Life Gear 20460A User manual

SWANY,
MAGNETIC UPRIGHT BIKE
ITEM NO: 20460A
OWNER’S MANUAL
IMPORTANT: Read all instructions carefully before using this product. Retain this
owner’s manual for future reference.
The specifications of this product may vary from this photo, subject to change without notice.
2013, Dec.

1
TABLE OF CONTENTS
WARRANTY ------------------------------------------------------------------------------- 2
IMPORTANT SAFETY INSTRUCTIONS ------------------------------------------- 3
PARTS LIST ------------------------------------------------------------------------------- 4
HARDWARE PACKING LIST --------------------------------------------------------- 5
TOOLS -------------------------------------------------------------------------------------- 5
OVERVIEW DRAWING -----------------------------------------------------------------6
ASSEMBLY INSTRUCTIONS --------------------------------------------------------- 7
OPERATING THE COMPUTER ------------------------------------------------------ 11
ADJUSTMENTS -------------------------------------------------------------------------- 13
MAINTENANCE -------------------------------------------------------------------------- 14
TROUBLESHOOTING ------------------------------------------------------------------ 14
WARM UPAND COOL DOWN ROUTINE ----------------------------------------- 15

2
ONE YEAR LIMITED WARRANTY
LifeGear Inc. warrants to the original purchaser that this product is free from defects in
material and workmanship when used for the purpose intended, under the conditions that it
has been installed and operated in accordance with LifeGear's Owner's Manual. LifeGear's
obligation under this warranty is limited to replacing or repairing free of charge, any parts
which may prove to be defective under normal home use. This warranty does not include
any damage caused by improper operation, misuse or commercial application.
From the date of purchase, the frame is warranted to be free from defects for 1 (one) year.
This warranty is offered only to the original owner and is not transferable. Proof of
purchase is required.
When ordering replacement parts please have the following information ready:
1. Owner's Manual
2. Model Number
3. Description of Parts
4. Part Number
5. Date of Purchase

3
IMPORTANT SAFETY INSTRUCTIONS
Basic precautions should always be followed, including the following important
safety instructions when using this equipment. Read all instructions before using
this equipment.
1. Read all instructions and follow it carefully before using this equipment. Make sure the
equipment is properly assembled and tightened before use.
2. Before exercise, in order to avoid injuring the muscle, warm-up exercises are
recommended.
3. Please make sure all parts are not damaged and fixed well before use. This
equipment should be placed on a flat surface when using. Using a mat or other
covering material on the ground is recommended.
4. Please wear proper clothes and shoes when using this equipment; do not wear clothes
that may catch any part of the equipment; remember to tighten the pedaling straps.
5. Do not attempt any maintenance or adjustments other than those described in this
manual. Should any problems arise, discontinue use and consult your local dealer.
6. Do not use the equipment outdoors.
7. This equipment is for household use only. It is not a commercial model.
8. Only one person at a time should use this equipment.
9. If you feel any chest pains, nausea, dizziness, or short of breath, you should stop
exercising immediately and consult your physician before continuing.
10. Care should be taken in mounting or dismounting the equipment.
11. Do not allow children to use or play on the equipment. Keep children and pets away
from the equipment while in use. This machine is designed for adults use only. The
minimum free space required for safe operation is not less than two meters.
12. The maximum weight capacity for this product is 110 kgs.
WARNING:Before beginning any exercise program consult your physician.
This is especially important for the people who are over 35 years old or who have
pre-existing health problems. Read all instructions before using any fitness
equipment.
CAUTION:Read all instructions carefully before operating this product.
Retain this Owner’s Manual for future reference.

4
PARTS LIST
No. Description Qty No. Description Qty
001 Main Frame 1 030 Hexagon Nut M10 2
002 Handlebar Post 1 031 Bolt M8x70 4
003 Seat Post Ø38.1x1.5 1 032 Adjustable Leveler M10 2
004 Handlebar Ø25x1.5x1100 1 033 Big Curve Washer Ø8xØ25 8
005 Front Stabilizer Ø60x1.5×330 1 034 Cap Nut M8 4
006 Rear Stabilizer Ø60x1.5×480 1 035 Front Left Stabilizer End Cap
Ø60x1.5 1
007 Left Cover 640x399x84 1 036 Front Right Stabilizer End Cap
Ø60x1.5 1
008 Right Cover 640x399x81 1 037 Washer Ø6xØ12x1 1
009 Left Foot Pedal YH-30X 1 038 Bolt M6x10 1
010 Right Foot Pedal YH-30X 1 039 Bearing 6000ZZ 2
011 Cover Cap Ø40xØ25x10 2 040 Idle Wheel Bracket 1
012 Belt PJ 310J5 1 041 Seat Post Knob M16x1.5 1
013 Belt Pulley with Crank Ø200J5 1 042 Seat Post Bushing 1
014 Washer Ø23xØ34.5x2.5 1 043 Seat Post Cover 1
015 Bearing Nut II 7/8" 1 044 Handlebar Post Cover 1
016 Bearing 2 045 Nylon Nut M8 3
017 Bearing Cup 2 046 Washer Ø16xØ8x1.5 3
018 Bearing Nut I 15/16" 1 047 Seat Cushion DADI 98-2-B 1
019 Hexagon Nut 7/8" 1 048 Computer HR1583 1
020 Washer Ø24xØ40x3 1 049 Tension Control Knob 1
021 Screw ST4.2×25 6 050 Bolt M5x10 4
022 Pan Head Phillips Self Drilling
Screw ST4.2x19 4 051 Bolt M8x15 5
023 Hexagon Nut M6 2 052 Curve Washer Ø16xØ8x1.5 2
024 Tension Bracket 2 053 Sensor with Wire 1
025 Spring Washer Ø6 2 054 Screw ST4.2x18 1
026 Eyebolt M6x36 2 055 Handlebar Foam Grip
Ø24xØ30x455 2
027 Nut M10x1x6 2 056 Handlebar End Cap Ø25 2
028 Flywheel Ø230x40xØ32 1 057 Hand Pulse Sensor with Wire
L=750mm 2
029 Rear Left Stabilizer End Cap 1 058 Screw ST4.2x20 4

5
PARTS LIST
HARDWARE PACKING LIST
TOOLS
No. Description Qty No. Description Qty
059 Extension Sensor Wire
(L=1100mm) 1 064 Bolt M8x15 (NYLOK Blue Patch) 2
060 Tension Cable L=1150mm 1 065 Seat Sliding Tube 1
061 Rear Right Stabilizer End Cap 1 066 Seat Sliding Tube End Cap (□38) 2
062 Bolt M5x25 1 067 Big Washer Ø8xØ25x2 1
063 Big Curve Washer Ø5 1 068 Seat Adjustment Knob M8 1
Allen Wrench S5
1 PC Multi Hex Tool with Phillips Screwdriver S13, S14, S15
1 PC
(31) Bolt M8x70
4 PCS (34) Cap Nut M8
4 PCS
(33) Big Curve Washer
Ø8xØ25
4 PCS

6
OVERVIEW DRAWING

7
ASSEMBLY INSTRUCTIONS
1. Front and Rear Stabilizers Installation
Position the Front Stabilizer (5) in front of the Main Frame (1) and align bolt holes.
Attach the Front Stabilizer (5) onto the front curve of the Main Frame (1) with two M8x70
Bolts (31), two Ø8xØ25 Big Curve Washers (33), and two M8 Cap Nuts (34). Tighten cap
nuts with the Multi Hex Tool with Phillips Screwdriver provided.
Position the Rear Stabilizer (6) behind the Main Frame (1) and align bolt holes.
Attach the Rear Stabilizer (6) onto the rear curve of the Main Frame (1) with two M8x70
Bolts (31), two Ø8xØ25 Big Curve Washers (33), and two M8 Cap Nuts (34). Tighten cap
nuts with the Multi Hex Tool with Phillips Screwdriver provided.
Hardware:
(31) Bolt M8x70
4 PCS (33) Big Curve Washer
Ø8xØ25
4 PCS
(34) Cap Nut M8
4 PCS
Multi Hex Tool with Phillips Screwdriver
S13, S14, S15
Tool:

8
2. Seat Cushion, Seat Sliding Tube, Seat Post, and Seat Post Cover Installation
Remove one Ø8xØ25x2 Big Washer (67) and one M8 Seat Adjustment Knob (68) from
underside of the Seat Sliding Tube (65). Guide bolt on underside of the Seat Sliding Tube
(65) through hole on top of the Seat Post (3), attach with one removed Ø8xØ25x2 Big
Washer (67) and one M8 Seat Adjustment Knob (68).
Remove three M8 Nylon Nuts (45) and three Ø16xØ8x1.5 Washers (46) from underside of
the Seat Cushion (47). Remove nylon nuts with the Multi Hex Tool with Phillips Screwdriver
provided. Guide bolts on underside of the Seat Cushion (47) through holes on top of the
Seat Sliding Tube (65), attach with three removed M8 Nylon Nuts (45) and Ø16xØ8x1.5
Washers (46). Tighten nylon nuts with the Multi Hex Tool with Phillips Screwdriver
provided.
Slide the Seat Post Cover (43) onto the tube of the Main Frame (1).
Insert the Seat Post (3) into the Seat Post Bushing (42) on the tube of the Main Frame
(1) and then attach the Seat Post Knob (41) onto the tube of the Main Frame (1) by
turning it in a clockwise direction to lock the Seat Post (3) in the suitable position.
Multi Hex Tool with Phillips Screwdriver
S13, S14, S15
Tool:

9
3. Handlebar Post and Tension Control Knob Installation
Remove four Ø8xØ25 Big Curve Washers (33) and four M8x15 Bolts (51) from the Main
Frame (1). Remove bolts with the S5Allen Wrench provided.
Connect the Sensor Wire (53) from the Main Frame (1) to the Extension Sensor Wire (59)
from the Handlebar Post (2).
Put the cable end of resistance cable of Tension Control Knob (49) into the cable lock of
Tension Cable (60), see Figure A.
Pull the resistance cable of Tension Control Knob (49) up and force it into the slot of metal
bracket of Tension Cable (60), see Figure B.
Insert the metal fitting on the resistance cable of Tension Control Knob (49) into the hole at
the end of the slot in the metal bracket of Tension Cable (60), see Figure C.
Connect the resistance cable of Tension Control Knob (49) to Tension Cable (60) complete,
see Figure D.
Insert the Handlebar Post (2) onto the tube of the Main Frame (1) and secure with four
Ø8xØ25 Big Curve Washers (33) and four M8x15 Bolts (51) that were removed. Tighten
bolts with the S5 Allen Wrench provided.
Allen Wrench S5
Tool:
A B C D
