LG MultiSITE MS8000 Series User manual

MS8350
Model No. VUCQMS8350
Commercial and Hotel HVAC Fan Coil Controller
MS8650
Model No. VUCQMS8650
Rooftop Unit, Heat Pump, and Indoor Air Quality Controller
MultiSITE™ MS8000 Series Room Controllers
INSTALLATION MANUAL

The instructions included in this manual must be followed to prevent prod-
uct malfunction, property damage, injury, or death to the user or other
people. Incorrect operation due to ignoring any instructions will cause
harm or damage. A summary of safety precautions begins on page 4.
Do not throw away, destroy, or lose this manual.
Please read carefully and store in a safe place for future reference.
Content familiarity required for proper installation.
For more technical materials such as submittals, engineering
databooks, and catalogs, visit www.lghvac.com.
For continual product development, LG Electronics U.S.A., Inc., reserves the right to change specifications without notice.
©LG Electronics U.S.A., Inc.
This document, as well as all reports, illustrations, data, information, and other materials are the property of LG Electronics U.S.A., Inc.
PROPRIETARY DATA NOTICE
This document, as well as all reports, illustrations, data, information, and
other materials are the property of LG Electronics U.S.A., Inc., and are
disclosed by LG Electronics U.S.A., Inc., only in confidence.

3
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Installation Manual
TABLE OF CONTENTS
Safety Precautions ...................................................................................................................................................................................................... 4-6
Introduction..................................................................................................................................................................................................................... 7
Choosing a Location................................................................................................................................................................................................... 8-9
Cleaning the Controller................................................................................................................................................................................................ 10
Installation for MS8350 and MS8650............................................................................................................................................................................11
Terminal Identication and Function for MS8350...................................................................................................................................................... 12
Terminal Identication and Function for MS8650...................................................................................................................................................... 13
Wiring for MS8350 ................................................................................................................................................................................................... 14-15
Wiring for MS8650 ................................................................................................................................................................................................... 16-18
Home Screen Display for MS8350 and MS8650......................................................................................................................................................... 19
Set-Up Screen For MS8350 and MS8650.................................................................................................................................................................... 20
Power Outage Clock Reset.......................................................................................................................................................................................... 21
Main Specications for MS8350 and MS8650............................................................................................................................................................ 22
Standards and Certications for MS8350 and MS8650............................................................................................................................................. 23

4
MultiSITE MS8000 Series Room Controllers
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
4
SAFETY PRECAUTIONS
TABLE OF SYMBOLS
DANGER
This symbol indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
This symbol indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
This symbol indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
This symbol indicates situations that may result in equipment or property damage accidents only.
This symbol indicates an action that should not be performed.
The instructions below must be followed to prevent product malfunction, property damage, injury or death to the user or other people. Incor-
rect operation due to ignoring any instructions will cause harm or damage. The level of seriousness is classified by the symbols described
below.
Safety of personnel is the primary concern during all procedures. Read and understand this safety summary. Read and understand the instal-
lation procedure before beginning installation. Use the appropriate tools and accessories during installation. Plan the work and do not
work alone, if possible. Know how to obtain emergency medical and fire fighting assistance.
DANGER
Do not use or store ammable gas or combustibles near
the unit.
There is risk of re, explosion, and physical injury or death.
Disconnect power before installing or servicing the unit.
There is risk of physical injury or death due to electric shock.
Properly size all circuit breakers or fuses.
There is risk of re, electric shock, explosion, physical injury, or death.
Do not share the electrical circuit with other devices.
There is risk of re, electric shock, physical injury, or death due to heat
generation.
Do not use damaged or loose power wiring. Do not
modify or extend the power wiring randomly. Ensure that the
power wiring will not be pulled nor weight be placed on the
power wiring during operation.
There is risk of re, electric shock, and physical injury or death.
The information contained in this manual is intended for use
by an industry-qualied, experienced, trained electrician
familiar with local, national, and regional codes and who is
equipped with the proper tools and test instruments.
Failure to carefully read and follow all instructions will result in personal
injury or death.
All electric work must be performed by a licensed electrician
and conform to local building codes or, in the absence of lo-
cal codes, with the National Electrical Code, and the instruc-
tions given in this manual.
If the power source capacity is inadequate or the electric work is not
performed properly, it will result in re, electric shock, physical injury or
death.
Use copper conductors only. Refer to local, state, and federal
codes, and use power wires of su󰀩cient current capacity and
rating.
Wires that are too small will generate heat, cause a re and physical
injury or death.
Before making power terminations during earth grounding,
de-energize the power source. Do not restore power until
completing all other mounting and wiring.
There is risk of electric shock and physical injury or death.

5
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Installation Manual
5
SAFETY PRECAUTIONS
Discharge yourself correctly before handling and installing
the controller.
There is risk of electric shock and physical injury or death.
Install in a controlled environment relatively free of contami-
nants.
There is risk of electric shock and physical injury or death.
Secure all eld wiring connections with appropriate wire
strain relief.
Improperly securing wires will create undue stress on equipment power
lugs. Inadequate connections will generate heat, cause a re and physi-
cal injury or death.
Ensure the system is connected to a power source that pro-
vides adequate power. Ensure that the wiring is the correct
size.
If the power source capacity is inadequate, the wiring is not the correct
size, or the electric work is not performed properly, it will result in short
circuiting, re, electric shock, physical injury or death.
Do not change the settings of the protection devices.
If the protection device is shorted and forced to operate improperly, or
parts other than those specied by LG are used, there is risk of re,
electric shock, explosion, and physical injury or death.
Properly tighten all power connections.
Loose wiring may overheat at connection points, causing a re, physical
injury or death.
Dispose of any packing materials safely.
• Packing materials, such as nails and other metal or wooden parts
will cause puncture wounds or other injuries.
• Tear apart and throw away plastic packaging bags so that children
may not play with them and risk suffocation and death.
Do not install the controller if it will be exposed to rain
or other precipitation. Do not install the unit in a location
exposed to open ame, extreme heat, or direct sunlight.
Do not touch the unit with wet hands.
There is risk of re, electric shock, physical injury, and/or death.
Use a soft, pre-moistened lint-free cloth for cleaning.
Avoid getting moisture in openings.
If moisture accesses the electrical components of the controller, there is
risk of re, electric shock, and physical injury or death.
Do not use caustic / corrosive products, ammonia, sol-
vents or any cleaning product containing alcohol or grit.
There is risk of re, electric shock, and physical injury or death.
Do not drop or crush the controller, or allow it to come
into contact with liquids.
There is risk of re, electric shock, and physical injury or death.
Do not spray anything directly on the controller or use
compressed air.
There is risk of re, electric shock, and physical injury or death.
Never use paint on the controller.
If moisture accesses the electrical components of the controller, there is
risk of re, electric shock, and physical injury or death.
Do not use a damaged device (such as one with a cracked
screen).
There is risk of re, electric shock, and physical injury or death.
Wear protective gloves when handling equipment.
Sharp edges cause personal injury.
CAUTION

6
MultiSITE MS8000 Series Room Controllers
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
6
SAFETY PRECAUTIONS
The information contained in this manual is intended for use
by an industry-qualied, experienced, trained electrician
familiar with local, national, and federal codes and who is
equipped with the proper tools and test instruments.
Failure to carefully read and follow all instructions will result in equip-
ment malfunction or equipment / property damage.
Ensure the system is connected to a power source that pro-
vides adequate power. Ensure that the wiring is the correct
size.
If the power source capacity is inadequate, the wiring is not the correct
size, or the electric work is not performed properly, it will result in control-
ler malfunction, miscommunication, and / or degraded performance.
Install the controller at least eight (8) inches away from in-
habitants, and do not locate near or operating in conjunc-
tion with any other antenna or transmitter.
There is risk of controller malfunction, miscommunication, and / or
degraded performance.
Disconnect power before installing or servicing the unit.
There is risk of equipment damage and degraded performance.
Clean up the site after all procedures are nished, and check
that no metal scraps, screws, or bits of wiring have been left
inside or surrounding the controller or indoor units.
Do not allow water, dirt, or animals to enter the controller.
There is risk of unit failure or degraded performance.
Do not spill water or other liquid on the inside of the con-
troller. Do not drop the controller into water. If the unit is
immersed in water or other liquid, contact your local autho-
rized LG distributor for support.
There is risk of unit failure or degraded performance.
This device is only intended for use as a monitoring and
control device. It is not a safety device. Do not use it for
any other purpose.
Tampering with the devices or unintended application of the devices will
result in a void of warranty. There also is risk of data loss or equipment
damage.
The controller is not compatible with a Power-Over-Ethernet
(POE) network. Do not connect the controller on a network
segment that carries power.
The unit may fail.
Use a soft, pre-moistened lint-free cloth for cleaning.
Avoid getting moisture in openings.
There is risk of equipment damage, and will void the manufacturer's
warranty.
Do not spray anything directly on the controller or use
compressed air.
There is risk of equipment damage, and it will void the manufacturer's
warranty.
Do not use caustic / corrosive products, ammonia, sol-
vents or any cleaning product containing alcohol or grit.
There is risk of equipment damage, and it will void the manufacturer's
warranty.
Never use tools directly on the touchscreen.
There is risk of damage to the controller screen, and it will void the
manufacturer's warranty.
Never use paint on the controller.
There is risk of equipment damage, and it will void the manufacturer's
warranty.
Do not drop or crush the controller, or allow it to come
into contact with liquids.
There is risk of equipment damage, and it will void the manufacturer's
warranty.
Do not use a damaged device (such as one with a cracked
screen).
Performance can be affected if the glass on the screen is broken, and it
will void the manufacturer's warranty.

7
Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
Introduction
This manual shows the installation instructions for the LG MultiSITE MS8350 Room Controller (Firmware Release version 2.1) and the LG
MultiSITE MS8650 Room Controller (Firmware Release version 2.1) for User and Integrators.
MS8350 Controllers
For Commercial and Hotel HVAC Fan Coil Applications.
Features
• Auto / Low / Med / High Fan Speeds
• Low-voltage 24 Vac
• Customizable color digital touch screen interface with Multi-lan-
guage support
• BACnet®MS/TP or Modbus®
• Automatic Demand Response (ADR) used to reduce energy load
when electric grid contingencies threaten supply-demand balance
• Custom LUA script can be uploaded to the Room Controller
• Role based configuration (password protected)
• Function code settings
• Function Code Search Tool
• Date and Time Display only when a network time synchronization
command is received
• Room temperature display
• On / Off Operation
• Auto / Cool / Heat / Fan Only Modes
• Occupied cooling and heating temperature setpoints
• Unoccupied cooling and heating temperature setpoints
• 7 day scheduling with mode
• Error code display during unit or system malfunction
MS8650 Controllers
For Rooftop Unit, Heat Pump and Indoor Air Quality Applications.
Features
• Auto / On / Smart Fan Speeds
• Low-voltage 24 Vac
• Customizable color digital touch screen interface with Multi-lan-
guage support
• BACnet MS/TP or Modbus
• Automatic Demand Response (ADR) used to reduce energy load
when electric grid contingencies threaten supply-demand balance
• Custom LUA script can be uploaded to the Room Controller
• Role based configuration (password protected)
• Function code settings
• Function Code Search Tool
• Date and Time Display only when a network time synchronization
command is received
• Room temperature display
• On / Off Operation
• Auto / Cool / Heat / Fan Only Modes
• Occupied cooling and heating temperature setpoints
• Unoccupied cooling and heating temperature setpoints
• 7 day scheduling with mode
• Error code display during unit or system malfunction
BACnet® is a registered trademark of ASHRAE.
Modbus®is a registered trademark of Schneider Electric USA, Inc.
INTRODUCTION

8
MultiSITE MS8000 Series Room Controllers
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
CHOOSING A LOCATION
A trained technician should always install the controller following local, national, and federal electrical codes; industry best
practices; the instructions in this manual; and using the proper tools and test instruments.
Failure to carefully read and follow all instructions will result in personal injury or death.
Discharge yourself correctly before handling and installing the controller.
There is risk of electric shock and physical injury or death.
Ensure the system is connected to a power source that provides adequate power. Ensure that the wiring is the correct size.
If the power source capacity is inadequate, the wiring is not the correct size, or the electric work is not performed properly, it will result in short circuit-
ing, re, electric shock, physical injury or death.
A trained technician should always install the controller following local, national, and federal electrical codes; industry best
practices; the instructions in this manual; and using the proper tools and test instruments.
Failure to carefully read and follow all instructions will result in equipment malfunction, controller and property damage, and will void the manufac-
turer's warranty.
This device is only intended for use as a monitoring and control device. It is not a safety device. Do not use it for any other
purpose.
Tampering with the devices or unintended application of the devices will result in a void of warranty. There also is risk of data loss or equipment dam-
age.
Ensure the system is connected to a power source that provides adequate power. Ensure that the wiring is the correct size.
If the power source capacity is inadequate, the wiring is not the correct size, or the electric work is not performed properly, it will result in controller
malfunction, miscommunication, and / or degraded performance.
Install the controller at least eight (8) inches away from inhabitants, and do not locate near or operating in conjunction with
any other antenna or transmitter.
There is risk of controller malfunction, miscommunication, and / or degraded performance.
Choosing a Location for the Controller

9
Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
A room temperature sensor is inside the controller, so the installation location is critical to proper system operation. Install the controller in a
location away from direct sunlight, high humidity, and direct flow or hot or cold air. Install the controller on a flat, clean wall surface approxi-
mately four to five (4 to 5) feet above the floor in an area with good circulation and average temperature.
Do's
• If replacing an existing controller, label wires before removing.
• Ensure the wall surface is flat and clean.
• Ensure the controller has sufficient, natural air circulation.
• Ensure the external thermal sensor wiring is away from electrical
sources.
• Install the controller four to five (4 to 5) feet (1.2 to 1.5m) above the
floor.
Do Not's
Do not install the controller:
• In drafts or dead spots behind doors and corners.
• In areas subjected to hot or cold air from ducts / air discharge grills
• Near radiant heat from sun or appliances
• Near or with a direct heat source.
• In areas exposed to direct sunlight.
• Near concealed pipes or chimneys.
• Uncontrolled areas such as on an outside wall.
Failure to comply with these recommendations will result in damage to the unit and void the manufacturer’s warranty.
4 to 5 feet
above the floor
NO
YES
NO
NO
Figure 1: Controller Location.
Choosing a Location for the Controller, continued.
CHOOSING A LOCATION

10
MultiSITE MS8000 Series Room Controllers
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
CLEANING THE CONTROLLER
Use a soft, pre-moistened lint-free cloth for cleaning. Avoid getting moisture in openings.
There is risk of equipment damage, and will void the manufacturer's warranty.
Do not spray anything directly on the controller or use compressed air.
There is risk of equipment damage, and it will void the manufacturer's warranty.
Do not use caustic / corrosive products, ammonia, solvents or any cleaning product containing alcohol or grit.
There is risk of equipment damage, and it will void the manufacturer's warranty.
Never use tools directly on the touchscreen.
There is risk of damage to the controller screen, and it will void the manufacturer's warranty.
Never use paint on the controller.
There is risk of equipment damage, and it will void the manufacturer's warranty.
Do not drop or crush the controller, or allow it to come into contact with liquids.
There is risk of equipment damage, and it will void the manufacturer's warranty.
Do not use a damaged device (such as one with a cracked screen).
Performance can be affected if the glass on the screen is broken, and it will void the manufacturer's warranty.
Use a soft, pre-moistened lint-free cloth for cleaning. Avoid getting moisture in openings.
If moisture accesses the electrical components of the controller, there is risk of re, electric shock, and physical injury or death.
Do not spray anything directly on the controller or use compressed air.
There is risk of re, electric shock, and physical injury or death.
Do not use caustic / corrosive products, ammonia, solvents or any cleaning product containing alcohol or grit.
There is risk of re, electric shock, and physical injury or death.
Never use paint on the controller.
If moisture accesses the electrical components of the controller, there is risk of re, electric shock, and physical injury or death.
Do not drop or crush the controller, or allow it to come into contact with liquids.
There is risk of re, electric shock, and physical injury or death.
Do not use a damaged device (such as one with a cracked screen).
There is risk of re, electric shock, and physical injury or death.
Cleaning the Controller

11
Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
Figure 2: Open the Cover.
Figure 3: Install the Base.
Figure 4: Reinstall Cover
Installation
1. Remove security screw (if any) on bottom of Controller cover.
2. Open unit by pulling on bottom side of Controller (Figure 1).
3. Read FCC ID and IC label installed in cover before installing any wireless product.
4. Ensure correct side of base faces up.
5. Pull cables six (6) inches (15cm) out from wall.
6. Align base and mark location of two mounting holes on wall (Figure 2).
7. Install anchors in wall.
8. Insert cable in central hole of base.
9. Insert screws in mounting holes on each side of base.
10. Strip each wire 1/4 inches (0.6cm) from end.
11.Insert each wire and screw according to wiring chart (see following pages).
12. Gently push excess wiring back into hole.
13. Gently align cover to top of base and snap in place from bottom (Figure 3).
14. Install security screw.
INSTALLATION FOR MS8350 AND MS8650
Before making power terminations during earth grounding, de-energize the
power source. Do not restore power until completing all other mounting and
wiring.
There is risk of electric shock and physical injury or death.

12
MultiSITE MS8000 Series Room Controllers
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
Control Type On/Off Floating Analog
1- BO1 Not used Not used Not used
2- BO2 Fan-L Fan-L Fan-L
3- BO3 Fan-M Fan-M Fan-M
4- BO4 Fan-H Fan-H Fan-H
5- RC / 24 Vac ~ Hot 24 Vac ~ Hot 24 Vac ~ Hot 24 Vac ~ Hot
6- C / 24 Vac ~ Com 24 Vac ~ Com 24 Vac ~ Com 24 Vac ~ Com
7- RH Aux Heat Aux Heat Aux Heat
8- BO8 Aux Heat Aux Heat Aux Heat
9- UO9 Normally Close Cool Valve Close Cool Valve Not used
10- UO10 Normally Close Heat Valve Close Heat Valve Not used
11- UO11 Normally Open Cool Valve Open Cool Valve Analog Heat Valve
12- UO12 Normally Open Heat Valve Open Heat Valve Analog Cool Valve
13- RS485 + RS485 +
14- RS485 - RS485 -
15- RS485 Ref RS485 Ref
16- UI16 UI16 Function
17- UI17 UI17 Function
18- Scom Common
19- UI19 UI19 Function
20- UI20 Remote Room Sensor
21- Scom Common
22- UI22 Remote Supply Sensor
23- UI23 Not used
24- UI24 Not used
Terminal Identification for a Three-Speed Fan System
TERMINAL IDENTIFICATION AND
FUNCTION FOR MS8350
Table 1: Terminal Identication and Function for a Three-Speed Fan Type System.
Terminal Identification for an Electronically Commutated Motor (ECM) Fan System
Control Type On/Off Floating Analog
1- BO1 Normally Close Heat Valve Close Heat valve Not used
2- BO2 Not used Not used Not used
3- BO3 Not used Not used Not used
4- BO4 ECM Fan Start ECM Fan Start ECM Fan Start
5- RC / 24 Vac ~ Hot 24 Vac ~ Hot 24 Vac ~ Hot 24 Vac ~ Hot
6- C / 24 Vac ~ Com 24 Vac ~ Com 24 Vac ~ Com 24 Vac ~ Com
7- RH Aux Heat Aux Heat Aux Heat
8- BO8 Aux Heat Aux Heat Aux Heat
9- UO9 Normally Close Cool Valve Close Cool Valve Not used
10- UO10 Analog ECM Fan Analog ECM Fan Analog ECM Fan
11- UO11 Normally Open Cool Valve Open Cool Valve Analog Heat valve
12- UO12 Normally Open Heat Valve Open Heat Valve Analog Cool Valve
13- RS485 + RS485 +
14- RS485 - RS485 -
15- RS485 Ref RS485 Ref
16- UI16 UI16 Function
17- UI17 UI17 Function
18- Scom Common
19- UI19 UI19 Function
20- UI20 Remote Room Sensor
21- Scom Common
22- UI22 Remote Supply Sensor
23- UI23 Not used
24- UI24 Not used
Table 2: Terminal Identication and Function for an ECM Fan Type System.

13
Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
Table 3: Terminal Identication and Function.
TERMINAL IDENTIFICATION AND
FUNCTION FOR MS8650
Description / Application Used in Applications: Indoor Air Quality, Heat Pump, and Rooftop Unit
Internal Temperature X
1- BO1 Aux
2- BO2 Y2
3- BO3 Y1
4- BO4 G
5- RC RC (24 Vac)
6- C Common
7- RH RH
8- BO8 W1
9- UO9 W2 / OB
10- UO10 Econo (0-10 Vdc)
11- UO11 Heat (0-10 Vdc)
12- UO12 Dehumidification output (24 Vac On/Off)
13- RS485 + BACnet (+)
14- RS485 - BACnet (-)
15- RS485 Ref BACnet Ref.
16- UI16 UI16 (multifunction input)
17- UI17 UI17 (multifunction input)
18- Scom Common
19- UI19 CO2 (0-10 Vdc input)
20- UI20 RS (Remote sensor input 10K thermistor)
21- Scom Common
22- UI22 SS (Supply sensor input 10K thermistor)
23- UI23 OS (Outside sensor input 10K thermistor)
24- UI24 Airflow (0-10 Vdc input)

14
MultiSITE MS8000 Series Room Controllers
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
Figure 5: Wiring - Single or Multispeed Motor.
Figure 6: BO8 Auxiliary Output Wiring.
All electric work must be performed by a licensed electrician and conform to local building codes or, in the absence of local
codes, with the National Electrical Code, and the instructions given in this manual.
If the power source capacity is inadequate or the electric work is not performed properly, it may result in re, electric shock, physical injury or death.
HIGH HIGH
MED
LOW LOW
HIGHHIGH HIGH
MED
LOW LOW
HIGH
3 Speed 2 Speed Single Speed
24 Vac
Transformer
Power and Fan
Figure 7: Wiring - ECM Motor.
Power and Fan
Relay Coil
Wiring ECM Motor
BO4 - Fan H
RC (24 Vac)
C (Common)
UO10 ECM Fan
24 Vac Transformer
0 - 10 Vdc signal
24 Vac signal to start fan (optional)
4
+
-
Power and Fan Relay Coil
RC (24 Vac)
C (Common)
RH
BO8 - Aux Heat
R
RC (24 Vac)
C (Common)
RH
BO8 - Aux Heat R
24 Vac Power to RelayDry Contact to End Device 24 Vac ~Maximum
WIRING FOR MS8350
Wiring

15
Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
Figure 8: Main Outputs Wiring.
Two (2) Pipe Applications Four (4) Pipe Applications
Control Type = On-Off
OR
Heating / Cooling Valve
Com
24 Vac
UO9
UO11
RC (24 Vac)
C (Common)
Com
Open
Close
Com
24Vac
0-10Vdc
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
24Vac
Com
24Vac
Com
Open
Close
Com
Open
Close
Heating valve
Cooling valve
OR
OR
UO10 NC
UO12 NO
UO09 NC
UO11 NO
RC (24 Vac)
C (Common)
Com
24 Vac
Com
24 Vac
Com
Open
Close
Com
24Vac
0-10Vdc
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
Open
Close
Com
Open
Close
Floating Control
2 Pipe Applications 4 Pipe Applications
Heating / Cooling valve
UO11
UO9
RC (24 Vac)
C (Common)
Com
Open
Close
Com
24Vac
0-10Vdc
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
24Vac
Com
24Vac
Com
Open
Close
Com
Open
Close
Heating valve
Cooling valve
UO12
UO10
UO11
UO9
RC (24 Vac)
C (Common)
Com
Open
Close
Com
24Vac
0-10Vdc
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
24Vac
Com
24Vac
Com
Open
Close
Com
Open
Close
Analog Control
Heating / Cooling valve
UO12
RC (24 Vac)
C (Common)
Com
Open
Close
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
24Vac
Com
24Vac
Com
Open
Close
Com
Open
Close
Heating valve
Cooling valve
UO11
UO12
RC (24 Vac)
C (Common)
Com
Open
Close
Com
24Vac
0-10Vdc
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
24Vac
Com
24Vac
Com
Open
Close
Com
Open
Close
WIRING FOR MS8350

16
MultiSITE MS8000 Series Room Controllers
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
WIRING FOR MS8650
VT8600
BO 2 - Y2 BO 3 - Y1
BO 4 - G
RC (24 Vac)
C (Common)
RH
BO 8 - W1
UO 9 - W2
UO 10 - Econo
UO 11 - Heat
UO 12 - Dehum
BACnet + BACnet - BACnet REF UI 16 UI 17 Common
UI 19 - CO2 UI 20 - RS Common UI 22 - SS UI 23 - OS UI 24 - Airflow
RTU: 2 Heating Stages / 2 Cooling Stages
13 14 15 16 17 18
7 8 9 10 11 12
19 20 21 22 23 24
1 2 3 4 5 6
BO 1 - Aux
ECONO
W2 W1 C R G Y1 Y2
C R
CO2
TRANSMITTER
(0-10 Vdc)
OUT
C OUT
R
AIR FLOW
MEASURING STATION
(0-10 Vdc)
FILTER
DPS
SAT
SENSOR
OAT
SENSOR
0-10 Vdc
24 Vac
Figure 9: Wiring - Rooftop Unit: Two (2) Heating Stages / Two (2) Cooling Stages.

17
Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
WIRING FOR MS8650
13 14 15 16 17 18
7 8 9 10 11 12
VT8600
BO 1 - Aux
BO 2 - Y2 BO 3 - Y1
BO 4 - G
RC (24 Vac)
C (Common)
RH
BO 8 - W1
UO 9 - W2
UO 10 - Econo
UO 11 - Heat
UO 12 - Dehum
BACnet + BACnet - BACnet REF UI 16 UI 17 Common
UI 19 - CO2 UI 20 - RS Common UI 22 - SS UI 23 - OS UI 24 - Airflow
RTU: 2 Cooling Stages / Modulating Heat
19 20 21 22 23 24
1 2 3 4 5 6
0-10 Vdc
24 Vac
ECONO
C R G Y1 Y2
C R
CO2
TRANSMITTER
(0-10 Vdc)
OUT
C OUT
R
AIR FLOW
MEASURING STATION
(0-10 Vdc)
FILTER
DPS
SAT
SENSOR
OAT
SENSOR
Mod. Heat
(0-10 Vdc)
Figure 10: Wiring - Rooftop Unit: Two (2) Cooling Stages / Modulating Heat.

Short Network
Message
18
MultiSITE MS8000 Series Room Controllers
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
VT8600
BO 1 - Aux
BO 2 - Y2 BO 3 - Y1
BO 4 - G
RC (24 Vac)
C (Common)
RH
BO 8 - W1
UO 9 - O/B
UO 10 - Econo
UO 11 - Heat
UO 12 - Dehum
BACnet +
BACnet - BACnet REF UI 16 UI 17 Common
UI 19 - CO2 UI 20 - RS Common UI 22 - SS UI 23 - OS UI 24 - Airflow
13 14 15 16 17 18
7 8 9 10 11 12
19 20 21 22 23 24
1 2 3 4 5 6
ECONO
OW C R G Y1 Y2
C R
CO2
TRANSMITTER
(0-10 Vdc)
OUT
C OUT
R
AIR FLOW
MEASURING STATION
(0-10 Vdc)
FILTER
DPS
SAT
SENSOR
OAT
SENSOR
HPU: 2 Compressors, Auxiliary Heat and Economizer
0-10 Vdc
24 Vac
WIRING FOR MS8650
Figure 11: Wiring - Heat Pump Unit: Two (2) Compressors, Auxiliary Heat and Economizer.

Time
System Status
Fan Status
Up Arrow
Increase Temperature Setpoint
Actual Setpoint
Down Arrow
Decrease Temperature Setpoint
Help
Language Selection
Temperature Units
Fan Mode
Short Network
Message
Date
Occupancy Status
Indoor Temperature
Indoor Humidity
Outdoor Temperature
System Mode
19
Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
Home Screen Display
User HMI is congurable and allows display functions such as Date, Time, Humidity, Outdoor Temperature, Setpoint, and others to be enabled or
disabled by setting various parameters.
HOME SCREEN DISPLAY FOR MS8350 AND MS8650
Figure 12: Home Screen Display with MS8350 Hospitality User Interface Shown.

20
MultiSITE MS8000 Series Room Controllers
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
Return to Home Screen
1/2 Setup
Network
Configuration
Setpoints - Display
Service View
Test Outputs
Language Selection
How to Enter the Set-up Screen
Figure 13: Entering the Set-up Screen.
Nonadjustable Parameter
• If a configuration/installer password is activated to prevent unauthorized access
to the configuration menu parameters, a password entry prompt shows to prevent
access to device configuration components.
• For more information on using and configuring the functions of the HMI, refer to
the LG MultiSITE MS8000 Series Room Controller User Manual.
Enter BACnet®and ZigBee®Network Settings
Enter Parameter Configuration Menu
Enter Setpoint and Display Settings
Enter Output Testing Mode
Enter Status and Service View
Enter Language Selection
SET-UP SCREEN FOR MS8350 AND MS8650
Figure 14: Set-up Screen Display.
Adjustable Parameter
Touch and hold this point for three
(3) seconds to enter set-up mode.
