LG AP-Q36GRA0 Product guide

Floor Standing
Cooling Only (R410A,50/60Hz)
6CSP0-04A (Replace : 6CSP0-03C)
P/No.: MFL60778813

Introduction
General information
Indoor unit
Thank you very much for your special patronage of LG air conditioners.
Keeping pace with developments in global environment policies, the company has developed a new refrigerant
(R410A) to replace Freon gas (R22), ahead of it being banned due to its environmentally - damaging greenhouse
effects.
This is our environment-friendly policy to protect the environment for the future.
LG’s "Floor Standing" is the indoor unit which is used as luxury domestic or commercial appliance and is used in
the places like restaurant, store or meeting room.
This unit has good design and is equipped with many special features. It comes in different color to suits the interi-
or design and maintains the harmony of the room.Installation of floor standing unit is easy and it has very low oper-
ating noise.Apart from that it has very special features such as child lock, neuro fuzzy control logic, dual plasma fil-
ter.
In installation field we can use this unit as the duct system also which makes it more dynamic and diversified than
other units.
A lot of information regarding the design and installation of this system is provided in this publication. This new
products series contains data on the same pattern.
Please utilize all the information for conducting your business efficiently.
Make sure the specification, dimension or others technical data are same as provided in enginering data book
before you start the project.
We look forward to your continuing support.
LG Electronics Inc.
Air Conditioning & Energy Solution Company
Floor Standing

Floor Standing
1. Models List
2. Model Number Nomenclature
3. List of Functions
4. Specifications
5. Dimensions
6. Piping Diagrams
7. Wiring Diagrams
8. Capacity Tables
9. The Coefficient of Capacity Change
10. Air flow and temperature distributions (reference data)
11. Operation Range
12. Sound Levels
13. Installation
14. Function of Remote Control

1. Models List
Floor Standing _ 1
Floor Standing
Floor Standing
1.1 Cooling Only
Nominal Capacity
Class_Rated
(kBtu/h)
Rated Capacity
(kW) Refrigerant Model Name Power Supply (V, Ø, Hz)
36 10.5
R410A
AP-Q36GRA0 220-240, 1, 50
220, 1, 60
48 14.1
AP-Q48GTA0
100 28.7 AP-Q100LFA0 380-415, 3, 50
380, 3, 60
n0 Series
Nominal Capacity
Class_Max
(kBtu/h)
Rated Capacity
(kW) Refrigerant Model Name Power Supply (V, Ø, Hz)
60 14.1 R410A
AP-Q60GT3E4 220-240, 1, 50
220, 1, 60
n4 Series

2. Model Number Nomenclature
2_ Floor Standing
Floor Standing
Floor Standing
A P - Q36 G R A 0
Chassis Type
Development Sequence
Electric Standard (Volts / Freq. / Phase)
G : 220-240V, 1Ø, 50Hz / 220V, 1Ø, 60Hz
L : 380-415V, 3Ø, 50Hz / 380V, 3Ø, 60Hz
Nominal Cooling Capacity(Rated)
Ex) 36 ➝36,000 Btu/h
Type of Air Conditioner
AP : R410A Floor Standing Type Air Conditioner
Function
A : Basic
Model Type
Q : Inverter Cooling Only
Set unit
U : Outdoor unit
N : Indoor unit
n0 Series
A P - Q60 G T 3 E 4
Chassis Type
Development Sequence
Electric Standard (Volts / Freq. / Phase)
G : 220-240V, 1Ø, 50Hz / 220V, 1Ø, 60Hz
L : 380-415V, 3Ø, 50Hz / 380V, 3Ø, 60Hz
Nominal Cooling Capacity(Max)
Ex) 60 ➝57,000 Btu/h
Type of Air Conditioner
AP : R410A Floor Standing Type Air Conditioner
Function
A : Basic E : Deluxe
Model Type
Q : Inverter Cooling Only
Set unit
U : Outdoor unit
N : Indoor unit
n4 Series

3. List of Functions
Floor Standing _ 3
Floor Standing
Floor Standing
Notes :
O : Applied, X : Not applied
Accessory model name : Installed at field, ordered and purchased separately by the corresponding model name, supplied with separate package.
3.1 Indoor Units
Category Functions APNQ36GRA0 APNQ48GTA0
Air flow
Air supply outlet 1 1
Airflow direction control (left & right) Auto Auto
Airflow direction control (up & down) Auto Auto
Auto swing (left & right) O O
Auto swing (up & down) O O
Airflow steps (fan/cool/heat) 4 / 4 / - 4 / 4 / -
Chaos wind(auto wind) X X
Jet cool/heat O / X O / X
Swirl wind X X
Air purifying
Triple filter (Deodorizing) X X
Plasma air purifier X X
Allergy Safe filter X X
Long-life prefilter (washable / anti-fungus) O O
Installation
Drain pump X X
E.S.P. control X X
Electric heater X X
High ceiling operation X X
Auto Elevation Grille X X
Reliability Hot start X X
Self diagnosis O O
Convenience
Auto changeover X X
Auto cleaning O O
Auto operation(artificial intelligence) O O
Auto Restart O O
Child lock O O
Forced operation X X
Group control X X
Sleep mode X X
Timer(on/off) O O
Timer(weekly) X X
Two thermistor control X X
Individual control
Standard Wired remote controller X X
Deluxe wired remote controller X X
Simple wired remote controller X X
Simple Wired remote controller(for hotel use) X X
Wireless remote controller O O
CAC network
function
General central controller (Non LGAP) X X
Network Solution(LGAP) O O
Dry contact
PDRYCB000 / PDRYCB400 / PDRYCB300 PDRYCB000 / PDRYCB400 / PDRYCB300
PI 485(for Indoor Unit) X X
Special function kit
Zone controller X X
CTI(Communication transfer interface) X X
Electronic thermostat X X
Others Remote temperature sensor X X
Telecom shelter controller X X

3. List of Functions
4_ Floor Standing
Floor Standing
Floor Standing
Notes :
O : Applied, X : Not applied
Accessory model name : Installed at field, ordered and purchased separately by the corresponding model name, supplied with separate package.
Category Functions APNQ60GT3E4 APNQ100LFA0
Air flow
Air supply outlet
1 1
Airflow direction control (left & right)
Auto Manual
Airflow direction control (up & down)
Auto Manual
Auto swing (left & right)
O X
Auto swing (up & down)
O X
Airflow steps (fan/cool/heat)
4 / 4 / - 2 / 3 / -
Chaos wind(auto wind)
X X
Jet cool/heat
O / X O / X
Swirl wind
X X
Air purifying
Triple filter (Deodorizing)
X X
Plasma air purifier
X X
Allergy Safe filter
X X
Long-life prefilter (washable / anti-fungus)
O O
Installation
Drain pump
X X
E.S.P. control
X X
Electric heater
X X
High ceiling operation
X X
Auto Elevation Grille
X X
Reliability Hot start
X X
Self diagnosis
O O
Convenience
Auto changeover
X X
Auto cleaning
O X
Auto operation(artificial intelligence)
O O
Auto Restart
O O
Child lock
O O
Forced operation
X O
Group control
X X
Sleep mode
X X
Timer(on/off)
O O
Timer(weekly)
X X
Two thermistor control
X X
Individual control
Standard Wired remote controller
X X
Deluxe wired remote controller
X X
Simple wired remote controller
X X
Simple Wired remote controller(for hotel use)
X X
Wireless remote controller
O O
Network function
General central controller (Non LGAP)
X X
Network Solution(LGAP)
O O
Dry contact
PDRYCB000 PDRYCB000 / PDRYCB400 / PDRYCB300
PI 485(for Indoor Unit) X X
Special function kit
Zone controller
X X
CTI(Communication transfer interface)
X X
Electronic thermostat
X X
Others
Remote temperature sensor
X X
Group control wrie
X X
Telecom shelter controller
X X

3. List of Functions
Floor Standing _ 5
Floor Standing
Floor Standing
3.2 Outdoor Units
Notes :
O : Applied, X : Not applied
Accessory model name : Installed at field, ordered and purchased separately by the corresponding model name, supplied with separate package.
Category Functions APUQ36GRA0 APUQ48GTA0 APUQ60GT3E4 APUQ100LFA0
Reliability
Defrost / Deicing X X
X X
High pressure switch X X X X
Low pressure switch X X X X
Phase protection X X X O
Restart delay (3-minutes) O O O O
Self diagnosis O O O O
Soft start X X X X
Test function O O O O
Convenience Night Silent Operation O O X X
CAC network function Network soluation(LGAP) O O O O
Device APUQ36GRA0 / APUQ48GTA0 /
APUQ100LFA0 APUQ60GT3E4
Central Controller
PQCSZ250S0
PACEZA000
PACS5A000
PACP5A000
PACM5A000
PMNFP14A1
BNU(Building
Network Unit)
PLNWKB000
PQNFB17C0
ODU Dry Contact X
Low Ambient Kit X (Logical operation)
AC Ez
AC Ez Touch
AC Smart 5
ACP 5
AC Manager 5
PI 485
LONWORKS Gateway
BACnet Gateway
PQCSZ250S0
PACEZA000
PACS5A000
PACP5A000
PACM5A000
PMNFP14A1
PLNWKB000
PQNFB17C0
X
O (Logical operation)

4. Specifications
6_ Floor Standing
Floor Standing
Floor Standing
4.1 Indoor Units
Note :
1. All data are based on the following conditions:
- Cooling Temperature : Indoor 27°C(80.6°F) DB / 19°C(66.2°F) WB
Outdoor 35°C(95°F) DB / 24°C(75.2°F) WB
- Heating Temperature : Indoor 20°C(68°F) DB / 15°C(59°F) WB
Outdoor 7°C(44.6°F) DB / 6°C(42.8°F) WB
- Interconnected Pipe Length is standard length.
- Difference Limit of Elevation (Outdoor ~ Indoor Unit) is Zero.
2. Wiring cable size must comply with the applicable local and national code.
3. Due to our policy of innovation some specifications may be changed without notification.
4. Sound Level Values are measured at anechoic chamber.
Therefore, these values can be increased owing to ambient conditions during operation.
Model Name APNQ36GRA0 APNQ48GTA0
Power Supply V, Ø, Hz 220-240, 1, 50
220, 1, 60
Power Input (Indoor Unit only) Rated W 150
Running Current (Indoor Unit only) A 0.50
Casing Color - Middle White
Dimensions Body W x H x D mm 590 × 1,840 × 320
W x H x D inch 23-7/32 x 72-7/16 x 12-19/32
Net Weight Body kg (lbs) 36.0 (79.4)
Heat
Exchanger
(Row x Column x Fins per inch) x No. - (3 x 38 x 19) x 1
Face Area m2(ft2) 0.30 (3.26)
Fan
Type - Sirocco
Air Flow Rate SH / H / M / L m3/min 23.5 / 21.0 / 17.0 / 14.0
SH / H / M / L ft3/min 830 / 742 / 600 / 494
Fan Motor Type - BLDC
Output W x No. 104 x 1
Dehumidification Rate
l / h (pts/h) 4.3 (9.1)
Sound Pressure Level SH / H / M / L dB(A) 52 / 48 / 44 / 41
Sound Power Level Cooling dB(A) -
Piping
Connections
Liquid mm(inch) Ø 9.52 (3/8)
Gas mm(inch) Ø 15.88 (5/8)
Drain (O.D. / I.D.) mm Ø 21.0 / 17.0
Safety Devices - Fuse
- Thermal Protector for Fan Motor
Power and Communication Cable (included Earth) No. x mm24C x 1.0
220-240, 1, 50
220, 1, 60
281
0.91
Middle White
590 × 1,840 × 460
23-7/32 x 72-7/16 x 18-1/8
49.0 (108.0)
(3 x 38 x 19) x 1
0.39 (4.17)
Sirocco
38.0 / 32.0 / 28.0 / 24.0
1,342 / 1,130 / 989 / 848
BLDC
224 x 1
5.2 (11.0)
53 / 50 / 47 / 43
-
Ø 9.52 (3/8)
Ø 15.88 (5/8)
Ø 21.0 / 17.0
Fuse
Thermal Protector for Fan Motor
4C x 1.0

4. Specifications
Floor Standing _ 7
Floor Standing
Floor Standing
Note :
1. All data are based on the following conditions:
- Cooling Temperature : Indoor 27°C(80.6°F) DB / 19°C(66.2°F) WB
Outdoor 35°C(95°F) DB / 24°C(75.2°F) WB
- Heating Temperature : Indoor 20°C(68°F) DB / 15°C(59°F) WB
Outdoor 7°C(44.6°F) DB / 6°C(42.8°F) WB
- Interconnected Pipe Length is standard length.
- Difference Limit of Elevation (Outdoor ~ Indoor Unit) is Zero.
2. Wiring cable size must comply with the applicable local and national code.
3. Due to our policy of innovation some specifications may be changed without notification.
4. Sound Level Values are measured at anechoic chamber.
Therefore, these values can be increased owing to ambient conditions during operation.
Model Name APNQ60GT3E4 APNQ100LFA0
Power Supply V, Ø, Hz
Power Input (Indoor Unit only) Rated W
Running Current (Indoor Unit only) A
Casing Color -
Dimensions Body W x H x D mm
W x H x D inch
Net Weight Body kg (lbs)
Heat
Exchanger
(Row x Column x Fins per inch) x No. -
Face Area m2(ft2)
Fan
Type -
Air Flow Rate SH / H / M / L m3/min
SH / H / M / L ft3/min
Fan Motor Type -
Output W x No.
Dehumidification Rate
l / h (pts/h)
Sound Pressure Level SH / H / M / L dB(A)
Sound Power Level Cooling dB(A)
Piping
Connections
Liquid mm(inch)
Gas mm(inch)
Drain (O.D. / I.D.) mm
Safety Devices -
-
Power and Communication Cable (included Earth) No. x mm2
220-240, 1, 50
220, 1, 60
700
4.0
Middle White
1,050 × 1,880 × 495
41-11/32 × 74-1/32 × 19-1/2
113.0 (249.0)
( 3 × 40 × 19) × 1
0.77 (8.29)
Sirocco
68 / 61 / - / 50
2,402 / 2,154 / - / 1,766
BLDC
900 × 1
12.6 (26.8)
58 / 55 / - / 51
-
Ø 9.52 (3/8)
Ø 22.2(7/8)
Ø 32 / 25
Fuse
Thermal Protector for Fan Motor
4C x 1.5
220-240, 1, 50
220, 1, 60
281
0.91
White
590 x 1,840 x 440
23-7/32 x 72-7/16 x 17-5/16
49.0 (108.0)
(3 x 38 x 19) x 1
0.39 (4.20)
Sirocco
37 / 33 / 28 / 24
1,307 / 1,165 / 989 / 848
BLDC
224 × 1
4.9 (10.4)
53 / 50 / 47 / 45
-
Ø 9.52 (3/8)
Ø 19.05 (3/4)
Φ21 / 17
Fuse
-
4C x 1.0
