LG CHEM RESU10H User manual

The information included in this manual is accurate at the time of publication.
However, this manual is subject to change without prior notice. In addition, the
concepts and installation instructions.
Please note the image shown is for illustration purposes only.
May.2017
CAUTION
After installation, the installer must explain the User Guide to the end-user.

......................................................................................
3
Contents
1 Safety 5
1.1 Symbols....................................................................................................................5
1.2 Safety instructions ................................................................................................. 6
1.2.1 General safety precautions........................................................................ 6
1.2.2 Battery handling guide.............................................................................. 6
1.2.3 Response to emergency situations ........................................................... 8
1.3 Warning label
Qualied personnel
......................................................................................................... 9
1.4
............................................................................................. 10
2 Product Introduction 11
2.1 Technical data....................................................................................................... 11
2.1.1 Dimensions and weight ........................................................................... 11
2.1.2 Performance............................................................................................... 12
2.2 Feature ................................................................................................................... 13
2.3 Packaging specication 13
3 Installation 14
3.1 Mechanical requirements ................................................................................... 14
3.1.1 Unboxing the package.............................................................................. 15
3.1.2 Items in the package................................................................................. 16
3.1.3 Installation locations ................................................................................ 16
3.1.4 Clearance.................................................................................................... 17
3.1.5 Tools & safety gears required ................................................................. 17
3.1.6 Mounting bracket...................................................................................... 19
3.1.7 Appearance and dimension .................................................................... 20
3.1.8 System clearance ....................................................................................... 20
3.1.9 Installing the battery pack....................................................................... 21
3.2 Cable connection .................................................................................................. 24
3.2.1 Auxiliary power switch and spring terminal blocks .......................... 26

4
4 Commissioning 27
4.1 LED indicators ..................................................................................................... 27
4.2 Powering up the battery pack ............................................................................ 28
4.3
Shutting o the battery pack ............................................................................ 28
6 Uninstallation & Return 32
6.1 Return/replacement instructions ........................................................................... 32
5 Troubleshooting 29
5.1 Troubleshooting ................................................................................................... 29
6.1.1 Uninstallation from the wall .................................................................... 32
6.1.2 Contact information .................................................................................. 34
5.1.1 Post-Installation Check List .................................................................... 30
5.1.2 Troubleshooting Guideline .................................................................... 30
Contents

5
1 Safety
1.1 Symbols
Caution, risk of electric shock
Install the product out of reach of children.
Read the instruction manual before starting installation and
operation.
Heavy weight may cause serious injury to the back.
Do not dispose of the product with household wastes.
Recyclable
Disconnect the equipment before carrying out maintenance or repair.
Observe precautions for handling electrostatic discharge sensitive
devices.
