LG PACP4B000 Instruction Manual

www.lg.com
P/NO : MFL68583904
Type: ACP IV
Model No.: PACP4B000
• Make sure to read the cautions for safety before installation and use, and use
it correctly.
• It is intended to keep protect the safety of the installer and user and to prevent
the property damage, etc.
• After reading the user manual, please keep it at a place where user can access
any time.
INSTALLATION/USER MANUAL
*MFL68583904*
ENGLISH

i
ENGLISH
EXPLANATORY NOTES
EXPLANATORY NOTES
Copyrights
The contents of this ACP IV User Guide are protected by international copyright laws, and the
Computer Program Protection Act. The contents of the User Guide and the programs mentioned
herein may only be used under license from LG Electronics in strict adherence to the user agreement.
You may not reproduce or distribute, by any means, copies of this User Guide, or any part of it,
without prior approval from LG Electronics.
Copyright © 2014 LG Electronics. All rights reserved.
Registered Trademarks
ACP IV is a registered trademark of LG Electronics. All other products and company names are
trademarks of their respective owners and are used for illustrative purposes only.

ii
ENGLISH
TIPS FOR SAVING ENERGY
TIPS FOR SAVING ENERGY
Here are some tips that will help you minimize the power consumption when you use the air
conditioner. You can use your air conditioner more efficiently by referring to the instructions below:
• Do not cool excessively indoors. This may be harmful for your health and may consume more
electricity.
• Block sunlight with blinds or curtains while you are operating the air conditioner.
• Keep doors or windows closed tightly while you are operating the air conditioner.
• Adjust the direction of the air flow vertically or horizontally to circulate indoor air.
• Speed up the fan to cool or warm indoor air quickly, in a short period of time.
• Open windows regularly for ventilation as the indoor air quality may deteriorate if the air
conditioner is used for many hours.
• Clean the air filter once every 2 weeks. Dust and impurities collected in the air filter may block
the air flow or weaken the cooling / dehumidifying functions.
For your records
Staple your receipt to this page in case you need it to prove the date of purchase or for warranty
purposes. Write the model number and the serial number here:
Model number :
Serial number :
You can find them on a label on the side of each unit.
Dealer’s name :
Date of purchase :

iii
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
Always comply with the following precautions to avoid dangerous situations and ensure peak
performance of your product
WARNING
It can result in serious injury or death when the directions are ignored.
CAUTION
It can result in minor injury or product damage when the directions are ignored.
WARNING
yInstallation or repairs made by unqualified persons can result in hazards to you and others.
yInstallation MUST conform with local building codes or, in the absence of local codes, with the
Nation Electrical Code NFPA 70/ANSI C1-1003 or current edition and Canadian Electrical Code
Part1 CSA C.22.1.
yThe information contained in the manual is intended for use by a qualified service technician
familiar with safety procedures and equipped with the proper tools and test instruments.
yFailure to carefully read and follow all instructions in this manual can result in equipment
malfunction, property damage, personal injury and/or death.
Installation
yAny question about the product installation should be asked to the service center or the
professional installation agency.
-It may cause fire, electric shock, explosion or injury.
yConsult the service center or the professional installation agency about reinstalling the
installed product.
-It may cause fire, electric shock, explosion or injury.
yPlease use the standardized parts.
-It may cause fire, electric shock, explosion, injury, or failure.
yDo not keep or use combustible gas or inflammable material near the product.
-IT may cause fire or electric shock.
yDo not disassemble, repair or modify the product at random.
-It may cause failure of the product.
yDo not install where raindrop can fall.
-It may cause failure of the product.

iv
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
yDo not install the product at wet place.
-It may cause failure of the product.
yProvided product and adaptor shall only be installed and used inside a building.
-It may cause fire or failure of the product.
*Do not install or use outside.
yInstall stably in a place that can endure the weight of the ACP IV.
-If the installation place is not strong enough, the ACP IV may fall and damaged.
yMake sure to enquire to the specialty store of the product purchase or service center for
electric works.
-It may cause fire or electric shock.
yDo not damage the power cord or bend it by force.
-It may cause fire or electric shock.
yYou need to use a safely insulated power supply which follows IEC61558-2-6 and NEC
Class2
-If you do not follow, It may cause fire, electric shock, explosion or injury.
yDo not connetion 220 V power to 24 V products
-If you do not follow, It may cause fire, electric shock, explosion or injury.
yDo not connect power cord to the control signal connector.
-It may cause fire or explosion.
Operation
yDo not change or extend the power cord with your own discretion.
-It may cause fire or electric shock
yDo not place any heating device near the product.
-It may cause fire.
yDo not use any heating device near the power cord.
-It may cause fire or electric shock.
yDo not let water flow into the product.
-It may cause electric shock or failure.
yDo not put heavy weight on the power cord.
-It may cause fire or electric shock.
yDo not put heavy weight on the product.
-It may cause the failure of the product.
yIf the product is flooded, consult the service center or the professional installation agency.
-It may cause fire or electric shock.

v
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
yLet the children or the old and the weak be controlled by the guardian to use.
-It may cause accident or failure.
yDo not give any shock to the product.
-Any shock to the product may cause failure.
yGrab the head of the plug of the power cord to pull when disconnecting the plug, and do
not click the plug with wet hands.
-It may cause fire or to deform the product.
yDo not use the product in certain environments as follows.
-If the product is used in a place with oil, steam, or sulfuric acid gas, performance may be de-
graded or product may be damaged.
yDo not press the switch or button with sharp objects.
-It may cause electric shock or failure of the product.
yPlease check the operation temperature.
-If the product is used in an environment with the temperature exceeding the operation bound-
ary, it may cause a severe damage.
Please check the usage temperature boundary in the manual. If there is no specified tempera-
ture, please use the product within the boundary of 0~40 °C.
yDo not put a container, etc. with water on the product.
-It may cause fire or electric shock.
yDo not click the switch with wet hand.
-It may cause electric shock or failure of the product.
yPlease read installation and user manual for connection with PC or peripheral devices.
-It may cause fire or failure of the product.
yIf a warning window appears on PC, product stops, or it does not work, immediately stop
the usage.
-It may cause fire or failure of the product.
CAUTION
Operation
yDo not use strong detergent such as solvent, but a soft cloth.
-It may cause fire or to deform the product.
yPlease check the rated capacity of the power.
-It may cause fire or failure of the product.

ENGLISH
MEMO

vii
ENGLISH
Table Of Contents
Table Of Contents
1
ACP IV FUNCTIONS AND SPECIFICATION
1ACP IV Functions
3ACP IV Components
4Names of each part of ACP IV
6ACP IV Hardware specification
7
Installing ACP IV
7Installing ACP IV
8Check points during the ACP IV installation
10 Setting the indoor unit address
12 Setting the PI485 and connecting the cable
14 Installing ACP IV and connecting cables
19 Setting the ACP IV network address

ENGLISH
MEMO

1
ENGLISH
ACP IV FUNCTIONS AND SPECIFICATION
ACP IV FUNCTIONS AND
SPECIFICATION
ACP IV (Advanced Control Platform IV) is the central controller that can manage up to 256
equipments in one space individually or as combined. ACP IV can monitor or control the equipments
installed in each room of the building from the places such as the management office of a building or
the administration office of a school.
ACP IV Functions
Major functions of the ACP IV are as follows.
Environment setting function using the ACP IV external buttons
ACP IV can use the external buttons installed outside of the ACP IV to set the following functions.
• Set Network environment (IP address, Net mask, Gateway)
• Set ACP ID when demand linkage
• SW upgrade function
• Data backup function
• Data recovery function
• RS-485 communication logging function
• ACP IV-screen display language setup
• Check the network connection function
PACP4B000
PACP4B000

2
ENGLISH
ACP IV FUNCTIONS AND SPECIFICATION
Embedded web server function
Without an installation of a separate PC program, when IP address of ACP IV is input in the address
window using Internet Explorer, the central control program in ACP IV web server is automatically
run, and the functions of various contents can be used.
PACP4B000
Internet
Internet
Explorer
Controlling of up to 256 air conditioner indoor units (ACS I/O Interlocking : Control up to 128 indoor
units and 16 I/O modules)
• Monitoring of error and operation status
• Controlling the peak power / demand power
• System setting function
• Up to 16 AHU can be interlocked
Devices that can interface with ACP IV
Device ACP IV
AC Ez o
Simple Central Controller o
AC Smart IV o
AC Manager IV o
Air Conditioner o
ERV o
AWHP o
Remote Shutdown o
Demand Controller o
Chiller o
(with chiller option S/W applied)
AHU o
ACS I/O o

3
ENGLISH
ACP IV FUNCTIONS AND SPECIFICATION
ACP IV Components
Inside the packaged box of the ACP IV, there are the components as in the following drawing. Open
the packaged box of the ACP IV, and check if all of the corresponding components are included.
PACP4B000
ACP IV
Power Supply Adaptor
Input: 100-240 V~
50/60 Hz, 1.2 A
Output: DC 12 V
3.33 A, 40 W MAX
Power Cord
250 V~, 3A
ACP IV
Installation/User Manual CD
ACP IV Quick Guide
www.lg.com
Type: ACP IV
Model No.: PACP4B000
• Make sure to read the cautions for safety before installation and use, and
use it correctly.
• It is intended to keep protect the safety of the installer and user and to
prevent the property damage, etc.
• After reading the user manual, please keep it at a place where user can
access any time.
• For more information, please read the manual in the CD.
QUICK GUIDE
ENGLISH FRANÇAISITALIANO DEUTSCH РУССКИЙ
ESPAÑOL
PORTUGUESE
TÜRKÇE
*MFL68583901*
P/NO : MFL68583901
NOTES
Components or options may differ from the actual product picture.

4
ENGLISH
ACP IV FUNCTIONS AND SPECIFICATION
Names of each part of ACP IV
ACP IV is composed as follows.
①
②
⑩ ⑪ ⑫
③ ④ ⑤ ⑥
⑦
⑧ ⑨

5
ENGLISH
ACP IV FUNCTIONS AND SPECIFICATION
Number Item Description
①Cover Front cover of the ACP IV
②RS-232 console port Reserved communication port
③Adaptor connection jack Jack for DC 12 V to connect to the power supply adaptor
④Buttons and LCD Buttons and LCD to set network environment and to dis-
play other information
⑤ Basic external input/
output signal connectors
Connection ports to connect to external input/output sig-
nals (DI:2, DO:2)
⑥
Optional input/output and
RS-485 communication
port (not supported in
Standard.)
Connection port to connect to external input/output signals
and RS-485 communication port for external expansion.
(8 DI’s, 2 DO’s, 2 RS-485 communication ports)
⑦RS-485 communication
port
RS-485 communication ports to connect to air conditioner
and ERV equipment (4 in total)
⑧Mini USB port USB to Serial port for software debugging
⑨USB port For software update and data backup
⑩Power switch Switch to turn on or off the power of the ACP IV
⑪Ethernet port Ethernet port to connect to internet and AC Manager IV
⑫SD card slot For RS-485 communication data backup.

6
ENGLISH
ACP IV FUNCTIONS AND SPECIFICATION
ACP IV Hardware specification
ACP IV hardware specification is as follows.
Category Description
Boundary of usage temperature 0 °C ~ 40 °C
CPU i.MX515
32Bit 800 MHz speed
RAM 128MB DDR2 SDRAM * 2EA
ROM 4GB i-NAND Flash
Communication ports
yEthernet 10 / 100 BASE-T
yUSB : USB Host (SW upgrade, data backup)
mini USB Device (Debug)
yRS-485 communication ports 6EA
ySD card slot (RS-485 communication logging)
yRS-232 Console Port (HMI)
External input/output ports DI, DO
LED 27EA (RS communication status, Ethernet communication
status, power status, operation status)
LCD 20 ×4 Character-LCD (network environment setting and
information display)
NOTES
License policy
This product follows GPL (General Public License) for the use of Embedded Linux.

7
ENGLISH
Installing ACP IV
Installing ACP IV
Installing ACP IV
This chapter describes how to install the ACP IV to use.
In order to use the ACP IV, the installation should be performed by the following order.
STEP 1. Check the cautions during the ACP IV installation
Before installing the ACP IV, check the cautions.
STEP 2. Study the cable connections diagram of the entire system
Study the cable connection diagram of the site where the ACP IV is installed.
STEP 3. Set the indoor unit address
Set the address of the ACP IV not to be overlapped with the connecting indoor unit.
STEP 4. Set PI485 and connect cables
Set DIP switch of PI485 correctly, and connect RS-485 communication cable.
STEP 5. Install ACP IV and connect cables
IInstall the ACP IV, and set network and other settings.
STEP 6. Set ACP IV network address
Set the network address to be able to access the ACP IV through internet.
S T E P 7. Set ACP IV functions
Set language, peak/demand, whether to use schedule, whether to use power display, etc.
STEP 8. Set web GUI access environment
Set the access environment in web GUI, which is the operation program of the ACP IV.
STEP 9. Input indoor unit and ventilator information
Set the access environment in web GUI, which is the operation program of the ACP IV.
STEP 10. Verify and check ACP IV installation
Verify and check whether the ACP IV is properly installed.

8
ENGLISH
Installing ACP IV
CAUTION
Installing the ACP IV
yThe ACP IV installation work needs the professional technique. Therefore, the installation
described in this chapter should be performed by the certified installation professional.
yConsult the service center or the professional installation agency certified by us about any
question or request related to the installation.
Check points during the ACP IV installation
• The number of PI485 connected to one RS-485 communication line
ACP IV provides 4 RS-485 ports for indoor unit connection. (CH 1~4)
Up to 16 PI485 for outdoor unit can be connected to one RS-485 port, and up to 31 PI485 for
SINGLE/ERV can be connected.
• The number of the indoor units that can be connected to one ACP IV
One ACP IV can be connected up to 256 indoor units. With ACS I/O interlocking, you can
connect 128 indoor units and 16 I/O modules. And with chiller interlocking, you can connect
128 indoor units and 10 chiller units.
But, to improve the communication performance of RS-485, it is recommended to be divided
and connected to 4 ports.
To one RS-485 port, all of 256 indoor units, which is the maximum number that can be
connected to the ACP IV, may be connected.

9
ENGLISH
Installing ACP IV
The maximum quantity of connected indoor unit is different depending on the quantity of
connected I/O modules.
Please refer to following information related to product connection quantity.
Quantity of
I/O Module
Quantity of
Device
0256
1248
2240
3232
4224
5216
6208
7200
8192
9184
10 176
11 168
12 160
13 152
14 14 4
15 136
16 128
256
128
16
* Devices: Indoor units, ERV, DI/DOs, DOKITs, AWHPs, AHUs
Quantity of
Device
Quantity ofI/O Module
• RS-485 communication cable connection
There is a polarity in RS-485 communication cable connection, so be careful not to reverse the
connection of the two cables.
Do not let the length of RS-485 communication cable exceed total of 1 Km.
RS-485 communication cable must be connected with BUS type.
• IP address of the ACP IV
IP address of the ACP IV, address of Gateway, and Net mask must be requested to the person
in charge of the network of the corresponding site.
CAUTION
RS-485 Connection of the ERV equipment
To connect ERV equipment, it is recommended to use the ports other than RS-485
communication ports which are connected to air conditioners.

10
ENGLISH
Installing ACP IV
Setting the indoor unit address
By considering the entire installation configuration connecting to one ACP IV, set the address to
each indoor unit not to be overlapped. 00~FF in hexadecimal can be set to the indoor unit address.
However, in case of I/O module, address 00 should not be set because address 00 is used as
Broadcast in MODBUS communication.
NOTES
Assigning indoor and outdoor unit number
If the outdoor unit product is Multi V, it is
recommended to assign the address by setting
the first digit of the address as the number of the
outdoor unit, and classifying the second digit as the
number or the indoor unit, for easy composition and
classification of the system.
Here is an example of configuring ACP IV and the device.
