LG PVDATN000 Operating instructions

ENGLISH
P/NO : MFL62179506
TYPE : Data Saving Module (Multi-V)
MODELS : PVDATN000
www.lg.com
Please read this manual carefully before operating
your set and retain it for future reference.
INSTALLATION/
OWNER’S MANUAL
AIR
CONDITIONER

2IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
Always comply with the following precautions to avoid dangerous situations and ensure peak
performance of your product
WARNING
It can result in serious injury or death when the directions are ignored
CAUTION
It can result in minor injury or product damage when the directions are ignored
WARNING
• Installation or repairs made by unqualified persons can result in hazards to you and others.
• Installation work must be performed in accordance with the National Electric Code by quali-
fied and authorized personnel only.
• The information contained in the manual is intended for use by a qualified service technician
familiar with safety procedures and equipped with the proper tools and test instruments.
• Failure to carefully read and follow all instructions in this manual can result in equipment mal-
function, property damage, personal injury and/or death.
WARNING
Installation
• Be sure to request to the service center or installation specialty store when installing products.
It will cause fire or electric shock or explosion or injury.
• Request to the service center or installation specialty store when reinstalling the installed product.
It will cause fire or electric shock or explosion or injury.
• Do not disassemble, fix, and modify products randomly.
It will cause fire or electric shock.
• Be sure to turn off outdoor unit power before installation. It will cause electric shock.
In-use
• Do not place flammable stuffs close to the product.
It will cause fire.
• Do not allow water to run into the product.
It will cause electric shock or breakdown.
• Do not give the shock to the product.
It will cause breakdown when giving the shock to the product.
• Request to the service center or installation specialty store when the product becomes wet.
It will cause fire or electric shock.
• Do not give the shock using sharp and pointed objects.
It will cause breakdown by damaging parts.
• Do not touch the board when the power is connected.
It can cause a fire, electric shock, explosion, injury and problem to the product.
!
!
!
!

IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
3
CAUTION
In-use
• Do not clean using the powerful detergent like solvent but use soft cloths.
It will cause fire or product deformation.
• Do not press the screen using powerful pressure or select two buttons.
It will cause product breakdown or malfunction.
• Do not touch or pull the lead wire with wet hands.
It will cause product breakdown or electric shock.
!
WARNING
This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
ENGLISH Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is attached to a product it means the
product is covered by the European Directive 2006/66/EC.
2. All electrical and electronic products should be disposed of separately from the
municipal waste stream via designated collection facilities appointed by the
government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative
consequences for the environment and human health.
4.
For more detailed information about disposal of your old appliance, please contact your
city of fice, waste disposal service or the shop where you purchased the product.
For your records
Staple your receipt to this page in case you need it to prove the date of purchase or for warranty
purposes. Write the model number and the serial number here:
Model number :
Serial number :
You can find them on a label on the side of each unit.
Dealer’s name :
Date of purchase :

4TABLE OF CONTENTS
ENGLISH
TABLE OF CONTENTS
5NAME OF EACH PART
6COMPONENTS
7SETTING AND USING
METHOD
7Date & Time setting
8PC Connection for Date & time Setting
15 Data Saving Module Operation
17 Installation Method
19 LED State
20 Data Converter

NAME OF EACH PART
ENGLISH
5
NAME OF EACH PART
Debugger Connector For bootloader program writing and debugging.
Start Switch On/Off switch for data save.
Dip Switch
The switch for selecting Multi-V model
Communication Connector
For Setting the Date and Time.
Outdoor Main PCB Connector
For Connecting Main PCB and Data Saving Module.
State LEDs Display current state and error.
Battery Socket Keeping Date and Time.
Reset Switch For rebooting Data Saving Module.
SD Card Slot For installing the SD card.
SD Card Slot Reset Switch Battery Socket
Power LED
RX LED
TX LED
Debugger
Connector
Communica-
tion Connector
Outdoor Main
PCB Connector
Start Switch
Dip Switch
State LEDs

6COMPONENTS
ENGLISH
COMPONENTS
Components
Data Saving Module Exploded view
Data Saving Module (1EA)
Manual (1EA)
Screw (1EA)
NOTE
!
SD Card and Battery are not provided by LG. You need to purchase Battery(CR2032) separately.

SETTING AND USING METHOD
ENGLISH
7
SETTING AND USING METHOD
Date & Time setting
Requirements
- Operating System : Windows 2000 Over
- PI232 and LGMV Cable*
PI232 Module LGMV Cable
- Data Saving Module and Cable
Data Saving Module Data Saving Cable
- RS232 cable* - Outdoor Main PCB
RS232 cable Outdoor Main PCB
NOTE
!
The product has ‘*’ mark is not provided by LG.

8SETTING AND USING METHOD
ENGLISH
• How to connect
- Connect Data Saving Module and Multi-V Outdoor Main PCB with Data Saving Cable
- Connect PC and PI232 module with RS232 cable.
- Connect Upgrade port in Data Saving module and PI232 module with program writing cable.
- Turn on the power of main PCB.
PC Connection for Date & time Setting
PC/Notebook PI232
LGMV Cable
Data Saving Module
Outdoor Main PCB
RS232
USB to Serial Converter
NOTE
!
If there is no COM port on PC, use the USB-to-RS232 converter.

SETTING AND USING METHOD
ENGLISH
9
Setting
• Hyperterminal
- Click Windows “Start” ➔“Programs” ➔“Accessories” ➔“Communication”
➔“Hyper Terminal”
- Click “New Connection” ➔Write Name ➔Select Com port ➔Click OK
Installation method
Connecting Description Connect to serial port

10 SETTING AND USING METHOD
ENGLISH
- Configure port setting as(2400 bits/sec, flow control : None) ➔Click OK
- Push reset button on Data Saving Module. then Data Saving Module information will be shown
on your Hyper Terminal
COM Properties
Start Data Saving Module

SETTING AND USING METHOD
ENGLISH
11
- Type “HELP” in the terminal. Then, Program version and guides for command will be displayed
in the terminal.
- A Command mode can be available by clicking space bar three times.
Then “------START COMMAND------” message will be displayed.
Start Command
Enter HELP

12 SETTING AND USING METHOD
ENGLISH
- Change date : DATE [yyyy-mm-dd] ex) DATE 2013-07-15
- Check modified date after typing new date.
• How to set date
- Type “DATE” : Display currently configured date
Input date
Check and Change date
NOTE
!
In case of replacing a battery, Date or Time is not Correct. It need to set date and time again.

SETTING AND USING METHOD
ENGLISH
13
- Change time : TIME [hh:mm:ss] ex) TIME 16:30:25
- Check modified time after typing new time.
• How to set time
- Type “TIME” : Display currently configured time
Input time
Check and Change time

14 SETTING AND USING METHOD
ENGLISH
• How to exit terminall
- Type “QUIT” and then click “Enter” key.
Then, “-------STOP COMMAND--------” Message will be displayed.
Stop command Mode

SETTING AND USING METHOD
ENGLISH
15
Data Saving Module Operation
Requirements
- Data Saving module
- SD Memory card
- Battery (CR2032)
• The outline of Data Saving Module
SD Card Slot Battery Socket
• SD Memory Card.
- Use 2GB ~ 8GB SD or SDHC
- FAT32 format should be preceded before in use.
- Maximum file size per a day : Approximately 150MBytes
- Output file format : S(model name)(year)(month)(day).csv
ex) Multi-V IV, 2013(year) 7(month) 15(day) →S4130715.CSV
NOTE
!
• Remove the SD card after turning off the start switch.
• When Data Saving Module lost power, battery have to set on battery socket for Keeping
Date and Time.
• SD card may lose data when using more than one month.
It is recommended to use within one month.

16 SETTING AND USING METHOD
ENGLISH
Step 1. Turn off start switch in Data Saving Module.
Step 2. Dip switch position depend on the model.
SW1 (ON) & SW2 (OFF) & SW3 (OFF) : Multi V V Generation
SW1 (OFF) & SW2 (ON) & SW3 (ON) : Multi V IV Generation
SW1 (OFF) & SW2 (ON) & SW3 (OFF) : Multi V III Generation
Step 3. Connect Data Saving Module to Outdoor Main PCB with Data Saving cable.
Step 4. Check LED state.
: Green LED (Off), Yellow LED(Off), Red LED
(Blinking 8 Times – SD memory card is not inserted)
Step 5. Check LED state after SD memory card insertion.
: Green LED (several minutes On state →Off : Calculate SD memory card capacity)
Yellow LED (Off), Red LED (in Normal state – Blinking in 1 sec interval)
Step 6. Check normal state. Then, turn start switch On
: Green LED (Blinking in 10 seconds interval : Recording data)
: Yellow LED (Always ON)
: Red LED (in Normal state – Blinking in 1 sec interval)
Operation
L1
ON
234
Outdoor Main PCB
Data Saving Module
NOTE
!
• Default state of dip switch is all off.

SETTING AND USING METHOD
ENGLISH
17
Installation Method
①Join the front case and the rear case.
②Anchor the front case at holes using anchor
screws
③Join the case in the Multi-V Control Box,
anchor the case at holes using anchor
screws.

18 SETTING AND USING METHOD
ENGLISH
④Connect connection wire to outdoor Main
PCB.
CAUTION
• Install the product on flat surface and screw 4 places.
Otherwise the Data Saving Module may not be anchored properly
• Do not screw too tightly. It may cause deformation of the case.
• Do not deform the case at random. It may cause malfunction of the Data Saving Module.
• It is recommended that assembling the front case and fixing the product on designated lo-
cation.
!

SETTING AND USING METHOD
ENGLISH
19
LED State
Power LED
Yellow
Green
Red
On / Off State
Writing State
Error State
RX LED
TX LED
• Green LED
: Display current state
- On recording : Blinking in 10 seconds interval
- When SD memory card is initially inserted or memory capacity calculation is operated at every
minutes : ON for several minutes(seconds) →OFF
• Yellow LED
: Display start of data recording
- Start SW On : always ON
- Start SW Off : always OFF
• Red LED
: Display normal or error state.
- Normal state : Blinking in 1 sec interval.
- Error state : LED OFF for 2 seconds →Blinking current error as bellows.
7 times : Memory card Lock
8 times : No memory card

20 SETTING AND USING METHOD
ENGLISH
Data Converter
• Data Converter
SD data converter is windows PC based program that converts encoded file to an easy form of
readable file for user.
• When execute DataConverter(130609).exe file, it displays as belows.
- Select file for convert (multiple selection is supported)
- Model Type Selection
(if selected file is Multi-V IV then model type will be automatically checked)
- Output File Selection (depend on the IDU num or HR unit existence)
(when there are no checks, it will converts only about ODU and IDU_GR1(1~16))
- Click “Start”
Select file for convert
Delete only checked files
Delete all files
Output file selection
Quit program
Destination folder
Progress state
