John Lewis Devon 803/61601 User manual

Stock code 803/61601, 803/61701, 803/61801
Devon Bunk Bed
Thank you for purchasing this Devon bunk bed. Please read the instructions carefully before use to ensure safe
and satisfactory operation of this product.
For product support or spare parts
please call the John Lewis Helpline;
T: 01244 689949
E: [e-mail]
Please check the pack contents before attempting to assemble this product. A full checklist of components is
This product is HEAVY, it should be assembled as near as possible to the point of use. TAKE CARE WHEN
LIFTING to avoid personal injury and (or) damage to the product.
This product takes approximately 90 MINUTES to assemble with 2 PEOPLE.
SMALL PARTS which should be KEPT AWAY FROM YOUNG CHILDREN.
If you require any additional information or have any issues with this product please call the John Lewis
Helpline on 01244 689949 or email [e-mail].

7 x 50mm
Ladder
left
side
- 1pc
Ladder
right
side
- 1pc
Ladder steps
- 2 pcs
Ladder steps
- 1 pc

Step 1 Insert dowels (C) in to the pre drilled holes on the side rails 4 and 5 and side panels 6, 7, 8, 9 and ladder
steps 13 and 14 as shown below.
Step 2 Attach ladder right side (11), ladder left side (12) and ladder steps (13) and (14) together using screw (H)
tighten using a philips head screw driver. As shown below.

Step 3 Attach side rails (4 and 5) and side panels (6 and 7) to headboard (1) using barrel nut (E) and bolts (B),
as shown below. Repeat this process to attach side rails (4 and 5) to headbaord (3), as shown below.
Tighten using allen key (A).

Step 4 Following on from step 3, attach headboard (2) to side rails (4 and 5) and side panels (6 and 7) as shown.
Tighten using a philips head screw driver.
Step 5 Starting at 1 end of the bed, scure the rst tted slat into place using screws (G). Next, secure the tted
slat to the other end of the bed using screws (G) ensuring there are no gaps between the slats and
headboards. Finally, secure the rest of the slats in to place using screws (G) as shown below.

Step 6 Insert dowels (I) in to the pre drilled holes on the headbaords (3), place the upper bed as shown below.
Step 7 Secure in to place using screw (G) in to the pre drilled holes as shown below. Tighten using a philips
head screw driver.

Step 8 Attach the ladder on to the side rails (5) using screw (F), in to the pre drilled holes fome the side of side
rails (5) as shown below. Tighten using allen key (A).
Step 9 Attach the side panels (8 and 9) on to the headboard (1) and ladder. Use barrel nuts (E) and bolt (B)
to secure the headboard (1) to side panels (9 and 10), tighten using allen key (A). Use screw (F) to
secure the side panels (8 and 9) to the ladder, tighten using a philips head screw driver, as shown below.

Step 10 Attach the vertical support rail (10) in to upper bunk sides, using screw (D) in to the pre drilled holes
as shown below. Tighten using a philips head screw driver.

Wood Furniture
ray’which can appear on oak furniture is a mark of good quality timber - these are just characterisitics of
the natural beauty of the wood. Some furniture is also deliberately aged and rustic.
drawer fronts by the way the slivers are arranged.
All timber surfaces will change colour and mellow over time. New furniture will initially vary in shade
from items that have been previously purchased.
How to care for your wood furniture
Furniture with a hard lacquer, wax polish or painted surface should be dusted with a dry cloth.
Waxed furniture will need to be given a coat of beeswax a couple of times a year to help maintain its
luster.
Spray polishes are best avoided as they contain silicones which may spoil the furniture’s surface by
building up over time.
Our furniture will endure most temperatures in the home but is is best to avoid placing furniture next
caused by central heating can cause damage such as warping.
