Life Fitness 93T Configuration guide

Page 1 of 15
Treadmill 93T 93T-0XXX-01
General Assembly S/N TTC100000
Touch-Up Paint Color Container
0017-00008-0196 Silver Bullet Bottle
0017-00008-0197 Silver Bullet Spray Can
0017-00008-0198 Stealth Gray Bottle
0017-00008-0199 Stealth Gray Spray Can
Manual/Video Part Number
Operation Manual, Eng M051-00K58-A081
Service Manual M051-00K58-A097
Installation Video M051-00K58-A098
Service Video M051-00K58-A099
A
ccess Panel Cover (2)
0K58-01279-0000
Screw (4)
0017-00101-1771
Leveler
Assembly
Rear End Cap
0K58-01268-0000
Rear End Cap
0K58-01268-0000
Screws (4)
0017-00101-1772
Striding Belt, Deck,
and Rear Roller
Handrail Assembly
Console
Assembly
Cup Holder, LT
AK58-00247-0002
Cup Holder, RT
AK58-00247-0001
Motor Cover,
Endcaps,
and Hardware
Frame Assembly
Access Panel Decal, RT
0K58-01336-0001
Access Panel Decal, LT
0K58-01336-0002
Power
Components
Cables

Page 2 of 15
Treadmill 93T93T-0XXX-01
Frame Assembly S/N TTC100000
Idler Arm
Assembly
Lift Motor
and Frame
Motor
Controller
Assembly Wax Lift
Board
Fan Assembly
A
K58-00126-0000 (100v)
AK58-00145-0000 (200V
Mounting Screws
0017-00101-1781
A
nti-StaticTinsel
0K58-01102-0001
Tinsel Spring
0017-00009-0901
Anti-Scu Pad (2)
0K58-01306-0000
Wax Components
Static Brush
Drive Motor
Assembly Front Roller
Assembly
Frame Tag PCB
B084-92187-D000

Page 3 of 15
Treadmill 93T 93T-0XXX-01
Console Assembly S/N TTC100000
Console Assembly Overlay Switch Bezel Assy Language
AK58-00198-0001 AK58-00204-0001 Eng/Met
AK58-00198-0002 AK58-00204-0001 Eng/Eur
AK58-00198-0003 AK58-00204-0003 German
AK58-00198-0004 AK58-00204-0004 Spanish
AK58-00198-0006 AK58-00204-0006 Japanese
AK58-00198-0007 AK58-00204-0007 French
AK58-00198-0008 AK58-00204-0008 Italian
AK58-00198-0009 AK58-00204-0009 Dutch
AK58-00198-00010 AK58-00204-00010 Portuguese
AK58-00198-00011 AK58-00204-00011 Chinese
PCB Assembly
A084-92184-A004
Rear Console Case
0K58-01272-0000
Rear Console Decal
0K58-01357-000
Console Screw (8)
0017-00101-1288
Console Accessory
Cover
0K58-01280-0000
PCB Mounting Screw (8)
0017-00101-1275
Polar/E-Stop Cable Assy
AK58-00237-0000
Polar PCB Cable Assy
AK39-00064-0000
Switch Membrane
118E-00001-0128
Front Console Case
0K58-01273-0001
Stop Switch
0K58-01321-0000
Micro-Switch
0017-00032-0185
CD Tray, Rubber Pad
0K58-01359-000
0
Tether Stop Assy
AK58-00246-0000
Magnet Disc
0K40-01070-0000
See Table
See Table

Page 4 of 15
Treadmill 93T 93T-0XXX-01
Handrail Assembly S/N TTC100000
Hardware Bag Assembly
AK58-00227-0000
Handrail Hex Nut (4)
0017-00103-0327
Handrail (2)
AK58-00259-0000
Top RT Handrail Boot
0K58-01303-0001
Console/Cup Holder
Mounting Screw (8)
0017-00101-1780
Bottom RT
Handrail Boot
0K58-01304-0001
Handrail Mounting
Screw (4)
0017-00101-1774
Handrail Boot
Screws (6)
0017-00101-1770
Bottom LT
Handrail Boot
0K58-01304-0002
Console Mounting
Screw (4)
0017-00101-1773
Top LT Handrail Boot
0K58-01303-0002
Handrail Screw (2)
0017-00101-1773
Handrail Tube Cap (2)
0K58-01323-0000
Upright, RT
AK58-00255-0001
Upright, LT
AK58-00255-0002
Upright Tube Cap (2)
0K58-01302-0000 Upright Tube
Cap Screw (2)
0017-00101-1772
Grommet (2)
0017-00042-0326
Upright Plug (2)
0K58-01305-0000
Upright Mounting
Screw - 0017-00101-1778 (6)
Washer - 0017-00104-0335 (6)
Upright, Plug (2)
0K58-01305-0000
Handrail Collar (2)
0K58-01348-0000
ERGO Bar Assembly
AK58-00190-0000
ERGO Bar Gasket (2)
0K58-01347-0000

Page 5 of 15
Treadmill 93T 93T-0XXX-01
Motor Cover, End Caps and Hardware S/N TTC100000
Front End Cap (2)
0K58-01267-0000
End Cap Screws (4)
0017-00101-1772
Front Cover
0K58-01266-0000
Screws (4)
0017-00101-1771
Motor Cover Screws (4)
0017-00101-1772 Motor Cover
A
K58-00228-0000
Bug Medallion Assembly
A
K58-00245-0000
Felt Strip - 28”
0017-00081-0294
Flex Deck Decal (2)
0K58-01365-0000

Page 6 of 15
NOTE: S/N TTC100168 & Below, use Kit No. GK58-00002-0066
Treadmill 93T 93T-0XXX-01
Belt, Deck, Rear Roller S/N TTC100000
Deck
0K58-01091-0001
Deck Mounting Screws (4)
0017-00101-1775
Grommet (2)
0017-00042-1147
TECSPAK Spring (8)
0K40-01026-0002
Washer (8)
0017-00104-0101
TECSPAK Tinnerman Clip (8)
0017-00103-0198
TECSPAK Mounting Screw (8)
0017-00101-1652
Belt Limit Label, RT
M051-00K58-A100
Caution Label
M051-00K58-A014
Striding Belt
0K58-01180-0000
Belt Limit Label, LT
M051-00K58-A101
Rear Roller Guard, LF
0K58-01349-0002
Round Grommet
0017-00042-0326
Roller Guard Screw (4)
0017-00101-1776
Rear Roller Guard, RT
0K58-01349-0001
Square Grommet
0017-00042-1147
Screw
0017-00101-1776
Washer
0017-00104-0043
Rear Roller
0K58-01002-0000
Rear Roller
Adjusting Screws
0017-00101-1779

Page 7 of 15
Treadmill 93T93T-0XXX-01
Lift Motor and Frame S/N TTC100000
Clevis Clip
0017-00007-0208
Clevis Pin
0017-00007-0214
Lift Motor
0K58-01062-0000
Lock Nut (2)
0017-00103-0285
Hex Screw (2)
0017-00101-1777
Flat Washer (2)
0017-00104-0259
Bronze Sleeve (2)
0K58-01089-0000
Line Cord Clip
0017-00042-0840
Lift Frame
Lock Nut
0017-00103-0025
Lift Motor Hex Bolt
0017-00101-1021
Vinyl Cap
0017-00042-1075
Wheel
0K58-01071-0000
Phillips Screw
0017-00101-1621
Washer
0017-00104-0189
Lift Frame End Cap
0017-00042-1076
IEC Receptacle
0017-00003-0949
Retainer Bracket w/Screw
0017-00042-1145
Frame Screws
0017-00101-1723
AK58-00220-0000

Page 8 of 15
Treadmill 93T 93T-0XXX-01
Motor Controller Assembly S/N TTC100000
Motor Controller Assembly
AK58-00153-0001 (120v/60Hz)
AK58-00153-0002 (230v/50Hz)
Wax/Lift PCB
A
084-92261-A001
Pin Collar Spacer
0017-00042-1070
Spacer Retainer
0017-00042-1071
Phillips Pan Screw
0017-00101-1641
Nut
0017-00103-0005
“LINE” End
Line Filter
Mounting Screws
0017-00101-0134
“LOAD” End
Speed Sensor
Cable Thermo-Switch
Cable
Bushing
0017-00042-1069
Hex Nut
0017-00103-0005
Thermal Switch
118E-00001-0132
Washer
0017-00104-0456
Phillips Screw
0017-00101-1059
Insulator Barrier
0K58-01228-0000
Hex Nut
0017-00103-0005
Retainer Bracket
0K58-01144-0000
Wax PCB Retainer
0K58-01149-0000
Washer
0017-00104-0456
Phillips Screw
0017-00101-1759
Line Filter (50Hz units Only)
0017-00003-0898

Page 9 of 15
Treadmill 93T 93T-0XXX-01
Drive Motor Assembly S/N TTC100000
Poly-V Pulley
0K58-01057-0001
Motor w/Caution Label
AK58-00171-0000
Slotted Hex Screw (2)
0017-00101-0975
Speed Sensor Assembly
AK58-00073-0001
Sensor Wheel
Mounting Screw (3)
0017-00101-1631
Sensor Wheel
0K58-01094-0000
Locking Nut (4)
0017-00103-0027
Washer (4)
0017-00104-0409
Insulating Shoulder
Washer (4)
0K58-01255-0000
Insulating Pad (2)
0K58-01256-0001
Flywheel Assembly
AK58-00090-0002

Page 10 of 15
Treadmill 93T 93T-0XXX-01
Wax Components S/N TTC100000
Brass Spray Tip
0017-00009-0842
Extrusion
0K58-01111-0001
Phillip Screws
0017-00101-0658
Tie Straps
0017-00042-0622
PVC Tube - 22”
0017-00041-0830
Spray Nozzle Assembly
AK58-00046-0000
Protective Sleeve
0K58-01080-0000
Wax Refill Bag
GK58-00002-0002
Wing Nuts
0017-00103-0284
Tube Reducer Connector
0017-00021-2188
Hose Clamp
0017-00042-0842
Wax Pump
AK58-00187-0000
Replacement Hose
AK58-00148-0000

Page 11 of 15
Treadmill 93T 93T-0XXX-01
Idler Arm Assembly S/N TTC100000
Idler Arm Assembly
AK58-00053-0002
Idler Pin
0017-00007-0248
Idler Spring Damper
0K26-02055-0000
Idler Spring
0k58-01085-0000
Wire Clamp
0017-00042-1072
Screw
0017-00101-1193
Limit Switch
0017-00032-0195
Limit Switch Cable
AK58-00027-0000
Motor Pulley
0K58-01057-0001
Allen Screw
0017-00101-0333
Grommet
0017-00042-0326
Drive Belt
0K58-01114-0000
Idler Pulley
0K26-01731-0000
Threaded Idler
0K58-01084-0002
Lock Nut: Idler
0017-00103-0324
Shaft
Tinsel Bracket
0K58-01263-0001
Tinsel Bracket Screw(2)
0017-00101-1193
Plug
0017-00042-1053
(For units not
equipped with
circuit breaker.)

Page 12 of 15
Treadmill 93T 93T-0XXX-01
Leveler Assembly AK58-00052-0000 S/N TTC100000
Bracket Leveler
0K58-01083-0000
Pivot Pin
0K58-01098-0000
Leveling Foot
0K58-01110-0000
Stop Nut
0K58-01099-0000
Hex Nut (4)
0017-00101-1253
Lock Washer (4)
0017-00104-0333
Flat Washer (4)
0017-00104-0190

Page 13 of 15
Treadmill 93T93T-0XXX-01
Front Roller AssyAK58-00066-0000 S/N TTC100000
Polley V Pulley 8”
0K58-01105-0000
Hex Bolt
0017-00101-1632Flat Washer
0017-00104-033
0
Lock Washer
0017-00104-0005
Flat Washer
0017-00104-0043
Mounting Bolt
0017-00101-0974

Page 14 of 15
Treadmill 93T 93T-0XXX-01
Power Components Schematic S/N TTC100000
Voltage Power Cable Part No. Breaker AMP/Part No.
120v GK58-00002-0061 Not Used
100v GK58-00002-0062 4 AMP/0017-00003-0950
200v GK58-00002-0063 2 AMP/0017-00003-0626
220/230v GK58-00002-0064 2 AMP/0017-00003-0626
240+ GK58-00002-0065 2 AMP/0017-00003-0626
10 Amp Line Filter
units with 220v or lower
0017-00003-0898
20 Amp Line Filter
units with 230v or higher
0017-00003-0943
On/Off switch
0017-00032-0198
4” Black Wire
AK58-00081-0000
6” White Wire
AK58-00082-0000
5” Green/Yellow Wire
AK58-00083-0000
Xformer Bracket Assembly
(foreign units only)
AK58-00210-0000
MOV/Filter Cable Assy.
AK58-00224-0001
Line Cord (Plug End Changes)
0017-00003-0947 12’ 120v
0017-00003-0923 Domestic
0017-00003-0948 12’ 220v
0017-00003-0915 RT Angle Plug
0017-00003-0781 220v/60Hz
0017-00003-0696 Continental
0017-00003-0890 Uk

Page 15 of 15
Treadmill 93T 93T-0XXX-01
Cables S/N TTC100000
WAXLIFT
POWERSUPPLY
LIFELINK
-3%SWITCH
TAG
EXTERNAL
MEMORY
FRAMEMOTOR
LIFT
8POS.MINIFITJRCONN.
8POS.MINIFITJRCONN.
4POS.MNLCON.
4POS.MICROFITCONN.
5POS.ILMINIFITJRCONN.
5POS.ILMINIFITJRCONN.
0%SWITCH
1234
GREEN/YELLOWN/C
UP
,RL
HOT
DN,RL2
8POS.MINIFITJRCONN.
10POS.MINIFITJRCONN.
P1
REEDSENSE
GND.
GND.
+8VDC
+8VDC
NC.
TXD
RXD
BUS_REQ
+12VDC
10
9
8
7
6
5
4
3
2
1
P8
1
2
3
4
5
+8VDC
GND.
BUSREQ
RXD
TXD
1
2
3
4
LEVELSWITCH
CLOSED@0%
0POSITION
GND.
BOTTOM
GND.
*WHTORRED
*BLACK
*BLACK
*WHTORRED
FASTONTERM(2PLCS)
2POSMICRO
1
2
3
*BLACK
*WHITE
*RED
0POSITION
GND.
BOTTOM
FASTONTERM(2PLCS)4POS.MICROFITCONN.
12345678
8
7
6
5
4
3
2
1
*BLACK
*WHITE
*RED
*GREEN
*BROWN
*BLUE
*ORANGE
*YELLOWCE
CS
NC.
SCK
MOSI
MISO
GND
VCC
CE
GND
VCC
CS
SCK
MOS1
MISO
NC.
P2
P2
P4P7
BLACK
WHITE
RED
ON9700WITH
DECLINEONLY
YELLOW
ORANGE
BROWN
RED
BLUE
PURPLE
GREEN
GRAY
WHITE
BLACK
10
9
8
7
6
5
4
3
2
1
LowerConsole
Cable
AK58-00034-0000
ZerotoNegative
SwitchCable
AK60-00009-0001
NegativeZeroSwitchCable
AK58-00027-0000
FrameTagCable
AK58-00030-0000
T
MOTORCONTROL
PUMP
MOTOR
WAX
2POS.MAT-N-LOKCONN.
6POS.MICROFITJRCONN.
6POS.MINIFITJRCONN.
3POS.SABRECONN.
3POS.MAT-N-LOKCONN.
MOTOR
2
1
3
WHITE
BLACK
GREEN
WHITE
BLACK
WHITE RED
BLACK
PURPLE
6POS.MNL2CON.
2
14
356
BLUE
BLUE
12
P6
1
2
3
4
5
6
1
2
3
4
5
6
*BLACK
*WHITE
*RED
*GREEN
*BROWN
*BLUE
8VDC
GND.
PINRLY
BUSREQ
RXD
TXD
P9
8VDC
GND.
PINRLY
BUSREQ
RXD
TXD
4
3
2
1
1234
P1
12
2POS.MAT-N-LOKCONN.
123456
6
5
4
3
2
1
6POS.MNL2CON.
123
123
CAPACITORBD.
VIN
GND
GND
VOUT
SPEED
PICK-UP
RED
BLACK
WHITE
3
2
1
RED
BLACK
WHITE
6
5
4
3
2
1
6POS.MNL2CON.
SABRECON
4POS.SABRECON.
VPOS
VPOS
VNEG
NEU
AC2
W18
U20
ACPWR
V19
GND
P2
GND
RPM_IN
VCC
P5
LINE
NEUTRAL
GND
P1
P4
P3
WHITE
BLACK
P1-3
120V
240V
IN
OUT
BLACK
RED
WHITE
BLUE
BLUE
GREEN/YELLOW
3
2
1
FAN
MOUNTEDINSIDECHANNEL
NEARMOTORCONTROLLER
2PM-N-L
MOUNTEDTO
MOTORCONTROLLER
WHITE
BLACKGRAY
1
2
4POS.
GRN/YLW
FROM
PEM
3POS.
MAT-N-LOK
CONN.
WaxCable
AK58-00029-0000
ThermalSwitchBracketCable
AK58-00137-0000
ThermalSwitchCable
AK58-00119-0000
MotorController
InterfaceCable
Ak58-00035-0000
SpeedCable
PickupExtension
AK58-00043-0000
WAXLIFT
POWERSUPPLY
