LG AN-PM19BA Operation manual

Order Number
: GETEC-C1-18-529
FCC Part 15 subpart C
Test Report Number
: GETEC-E3-18-030
Page 1 / 1
EUT Type: Premium Magic Remote
FCC ID.: BEJPM19BA
APPENDIX H
: USER’S MANUAL

Information
Model Name : AN-PM19BA
Premium Magic Remote
User

목차
1. 리모콘의 개요 및 제원
(1) 개요
(2) 제원
2. 주의 사항
3. 고객 지원
Korean
한국어

1. 리모콘의 개요 및 제원
(1) 개요
- 프리미엄 매직 리모컨의 사용 방법은 TV 매뉴얼을 참조하세요.
이 리모컨은 사용자가 댁내에서 리모컨을 무선 마우스처럼 사용하여
TV를 제어할 수 있는 제품으로써, 기존 적외선 리모컨이 육안상에 위치한
제품을 제어했던 반면에 댁내 10m 이내에서 방향에 상관없이 제어 할 수
있는 2.4 GHz대RF 리모컨이다. (음성인식지원)
(2) 제원
구분 내 용
모델명 AN-PM19BA
무선 사양 및 주파수 Bluetooth LE / 2.400 GHz ~ 2.4835 GHz
채널 40 채널
전원 DC 3V
알카라인 AAA 1.5 V 건전지 2개사용
동작 온도 0 ℃ ~ 40 ℃

2. 주의 사항
(1) 건전지를 교체한 후에는 리모컨 사용법에 따라 페어링 후에 사용 한다.
(2) 건전지를 교체 후에 리모컨이 정상 동작하지 않는 경우, 페어링 설정을
다시 해 주세요.
(3) 장기간 리모컨을 사용하지 않는 경우, 건전지를 제거해 두는 것이 좋다.
(4) 건전지를 분해하거나, 열을 가해서는 안 된다.
(5) 건전지를 떨어뜨리거나, 케이스가 손상될 정도로 극심한 충격을 줘서는
안된다.
(6) 건전지를 물에 넣어서는 안 된다.
(7) 건전지를 거꾸로 삽입시 폭발의 위험이 있다.
(8) 지정된 장소에 사용한 건전지를 폐기 한다.
(9) 건전지 뚜껑을 열면, 라벨을 확인할 수 있습니다.
3. 고객 지원
TV 매뉴얼의 서비스 연락처를 참조하세요.
[KCC 인증 마크 및 인증번호]
상호명:엘지전자(주)
인증번호 : R-C-LGE-PM19BA
제조연월 : 2019.
제조자/제조국가 : 엘지전자(주)/대한민국
기자재의 명칭/모델명 : 특정소출력
무선기기(무선데이터통신시스템용 무선기기)/AN-PM19BA
A/S 정보 : ㈜ 엘지전자서비스
Tel : [phone]
홈페이지 : www.lgeservice.co.kr

Table of Contents
1. Overview and specification of the remote control
(1) Overview
(2) Specification
2. Precautions
3. Customer Support
English

1. Overview and Specifications for the Remote Control
(1) Overview
- Instructions for using the Premium Magic Remote control are in the
TV manual.
this remote uses RF(Radio Frequency) instead of IR (InfaRed light).
this remote will operate within 10m of the tv and does
not require it be pointed at the tv.(voice recognition support)
(2) Specifications
"This device can be operated in at least one Member State without
infringing applicable requirements on the use of radio spectrum"
Categories Details
Model No. AN-PM19BA
Range of frequency 2.400 GHz ~ 2.4835 GHz
Output Power(Max.) 1 dBm
Channel 40 channels
Power source AAA 1.5 V,
2 alkaline batteries are used
Operational
temperature range 0 ℃ ~ 40 ℃

2. Precautions
(1) After replacement of the battery, use the remote control following pairing
in accordance with user manual.
(2) If the unit does not operate after replacement of battery, reattempt pairing
in accordance with the user manual.
(3) If the remote controller is not being used for prolonged period of time, it is
recommended you remove the battery from the unit.
(4) Do not dismantle or exert heat to the battery.
(5) Do not drop battery or exert extreme impact that may even cause the case
to be damaged.
(6) Do not immerse the battery in water.
(7) There is danger of explosion if a the battery is inserted reversely.
(8) Properly dispose of used batteries.
(9) Open the battery cover to find the label.
3. Customer Support
Refer to the contact number for services provided in the TV Manual.

Federal Communications Commission(FCC) Statement
Federal Communications Commission(FCC) Statement
You are cautioned that changes or modifications not expressly
approved by the part responsible for compliance could void
the user’s authority to operate the equipment.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected
- Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received, including
interference that may cause undesired operation of the
device.
You are cautioned that changes or modifications not expressly
approved by the part responsible for compliance could void the
user’s authority to operate the equipment.
FCC Caution
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this equipment and For indoor use only, use outdoors or in
other modes not covered by this manual may violate the FCC
regulation and violate the user authority to use the product.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter. End users
must follow the specific operating instructions for satisfying RF exposure
compliance.

Industry Canada Statement
[English]
Industry Canada Statement
(For Canada)
This device complies with Industry Canada’s licence-exempt RSS
Stadard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Avis d'industrie canada
Cet appareil est conforme aux normes CNR d’Industrie Canada
applicables aux dispositifs exempts de licence. L’exploitation est autorisée
aux deux conditions suivantes :
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en compromettre
le fonctionnement.
IC Radiation Exposure Statement
(For Canada)
This equipment complies with IC radiation exposure limits set forth for an
Uncontrolled environment.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY
TO OPERATE THE EQUIPMENT.

[French]
Avis d'Industrie Canada
(Pour le Canada)
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes :
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
Avis d’Industrie Canada sur l’exposition aux rayonnements
Avis d'industrie canada
(Pour le Canada)
Cet appareil est conforme aux limites d’exposition aux rayonnements
d’Industrie Canada pour un environnement non contrôlé.
REMARQUE : LE FABRICANT N’EST PAS RESPONSABLE DES INTERFÉRENCES
RADIOÉLECTRIQUES CAUSÉES PAR DES MODIFICATIONS NON AUTORISÉES
APPORTÉES À CET APPAREIL. DE TELLES MODIFICATIONS POURRAIENT
ANNULER L’AUTORISATION ACCORDÉE À L’UTILISATEUR DE FAIRE
FONCTIONNER L’APPAREIL.

CE Statement
1) Certification Marking
[ENGLISH]
Hereby, LG Electronics declares that the radio equipment type
[Magic Remote] is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the
following internet address:
http://www.lg.com/global/support/cedoc/cedoc#
LG Electronics European Shared Service Center B.V.
Krijgsman 1
1186 DM Amstelveen
The Netherlands
Wireless function S/W Version: 17354
H/W Version: PNCFA1431A
