
A
pp
roval
Mech:
Resubmit
Other
Tag#:
(Company) (ProjectManager)
SingleZoneHighStaticDuct
LH247HV
Page1of3DFS‐SB‐AM‐001‐US013E28
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
©LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com
Performance:
Capacity(Btu/h) 24,000
SEER 17.0
EER 12.0
Cooling:
Heating:
Capacity(Btu/h) 27,000
HSPF 10.0
CoolingNominalTestConditions: HeatingNominalTestConditions:
Indoor: 80°FDB/67°FWB Indoor: 70°FDB/60°FWB
Outdoor: 95°FDB/75°FWB Outdoor: 47°FDB/43°FWB
Electrical:
MCA(A) 18.1
MOP(A) 30
FanMotor(A) 0.6
CoolingRatedAmps(A) 15.1
HeatingRatedAmps(A) 15.1
CoolingPowerInput(kW) 2.00
HeatingPowerInput(kW) 2.28
Piping:
LiquidLine(in,OD) 3/8
AdditionalRefrigerant(oz/ft) 0.43
MaxElevation(ft) 98
MaxPipeLength(ft)² 164
VaporLine(in,OD) 5/8
Features:
•ESPcontrol
•Hotstart
•Inverter(variablespeedfan)
•Internalcondensatepump
•Autorestart
•Controllockfuncon
•Groupcontrol
•Timer(on/off)
•Sleepmode
OperatingRange:
OutdoorUnit:
IndoorUnit:
UnitData:
RefrigerantType R410A
RefrigerantCharge(lbs) 4.4
Fan:
Notes:
1.Acceptableoperangvoltage:187V‐253V.
2.Pipinglengthsareequivalent.
3.SoundPressurelevelsaretestedinananechoicchamberunderISOStandard1996.
4.Allcommunicaon/powercabletobeminimum18Americanwiregauge(AWG),4‐
conductor,stranded,shieldedandmustcomplywithapplicablelocalandnationalcode.
5.SeeEngineeringManualforsensibleandlatentcapacies.
6.Powerwiringcablesizemustcomplywiththeapplicablelocalandnaonalcode.
7.Theindoorunitcomeswithadryheliumcharge.
8.Thisdataisrated0abovesealevel,with25ofrefrigerantlineanda0level
differencebetweenoutdoorandindoorunits.
9.MustfollowinstallaoninstruconsintheapplicableLGinstallaonmanual.
ODUType Propeller
IDUType Sirocco
Motor/Drive BrushlessDigitallyControlled/Direct
RefrigerantControl EEV
ODUNetWeight(lbs) 133
ODUShippingWeight(lbs) 146
IDUNetWeight(lbs) 73
IDUShippingWeight(lbs) 95
FanSpeeds(Fan/Cooling/Heating) 3/3/3
FanQuantity(ODU+IDU) 1+1
Heating(°FWB) 0‐64
Cooling(°FWB) 57‐77
IndoorUnit(IDU)‐LHN247HVOutdoorUnit(ODU)‐LUU247
SEER‐SeasonalEnergyEfficiencyRatio EER‐EnergyEfficiencyRatio
HSPF‐HeatingSeasonalPerformanceFactor
MOP‐MaximumOvercurrentProtection MCA‐MinimumCircuitAmpacity
ACEz‐PQCSZ250S0
LGProgrammableController‐PREMTB10U
DryContactUnitDryContactUnit(1contact,24VACexternalpower)‐PQDSB1
O
p
tionalAccessories
(
soldse
p
aratel
y)

PQRCVCL0QW
IncludedAccessories:
•SimpleControllerwithMode(White)‐PQRCVCL0QW
Compressor(A) 13.5
DehumidificationRate(pts/hr) 7.0
ODUAirCirculation(CFM) 2048
IDUAirCirculationH/M/L(CFM) 688/618/530
MaxExternalStaticPressure(inwg) 0.39
Cooling(°FDB) 5‐118
IDUHeating(°FDB) 59‐81
PowerSupply(V¹/Hz/Ø) 208‐230/60/1
ODUSoundPressureMax(Cool/Heat)±3dB(A)³ 48/52
IDUSoundPressure(H/M/L)±3dB(A)³ 38/36/35
PipeLength(noadd'lRefrigerant,ft) 25

JobName/Location:
Tag#:
Date:
PONo.:
SingleZoneHighStaticDuct
Page2of3DFS‐SB‐AM‐001‐US013E28
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
©LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com
OutdoorUnit
(
ODU
)
‐LUU247HV

JobName/Location:
Tag#:
Date:
PONo.:
SingleZoneHighStaticDuct
Page3of3DFS‐SB‐AM‐001‐US013E28
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com
IndoorUnit
(
IDU
)
‐LHN247HV
